Waterproof and Dustproof Solar Charge Controller
User's Manual
Ver.1.01E
IP68
1. Introduction
Thank you for purchasing "SolarAmp BG" solar charge controller. This
manual contains important safety, installation and operating instructions
for "SolarAmp BG" solar charge controller in order to prevent the users
from any damage. Make sure to read all of the instructions and cautions in
the manual before beginning installation.
2. Product Overview
"SolarAmp BG" is very compact design and very simple to use, which has
full electronic protections, waterproof and dustproof.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for DENRYO Solar Amp BG
Summary of Contents for DENRYO Solar Amp BG
- Page 1 Waterproof and Dustproof Solar Charge Controller User's Manual Ver.1.01E IP68 1. Introduction Thank you for purchasing “SolarAmp BG” solar charge controller. This manual contains important safety, installation and operating instructions for “SolarAmp BG” solar charge controller in order to prevent the users from any damage.
- Page 2 3. Features ・Waterproof and dustproof (IP68) NOTE: This does not guarantee no damage, no breakdown, or waterproof and dust proof performance in all conditions. ・3-stage Charging (Bulk, Absorption, Float) ・Discharged Battery Recovery ・Full Electronic Protections High / Low Voltage Protection, Over Discharge Protection, Over Load Protection, High Temperature Protection, Reverse Polarity Protection, Load Short Circuit Protection, Surge Protection ・Current Regulation Caused High Temperature...
- Page 3 5. Safety Information 5-1: DO NOT short circuit (For all 5-2: Explosion hazard terminals) 5-3: Keep out of direct sunlight 5-4: Positive earth ground 5-5: DO NOT reverse polarity connection (For all terminals)
- Page 4 6. Connection Connect each wire in order (1. LOAD 2. BATTERY 3. PV panel) as the figure below. Please use the proper size wire and connector. Blue Black Red White...
- Page 5 7. Appearance Mounting holes Unit: mm...
- Page 6 8. LED Indicator “SolarAmp BG” shows the charging, warning and error status by LED. If any warning or error comes up when charging, LED will show both charging status and warning or error status alternately. In this case, the charging LED will only blink 1 time, do not show the charging stage. LED/Color Description Green...
- Page 7 9. Specifications Model No. SA-BGA10 System Voltage 12Vdc Max. Input Voltage 25Vdc Min. Input Battery Voltage 6Vdc Max. Input Current Max. Load Current Self-consumption Current 2mA (Typical) Charging Algorithm 3-stage (Bulk, Absorption, Float) Charging Voltage 14.4Vdc Float Charging Voltage 13.7Vdc High Voltage Protection 18Vdc Warning...
- Page 8 DENRYO CO., LTD. 28-5, Nishinippori 2 Chome, Arakawa-ku,Tokyo, 116-0013 Japan TEL : +81-3-3802-3671 FAX : +81-3-3802-2974 Email : info-en@denryo.com Website: www.denryo.com DM-5202...
