LCD
Digital Colour TV
Operating Instructions
KDL-55EX72x / 46EX72x / 46EX52x / 46CX52x / 40EX72x / 40EX52x / 40CX52x / 37EX72x
KDL-32EX72x / 32EX52x / 32EX42x / 32CX52x / 26EX32x / 24EX32x / 22EX32x
4-269-995-12(1)
Getting Started
Using Your BRAVIA TV
Network Setup
Additional Information

Advertisement

Table of Contents

   Also See for Sony KDL-32EX72X

   Related Manuals for Sony KDL-32EX72X

   Summary of Contents for Sony KDL-32EX72X

  • Page 1 Digital Colour TV Operating Instructions KDL-55EX72x / 46EX72x / 46EX52x / 46CX52x / 40EX72x / 40EX52x / 40CX52x / 37EX72x KDL-32EX72x / 32EX52x / 32EX42x / 32CX52x / 26EX32x / 24EX32x / 22EX32x 4-269-995-12(1) Getting Started Using Your BRAVIA TV...
  • Page 2: Trademark Information

    Please refer to the illustration that actually equipped with the product. Introduction Thank you for choosing this Sony product. Before operating the TV, please read this manual thoroughly and retain it for future reference. The manufacturer of this product is Sony Corporation, 1-7-1 Konan Minato-ku Tokyo, 108-0075 Japan.
  • Page 3: Lcd Screen

    KDL-46/40/32EX724, KDL-26EX321, KDL-26/24/ 22EX320: Notice for Wireless Signal 1. Hereby, Sony, declares that this unit is in compliance with the essential requirements and other relevant provisions of Directive 1999/5/EC. To obtain the declaration of conformity (DoC) for R&TTE Directive, please access the following URL address.
  • Page 4: Disposal Of The Tv Set

    contain mercury. Follow your local ordinances and regulations for disposal. Handling and cleaning the screen surface/cabinet of the TV set Be sure to unplug the mains lead connected to the TV set from mains socket before cleaning. To avoid material degradation or screen coating degradation, observe the following precautions.
  • Page 6: Table Of Contents

    Table of Contents Getting Started Checking the accessories ... 8 Inserting batteries into the remote... 8 1: Attaching the Table-Top Stand ... 9 2: Adjusting the viewing angle of the TV ... 10 3: Connecting an antenna (aerial)/Set Top Box/recorder (e.g. DVD recorder) ... 11 4: Connecting audio/video devices ...
  • Page 7: Parts Description

    After setting up your BRAVIA TV and learning basic operations with this manual, see the built-in manual (i-Manual) for further explanation of the features of your TV. This TV has a built-in manual (i-Manual). To access the i-Manual, press i-MANUAL on the remote, and select an item. For details, see page 18 of this manual.
  • Page 8: Getting Started

    Getting Started Checking the accessories Remote (1) Size AAA batteries (R3 type) (2) Table-Top Stand (1) Fixing screws for Table-Top Stand (M5 x 16) (3) (except KDL-26/24/22EX32x) Fixing screws for Table-Top Stand (M4 x 12) (2) (KDL-26/24/22EX32x only) Assembling screws for Table-Top Stand (M6 x 14) (4) (KDL-55/46EX72x, KDL-46EX52x, KDL-46CX52x only)
  • Page 9: 1: Attaching The Table-top Stand

    1: Attaching the Table-Top Stand Refer to the supplied Table-Top Stand leaflet for proper attachment for some TV models. Place the TV set on the Table-Top Stand. B For KDL-55/46/40/37/32EX72x, KDL-46/40/32EX52x, KDL-46/40/32CX52x, KDL-32EX42x Guide pins • Align the TV from the top, slide it in until the guide pins cannot be seen.
  • Page 10: 2: Adjusting The Viewing Angle Of The Tv

    • Be sure the TV is on the vertical position before switching on. TV set must not powered on with LCD panel face down to avoid uneven picture uniformity. B For KDL-55/46/40/37/32EX72x, KDL-46/40/32EX52x, KDL-46/40/32CX52x, KDL-32EX42x B For KDL-26/24/22EX320 B For KDL-26EX321 2: Adjusting the viewing angle of the TV This TV can be adjusted within the angles as...
  • Page 11: 3: Connecting An Antenna (aerial)/set Top Box/recorder (e.g. Dvd Recorder)

