- Page 1 3-280-122-11 (1) Wireless Stereo Headset Operating Instructions DR-BT22iK © 2007 Sony Corporation...
- Page 2 U.S. and other countries. The Bluetooth word mark and logos are owned by the Bluetooth SIG, Inc. and any use of such marks by Sony Corporation is under license. Other trademarks and trade names are those of their respective owners.
- Page 3 This Bluetooth transmitter is designed for iPod only. You cannot connect any other portable audio players. Sony cannot accept responsibility in the event that data recorded to iPod is lost or damaged when using an iPod connected to...
-
Page 5: Table Of Contents
Table of Contents What is Bluetooth wireless technology? ...6 Features ...7 Getting Started Checking supplied items ...8 Location and Function of Parts ...9 Bluetooth headset ... 9 Bluetooth transmitter ...10 Basic use of headset ...11 Charging the headset ...11 Folding...14 Unfolding ...14 Wearing ...15 Connecting to an iPod ...16... -
Page 6: What Is Bluetooth Wireless Technology
What is Bluetooth wireless technology? Bluetooth wireless technology ™ is a short-range wireless technology that enables wireless data communication between digital devices, such as a computer or digital camera. Bluetooth wireless technology operates within a range of about 10 meters (about 30 feet). Connecting two devices as necessary is common, but some devices can be connected to... -
Page 7: Features
Features This product is an audio kit comprising of a transmitter and headset using Bluetooth wireless technology. You can enjoy music wirelessly by transmitting the audio signals to a headset by connecting the Bluetooth transmitter to iPod (see page 3 for compatible iPod models) with the iPod connector* (30 pin). -
Page 8: Getting Started
Getting Started Checking supplied items Bluetooth headset DR-BT22 (1) Bluetooth transmitter TMR-BT8iP (1) AC power adaptor (1) Operating Instructions (this book) (1) Warranty Card (1) ... -
Page 9: Location And Function Of Parts
Location and Function of Parts Bluetooth headset Right housing Multi function button Controls various functions when calling with a headset by combining with a Bluetooth mobile phone. POWER button Microphone RESET button Push this button when the headset does not operate properly. -
Page 10: Bluetooth Transmitter
Bluetooth transmitter iPod connector (0 pin) Connects to the dock connector of an iPod (page 16). Transmitter indicator Indicates the transmitter’s status (page 23). Hereafter, “Bluetooth headset” is abbreviated as “headset, ” and “Bluetooth transmitter” as “transmitter. ” ... -
Page 11: Basic Use Of Headset
Basic use of headset Charging the headset The headset contains a rechargeable Lithium-Ion battery, which should be charged before using for the first time. Connect the supplied AC power adaptor to the DC IN 3 V jack on the headset. To an AC outlet AC power adaptor (supplied) - Page 12 If the life of the built-in rechargeable battery drops to half the normal length, the battery should be replaced. Consult your nearest Sony dealer for replacement of the rechargeable battery.
- Page 13 Checking the remaining battery When pressing the POWER button while the headset is turned on, the headset indicator (red) flashes. You can check the remaining battery by the number of times the headset indicator (red) flashes. Headset Indicator (red) 3 times 2 times 1 time Note...
-
Page 14: Folding
Folding Hold near the foldable part with both hands and lift up the right housing to fold it as illustrated. Close the center part of the headband. Fold the left housing of the headband. Unfolding Unfold the left housing of the headband as illustrated. -
Page 15: Wearing
Notes Do not pull open this way. Be careful not to hit your face or eyes with the top of the headband. Wearing Unfold the headset according to the procedures on page 14, then extend the headset to adjust the length. Put the housing with ... -
Page 16: Connecting To An Ipod
Connecting to an iPod Connect the transmitter to the dock connector port of an iPod (see page 3 for compatible iPod models) firmly. To turn on the transmitter Connect the transmitter to the iPod. Press the power button of the transmitter for about 1 second to turn it on, or start to play back on iPod. - Page 17 Notes To listen to music from the headphone jack of the iPod, disconnect the transmitter from the iPod. While the transmitter is turned on, it consumes power from the iPod. We recommend disconnect the transmitter from iPod when not using the Bluetooth function.
