Trinitron Color TV

Operating Instructions

• Before operating the unit, please read this manual thoroughly and retain
it for future reference.
Инструкция по эксплуатации
• Перед работой с устройством внимательно прочтайте инструкцию
и сохраните её для дальнейшего использования.
KV-AZ21
© 2005 Sony Corporation
2-649-680-11 (3)
GB
RU
M91

Advertisement

Table of Contents
loading

Related Manuals for Sony M91

Summary of Contents for Sony M91

  • Page 1: Operating Instructions

    • Before operating the unit, please read this manual thoroughly and retain it for future reference. Инструкция по эксплуатации • Перед работой с устройством внимательно прочтайте инструкцию и сохраните её для дальнейшего использования. KV-AZ21 © 2005 Sony Corporation 2-649-680-11 (3)
  • Page 2 WARNING • Dangerously high voltages are present inside the TV. • TV operating voltage: 110 – 240 V AC. • Do not plug in the power cord until you have completed making all other connections; otherwise a minimum leakage current might flow through the antenna and other terminals to ground.

  • Page 3: Table Of Contents

    Changing the “Setup” setting ... 18 Viewing Teletext ... 19 Enjoying stereo or bilingual programs ... 20 Listening to the FM Radio ... 21 Troubleshooting ... 22 Specifications ... 24 Made in Malaysia. Sony Corporation 6-7-35 Kitashinagawa, Shinagawa-ku, Tokyo, 141-0001 Japan.

  • Page 4: Securing The Tv

    x Securing the TV To prevent the TV from falling, use the supplied screws, clamps and band to secure the TV. Use only the supplied screws. Use of other screws may damage the TV. screws Screw the band to the TV stand and to the provided hole at the rear of your TV.

  • Page 5: Setting Up Your Tv ("Initial Setup")

    x Setting up your TV (“Initial Setup”) When you turn on your TV for the first time, the “Начальная настройкa” (“Initial Setup”) menu will appear. You may change the menu language, preset the TV channels automatically, sort or edit the channels and adjust the picture position using the buttons on the remote control or TV top control panel.
  • Page 6 Setting up your TV (“Initial Setup”) (continued) d) If you wish to edit the channels, press to change to edit mode. Press b until the mode that you wish to edit is highlighted: Label, Skip, Then press 1) To label, press V or v to select the alphanumeric characters for the label.

  • Page 7: Tv Top Control, Front And Rear Panels

    x TV top control, front and rear panels TV top control panel WEGA GATE (MONO) TV front panel (MONO) Button/Terminal PROG +/– 2 +/– WEGA GATE menu operations V,v,B,b WEGA GATE TV rear panel MONO) Function Turn off or turn on the TV. Remote control sensor.

  • Page 8: Connecting Optional Components

    x Connecting optional components Connecting to the video input terminal ( t ) TV front panel (MONO) TV rear panel MONO) Notes • If you connect a VCR to 8 (antenna input), preset the signal output from the VCR to the program number 0 on the TV (see page 17).

  • Page 9: Connecting To The Monitor Output Terminal ( T)

    Connecting to the monitor output terminal ( T ) TV rear panel MONO) Connecting to the component video input terminal ( TV rear panel MONO) Notes • If your DVD player can output interlace and progressive mode signals, select the interlace output when connecting to either 525i/60Hz or 625i/50Hz interlace signals.

  • Page 10: Using The Remote Control And Basic Functions

    x Using the remote control and basic functions PROG WEGA RETURN GATE Button Description 1 ?/1 Turn off temporarily or turn on the TV. Display the TV program. Jump to last program number that has been watched for at least five seconds. PROG +/–...
  • Page 11 Button Description WEGA GATE menu operations Confirm selected items. WEGA GATE Display or cancel WEGA GATE menu. V, v, B, b Select and adjust items. RETURN Return to the previous level. Timer operations Set TV to turn on automatically according to the desired period of time (max.

  • Page 12: Introducing The Wega Gate Navigator

    x Introducing the WEGA GATE navigator WEGA GATE is a gateway that allows you access to preset TV channels, connected external inputs, FM Radio mode and “Settings” menu. WEGA GATE “TV” External Inputs FM Radio Settings Select Confirm “External Inputs” “FM Radio”...

  • Page 13: Settings" Adjustment

    x “Settings” Adjustment You are able to change the settings of your TV from “Settings” in WEGA GATE menu. Press WEGA GATE button to display WEGA GATE menu. Press V or v to select “Settings” and press The following is an overview of the items that can be adjusted. Picture Picture Mode: Vivid...

  • Page 14: Changing The "Picture" Setting

    x Changing the “Picture” setting The “Picture” menu allows you to adjust the picture settings. Press WEGA GATE and select “Settings”. Make sure the “Picture” icon ( Press V or v to select the desired item (e.g., “Picture Mode”), then press Select “Picture Mode”...