    • Ensure that there are no objects in front of the TV. IR Sensor 3D Sync Transmitter (KDL-55/46/40/37/32EX72x only) Presence Sensor (except KDL-46/40/32EX520, KDL-40/32EX523) • Do not expose the Presence Sensor to direct sunlight or other strong light, as malfunction may occur.
  • Page 12: 5: Preventing The Tv From Toppling Over

    5: Preventing the TV from toppling over Install a wood screw (4 mm in diameter, not supplied) in the TV stand. Install a machine screw (M4 × 10, not supplied) into the screw hole of the TV. Tie the wood screw and the machine screw with a strong cord (not supplied).
  • Page 13: 7: Performing The Initial Set-up

    • “Full Scan” may not be available depending on your region/country. For a list of compatible cable providers, refer to the support web site: http://support.sony-europe.com/TV/ DVBC/ Programme Sorting: Changes the order of analogue channels stored in the TV. Press F/f to select the channel you want...
  • Page 14: Using Your Bravia Tv

    Using Your BRAVIA TV Watching the TV GUIDE • The number 5, N, PROG + and AUDIO buttons on the remote have a tactile dot. Use the tactile dots as a reference when operating the TV. Turn on the TV. Press 1 on the TV to turn on the TV.
  • Page 15 Parts and controls of the remote Use the supplied remote to control your TV. Basic remote operations are explained here. For details on all of the remote function, press i-MANUAL and see the built-in manual (i-Manual) (page 18). For KDL-55/46/40/37/32EX72x Rear of Remote Control 1 :/1 Press to turn the TV on and off from standby mode.
  • Page 16: Selecting Various Functions And Settings (home Menu)

    Selecting various functions and settings (Home Menu) You can select all the features from the Home menu. See page 17 for the Home menu map. 1, 3 Press HOME. Press F/f/G/g/ to select items. To select items in the Home menu (e.g., selecting “Settings”) 1 Press G/g to select “Settings”.
  • Page 17 Home menu map After pressing HOME on the remote, following icons are displayed as categories. The categories are available depending on your TV model, region, country and broadcasting conditions. Media Inputs Favourites/History Settings Widgets Applications Qriocity Internet Content Recommendations Recordings You can select a list of TV channels, or a programme guide.
  • Page 18: Displaying Operating Instructions (i-manual)

    Displaying Operating Instructions (i-Manual) Operating instructions are built into your BRAVIA TV and can be displayed on the screen. To learn more about your TV features, access your i-Manual with the touch of a button. Press i-MANUAL. Press F/f/G/g/ to select items. To select items in the i-Manual 1 Press F/f to select an item.
  • Page 19 Description of the i-Manual screen To use the bookmark The i-Manual has a bookmark function. Pages can be bookmarked with coloured buttons, according to the instructions at the bottom of the screen. To access your registered bookmarks, go to the top page of the i-Manual and select “Bookmarks”.
  • Page 20: Network Setup

    Network Setup When you connect this TV to the Internet, you can enjoy multiple functions: displaying a photograph that shows its location on the map, enjoying Internet video, etc. For details on the functions, refer to the i-Manual. • You will need to contract with an Internet service provider to connect to the Internet.
  • Page 21: Setting Up The Internet Connection

    Setting up the Internet connection Using the network feature you can connect the TV to the Internet. The set-up procedure differs depending on the type of network and LAN router. Before setting up the Internet connection, be sure to set up a LAN router. Check your wireless LAN environment using the following chart.
  • Page 22: If You Cannot Connect To The Internet

    Type 3: Unsecured network with any type of wireless LAN router To set up a wireless LAN, SSID (wireless network name) will be required. Press HOME, then select “Network” > “Network Set-up”. Select “Wireless Set-up”. Select “Scan”, then select a network from the list of scanned wireless networks.
  • Page 23: Additional Information

    Press 1 on the TV to turn it off, disconnect the AC power cord (mains lead), and inform your dealer or Sony service centre of how the indicator flashes (number of flashes). When the 1 (standby) indicator is not flashing, check the items in the tables as follows.
  • Page 24: Specifications

