Sony VAIO TX VGN-TX26GP/W Specification

Platinum styling. Entertaining possibilities in motion.
VAIO TX
VGN-TX26GP/W
Intel ® Centrino ® Mobile Technology
Specifications
Model VGN-TX26GP/W
Platform Intel ® Centrino ® Mobile Technology
1
• Intel ® Pentium ® M Processor Ultra Low Voltage 733 (1.10GHz)*
® ®
• Intel PRO/Wireless 2200BG Network Connection • Intel 915GMS Express Chipset
Operating System Microsoft ® Windows ® XP Professional with Service Pack 2 (English version) Multilanguage User Interface (pre-installed Traditional Chinese)
Processor System Bus 400MHz
Memory Bus 400MHz
Cache Memory L1 Cache: 64KB L2 Cache: 2MB (on CPU)
2
Main Memory 512MB DDR2 SDRAM (512MB on board, upgradeable up to 1.5GB)*
1 SO-DIMM slot
3
Hard Disk 60GB (C: 20GB, D: 40GB* ) Ultra ATA/100
4
Optical Drive CD-RW/DVD-ROM Drive*
Maximum reading speed: DVD+R, DVD-R, DVD+RW, DVD-RW, DVD+R DL (Double Layer): 4× / DVD-ROM: 8× / CD-R, CD-RW, CD-ROM: 24×
Maximum writing speed: CD-R, CD-RW: 24×
Graphics Accelerator Intel ® Graphics Media Accelerator 900
Video Memory Maximum 128MB (shared with main memory)
11.1˝ Wide (WXGA: 1366 × 768) TFT colour display (Clear Bright LCD: White LED, Wide View)
Display
• USB 2.0 × 2* 5
Interfaces • i.LINK (IEEE 1394) S400 (4 pin) • Network (RJ-45) connector (100BASE-TX/10BASE-T) • Headphone jack (stereo mini)
• Microphone jack (stereo mini) • Monitor connector (VGA, D-SUB 15 pin) • Modular (RJ-11) connector • Port Replicator connector
6
• Memory Stick Slot* (Standard/Duo Size compatible, MagicGate compatible, Memory Stick PRO compatible, High-speed data transfer compatible)
7
• SD card slot* (MMC card compatible)
8
Wireless LAN • Integrated Wireless LAN IEEE 802.11b/802.11g* • Intel ® PRO/Wireless 2200BG Network Connection
9
• Data rate: maximum 11Mbps (802.11b) 54Mbps (802.11g)* • Frequency: 2.4GHz
® 9
Bluetooth • Bluetooth ® standard version 2.0+EDR* • Output: maximum +6dBm • Frequency: 2.4GHz
Modem V.92 and V.90 Compliant
Type I/II × 1, CardBus Support
PC Card Slot
Audio • Intel ® High Definition Audio compatible • 3D audio (Direct Sound 3D support) • Built-in stereo speakers
Keyboard / Input Device • 17mm Key pitch / 1.7mm Key stroke • 82 Keys • Intelligent Touchpad
10 11
Battery VGP-BPS5* Lithium-ion battery: up to 8.5 hours of use*
Dimensions (W × H × D) 272.4 × 21-28.5 × 195.1mm
Weight 1.26kg (including the supplied battery)
Software Applications • Adobe Reader 7 • Adobe Photoshop Elements 4.0 (Installer) • Adobe Premiere Standard • DVgate Plus 2.2 • Image Converter 2 Plus
• Instant Mode 1.1 • Norton Internet Security 2006 • Roxio DigitalMedia SE 7 • PictureGear Studio 2.0 • SonicStage 3.3
• SonicStage Mastering Studio 2.1 • SonicStage Mastering Studio Audio Filter 2.0 • VAIO Control Center 1.1 • VAIO Edit Components 5.0
• VAIO Media 5.0 • VAIO Original Screen Saver • VAIO Recovery Utility 2.6 • VAIO Update 2.1• VAIO Zone 1.4 • WinDVD 5 for VAIO
Supplied Accessories • AC adapter (VGP-AC16V8) • Lithium-ion battery (VGP-BPS5) • Headphone (MDR-Q22LP/S02)
12
Warranty One year*
Features and specifications are subject to change without notice.
