LCD Digital Colour TV
Operating Instructions
Before operating the TV, please read the "Safety
information" section of this manual.
Retain this manual for future reference.
For useful information about Sony products
2-894-287-12(1)
U
Advertisement
Table of Contents
Related Manuals for Sony Bravia KDL-32S2510
Summary of Contents for Sony Bravia KDL-32S2510
- Page 1 LCD Digital Colour TV KDL-46S2510 KDL-46S2530 KDL-40S2510 KDL-40S2530 KDL-32S2510 KDL-32S2520 KDL-32S2530 © 2006 Sony Corporation Operating Instructions Before operating the TV, please read the “Safety information” section of this manual. Retain this manual for future reference. For useful information about Sony products 2-894-287-12(1)
-
Page 2: Trademark Information
Never use the plug without the fuse cover. If you should lose the fuse cover, please contact your nearest Sony service station. How to replace the fuse Open the fuse compartment with a blade screwdriver, and replace the fuse. -
Page 3: Table Of Contents
Table of Contents Start-up Guide Safety information ...7 Precautions ...10 Overview of the remote ...11 Overview of the TV buttons and indicators ...12 Watching TV Watching TV...13 Checking the Digital Electronic Programme Guide (EPG) Using the Favourite list ...17 Viewing pictures from connected equipment ...18 Using MENU Functions Navigating through menus ...19 Picture menu ...20... -
Page 4: Start-Up Guide
Start-up Guide 1: Checking the accessories Remote RM-ED008 (1) Size AA batteries (R6 type) (2) Mains lead (Type C-6) (1) Coaxial cable (1) Cable holder (1) Support belt (1) and screws (2) To insert batteries into the remote Notes • Observe the correct polarity when inserting batteries. •... - Page 5 3: Bundling the cables 4: Preventing the TV from toppling over 5: Selecting the language and country/ region Connect the TV to your mains socket (220- 240V AC, 50Hz). Press 1 on the TV (top side). When you switch on the TV for the first time, the Language menu appears on the screen.
-
Page 6: Auto-Tuning The Tv
Press to select the language displayed on the menu screens, then press Press to select the country/region in which you will operate the TV, then press If the country/region in which you want to use the TV does not appear in the list, select “-” instead of a country/region. -
Page 7: Safety Information
Sony service centre to exchange it. • Do not use the supplied mains lead on any other equipment. • Use only an original Sony mains lead, not other brands. Mains socket • The TV set with a three-wire grounding... - Page 8 Wall-mount bracket SU-WL51. – KDL-32S2510/KDL-32S2520/KDL-32S2530: Wall-mount bracket SU-WL31. • It is strongly recommended that you use the official Sony wall-mount bracket to allow adequate air circulation and to avoid accumulated dust on the TV. • If the TV set is to be installed on a wall, have the installation carried out by qualified service personnel.
- Page 9 • Do not touch the mains lead and the TV set with wet hands. Doing so may cause an electric shock or damage to the TV set. Moisture and flammable objects • Do not place any objects on the TV set.
-
Page 10: Precautions
Precautions Viewing the TV • To view the TV comfortably, the recommended viewing position is from four to seven times the screen’s vertical length away from the TV set. • To obtain a clear picture, do not expose the screen to direct illumination or direct sunlight. -
Page 11: Overview Of The Remote
Overview of the remote The A/B, PROG + and number 5 buttons have tactile dots. Use the tactile dots as references when operating the TV. 1 "/1 – TV standby Switches the TV on and off from standby mode. 2 A/B – Dual Sound (page 23) 3 Coloured buttons Selects the options at the bottom of the Favourite and EPG digital menus. -
Page 12: Overview Of The Tv Buttons And Indicators
Overview of the TV buttons and indicators MENU Note Make sure that the TV is completely switched off before unplugging the mains lead. Unplugging the mains lead while the TV is turned on may cause the indicator to remain lit or may cause the TV to malfunction. (page 19) –... -
Page 13: Watching Tv
Watching TV Watching TV Press 1 on the TV (top side) to switch on the TV. When the TV is in standby mode (the 1 (standby) indicator on the TV (front) is red), press "/1 on the remote to switch on the TV. Press DIGITAL to switch to digital mode or ANALOG to switch to analogue mode. -
Page 14: Picture Freeze
To access Text Press /. Each time you press /, the display changes cyclically as follows: Text t Text over the TV picture (mix mode) t No Text (exit the Text service) To select a page, press the number buttons or PROG +/-. -
Page 15: Checking The Digital Electronic Programme Guide (Epg)
Checking the Digital Electronic Programme Guide (EPG) Digital Electronic Programme Guide (EPG) * Please note that this function may not be available in some countries. Turn off the EPG Move through the EPG Watch a current programme Sort the programme information by category –... - Page 16 Set a programme to be displayed automatically on the screen when it starts – Reminder Set the time and date of a programme you want to record – Manual timer REC Cancel a recording/reminder – Timer list You can also display the Digital Electronic Programme Guide (EPG) by selecting “Digital EPG” in the “MENU” (page 19). Do this Press to select the future programme you want to...
