LCD
Digital Color TV
Setup Guide
(Operating Instructions)
XBR-60LX900 / 52LX900 / 46LX900 / 40LX900
Setting up your TV
To watch TV
Additional Information
Sony Customer Support
U.S.A.: www.sony.com/tvsupport
Canada: www.sony.ca/support
United States
Canada
1.800.222.SONY
1.877.899.SONY
Please Do Not Return
the Product to the Store
4-187-898-
(1)
Advertisement
Table of Contents
Related Manuals for Sony Bravia XBR-60LX900
Summary of Contents for Sony Bravia XBR-60LX900
- Page 1 Digital Color TV Setup Guide (Operating Instructions) XBR-60LX900 / 52LX900 / 46LX900 / 40LX900 4-187-898- Setting up your TV To watch TV Additional Information Sony Customer Support U.S.A.: www.sony.com/tvsupport Canada: www.sony.ca/support United States Canada 1.800.222.SONY 1.877.899.SONY Please Do Not Return...
- Page 2 “XMB ”and “xross media bar” are ™ trademarks of Sony Corporation and Sony Computer Entertainment Inc. “PlayStation” is a registered trademark and “PS3” is a trademark of Sony Computer Entertainment Inc. ® DLNA , the DLNA Logo and DLNA ®...
-
Page 3: Table Of Contents
® The BRAVIA Full HDTV Experience Thank you for choosing Sony! Your new BRAVIA opens the door to the “Full HDTV Experience.” This document will help you get the most out of your TV. Please take a moment to register your TV at: U.S.A.: http://productregistration.sony.com... -
Page 4: Checking The Accessories
Checking the accessories AC power cord (1) Remote control (1) Size AAA batteries (2) Table-Top Stand (1) (except XBR-60LX900) Fixing screws for Table-Top Stand (M5 × 16) (4) (except XBR-60LX900) Assembling screws for Table-Top Stand (M5 × 16) (4) (XBR-40LX900 only) Bottom cover (1) Stand rear cover (1) Black spacers (4) -
Page 5: Programming The Remote Control
Follow the steps below to program your TV remote control. 1 Look for the code in the Manufacturer’s Code List (refer to i-Manual) that corresponds to the equipment you would like to operate with the Sony remote control. If more than one code is provided, try programming the first code listed. -
Page 6: Setting Up Your Tv
Setting up your TV Some TV models are packaged with a detached Table-Top Stand so you can mount your TV to a wall right away. If you are not mounting the TV to a wall, you will need to attach the Table- Top Stand. -
Page 7: Adjusting The Viewing Angle
After all the screws have been tightened, cover the Table-Top Stand with the supplied stand rear cover. Adjusting the viewing angle This TV can be adjusted within the angles shown below (except XBR-60LX900). 0° Remove screw as shown. • Reverse the steps when readjusting the angle back to 0 degrees. Slide in. -
Page 8: Connecting The Tv
Connecting the TV The following chart shows the high-definition (HD) and standard-definition (SD) video formats supported by your BRAVIA TV inputs. * For supported PC formats refer to the i-Manual. Detaching the terminal cover • After connecting cables, re-attach the terminal cover to the TV. - Page 9 Shown with a Set Top Box with HDMI connection Set Top Box Cable System or VHF/UHF Antenna System Shown with a Set Top Box with COMPONENT connection Set Top Box Cable Antenna (Continued)
- Page 10 ® Shown with HD BRAVIA Sync™ Basic Connection *Rear of TV (Dish) Cable/ Antenna Shown with HD Basic Connection with Home Theater System Rear of TV Cable/ Antenna HD Cable Box or HD Satellite Receiver * Signifies a BRAVIA Sync capable device. Blu-ray Disc/DVD Cable/SAT (Dish) SD Cable Box or...
- Page 11 Shown with PC Connection with SD VCR/DVD Side Panel Rear of TV Notebook PC Splitter VCR/DVD Combo Cable/Antenna...
