- Page 1 Texas Instruments Registration Identification System 23 mm Glass Encapsulated Transponder RI-TRP-RRHP RI-TRP-WRHP Reference Manual 11-09-21-023 25-July-1996...
- Page 2 Texas Instruments reserves the right to change its products or services at any time without notice. TI provides customer assistance in various technical areas, but does not have full access to data concerning the uses and applications of customer's products.
-
Page 3: Table Of Contents
25 July 1996 23 mm Transponder Reference Manual Contents 1. Introduction ........................... 4 2. Transponder Packaging ......................... 5 3. Product Codes ..........................5 4. Function ............................5 4.1 Read (Reading of RO and R/W Transponders) ................ 5 4.2 Write and Program ........................8 5. -
Page 4: Introduction
23 mm Transponder Reference Manual 25 July 1996 1. Introduction The TIRIS 23 mm Glass Encapsulated Pulsed FM Transponder is a key product in low frequency RFID systems that can be used for a variety of applications, such as automotive security systems. The device is available in Read Only (RO) and Read/Write (R/W) versions. -
Page 5: Transponder Packaging
25 July 1996 23 mm Transponder Reference Manual 2. Transponder Packaging The dimensions of the transponder are given in Figure 3. The 23 mm shape offers several advantages: 1. The transponder is hermetically sealed. 2. The transponder is robustly constructed to withstand vibration (IEC68-2-6) and shock (IEC68-2-6). -
Page 6: Figure 4: Charge And Read Function Of The Transponder
23 mm Transponder Reference Manual 25 July 1996 The typical data low bit frequency is 134.2 kHz, the typical data high bit frequency is 123.2 kHz. The low and high bits have different durations, because each bit takes 16 RF cycles to transmit. The high bit has a typical duration of 130 µs, the low bit of 119 µs. -
Page 7: Figure 5: Fm Principle Used For The Read Function Of Tiris Transponders
25 July 1996 23 mm Transponder Reference Manual 134.2 kHz 123.2 kHz 134.2 kHz 123.2 kHz 129.2 µs 119.9 µs Figure 5: FM Principle Used for the Read Function of TIRIS Transponders START STOP DISCHARGE READ DATA DATA IDENTIFICATION DATA BITS BITS 112 bits... -
Page 8: Write And Program
23 mm Transponder Reference Manual 25 July 1996 4.2 Write and Program A new identification number can be written (programmed) into a R/W transponders in the following manner: After the charge phase the R/W transponder enters the write mode providing the reader starts to modulate the field by switching the transmitter on and off (TXCT-). -
Page 9: Characteristics Of The Pulsed Fm System
25 July 1996 23 mm Transponder Reference Manual WRITE HIGH BIT LOW BIT PROGRAM TRANSMITTER OFF TXCT - TRANSMITTER ON t offL t onL t offH t onH t prog Figure 8: The Write and Program Function 112 bit 128 bit WRITE WRITE RF MODULE... -
Page 10: Reader And System Design Impact
23 mm Transponder Reference Manual 25 July 1996 5.2 Reader and System Design Impact * Ease of receiver and power function design and the optimization of performance due to sequential power/read functions. * Low field strength for transponder charge, resulting in lower cost of the power function. * Optional performance and cost trade-offs by variation of: interrogation speed by software down to 35 ms. -
Page 11: Emi/Emc Performance
25 July 1996 23 mm Transponder Reference Manual 6. EMI/EMC Performance 6.1 General For any given RF-ID system, the EMI/EMC performance is determined by three factors: 1. The reader design and the resulting noise immunity performance 2. The signal strength of the transponder and Signal/Noise ratio at the receiver input 3. -
Page 12: Figure 10: Emi Performance Test Of The Tiris System
23 mm Transponder Reference Manual 25 July 1996 The TIRIS system performance using reader and 23 mm transponder is shown in figures 10, 11 and 12. Figure 10 shows the system immunity over a spectrum of 6 decades. At the most critical Radio Short Wave Broadcast frequencies 400 V/m were encountered. -