*1 CPU speed will be reduced under certain operating conditions. *2 By adding one 1GB memory module. *3 Includes necessary data for recovery (setting back to initial
shipment settings) in the hard disk drive consuming approximately 5GB in size. *4 This product is designed to playback discs that conform to the Compact Disc Digital
Audio standard specifications (CD Standard). A DualDisc is a two sided disc product which mates DVD recorded material on one side with digital audio material on the
other side. Please be aware that the audio side (non-DVD side) of a DualDisc may not play on this product because it does not conform to the CD Standard. *5 High-
speed/Full-speed/Low speed compatible. *6 Compatibility confirmed with Sony branded "Memory Stick" media only. *7 Does not support SD card's copyright
technology. *8 Deploying IEEE 802.11b and IEEE 802.11g products on the same wireless network may reduce the communication speed due to radio interference.
Taking this into consideration, the IEEE 802.11g products are designed to reduce the communication speed to ensure communication with IEEE 802.11b products.
When the communication speed is not as fast as expected, changing the wireless channel on the access point may increase the communication speed. *9 The
communication speed varies depending on the distance between communication devices, existence of obstacles between such devices, the device configuration, the
radio conditions, and the software in use. In addition, communication may be cut off depending on the radio conditions. *10 This product may only function with a
genuine Sony battery designed for this model. *11 Estimated battery life (under JEITA Battery Run Time Measurement Method (ver.1.0).) When the power-saving mode is
on. Actual battery life may vary with different operating conditions and settings. For further details, please visit vaio-online.sony.com *12 Warranty conditions may vary by
region.
The trademarks, including but not limited to "SONY", "VAIO", "Memory Stick" and "SonicStage" are either trademarks or registered trademarks of Sony Corporation
and/or its subsidiaries. Adobe, Adobe Photoshop, Adobe Reader and Adobe Premiere are trademarks of Adobe Systems Incorporated in the United States and/or other
countries. Intel, Intel logo, Intel Inside, Intel Inside logo, Intel Centrino, Intel Centrino logo, Intel SpeedStep, and Pentium are trademarks or registered trademarks of Intel
Corporation or its subsidiaries in the United States and other countries. Microsoft and Windows are either trademarks or registered trademarks of Microsoft Corporation in
the United States and other countries. All other product and brand names may be trademarks or registered trademarks of their respective owners. Whilst information
given is true at time of printing, small production changes in the course of our company's policy of improvement through research and design might not necessarily be
included in the specifications. E&OE. Actual models may differ slightly in appearance to illustrations provided.
Optional Accessories
(availability depends on region)
VGP-PRTX1 VGP-UMS50
Port Replicator
DC-IN Stylish, easy-to-use sloping design
Monitor connector (VGA, D-SUB 15 pin) Innovative PTFE sole for precise operation
Network connector Sensor resolution: 800 dots per inch
USB 2.0 connector (×3)
VGP-BPL5 VGP-CKTX1
Lithium-ion Battery
Rechargeable battery Perfect size for VAIO TX
Ideal slim, lightweight PC case
Seven layer cushioning fabric
Soft, luxurious feel in hand
vaio-online.sony.com
Sony recommends Microsoft
Windows XP Professional.
®
VGN-TX26GP/W
1 2 3
7
9
10
11 12 13
16 17
18 19 20 21 22
23 24 25
1. AV Mode button
2. Play/Pause button
3. Stop button
4. Previous track button
5. Next track button
6. Disc eject button
7. Indicators
8. Network (RJ-45) connector (100BASE-TX/10BASE-T)
9. DC-IN connector
10. i.LINK (IEEE1394) S400 (4 pin) connector
11. USB 2.0 connector
PC Card Slot (Type I/II × 1)
12.
13. PC Card eject button
14. Modular (RJ-11) connector
15. USB 2.0 connector
USB Optical Mouse
16. Memory Stick slot
(Standard/Duo Size compatible, MagicGate compatible, Memory Stick
PRO compatible, high-speed data transfer compatible)
17. SD card slot (MMC card compatible)
18. Wireless LAN switch
19. Mute button
20. Volume buttons
21. Headphone jack (stereo mini)
Carrying Case
22. Microphone jack (stereo mini)
23. CD-RW/DVD-ROM drive
24. Manual eject hole
25. Disc eject button
26. Monitor connector (VGA, D-SUB 15 pin)
®
4 5 6
8
14 15
26
