Application: Designed to lift a wide range of motor vehicles.
2
27
24, 25, 26
22, 23
21
19, 20
18, 15
Item
Part
No.
No.
Qty.
2
12368
1
3
509167
1
4
10549
1
5
524955
1
6
524953
1
7
529219
1
8
513566
1
9
501814
1
10
10472
1
11
512035
1
12
512037
2
13
501800
2
14
15953
2
15
14855
4
18
512034
1
© 2004 SPX Corporation
SPX Corporation
655 Eisenhower Drive
Owatonna, MN 55060-0995 USA
Phone: (507) 455-7000
Tech. Serv.: (800) 533-6127
Fax: (800) 955-8329
Order Entry: (800) 533-6127
Fax: (800) 283-8665
International Sales: (507) 455-7223
Fax: (507) 455-7063
Two-Speed Service Jack
Max. Capacity: 3 Tons
3
4
5
(Parts
list on
back)
14, 15
Description
(3/8-16)
Hex Hd. Cap Screw
U-joint
Roll Pin
Hydraulic Unit
Decal
Saddle, Pad, and Retaining
Ring
Saddle Pivot
Anchor Pin
(1/8 x 1-1/2")
Cotter Pin
Load Block
Retaining Ring
Front Wheel
(3/4")
Washer
(3/4")
Retaining Ring
Rod
Shaded areas reflect the last
revisions made to this form.
Parts List and
Operating Instructions
for:
6
Saddle Low Point:
Saddle High Point:
7
8
9
10
11, 12
13
Item
Part
No.
No.
Qty.
19
512033
20
12101
21
501288
22
10252
23
10216
24
11623
25
12004
26
513563
27
501817
Parts Included But Not Shown
501234
513781
516574
516675
Sheet No.
Issue Date: Rev. F, May 19, 2006
Form No. 524954
4 in.
24 in.
Lifting Range:
20 in.
Handle Length:
48 in.
Description
1
Rod
2
Retaining Ring
2
Caster
(3/4")
2
Lockwasher
(3/4")
2
Hex Nut
4
Bolt
4
Washer
4
Bushing
1
Press-in Grease Fitting
1
Pump Roller
1
Spring
1
Handle Assembly
1
Roller Retaining Pin Kit
1 of 2
1739
