- Page 1 FD Trinitron Colour Television Instruction Manual KV-28CL11B KV-29CL11B © 2003 by Sony Corporation 4-102-684-52...
-
Page 2: How To Replace The Fuse
Never use the plug without the fuse cover. If you should lose the fuse cover, please contact your nearest Sony service centre. How to replace the Fuse Open the fuse compartment with a flat blade screwdriver, and replace the fuse. -
Page 3: Table Of Contents
Introduction Thank you for choosing this Sony FD Trinitron Colour Television. Before operating the TV, please read this manual thoroughly and retain it for future reference. Table of Contents Safety Information Safety Information... 4 Overview Overview of the remote control... 5 Overview of the TV buttons ... -
Page 4: Safety Information
Safety Information This set is to operate on a 220-240V AC supply only. Take care not to connect too many appliances to the same power socket as this could result in fire or electric shock. Never push objects of any kind into the set as this could result in a fire or electric shock. -
Page 5: Overview
Overview of the remote control 1 To temporarily switch off the TV: Press to temporarily switch off the TV (the standby indicator on the TV lights up). Press again to switch on the TV from standby mode. To save energy we recommend switching off completely when the TV is not in use. -
Page 6: Overview Of The Tv Buttons
Overview of the TV buttons Push up the flap on the front of the TV to reveal the front control panel. Video Audio Input Input jack jacks Overview Standby indicator Selecting Auto Start Input source Up Button Headphones Volume control jack buttons On/Off switch... -
Page 7: Installation
Connecting the aerial and VCR For more details on VCR connection, please refer to the section “Connecting Optional Equipment” of this instruction manual on page 18. Note: Connecting cables are not supplied. Inserting batteries into the remote control Please ensure you insert the supplied batteries using the correct polarities. Always remember to dispose of used batteries in an environmentally friendly way. -
Page 8: First Time Operation
Switching On the TV and Automatically Tuning The first time you switch on your TV, a sequence of menu screens appear on the TV enabling you to: 1) choose the language of the menu screen, 2) choose the country in which you wish to operate the TV, 3) adjust the picture slant, 4) search and store all available channels (TV broadcasts) and 5) change the order in which the channels (TV broadcasts) appear on the screen. - Page 9 Do you want to start automatic tuning? Auto Tuning Programme: System: Channel: Searching... No channel found Please connect aerial Confirm Programme Sorting Programme: TVE2 Select channel: Exit: MENU Programme Sorting Programme: TVE2 Select new position: Exit: MENU Your TV is now ready for use. The Auto Tuning menu appears on the screen.
-
Page 10: Introducing And Using The Menu System
Introducing and Using the Menu System Your TV uses an on-screen menu system to guide you through the operations. Use the following buttons on the remote control to operate the menu system: Press the MENU button to switch the first level menu on. •... -
Page 11: Sound Adjustment
Level 1 Level 2 Picture Adjustment Mode: Personal Contrast Brightness Colour Sharpness Reset Sound Adjustment Sound Adjustment Mode: Personal Mode: Treble Treble Bass Bass Balance Balance Reset Reset Dual Sound: Mono Dual Sound: Detail Adjustment Detail Adjustment SOUND ADJUSTMENT The “Sound Adjustment” menu allows you to alter the sound settings. To do this: after selecting the item you want to alter, press adjust it and finally press OK to store the new adjustment. -
Page 12: Sleep Timer
Level 1 Level 2 Picture Adjustment Mode: Personal Contrast Brightness Colour Sharpness Reset Timer Sleep Timer: Picture Adjustment Mode: Personal Contrast Brightness Colour Sharpness Reset Picture Adjustment Mode: Personal Contrast Brightness Colour Sharpness Reset Picture Adjustment Mode: Personal Contrast Brightness Colour Sharpness Reset... -
Page 13: Programme Labels
Level 1 Level 2 Picture Adjustment Mode: Personal Contrast Brightness Colour Sharpness Reset Picture Adjustment Mode: Personal Contrast Brightness Colour Sharpness Reset Level 3 / Function PROGRAMME LABELS The “Programme Labels” option in the “Set Up” menu allows you to name a channel using up to five characters (letters or numbers). -
Page 14: Manual Programme Preset
Level 1 Picture Adjustment Mode: Personal Contrast Brightness Colour Sharpness Reset MANUAL PROGRAMME PRESET The “Manual Programme Preset” option in the “Set Up” menu allows you to: 1) Preset channels or a video input source one by one to the programme order of your choice. a) After selecting the ”Manual Programme Preset”... -
Page 15: Auto Format
Level 1 Level 2 Picture Adjustment Mode: Personal Contrast Brightness Colour Sharpness Reset Smart 14:9 Zoom Wide Picture Adjustment Mode: Personal Contrast Brightness Colour Sharpness Reset Level 3 / Function AUTO FORMAT (for KV-28CL11B only) The “Auto Format” option in the “Detail Set Up” menu allows you to automatically change the aspect ratio of the screen. -
Page 16: Av2 Output
Level 1 Picture Adjustment Mode: Personal Contrast Brightness Colour Sharpness Reset Picture Adjustment Mode: Personal Contrast Brightness Colour Sharpness Reset Picture Adjustment Mode: Personal Contrast Brightness Colour Sharpness Reset Menu System Level 2 Level 3 / Function AV2 OUTPUT The “AV2 Output” option in the “Detail Set Up” menu allows you to select the source to be output from the Scart connector from this Scart any signal coming from the TV or from... -
Page 17: Teletext
Teletext Teletext is an information service transmitted by most TV stations. The index page of the teletext service (usually page 100) gives you information on how to use the service. To operate teletext, use the remote control buttons as indicated below. Please ensure you use a channel (TV Broadcast) with a strong signal, otherwise teletext errors may occur. -
Page 18: Connecting Optional Equipment
**This option is only available depending on the country you have selected in the ‘Language/Country’ menu. Additional Information “PlayStation”* Decoder or through a VCR connected to this ). Repeat this option for each scrambling signal. Decoder * “PlayStation” is a product of Sony Computer Entertainment, Inc. * “PlayStation” is a trademark of Sony Computer... -
Page 19: Using Optional Equipment
Using Optional Equipment Connect your equipment to the designated TV socket, as indicated in the previous page. Switch on the connected equipment. To watch the picture of the connected equipment, press the input symbol appears on the screen. Symbol Input Signals Audio / video input signal through the scart connector C. -
Page 20: Specifications
Specifications TV system: Depending on your country selection: B/G/H, D/K, L, I Colour system: PAL, SECAM NTSC 3.58, 4.43 (only Video In) Channel Coverage: VHF: E2-E12 UHF: E21-E69 CATV: S1-S20 HYPER: S21-S41 D/K: R1-R12, R21-R69 L:F2-F10, B-Q, F21-F69 I:UHF B21-B69 Picture Tube: Flat Display FD Trinitron 28”... -
Page 21: Troubleshooting
• Using the menu system, display the “Set Up” menu. Then select the “Detail Set Up” option and set “AV2 Output” to “TV”. • Replace the batteries. • Contact your nearest Sony service centre. Never open the casing yourself. button on the front of the TV. - Page 22 Additional Information...
- Page 24 4-102-684-52 410268452 KV-28CL11B/29CL11B Sony Corporation Printed in Spain Recyclable...
