How do I connect my Sony DAV-FC7 home theater system to my TV?

To connect your system to your TV, you will need a video cord. Connect the TV to the MONITOR OUT jack on the system. When connecting, ensure you match the color-coded sleeves of the cord to the appropriate jacks on the components. For more information, see page 20 of the manual.

What should I do if my Sony DAV-FC7 home theater system won't turn on?

If your system won't turn on, check that the AC power cord is connected securely.

Why is there no sound coming from my Sony DAV-FC7 system?

If there is no sound from your system:Check that the speaker cord is not connected securely.Press MUTING on the remote if "MUTING ON" is displayed on the front panel display.The system might be in pause mode or in Slow-motion Play mode; press the play button to return to normal play mode.If fast forward or fast reverse is being performed, press the play button to return to normal play mode.Check the speaker settings. For more information, see page 74 of the manual.

What should I do if the speakers connected to my Sony DAV-FC7 are not working?

If your speakers are not working:Check that the speaker cords are connected securely to the appropriate terminals. Ensure the bare wire of each speaker cord does not touch another speaker jack or another speaker cord, as this can cause short-circuiting.Verify that the sound field function is on.Check the speaker settings (pages 23, 70).If no sound is heard from a speaker while outputting a test tone, or if the test tone is output from a speaker other than the one currently displayed, the speaker may be short-circuited; check the speaker connection again.

How can I connect external music devices to my Sony DAV-FC7?

You can connect external music devices to the system by using audio cords to link the device's audio output jacks to the VIDEO 2 AUDIO IN jacks on the system.

What should I do if my Sony DAV-FC7 system's sound is not turning on?

If there is no sound from your system:Check that the speaker cord is not connected securely.Press MUTING on the remote if "MUTING ON" is displayed on the front panel display.The system might be in pause mode or in Slow-motion Play mode; press the play button to return to normal play mode.If fast forward or fast reverse is being performed, press the play button to return to normal play mode.Check the speaker settings. For more information, see page 74 of the manual.

How do I unlock my Sony DAV-FC7 home theater system?

To unlock your system if Custom Parental Control is set for a disc, you need to enter your 4-digit password using the number buttons when prompted. If you forget your password, you can enter the 6-digit number "199703" using the number buttons when the CUSTOM PARENTAL CONTROL display asks for your password. The system will then ask you to enter a new 4-digit password. For more information, see page 54 of the manual.

How do I troubleshoot disc playback issues on my Sony DAV-FC7?

If you are experiencing disc playback issues:Ensure there is a disc inserted.Check that the disc is not upside down; insert the disc with the playback side facing down.Verify that the disc is not skewed in the system.Note that the system cannot play CD-ROMs (except for certain extensions), or discs with a region code that does not match the system.If the system was brought directly from a cold to a warm location, moisture may have condensed inside; remove the disc and leave the system turned on for about half an hour until the moisture evaporates.If a disc does not start from the beginning, check if Program Play, Shuffle Play, or Repeat Play is selected. Press CLEAR to cancel these functions. If Resume Play is selected, press the stop button on the system or remote and then start playback.If playback stops automatically, some discs may contain an auto pause signal.

Why is my Sony DAV-FC7 remote control not working?

If your remote control is not working, consider the following:There may be obstacles between the remote and the system.The distance between the remote and the system might be too far.The remote may not be pointed at the remote sensor on the system.The batteries in the remote may be weak. For more information, see page 75 of the manual.

How can I reset the surround sound settings on my Sony DAV-FC7?

To return the system parameters, including speaker settings, to the default settings:Press AMP MENU repeatedly on the remote until “CUSTOMIZE” appears in the front panel display.Press the up/down arrow until “MEMO. CLR. N” appears.Press the up/down arrow until “MEMO. CLR. Y” appears, then press ENTER.Press the up/down arrow until “Really? Y” appears, then press ENTER. “ALL CLEAR!” will appear, and settings will return to default. For more information, see page 64 of the manual.

How do I reset the sound settings on my Sony DAV-FC7?

To return the system parameters, including speaker settings, to the default settings:Press AMP MENU repeatedly on the remote until “CUSTOMIZE” appears in the front panel display.Press the up/down arrow until “MEMO. CLR. N” appears.Press the up/down arrow until “MEMO. CLR. Y” appears, then press ENTER.Press the up/down arrow until “Really? Y” appears, then press ENTER. “ALL CLEAR!” will appear, and settings will return to default. For more information, see page 64 of the manual.

What types of audio inputs does the Sony DAV-FC7 support?

The Sony DAV-FC7 system supports the following audio inputs:Analog audio via VIDEO 1 and VIDEO 2 AUDIO IN jacks.Optical digital audio via the VIDEO 2 OPTICAL DIGITAL IN jack.

What are the recommended speaker placement guidelines for the Sony DAV-FC7 system?

For optimal surround sound, follow these speaker placement guidelines:All speakers, except the subwoofer, should ideally be the same distance from the listening position.The front speakers can be placed 1.0 to 7.0 meters (3 to 23 feet) from the listening position.The center speaker can be placed up to 1.6 meters (5 feet) closer to the listening position than the front speakers.The surround speakers can be placed up to 4.6 meters (15 feet) closer to the listening position than the front speakers.Do not place the center and surround speakers farther away from the listening position than the front speakers.If using a CRT-based TV or projector, install the subwoofer at least 0.3 meter (1.0 foot) from the TV set to prevent color irregularity. For more information, see page 23 of the manual.