-
Page 12: Securing The Tv
An alternative way to secure the TV is with an optional Sony Support Belt Kit. Screw hole on the Table-Top Stand Contact Sony Customer Support to obtain the optional Support Belt Kit by providing your TV model name. • For United States call: 1-800-488-7669 or visit: www.sony.com/accessories... -
Page 13: Organizing The Ac Power Cord
Anchor the TV to the Wall. Anchor the TV to the wall by using bolts, wall anchor and chain (or rope). Anchor bolts (not supplied) Wall- mount holes • Your TV is shipped with screws attached to the rear of the TV. (They are fastened in the screw holes for wall mounting.) Be sure to remove the upper two screws prior to anchoring the TV on a wall. -
Page 14: Running Initial Setup
Running initial setup Complete your cable connections before proceeding with the Initial Setup. Connect the TV to your nearest power outlet. Check the ENERGY SAVING SWITCH setting is on (z). Press POWER on the TV. When you switch the TV on for the first time, the Language menu appears on the screen. -
Page 15: Using A Wall-Mount Bracket
Prepare the TV for the Wall-Mount Bracket before making cable connections. For product protection and safety reasons, Sony strongly recommends that you use the Wall-Mount Bracket designed for your TV and the installation should be performed by a Sony dealer or licensed contractor. -
Page 16: To Watch Tv
To watch TV To watch programs GUIDE OPTIONS HOME To use the TV features Press HOME to display TV Home Menu/ to access TV Settings and other ™ media and network related content. Settings Picture & Display Adjust the picture and screen settings Turn on the TV. -
Page 17: To Use I-Manual
To use i-Manual Welcome to i-Manual “BRAVIA” TV Features Watching TV Introduces convenient features such as TV Guide, Favorites, etc. Using the Home Menu You can find how to customize your TV settings, etc. • Images and illustrations may differ from what you see on your TV. Your BRAVIA TV comes with an on-screen manual. -
Page 18: To Use 3D Glasses
To use 3D Glasses Before use: Remove the battery’s insulating sheet before using the 3D Glasses for the first time. Parts and components 3D Glasses (2) 1 Slide switch Set the switch for a comfortable fit. Set both the switches on either side for a comfortable fit. - Page 19 • To preserve our environment dispose of used batteries according to your local laws or regulations. Safety precautions • You should only use the 3D Glasses for watching 3D video images on a compatible Sony television. • Do not drop or modify these 3D Glasses.
-
Page 20: Troubleshooting
Press POWER on the TV to turn it off, disconnect the AC power cord, and contact Sony Customer Support (information provided on the front cover) with how many times the indicator flashes. When the STANDBY indicator is not flashing Check the items in the tables below. -
Page 21: How To Care For Your Bravia
How to Care for Your BRAVIA Safety is very important, please read and follow the safety documentation (Safety Booklet) separately provided. Unplug the TV and other connected equipment from the wall outlet before you begin cleaning your TV. • Wipe the LCD screen gently with a soft cloth. •... -
Page 22: Specifications
Specifications Model name XBR- System Television system NTSC: American TV standard ATSC (8VSB terrestrial): ATSC compliant 8VSB QAM on cable: ANSI/SCTE 07 2000 (Does not include CableCARD functionality) Channel coverage Analog terrestrial: 2 - 69 / Digital terrestrial: 2 - 69 Analog Cable: 1 - 135 / Digital Cable: 1 - 135 Panel system LCD (Liquid Crystal Display) Panel... - Page 23 “Additional Information for Using Sony Wall-Mount Bracket”. To Customers Sufficient expertise is required for TV installations. Be sure to subcontract the installation to a Sony dealer or licensed contractor and pay adequate attention to safety during the installation.
- Page 24 United States Software Canada Updates: NOTE: If your TV is connected to the Internet, you can check for software updates by selecting Settings, Product Support and then Automatic Software Update. © 2010 Sony Corporation Printed in U.S.A. http://productregistration.sony.com http://www.SonyStyle.ca/registration http://www.sony.com/tvsupport http://www.sony.ca/support...