    Specifications System Panel system LCD (Liquid Crystal Display) Panel TV system Analogue: Depending on your country/area selection: B/G/H, D/K, L, I, M Digital: DVB-T2 (KDL-55EX723/46EX724/46EX723/46EX524/40EX724/40EX723/40EX524/ Colour/video system Analogue: PAL, PAL60 (only video input), SECAM, NTSC3.58, NTSC4.43 (only video input) Digital: MPEG-2 MP@ML/HL, H.264/MPEG-4 AVC MP/HP@L4 Channel coverage Analogue: VHF: E2–E12/UHF: E21–E69/CATV: S1–S20/HYPER: S21–S41 D/K: R1–R12, R21–R69/L: F2–F10, B–Q, F21–F69/I: UHF B21–B69/M: A2-A13, A14-A79...
  • Page 25 Model name KDL- 55EX72x Power in “Home”/ 113 W consumption “Standard” mode in “Shop”/ 177 W “Vivid” mode Average annual energy 165 kWh consumption* Standby power 0.25 W (15 W in software / EPG update consumption* mode) Display resolution 1,920 dots (horizontal) × 1,080 lines (vertical) Dimensions (Approx.) (w ×...
  • Page 26 Table-Top Stand 7.9 kg Supplied accessories See “Checking the accessories” (page 8). Optional accessories Wall-Mount Bracket: SU-WL500 3D Glasses: TDG-BR250/TDG-BR200/TDG-BR100/TDG-BR50 (KDL-32EX72x) USB Wireless LAN Adapter Operating temperature 0 ºC – 40 ºC Operating humidity 10% – 80% RH (non-condensing)
  • Page 27: Installing The Accessories (wall-mount Bracket)

    TV will be 6 cm. Use this space to route cables to the TV. Wall For product protection and safety reasons, Sony strongly recommends that installing of your TV be performed by Sony dealers or licensed contractors. Do not attempt to install it yourself.
  • Page 28 SU-WL500, SU-WL100 For KDL-55/46/40/37/32EX72x, KDL-46/40/32EX52x, KDL-46/40/32CX52x, KDL-32EX42x SU-WL500 Mounting Hook × Soft cloth • Attach the Mounting Hook using the four screws supplied with the Wall-Mount Bracket. • When attaching the Table-Top Stand again, be sure to fasten the screws (previously removed) to the original holes on the rear of the TV.
  • Page 29 SU-WL500 Screw location When installing the Mounting Hook on the SU-WL100 Hook location When installing the TV onto the Base Bracket. Hook location When installing the TV onto the Base Bracket. (Continued)
  • Page 30: Tv Installation Dimensions Table

    TV installation dimensions table 1 SU-WL500 Screen centre point 2 SU-WL100 Screen centre point Screen Display Model centre dimensions Name dimension KDL- 1 SU-WL500 55EX72x 126.9 76.9 46EX72x 107.8 66.0 12.0 46EX52x 107.8 66.0 12.0 46CX52x 112.2 68.2 40EX72x 94.3 58.6 15.7 40EX52x...
  • Page 31: Safety Information

    • Leave space around the TV set as shown below. • It is strongly recommended that you use a Sony wall-mount bracket in order to provide adequate air-circulation. Installed on the wall 30 cm 10 cm...
  • Page 32 Turn off the TV set and unplug the mains lead immediately if any of the following problems occur. Ask your dealer or Sony service centre to have it checked by qualified service personnel. When: – Mains lead is damaged.
  • Page 33 Keep this Instruction manual safe you’ll need it Television in the UK is going digital, bringing us all more. Please see overleaf to find out when your area switches to digital. Digital UK is the independent, non-profit organisation leading the process of digital TV switchover in the UK.
  • Page 34 If you are missing any channels, it may be that they are not available in your area, or that your aerial needs upgrading. If you have any questions, please contact Sony on 0844 8466555 or call Digital UK on 0845 6 50 50 50 or visit www.digitaluk.co.uk †Calls charged at BT rate of 3p per minute daytime and 1p per minute evenings and weekends.
  • Page 36 For useful information about Sony products 4-269-995-12(1) © 2011 Sony Corporation...