  • Page 15: Changing The "Sound" Setting

    x Changing the “Sound” setting The “Sound” menu allows you to adjust the sound settings. Press WEGA GATE and select “Settings”. Press V or v to select the “Sound” icon ( Press V or v to select the desired item (e.g., “Sound Mode”), then press Select “Sound Mode”...

  • Page 16: Changing The "Channel Setup" Setting

    x Changing the “Channel Setup” setting The “Channel Setup” menu allows you to preset channels automatically, manually preset channels, sort or edit the channels and preset FM Radio stations. Press WEGA GATE and select “Settings”. Press V or v to select the “Channel Setup” icon ( Press V or v to select the desired item (e.g., “Auto Program”), then press Select “Auto Program”...

  • Page 17: Presetting Channels Manually

    Presetting channels manually After selecting “Manual Program”, select the program number to which you want to preset a channel. (1) Make sure “Program” is selected, then press (2) Press V or v until the program number you want to preset appears on the menu, then press Select the desired channel.

  • Page 18: Changing The "Setup" Setting

    x Changing the “Setup” setting The “Setup” menu allows you to change the menu language, adjust the picture position, label the connected equipment, select the color system, set the wake up timer beep and reset your TV to factory settings. Press WEGA GATE and select “Settings”.

  • Page 19: Viewing Teletext

    x Viewing Teletext Some TV stations broadcast an information service called Teletext which allows you to receive various information, such as stock market reports and news. You can use the buttons on the remote to view Teletext. PROG WEGA RETURN GATE (red, green,...

  • Page 20: Enjoying Stereo Or Bilingual Programs

    x Enjoying stereo or bilingual programs You can enjoy stereo sound or bilingual programs of NICAM and A2 stereo systems by using the A/B button. PROG WEGA RETURN GATE Note • If the stereo sound is noisy when receiving a stereo program, select “Mono”. The sound becomes monaural but the noise is reduced.

  • Page 21: Listening To The Fm Radio

    Listening to the FM Radio You are able to listen to the FM radio stations using your TV. To access to FM Radio mode: Press WEGA GATE button and select “FM Radio” (see page 12). Press FM button on the top control panel (see page 7). To exit from FM Radio mode: Press WEGA GATE button, select the desired items: “TV”...

  • Page 22: Troubleshooting

    • Check the antenna cable and connection on the TV, VCR and at the wall noisy sound (see page 8). • Check the antenna setup. Contact a Sony dealer for advice. • Display the “Channel Setup” menu and select “Manual Program” to preset the channel again (see page 17).
  • Page 23 (switch) to your TV (see page 8). • Count the number of times the 1 (standby) indicator flashes. The 1 (standby) indicator on your Press ! (main power) to turn off your TV. Contact your nearest Sony TV flashes red service center. several times after every three seconds.

  • Page 24: Specifications

    x Specifications Power requirements Power consumption (W) Television system Color system Stereo/Bilingual system Teletext language Channel coverage 8 (Antenna) Audio output (Speaker) Number of terminal (Video) (Audio) (S Video) (Component Video) i (Headphone) FM Radio Tuning Range Intermediate Frequency Picture tube Tube size (cm) Screen size (cm) Dimensions (w/h/d, mm)
  • Page 25 ВНИМАНИЕ!
  • Page 26 Содержание Sony Corporation 6-7-35 Kitashinagawa, Shinagawa-ku, Tokyo, 141-0001 Japan. Задняя крышка...
  • Page 27 x Безопасная установка телевизора Винты x Перед эксплуатацией Шаг 1 Примечание Шаг 2 Советы Шаг 3 Примечание Шаг 4 20 мм 3,8 мм Зажимы или Крепежная лента...
  • Page 28 x Настройка ТВ (“Начальная настройкa”) Продолжение...
  • Page 29 Настройка ТВ (“Начальная настройкa”) (продолжение) Совет...
  • Page 30 WEGA GATE (MONO) (MONO) PROG +/– V,v,B,b WEGA GATE MONO) PROG MONO)
  • Page 31 (MONO) MONO) MONO)
  • Page 32 MONO) MONO) MONO) MONO)
  • Page 33 PROG WEGA GATE RETURN 1 ? 1 PROG +/– 0 – 9 100 300 1k 3k 8k 100 300 1k 3k 8k 100 300 1k 3k 8k...
  • Page 34 WEGA GATE V v B b RETURN V v B b...
  • Page 35 –PROG+ V v B b...
  • Page 37 V v B...
  • Page 40 V v B...
  • Page 42 PROG WEGA GATE RETURN...
  • Page 43 PROG WEGA RETURN GATE NICAM NICAM NICAM NICAM...
  • Page 44 PROG WEGA RETURN GATE V v B b...
  • Page 47 KV-AZ21M91...