-
Page 17: Using The Favourite List
Using the Favourite list Favourite list * Please note that this function may not be available in some countries. Create your Favourite list for the first time A message appears asking if you want to add channels to the Favourite list Turn off the Favourite list Watch a channel Add or remove channels in the Favourite... -
Page 18: Viewing Pictures From Connected Equipment
Viewing pictures from connected equipment Switch on the connected equipment, then perform one of the following operation. For equipment connected to the scart sockets using a fully-wired 21-pin scart lead Start playback on the connected equipment. The picture from the connected equipment appears on the screen. -
Page 19: Using Menu Functions
Using MENU Functions Navigating through menus “MENU” allows you to enjoy various convenient features of this TV. You can easily select channels or external inputs with the remote. Also, settings for your TV can be changed easily using “MENU”. Menu Digital Favourites (only in areas with digital broadcasting) -
Page 20: Picture Menu
Picture menu Target Inputs Selects whether to apply settings made in the Picture menu to all inputs, or only to the input currently being watched. “All”: Applies settings to all inputs. “Viewing Only”: Applies settings only to the current input. Picture Mode Selects the picture mode. - Page 21 Sharpness Sharpens or softens the picture. Noise Reduction Reduces the picture noise (snowy picture) in a weak broadcast signal. “Auto”: Automatically reduces the picture noise. “High”/“Medium”/“Low”: Modifies the effect of the noise reduction. “Off”: Turns off the Noise Reduction feature. Advanced Settings Customizes the Picture function in more detail.
-
Page 22: Sound Menu
Sound menu Target Inputs Selects whether to apply settings made in the Sound menu to all inputs, or only to the input currently being watched. “All”: Applies settings to all inputs. “Viewing Only”: Applies settings only to the current input. Sound Mode Selects the sound mode. - Page 23 Dual Sound Selects the sound from the speaker for a stereo or bilingual broadcast. “Stereo”, “Mono”: For a stereo broadcast. “A”/“B”/“Mono”: For a bilingual broadcast, select “A” for sound channel 1, “B” for sound channel 2, or “Mono” for a mono channel, if available. If you select other equipment connected to the TV, set “Dual Sound”...
-
Page 24: Screen Menu
Screen menu Target Inputs Selects whether to apply settings made in the Screen menu to all inputs, or only to the input currently being watched. “All”: Applies settings to all inputs. “Viewing Only”: Applies settings only to the current input. Screen Format For details about the screen format, see “To change the screen mode manually to suit the broadcast”... -
Page 25: Set-Up Menu
Set-up menu Auto Start-up Starts the “first time operation menu” to select the language and country/region, and tune in all available digital and analogue channels. Usually, you do not need to do this operation because the language and country/region will have been selected and channels already tuned when the TV was first installed (page 5, 6). - Page 26 On Timer Sets the timer to turn on the TV. “Day”: Selects the day on which you want to activate the On Timer. “Time”: Sets the time to turn on the TV. “Duration”: Selects the time period after which the TV automatically switches to standby mode again.