Why is my Sony DAV-FC7 receiver overheating?

The system may overheat if it is placed in a confined space where ventilation is poor or if the ventilation slots are blocked. To prevent this, allow adequate air circulation and do not place anything on the system that might block the ventilation slots. For more information, see page 3 of the manual.

What are the key specifications of the Sony DAV-FC7 home theater system?

Key specifications for the system include:Amplifier section: 100 W + 100 W (4 ohms at 1 kHz, THD 10%) for front speakers, 100 W for center, 100 W + 100 W for surround, and 100 W for subwoofer.Inputs: VIDEO 1 and VIDEO 2 (sensitivity: 150 mV and 300 mV respectively).Outputs: VIDEO 1 (voltage: 1 V) and PHONES (accepts stereo headphones only).Dimensions (approx.): 380 x 70 x 345 mm (w/h/d) including projecting parts.Mass (approx.): 4.8 kg (10 lb 10 oz). For more information, see page 77 of the manual.

How do I adjust the theatre sound settings on my Sony DAV-FC7?

To adjust the theatre sound settings, which are part of the sound fields:Press SOUND FIELD +/- on the remote repeatedly until the desired sound field, such as "CINEMA STUDIO EX A," "CINEMA STUDIO EX B," or "CINEMA STUDIO EX C," appears in the front panel display.These modes reproduce the sound characteristics of Sony Pictures Entertainment's studios, providing an ideal movie theatre sound environment. For more information, see pages 47 and 48 of the manual.

Can I connect an external subwoofer to my Sony DAV-FC7 system?

No, you should not connect any speakers other than those supplied with this system. The system is designed to be used with the supplied subwoofer connected to the SPEAKER WOOFER (purple) jack.

How do I adjust the display settings on the main unit of my Sony DAV-FC7?

To change the brightness of the front panel display on the main unit:Press AMP MENU repeatedly on the remote until "CUSTOMIZE" appears in the front panel display.Press the up/down arrow until "DIMMER" appears.Press +/-. Each press will change the brightness of the front panel display. For more information, see page 63 of the manual.

Specifications - Sony Dav-Fc7 Operating Instructions Manual

Compact av system

Hide thumbs Also See for DAV-FC7:

Operating instructions manual (89 pages)

Connection and installation manual (1 page)

Install manual (1 page)

Table Of Contents

Table of Contents

Enlarged version

Specifications

AUDIO POWER SPECIFICATIONS POWER

OUTPUT AND TOTAL HARMONIC

DISTORTION:

With 4 ohm loads, both channels driven, from 20 –

20,000 Hz; rated 75 watts per channel minimum RMS

power, with no more than 0.7 % total harmonic

distortion. (from 250 milli watts to rated output)

Amplifier section

Stereo mode

Surround mode

* Depending on the sound field settings and the source,

there may be no sound output.

Inputs

Outputs

Super Audio CD/DVD system

Laser

Signal format system

Frequency response (at 2 CH STEREO mode)

Harmonic distortion

100 W + 100 W (4 ohms

at 1 kHz, THD 10 %)

Front:

100

W +

100

centre*:

100

Surround*:

W +

100

W (4 ohms at 1 kHz,

THD 10 %)

100

Subwoofer*:

(4 ohms at 100 Hz, THD

10 %)

VIDEO 1:

Sensitivity: 150 mV

Impedance: 50 kilohms

VIDEO 2:

Sensitivity: 300 mV

Impedance: 50 kilohms

VIDEO 1 (AUDIO

OUT):

Voltage: 1 V

Impedance: 1 kilohm

PHONES:

Accepts stereo

headphones only.

Semiconductor laser

(Super Audio CD/DVD:

= 650 nm)

(CD:

= 780 nm)

Emission duration:

continuous

NTSC or NTSC/PAL

DVD (PCM): 2 Hz to

22 kHz (±1.0 dB)

CD: 2 Hz to 20 kHz

(±1.0 dB)

Less than 0.03 %

Tuner section

System

FM tuner section

Tuning range

North American models: 87.5 – 108.0 MHz

Other models:

Antenna

Antenna terminals

Intermediate frequency

AM tuner section

Tuning range

North American models: 531 – 1,710 kHz (with the

Other models:

Antenna

Intermediate frequency

Video section

Inputs

Outputs

Speakers

Front/Surround

Speaker system

Speaker unit

Rated impedance

Dimensions (approx.)

Mass (approx.)

PLL quartz-locked digital

synthesizer system

(100 kHz step)

87.5 – 108.0 MHz

(50 kHz step)

FM wire antenna

75 ohms, unbalanced

10.7 MHz

interval set at 9 kHz)

530 – 1,710 kHz (with the

interval set at 10 kHz)

531 – 1,602 kHz (with the

interval set at 9 kHz)

530 – 1,710 kHz (with the

interval set at 10 kHz)

AM loop antenna

450 kHz

Video: 1 Vp-p 75 ohms

S video:

Y: 1 Vp-p 75 ohms

C: 0.286 Vp-p 75 ohms

COMPONENT:

Y: 1 Vp-p 75 ohms

, P

: 0.7 Vp-p

75 ohms

Bass reflex

70 mm (2

inches) dia.

cone type

4 ohms

128 × 216 × 114 mm

× 8

× 4

inches)

(w/h/d, with the stand)

0.53 kg (1 lb 3 oz)

continued