Page 13: Figure 11: Emi Performance In Automotive Environment
25 July 1996 23 mm Transponder Reference Manual 1,000 ELECTRICAL FIELD STRENGTH (VOLTS/m) Figure 11: EMI performance at commonly used radio communication frequencies in automotive environment. White noise performance of TIRIS TIRIS Pulsed FM AM Systems µΑ/m] NOISE LEVEL [dBµΑ Figure 12: Reading range under broad band noise (white noise) conditions Page 13 of 22... -
Page 14: Measurement Set-Ups
23 mm Transponder Reference Manual 25 July 1996 7. Measurement Set-Ups This Section describes typical measurement set-ups to determine transponder relevant data like: resonant frequency, bandwidth, quality factor, powering field strength and transponder signal field strength listed in Section 9 "Rocommended Operating Conditions". 7.1 Measurement Set-Up: Resonance frequency, bandwidth, quality factor of transponder This test set-up is suitable for resonant frequency (f res) measurements as well as the determination of the -3dB bandwidth (∆f) of the transponder. -
Page 15: Measurement Set-Up: Powering Field Strength
25 July 1996 23 mm Transponder Reference Manual 3 dB Pick-up coil Figure 14: Determination of the resonance frequency and -3dB bandwidth by monitoring the pick-up coil voltage 7.2 Measurement Set-Up: Powering Field Strength The following set-up is used to determine the minimum required powering field strength. COILS TRANSPONDER ANTENNA AXIS... -
Page 16: Figure 16: Received Signal At The Pick Up Coil, If Power Field Strength Is Sufficient
23 mm Transponder Reference Manual 25 July 1996 Determination of the minimum powering field strength is possible by changing the field strength through increasing the coil current. The relation between the generated magnetic flux / field strength and coil current can either be measured with a calibrated filed probe, or calculated as follows: µ... -
Page 17: Measurement Set-Up: Transponder Signal Strength
25 July 1996 23 mm Transponder Reference Manual 7.3 Measurement Set-Up: Transponder Signal Strength The 23 mm transponder has to be located into a homogeneous field (Helmholtz set-up). The pulsed power signal is generated by a signal generator. A calibrated field strength probe picks up the transponder signal. -
Page 18: Absolute Maximum Ratings
23 mm Transponder Reference Manual 25 July 1996 8. Absolute Maximum Ratings All data given for free air operating temperature range (unless otherwise noted). PARAMETER CONDITION MIN. NOM. MAX. UNIT Ta read Operating temperature (read) Ta Prog Operating temperature (program) Storage temperature Storage temperature 5 min... -
Page 19: Characteristics
25 July 1996 23 mm Transponder Reference Manual 10. Characteristics All data given for free air temperature range, a charge time of 50 ms, and a transmitter frequency of 134.2 kHz +/- 40 Hz (unless otherwise noted). PARAMETER CONDITION MIN. NOM. -
Page 20: Environmental Data And Reliability
23 mm Transponder Reference Manual 25 July 1996 11. Environmental Data and Reliability PARAMETER CONDITIONS MIN. NOM. MAX. UNIT 25 o C Programming cycles Note 1 100 k cycles Data retention time Note 1 100k cycles years @ 25 o C storage temperature EM Radiation immunity... -
Page 21: Packing Symbolization
25 July 1996 23 mm Transponder Reference Manual 14. Packing Symbolization The Transponders are packed in a a carrier tape which is closed with a cover tape carrying product information and Country of Origin information as below: MALAYSIA xxxxxxxxxxxxxxxx Note: 'XXXXXXXXXXXXXXXX' is the 16 digits Identification Code (ID) in hexadecimal numbers. -
Page 22: Appendix A: Conversion Formula
23 mm Transponder Reference Manual 25 July 1996 Appendix A: Conversion Formula Conversion formula between magnetic flux, magnetic field strength and electric field strength. µ ⋅ ⋅ µ µ µ dB A dB A dB V − ...