-
Page 27: Pc Settings Menu
PC Settings menu Screen Format Selects a screen mode for displaying input from your PC. “Normal”: Displays the picture in its original size. “Full1”: Enlarges the picture to fill the display area, keeping its original horizontal- to-vertical aspect ratio. “Full2”: Enlarges the picture to fill the display area. Reset Resets the PC settings except “Screen Format”... -
Page 28: Analogue Set-Up Menu (Analogue Mode Only)
Analogue Set-up menu (Analogue mode only) 1 Digit Direct When “1 Digit Direct” is set to “On”, you can select an analogue channel using one preset number button (0 - 9) on the remote. Note When “1 Digit Direct” is set to “On”, you cannot select channel numbers 10 and above entering two digits using the remote. - Page 29 Manual Programme Before selecting “Label”/“AFT”/“Audio Filter”/“Skip”/“Decoder”, press PROG +/- Preset to select the programme number with the channel. You cannot select a programme number that is set to skip (page 30). Programme Presets programme channels manually. Press Press (if tuning a VCR, select channel 00), then press RETURN. Press Press press...
- Page 30 Skip Skips unused analogue channels when you press PROG +/- to select channels. (You can still select a skipped channel using the number buttons.) Decoder Views and records the scrambled channel selected when using a decoder connected directly to scart connector 1, or to scart connector 2 via a VCR.
-
Page 31: Digital Set-Up Menu
Digital Set-up menu Digital Tuning Displays the “Digital Tuning” menu. Digital Auto Tuning Tunes in all the available digital channels. Usually you do not need to do this operation because the channels are already tuned when the TV was first installed (page 6). However, this option allows you to repeat the process (e.g., to retune the TV after moving house, or to search for new channels that have been launched by broadcasters). - Page 32 “Software Download”: Enables the TV to automatically receive software updates, free through your existing aerial (when issued). Sony recommends that this option is set to “On” at all times. If you do not want your software to be updated, set this option to “Off”.
-
Page 33: Using Optional Equipment
Using Optional Equipment Connecting optional equipment You can connect a wide range of optional equipment to your TV. Connecting cables are not supplied. Connecting to the TV (side) S VHS/Hi8/DVC camcorder Headphones To connect Do this Conditional Access To use Pay Per View services. Module (CAM) A For details, refer to the instruction manual supplied with your CAM. - Page 34 Connecting to the TV (rear) Digital satellite receiver DVD player with component output DVD recorder Decoder Video game equipment DVD player Decoder To connect PC D Digital satellite receiver or DVD player E, F DVD player DVD player with component output Video game equipment, DVD player or decoder...
- Page 35 Using the Tools menu in PC input mode Press TOOLS to display the following options when viewing pictures input from the connected PC. Options Description Power Saving See page 26. Picture Mode See page 20. Sound Mode See page 22. Auto Adjustment See page 27.
-
Page 36: Additional Information
Additional Information Specifications Display Unit Power Requirements: 220–240 V AC, 50 Hz Screen Size: KDL-46S2510/KDL-46S2530: 46 inches (Approx. 116.9 cm measured diagonally) KDL-40S2510/KDL-40S2530: 40 inches (Approx. 101.6 cm measured diagonally) KDL-32S2510/KDL-32S2520/KDL-32S2530: 32 inches (Approx. 80.1 cm measured diagonally) Display Resolution: 1,366 dots (horizontal) ×... - Page 37 Sound Output 10 W + 10 W Supplied Accessories Refer to “1: Checking the accessories” on page 4. PC Input Signal Reference Chart Signals Horizontal (Pixel) Vertical (Line) SVGA 1024 1024 1024 WXGA 1280 1280 1360 • This TV’s PC input does not support Sync on Green or Composite Sync. •...
-
Page 38: Troubleshooting
For example, the indicator flashes for two seconds, stops flashing for one second, and flashes for two seconds. Press 1 on the TV (top side) to switch it off, disconnect the mains lead, and inform your dealer or Sony service centre of how the indicator flashes (duration and interval). When it is not flashing Check the items in the tables below. - Page 39 Sound Problem Cause/Remedy No sound, but good picture • Press 2 +/– or % (Mute). • Check that “Speaker” is set to “On” in the “Set-up” menu (page 26). Noisy sound • See the “Picture noise” causes/remedies on page 38. Channels Problem Cause/Remedy...
-
Page 40: Index
Index Numerics 1 Digit Direct 28 14:9 14 4:3 Default 24 4:3 14 Adv. Contrast Enhancer 21 Advanced Settings 21 Aerial, connecting 4 AFT 29 All Reset 26 Analogue Set-up menu 28 Audio Filter 29 Audio Language 32 Audio Type 32 Auto Adjustment 27 Auto Clock Set 14 Auto Format 24... - Page 41 Wide 14 Zoom 14...
