Sony VAIO VAIO PCGZ505LE Service Manual
Sony laptop user manual
Hide thumbs
Also See for VAIO VAIO PCGZ505LE:
- User manual (119 pages) ,
- Supplementary manual (15 pages) ,
- Specifications (1 page)
Table of Contents
Advertisement
Quick Links
Download this manual
See also:
User Manual
Advertisement
Table of Contents
Related Manuals for Sony VAIO VAIO PCGZ505LE
Summary of Contents for Sony VAIO VAIO PCGZ505LE
- Page 2 Information in this document is subject to change without notice. Sony and VAIO are trademarks of Sony. Intel logo and Intel Inside logo are registered trademarks of Intel Corporation. Pentium MMX is a trademark of Intel Corporation. Microsoft, MS-DOS, Windows, the Windows 95 and Windows 98 logo are trademarks of Microsoft Corporation.
-
Page 3: Table Of Contents
Section Title CHAPTER 1. REMOVAL 1-1. Flowchart ... 1-1 1-2. Main Electrical Parts Location Diagram ... 1-1 1-3. Removal ... 1-2 1. Keyboard Unit ... 1-2 2. Palm Rest Assembly ... 1-2 3. SWX-47 Board, Touch Pad, and Speaker Unit ... 1-3 4. -
Page 4: Chapter 1. Removal
1-1. Flowchart POWER KEYBOARD PALM REST UNIT ASSY P1-2 P1-2 • P XX means pages that appears in this manual. • Remember that hard disk drives are easily damaged by vibration. Always handle with care. • When the thermal sheet (Part No. 4-645-921-01) of the computer reaches a certain temperature, it becomes soft, which increases the contact. -
Page 5: Keyboard Unit
1-3.Removal 1. Keyboard Unit 1 +B 2X5 (X2) 2. Palm Rest Assembly q; Palm Rest ASSY 1 Cover (DL) 3 Cover (BBL) 3 Escutcheon (AU) 3 Escutcheon (MU) Confidential PCG-Z505LE/Z505LEK/Z505LS/Z505LSK (UC) 5 Keyboard Unit (US) 1 +B 2X5 (X4) Radiation (NN) 5 +B 2X5 6 +B 2X5 4 +B 2X5 (X3) -
Page 6: Swx-47 Board, Touch Pad, And Speaker Unit
3. SWX-47 Board, Touch Pad, and Speaker Unit 7 Escutcheon (PAD) 0 Touch Pad 9 Insulating Sheet (PAD) 6 Button (PAD) 5 +B 2X3.5 (X2) 4 SWX-47 Board 1 +B 2X3.5 (X2) 4. Modular Jack, Harness (DC Jack), and RO-36 Board 8 RO-36 Board qs Speaker Unit Cushion (T4) -
Page 7: Hdd, And Swx-48 Board
5. HDD, and SWX-48 Board 6 B 2X3.5 (X2) FPC (HDD) 9 +P 3X4 (X2) Bracket (HDDF) Bracket (HDDR) 9 +P 3X4 (X2) 0 HDD 1 +B 2X4 2 SWX-48 Board 3 Escutcheon (D) FPC (14P) 6. DC Fan 1 +B 2X3.5 (X5) 3 DC Fan Confidential PCG-Z505LE/Z505LEK/Z505LS/Z505LSK (UC) -
Page 8: Ifx-122 Board, Cnx-106 Board, And Pc Card Connector
7. IFX-122 Board, CNX-106 Board, and PC Card Connector 1 +B 2X3.5 (X3) 5 CNX-106 Board Dummy Card PC Card Connector 8. Main Board Assembly (MBX-42 Board), IFX-123 Board, V/L Rechargeable Battery, and Memory Module 1 +B 2X3.5 Main Board ASSY (MBX-42 Board) 1 +B 2X4 9 V/L Rechargeable... -
Page 9: Display Assembly
9. Display Assembly 2 +B 2.6X4 (X2) 1 +B 2X3.5 This connector was already removed together when the main board assembly was removed. 10. Bezel Housing Assembly 5 +B 2X5 (X2) 4 Hole Blind (A) 1 Cover (DC) ASSY Confidential PCG-Z505LE/Z505LEK/Z505LS/Z505LSK (UC) Display ASSY 2 +B 2.6X4... -
Page 10: Lex-20 Board, Inverter Unit, And Lcd Unit
11. LEX-20 Board, Inverter Unit, and LCD Unit Bracket (LCD-L) qs +B 2X3 (X2) LCD Unit Bracket (LCD-R) qa LCD Harness qs +B 2X3 (X2) 8 Inverter Unit 1 +B 2X4 3 Complete PWB LEX-20 +B 2X5 +B 2X4 Confidential PCG-Z505LE/Z505LEK/Z505LS/Z505LSK (UC) (END) -
