Maintenance Manual
7
Note!
Replace the Special filter when needed or when the warning message "NOTIFY RESPONSIBLE! CLEAN SPE-
CIAL FILTER" is displayed. It can be vacuum cleaned up to four times.
Note!
Do not use water to clean the Special filter.
When remounting; position the Special filter (C) below the lint filter (B). Make sure the Special filter (C) is in center po-
sition when inserting the filters on the filter bracket.
Make sure the filters are in position and below the locking bracket. Tighten the nuts on the locking bracket, press the
locking bracket down at the same time as tightening the nuts.
If the filter (A) has been demounted; remount the filter (A).

3.3 Clean the water valve

At regular basis, check the water valve and filter.
Disconnect the power to the machine.
Disconnect the water supply to the heat pump.
Disassemble the water valve (A) and check that the hole is not blocked. Check the filter.
Check the drain for condensed water (B) and the drain for cooling water (C).
fig.8038A
Clean and remove any dirt or coating if necessary.
Remount the valve.
