PCG-FXA53/FXA59

SERVICE MANUAL

Ver 2-2002G
Revision History
Lineup :
PCG-FXA59
PCG-FXA53
9-874-549-02
For American Area
CanadianModel
• Design and specifications are subject to
change without notice.
NOTEBOOK COMPUTER
US Model
S400

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VAIO PCG-FXA59 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Sony VAIO PCG-FXA59

Summary of Contents for Sony VAIO PCG-FXA59

  • Page 1: Service Manual

    PCG-FXA53/FXA59 SERVICE MANUAL Ver 2-2002G Revision History Lineup : PCG-FXA59 PCG-FXA53 9-874-549-02 For American Area US Model CanadianModel • Design and specifications are subject to change without notice. NOTEBOOK COMPUTER S400...
  • Page 2 Information in this document is subject to change without notice. Sony, VAIO and CLIE are trademarks or registered trademarks of Sony. Microsoft, Windows, Windows Media, Outlook, Bookshelf and other Microsoft products are trademarks or registered trademarks of Microsoft Corporation in the United States and other countries.

  • Page 3: Table Of Contents

    Section Title CHAPTER 1. BLOCK DIAGRAM CHAPTER 2. FRAME HARNESS DIAGRAM CHAPTER 3. EXPLODED VIEWS AND PARTS LIST ... 3-1 3-1. Main Section ... 3-2 3-2. FDD Section ... 3-5 3-3. LCD Section (FXA53 Model) – Made by AC – ... 3-7 3-3-A.

  • Page 4: Chapter 1. Block Diagram

    AMD Mobile Athlon XP 1500 + (Cache:128KB L1 256KB L2) (FSB 200 MHz) 462 PIN PGA SOCKET A Main Memory PC133 SO-DIMM 256MB X1 (Max.512MB) SO-DIMM SO-DIMM D RAM North Bridge Slot A Slot B SIG NAL VIA KT133A VT8363A CPU CLOCK CLK GEN PCI CLOCK...

  • Page 5: Chapter 2. Frame Harness Diagram

    FRAME HARNESS DIAGRAM DC-IN KEY BOARD INVERTER DC FAN FFC LED PCN1 CON13 CON4 VIDEO OUT CON5 CPU1 EXTERNAL MICROPHONE CON18 HEADPHONE CON17 CON8 IEEE 1394 i.LINK CON1 Side CON2 PC CARD CONNECTOR OPTION PC133 SO-DIMM BATTERY PACK TOUCH PAD CHAPTER 2.

  • Page 6: Chapter 3. Exploded Views And Parts List

    NOTE: • The mechanical parts with no reference number in the exploded views are not supplied. • Items marked “ * ” are not stocked since they are seldom required for routine service. Some delay should be anticipated when ordering these items. •...

  • Page 7: Main Section

    3-1. Main Section Ref.No. Part No. Description X-4623-848-3 [CH]...ASSY BOTTOM (Q) 4-640-837-22 DOOR BATTERY 4-651-706-01 HEATSINK BOTTOM 4-656-752-01 [CH]...INSULATOR HEATSINK BOTTOM 4-643-832-21 DUMMY CARD A-8049-276-A COMPLETE PWB SWX-74 X-4623-389-1 ASSY HOOD KEYBOARD Z (P) 1-529-287-11 SPEAKER UNIT 1-790-639-22 FPC 50PIN (FOR HDD) A-8059-429-A ASSY HDD 30GB (H,20,F) (S) 1-476-647-12 KEY BOARD UNIT (US) X-4623-849-3 [CH]...ASSY PALMREST (Q)
  • Page 8 B33 B33 Supplied with 88 Supplied with 1 Supplied with 19 Supplied with 88 Supplied with 88 (Refer to Page 3-8.) 800 (Refer to Page 3-5.) Confidential PCG-FXA53/FXA59 (AM)

  • Page 9: Fdd Section

    3-2. FDD Section How to use properly the FDD repair parts. Types of service to be provided are different depending on the part No. of the FDD in use. Label FD X-XXX-XXX-XX Label Part No. The service types are shown below depending on the part No. that is printed in the bottom right of the FD label. [Label Part No.
  • Page 10 3-3. LCD Section (FXA53 Model) – Made by AU – Supplied with 303 Ref.No. Part No. * 322 * 323 NOTE : Set the DIP switch on the MBX-61 board (Main board) to match with the LCD (A-8023-466-A) that is used in this computer. The upper position where ON indication is shown is the ON position .

  • Page 11: 3-3-A. Lcd Section (Fxa59 Model) - Made By Sh

    3-3-A. LCD Section (FXA59 Model) – Made by SH – Supplied with 403 3-8(a) Ref.No. Part No. NOTE : Set the DIP switch on the MBX-61 board (Main board) to match with the LCD (A-8023-483-A) that is used in this computer. The upper position where ON indication is shown is the ON position .

  • Page 12: Connector Section (Ch Type Only)

    3-4. Connector Section (CH Type only) Bracket I/O Ref.No. Among the parts that are used on the boards of this model, only the connectors that are show in the list can be replaced. (The parts other that the specified connectors cannot be replaced.) Before replacing the connector of reference number 901, 902 and 903, remove the bracket I/O.

  • Page 13: Chapter 4. Others

    4-1. Replacing the CPU 1. Removing the CPU 1 Install the special tool in the CPU. 2 Insert a flat head (-) screwdriver tip into the groove as shown. 3 While holding the special tool, slant the screwdriver in the direction of the arrow. 4 The base under the CPU moves slightly in the direction of the arrow and the CPU lock is released.
  • Page 14 9-874-509-01 9-874-549-02 : Additional Models This manual and the constituent data may not be replicated, copied nor reprinted in whole or in part without prior written authorization of Sony Corporation. Sony Corporation — 24 — English 2002D1600-1 © 2002 Sony Corporation...

  • Page 15: Revision History

    Revision History Suffix Ver. Date First Ver. 1 2002.04.26 Edition Ver. 2 2002.07.01 Front Page (Model Line Up), Page 3-8(a), Page 3-8(b), Back Cover < Remarks > Contents QM No. N2002_064K [Confidential] PCG-FXA53/FXA59 (AM)