Page 11: Chapter 2. Self Diagnostics
2-1. Note This chapter describes the items to be checked and the self-tests to be performed using the main unit, floppy-disk drive, and CD-ROM drive. 2-2. Necessary Tools • PCG-Z505L series main unit • Floppy-disk drive • CD-ROM drive • Battery •... -
Page 12: Outline Of Service Diagnostics Functions
2-4. Outline of Service Diagnostics Functions • Check ROM Information... Displays the model information, serial number, BIOS and other information saved in the BIOS ROM. Does not test whether or not the personal computer is normal. • Battery test... Tests the battery as to whether the battery is attached or removed, the main power is supplied from an AC power adapter or not, and the battery is charged or discharged. - Page 13 • Main Memory test... Tests the main memory. The Main Memory test contains the following three test menus. Select the desired menu that suits your need. The test is exited automatically when the respective test items end normally. • Fast : Tests once.
- Page 14 • IEEE 1394 Interface test... Performs the 1394 communication test. Another personal computer to communicate with is necessary for this test. The models released from the year 2000 have already been confirmed that they do not cause any problems regarding the IEEE1394 interface.
-
Page 15: Inspecting Windows
2-5. Inspecting Windows The Windows inspection contains the following two types of inspection. Audio Modem Before starting inspections, create a floppy disk from the service diag CD to be serviced. The files to be used for inspection are stored in the following sub directory inside the CD. Copy all the files in the folder to the floppy disk. -
Page 16: Chapter 3. Block Diagram
DCLK 1 0 0 M H z L o c a l B u s ATF0 ADM1021 ATF_INT AB_GP1 PCI Dev # 0,1 ROW#0,1 RJ11 AGP BUS(3.3V) PCI BUS(3.3V) ATF_INT PIIX4M PCI-ISA BRIDGE RT C PCI Dev #7 Flash BIOS 29LV004 DC-I N POWER... -
Page 17: Frame Harness Diagram
FRAME HARNESS DIAGRAM DISPLAY ASSY LCD HARNESS CN6095 Side SPEAKER LEX-20 BOARD (SIDE A) CN571 DC IN CN351 CN1151 CN451 i-LINK J572 MIC IN J571 HEADPHONE VANADIUM LITHIUM ION BATTERY CN401 CARD CARD CONNECTOR CN3201 CN3203 CN3801 IFX-122 CN3803 BOARD (SIDE A) CN3802 CN3100... -
Page 18: Chapter 5. Exploded Views And Parts List
EXPLODED VIEWS AND PARTS LIST NOTE: • The mechanical parts with no reference number in the The components identified by mark 0 or dotted line with mark 0 are critical for safety. exploded views are not supplied. Replace only with part number specified. •... -
Page 19: Lcd Section - Made By Hi
5-2. LCD Section – Made by HI – Confidential PCG-Z505LE/Z505LEK/Z505LS/LSK (UC) Ref.No. Part No. X-4622-146-2 COVER (DC) ASSY X-4622-569-4 HOUSING (DISPLAY) ASSY X-4623-047-2 HOUSING (BEZEL) ASSY A-8048-165-A LCD UNIT (12TFT XGA) (S) 1-418-398-21 INVERTER UNIT 1-960-865-12 HARNESS, LCD 4-639-580-01 KNOB (LATCH) 4-639-623-01 SPRING (LATCH), COIL 4-641-415-02 TILT UNIT (L) 4-641-416-02 TILT UNIT (R) - Page 20 PCG-Z505LE/Z505LEK/Z505LS/Z505LSK (UC) This manual and the constituent data may not be replicated, copied nor reprinted in whole or in part without prior written authorization of Sony Corporation. English Sony Corporation 2000I1600-1 Printed in xxx 9-872-139-11 © 2000 Sony Corporation — ? —...
