LCD
Digital Colour TV
Operating Instructions
KDL-52NX803 / 46NX703 / 40NX803 / 40NX703
4-180-179-11(1)
Setting Up
Watching TV
Additional Information

Advertisement

Table of Contents

   Related Manuals for Sony BRAVIA 4-180-179-11(1)

   Summary of Contents for Sony BRAVIA 4-180-179-11(1)

  • Page 1 Digital Colour TV Operating Instructions KDL-52NX803 / 46NX703 / 40NX803 / 40NX703 4-180-179-11(1) Setting Up Watching TV Additional Information...
  • Page 2: Trademark Information

    ™ trademarks of Sony Corporation and Sony Computer Entertainment Inc. Notice for Wireless Signal 1. Hereby, Sony, declares that this unit is in compliance with the essential requirements and other relevant provisions of Directive 1999/5/EC. To obtain the declaration of conformity (DoC) for R&TTE Directive, please access...
  • Page 3: Table Of Contents

    Table of Contents Checking the accessories ...3 Inserting batteries into the remote ...3 Setting Up Attaching the Table-Top Stand ...4 Connecting an antenna (aerial)/Set Top Box/recorder (e.g. DVD recorder) ...5 Preventing the TV from toppling over ...5 Bundling the cables...6 Performing the initial set-up ...6 Detaching the Table-Top Stand from the TV ...7 Watching TV...
  • Page 4: Setting Up

    Attaching the Table-Top Stand Refer to the supplied Table-Top Stand leaflet for proper attachment for some TV models. Place the TV set on the Table-Top Stand. Fix the TV to the Table-Top Stand according to the arrow marks guide the screw holes using the supplied screws.
  • Page 5: Connecting An Antenna (aerial)/set Top Box/recorder (e.g. Dvd Recorder)

    Connecting an antenna (aerial)/Set Top Box/ recorder (e.g. DVD recorder) Connecting a Set Top Box/recorder (e.g. DVD recorder) with SCART Set Top Box/recorder (e.g. DVD recorder) • Right Angle Type Universal SCART Lead is recommended for this connection. Connecting a Set Top Box/recorder (e.g.
  • Page 6: Bundling The Cables

    If no channel is found using “Quick Scan”, try “Full Scan” (though it may take some time). For a list of compatible cable providers, refer to the support web site: http://support.sony-europe.com/TV/ DVBC/ KDL-52/ 40NX803 KDL-46/ 40NX703...
  • Page 7: Detaching The Table-top Stand From The Tv

    Programme Sorting: Changes the order of analogue channels stored in the TV. Press F/f to select the channel you want to move to a new position, then press Press F/f to select the new position for the channel, then press •...
  • Page 8: Watching Tv

    Watching TV To watch programmes GUIDE OPTIONS HOME • The number 5, N, PROG + and AUDIO buttons on the remote have a tactile dot. Use the tactile dots as a reference when operating the TV. To utilise the TV’s features HOME button Press to display various operation and setting screens.
  • Page 9: To Use I-manual

    To use i-Manual Welcome to i-Manual “BRAVIA” TV Features Watching TV Introduces convenient features such as EPG Guide, Favourites, etc. Using the HOME Menu Customise your TV settings, etc. • Images and illustrations may differ from what is displayed on the screen. Operating instructions are built into your BRAVIA TV and can be displayed on the screen.
  • Page 10: Additional Information

    Press 1 on the TV to turn it off, disconnect the AC power cord (mains lead), and inform your dealer or Sony service centre of how the indicator flashes (number of flashes). When the 1 (standby) indicator is not flashing Check the items in the tables below.
  • Page 11: Specifications

    Specifications System Panel system LCD (Liquid Crystal Display) Panel TV system Analogue: Depending on your country/area selection: B/G/H, D/K, L, I Digital: DVB-T2/DVB-T/DVB-C Colour/video system Analogue: PAL, PAL60 (only video input), SECAM, NTSC3.58, NTSC4.43 (only video input) Digital: MPEG-2 MP@ML/HL, H.264/MPEG-4 AVC MP/HP@L4 Channel coverage Analogue: VHF: E2–E12/UHF: E21–E69/CATV: S1–S20/HYPER: S21–S41 D/K: R1–R12, R21–R69/L: F2–F10, B–Q, F21–F69/I: UHF B21–B69...
  • Page 12 Model name KDL- 52NX803 Optional accessories Wall-Mount Bracket: SU-WL700 TV stand: SU-52NX1 (KDL-52NX803) Specified standby power is reached after the TV finishes necessary internal processes. 4 hours a days and 365 days a year • To save power consumption – when you reduce backlight setting (the brightness of the screen), the power consumption reduce. –...
  • Page 13: Installing The Accessories (wall-mount Bracket)

    Installing the Accessories (Wall-Mount Bracket) To Customers: For product protection and safety reasons, Sony strongly recommends that installing of your TV be performed by Sony dealers or licensed contractors. Do not attempt to install it yourself. To Sony Dealers and Contractors: Provide full attention to safety during the installation, periodic maintenance and examination of this product.
  • Page 14: Tv Installation Dimensions Table

    Place the spacers (KDL-52/40NX803 only). 1 Remove the four screws, and be sure to store them in a safe place, keeping them away from children. 2 Place the four spacers (supplied). • When attaching the Table-Top Stand again, be sure to fasten the four screws (previously removed) to the original holes on the rear of the TV (KDL-52/40NX803 only).
  • Page 15: Safety Information

    • Leave space around the TV set as shown below. • It is strongly recommended that you use a Sony wall-mount bracket in order to provide adequate air-circulation. Installed on the wall 30 cm 10 cm...
  • Page 16: Precautions

    Turn off the TV set and unplug the mains lead immediately if any of the following problems occur. Ask your dealer or Sony service centre to have it checked by qualified service personnel. When: – Mains lead is damaged.
  • Page 17 Keep this Instruction manual safe you’ll need it Television in the UK is going digital, bringing us all more. Please see overleaf to find out when your area switches to digital. Digital UK is the independent, non-profit organisation leading the process of digital TV switchover in the UK.
  • Page 18 If you are missing any channels, it may be that they are not available in your area, or that your aerial needs upgrading. If you have any questions, please contact Sony on 08705 111 999 or call Digital UK on 0845 6 50 50 50 or visit www.digitaluk.co.uk †Calls charged at BT rate of 3p per minute daytime and 1p per minute evenings and weekends.
  • Page 20 European Comission. You can get more information in following link: http://ec.europa.eu/environment/ecolabel/ Sony gives a minimum of 2 years guarantee for this LCD TV and 7 years availability for replacement of electronic parts. For useful information about Sony products ©...
