Summary of Contents for Euromaid G7FS1
- Page 1 User Manual 75cm Gas Cooktop G7FS1...
- Page 2 Product / Installer details For future reference we suggest that you staple a copy of your purchase receipt here and complete the below so the information is always at hand. Product Details G7FS1 Model number: ________________________________________________________________________________________ 75cm gas cooktop Description: __________________________________________________________________________________________...
- Page 3 Dear Customer, Congratulations on the purchase of your new product from Glen Dimplex Australia Pty Ltd. We recommend you please take some time to read the instruction manual thoroughly to familiarise yourself with the functionality and operations to ensure optimum performance of your new appliance. After reading the manual, please store it in a safe and accessible location for future reference.
- Page 4 Please read this user manual first! Dear Customer, We hope that you get the best results from your product which has been manufactured with high quality and state- of-the-art technology. Therefore, please read this entire user manual and all other accompanying documents carefully before using the product and keep it as a reference for future use.
-
Page 5: Table Of Contents
TABLE OF CONTENTS Preparation Important instructions and warnings for safety and environment Tips for saving energy ......... 19 Initial use ............19 General safety ............4 First cleaning of the appliance ......19 Safety when working with gas......... 4 Electrical safety ............. 5 How to use the hob Product safety ............ -
Page 6: Important Instructions And Warnings For Safety And Environment
Important instructions and warnings for safety and environment This section contains safety other relevant documents and instructions that will help protect from parts should be also given. risk of personal injury or property • Installation and repair procedures damage. Failure to follow these must always be performed by instructions shall void any warranty. -
Page 7: Electrical Safety
installation regulations. Particular which has a lethal effect even in attention shall be given to the very small doses. relevant requirements regarding • Request information about gas ventilation; See Before installation, emergency telephone numbers and safety measures in case of page 12 gas smell from your local gas •... -
Page 8: Product Safety
specified in the “Technical • Any work on electrical equipment specifications”. Have the and systems should only be grounding installation made by a carried out by authorised and qualified electrician while using qualified persons. the product with or without a •... -
Page 9: Intended Use
• Do not use steam cleaners to • Ensure liquid or moisture is not clean the appliance as this may accessible to the electrical cause an electric shock. connection point. • WARNING: Unattended cooking on • To prevent gas leakage ensure a cook top with fat or oil can be that the gas connection is sound. -
Page 10: Disposing Of The Old Product
Compliance with RoHS Directive: Disposing of the old product The product you have purchased complies with Compliance with the WEEE Directive and EU RoHS Directive (2011/65/EU). It does not Disposing of the Waste Product: contain harmful and prohibited materials specified in the Directive. Package information This product complies with EU WEEE Directive (2012/19/EU). -
Page 11: General Information
General information Overview Pan support Auxiliary burner Normal burner Burner plate Assembly clamp Rapid burner Control panel Wok burner Base cover Normal burner Rapid burner Rear left Auxiliary burner Front left Wok burner Middle Normal burner Front right Normal burner Rear right 9/EN... -
Page 12: Package Contents
Package contents Wok pan adaptor Accessories supplied can vary depending on the product model. Not every accessory described in the user manual may exist on your product. Used for hosting a wok pan with a round bottom. User manual Technical specifications Voltage / frequency 220-240 V ~ 50 Hz Fuse... -
Page 13: Injector Table
Injector table Natural Gas Cooktop Burner Gas type Injector Size (mm) (kPa) (MJ/h) G7FS1 Auxiliary Natural gas 0.90 Semi-Rapid 1.18 Rapid 1.55 11.5 2.00 18.0 Universal LPG Cooktop Burner Gas type Injector Size (mm) (kPa) (MJ/h) G7FS1 Auxiliary Universal 0.50 2.75... -
Page 14: Installation
Installation Before installation Installation must be in accordance with this The cook top is designed for installation into instruction manual, AS 5601.1 'gas installations' for commercially available work tops. A safety distance installation and pipe sizing, local gas fitting must be left between the appliance and the kitchen regulations, municipal building codes, local electrical walls and furniture. - Page 15 total ventilation opening corresponding to the total gas consumption of the appliance as specified in the table below, then there must definitely be an additional fixed ventilation opening in the room to ensure that the total minimum ventilation requirements for the total gas consumption of the appliance is achieved.
-
Page 16: Installation And Connection
Installation and connection While performing the wiring, you must apply • The product must be installed in accordance with with the national/local electrical regulations and must use the appropriate socket outlet/ all local gas and electrical regulations. line and plug for oven. In case of the Electrical connection product's power limits are out of current Connect the product to a grounded outlet/line Connect... - Page 17 15/EN...
- Page 18 the contours of the lower housing of the hob but Gas connection make sure that the putty does not overlap. DANGER: 4. Fill the corners by forming bends at the corners as Product can be connected to gas supply illustrated in the figure. Form as much bend as system only by an authorised and qualified required to fill the gap in the corners.
-
Page 19: Gas Conversion
2. Unscrew injectors by turning the counter- Rear view (connection holes) clockwise. 3. Fit new injectors. 4. Check all connections for secure fitting and tightness. New injectors have their position marked on their packing or injector table on Injector table, page 10 can be referred to. (Varies depending on the product model.) On some hob burners, the injector is covered with a metal piece. -
Page 20: Future Transportation
Depending on the type of gas tap used in your If the gas type of the unit is changed, then appliance the adjustment screw position may vary. the rating plate that shows the gas type of the unit must also be changed. Future Transportation •... -
Page 21: Preparation
Preparation Tips for saving energy Initial use The following information will help you to use your First cleaning of the appliance appliance in an ecological way, and to save energy: The surface might get damaged by some • Defrost frozen dishes before cooking them. detergents or cleaning materials. -
Page 22: How To Use The Hob
How to use the hob General information about cooking Using the hobs Never fill the pan with oil more than one third of it. Do not leave the hob unattended when heating oil. Overheated oils bring risk of fire. Never attempt to extinguish a possible fire with water! When oil catches fire, cover it with a fire blanket or damp... - Page 23 • If the gas does not ignite after you press and release the knob, repeat the same procedure by keeping the knob pressed for 15 seconds. DANGER: Release the button if the burner is not ignited within 15 seconds. Wait at least 1 minute before trying again. There is the risk of gas accumulation and explosion! Wok burner...
-
Page 24: Maintenance And Care
Maintenance and care General information Cleaning the hob Service life of the product will extend and the Gas hobs possibility of problems will decrease if the product is 1. Remove and clean the saucepan carriers and cleaned at regular intervals. burner caps. -
Page 25: Troubleshooting
Troubleshooting Product emits metal noises while heating and cooling. This is not a fault. • When the metal parts are heated, they may expand and cause noise. >>> There is no ignition spark. Check fuses in the fuse box. • No current. - Page 26 This page has been left BLANK intentionally 24/EN...
- Page 27 This page has been left BLANK intentionally 25/EN...
- Page 28 For all product enquiries (including warranty support), please contact our Customer Care team on 1800 444 357 or via email: customercare@hapl.com.au...