-
Page 18: Operating
Operating Listening to music of the iPod You can listen to music of the iPod (see page 3 for compatible iPod models) on the headset. Press and hold the POWER button on the headset for about 3 seconds. The headset indicator (blue) and headset indicator (red) flash together twice and the headset is turned on. - Page 19 T ip You can control the volume on the headset. (The volume of the iPod is not changed.) You can also fast-forward or fast-rewind while playing back (page 20). Notes Even if you control the volume on the iPod, sound from the headset will not change.
-
Page 20: Controlling An Ipod With The Headset
Controlling an iPod with the headset You can control an iPod (see page 3 for compatible iPod models) using the control button of the headset. Before starting remote control operation, check that step 1 and of “Listening to music of the iPod” are completed (page 1). Transmitter Remote control Control for the iPod You can playback or pause the iPod by pressing the ... -
Page 21: Advanced Operation
Advanced operation Pairing with other Bluetooth devices What is pairing? Bluetooth devices need to be “paired” with each other beforehand. Once Bluetooth devices are paired, there is no need for pairing again, except in the following cases: Pairing information is deleted after repair, etc. ... - Page 22 Press and hold the power button of the transmitter for about 7 seconds or more to enter “Pairing in process.” After about 1 second, the transmitter indicator will flash twice, but keep pressing the power button. Notes When fi rst power on the transmitter aft er initialized, the transmitter will enter “Pairing in process”...
-
Page 23: Status Indicator
T ip When pairing the transmitter with a number of Bluetooth receiving devices, repeat steps to for each device individually. Note For using the Bluetooth function, it is required that the Bluetooth device on the other side is corresponding with the same profile as the transmitter. However, even if it is corresponding with the same profile, functions may differ depending on the specification of the Bluetooth device. -
Page 24: Pairing Headset With Other Bluetooth Transmitting Devices
Pairing headset with other Bluetooth transmitting devices Place the Bluetooth transmitting device to be paired together within 1 m (3 ft) of the headset. Press and hold the POWER button of the headset for about 7 seconds or more to enter “Pairing in process” while the headset is turned off. - Page 25 Note Passcode* of the headset is fi xed at “0000. ” Depending on the Bluetooth receiving device, it may be necessary to input the passcode (in this case, “0000”). Th e headset cannot be paired with a Bluetooth receiving device whose passcode is not “0000.
- Page 26 On Headset Indicators Status Searching Connectable Connecting HFP/HSP or A2DP (Standby for receiving audio signal) HFP/HSP and A2DP (Standby for receiving audio signal) Listening Listening during standby for telephone call Incoming call Talking Calling while playing back music B : Headset indicator (blue) R : Headset indicator (red) Indicator –...
-
Page 27: Re-Pairing The Transmitter And The Headset
Re-pairing the transmitter and the headset Turn on the power of iPod. (Make sure the iPod is in pause mode.) Connect the transmitter to the iPod (page 16). Place the transmitter and the headset to be paired together within 1 m (3 ft). Press and hold the POWER button of the headset for about 7 seconds or more to enter “Pairing in process”... - Page 28 Notes When fi rst power on the transmitter aft er initialized, the transmitter will enter “Pairing in process” automatically. Th e pairing information is initialized if you press and hold the power button for 15 seconds. Th e transmitter indicator lights up for 5 seconds before the initialization starts.
-
Page 29: Calling With Headset
Calling with headset Preparation for calling (Bluetooth connection) Check the following before operating the headset. – The Bluetooth function is active on the mobile phone. – Pairing of the headset and the Bluetooth mobile phone is complete. Headset indicator (blue) Headset indicator (red) Multi function button Press and hold the POWER button for about 3 seconds while the... - Page 30 To make a connection by operating Bluetooth mobile phone Make the Bluetooth connection (HFP or HSP*) from the Bluetooth mobile phone to the headset. Refer to the manual supplied with your Bluetooth mobile phone for operation details. The list of recognized devices appears on the display of the Bluetooth mobile phone.
-
Page 31: To Receive A Call
To receive a call When an incoming call arrives, a ring tone will be heard from the headset. Press the multi function button on the headset. The ring tone differs in the following ways, depending on your mobile phone. – ring tone set on the headset –... -
Page 32: Controlling The Bluetooth Mobile Phone - Hfp, Hsp
Controlling the Bluetooth mobile phone – HFP, HSP The operation of the buttons on the headset varies depending on your mobile phone. HFP (Hands-free Profile) or HSP (Headset Profile) is used for Bluetooth mobile phone. Refer to the operating instructions supplied with your Bluetooth mobile phone on supported Bluetooth profiles or how to operate. -
Page 33: Calling While Playing Back Music
Calling while playing back music The Bluetooth connection using HFP or HSP as well as A2DP is necessary to make a call while playing back music. For example, to make a call using a Bluetooth mobile phone while listening to music on a Bluetooth compatible music player, the headset needs to be connected to the mobile phone using HFP or HSP. -
Page 34: Additional Information
Additional Information Precautions On Bluetooth communication Bluetooth wireless technology operates within a range of about 10 meters (about 30 feet). Maximum communication range may vary depending on obstacles (human body, metal, wall, etc.) or electromagnetic environment. Steel cabinet The transmitter Optimal performance Limited performance ... - Page 35 This unit supports security capabilities that comply with the Bluetooth standard to provide a secure connection when the Bluetooth wireless technology is used, but security may not be enough depending on the setting. Be careful when communicating using Bluetooth wireless technology.
- Page 36 If you experience discomfort after using the Bluetooth device, stop using the Bluetooth device immediately. Should any problem persist, consult your nearest Sony dealer. Listening with this product at high volume may affect your hearing. For traffic safety, do not use this product while driving or cycling.
-
Page 37: Disposing Of The Headset
Disposing of the headset The headset has a Lithium-ion rechargeable battery built in the left housing. For environmental conservation, be sure to remove the built-in rechargeable batteries from the headset before disposing, and dispose of the battery appropriately. Remove the ear pad on the left housing, and then detach the left housing. - Page 38 Pull out the connector and remove the rechargeable battery. The rechargeable battery is fixed with adhesive tape. Insert an object such as flathead screwdriver and lift up the battery to remove it.
-
Page 39: Troubleshooting
Troubleshooting If you run into any problems using this product, use the following checklist and read the product support information on our website. Should any problem persist, consult your nearest Sony dealer. Symptom The transmitter is not turned on. (Or turns off shortly after turning on.) - Page 40 Symptom Sound break, noise or playback speed change. The headset does not operate properly. Pairing cannot be established. Bluetooth connection cannot be established with a device that has been “paired” before. Cannot make the Bluetooth connection. Cannot make the Bluetooth connection from your mobile phone to the headset.
-
Page 41: Initializing
Initializing Initializing the transmitter You can reset the transmitter to its default and delete all pairing information. Connect the transmitter to the iPod. Press and hold the power button for more than about 15 seconds. During these 15 seconds, the transmitter indicator changes in sequence as follows: –... -
Page 42: Specifications
Specifications General Output Bluetooth Specifi cation Power Class 2 Maximum communication range Line of sight approx. 10 m (30 ft )*1 Frequency band 2.4 GHz band (2.4000 GHz – 2.4835 GHz) Modulation method FHSS Transmission range (A2DP) 20 - 20,000 Hz (Sampling frequency 44.1 kHz) Transmitter Communication System... - Page 43 *1 The actual range will vary depending on factors such as obstacles between devices, magnetic fields around a microwave oven, static electricity, reception sensitivity, aerial’s performance, operating system, software application, etc. *2 Enhanced Data Rate *3 Bluetooth standard profiles indicate the purpose of Bluetooth communication between devices.
- Page 44 Printed in Malaysia...
