Instructions on "Installing the Wall-Mount Bracket" are not supplied in the
form of a separate leaflet with this TV. These installation instructions are
included within this TV's instructions manual.
For useful information about Sony products
Printed in Spain
KDL-52Z4500
KDL-46Z4500
KDL-40Z4500
4-116-578-11(1)
K
© 2008 Sony Corporation
LCD Digital Colour TV
K
4-116-578-11(1)
Advertisement
Table of Contents
Related Manuals for Sony 4-116-578-11(1)
Summary of Contents for Sony 4-116-578-11(1)
- Page 1 Instructions on “Installing the Wall-Mount Bracket” are not supplied in the form of a separate leaflet with this TV. These installation instructions are included within this TV’s instructions manual. For useful information about Sony products Printed in Spain KDL-52Z4500 KDL-46Z4500...
-
Page 2: Notice For Customers In The United Kingdom
Interface are trademarks or registered trademarks of HDMI Licensing LLC. s “BRAVIA” and Corporation. s “XMB” and “xross media bar” are the trademarks of Sony Corporation and Sony Computer Entertainment Inc. ) will only work in are trademarks of Sony... -
Page 3: Table Of Contents
Table of Contents Start-up Guide Safety information ... 9 Precautions ... 11 Remote and TV Controls/Indicators ... 12 Watching TV Watching TV... 16 Using GUIDE Plus+™ System and the Digital Electronic Programme Guide (EPG) Using the Digital Favourite List Using Optional Equipment Connecting Chart ... -
Page 4: Start-Up Guide
Start-up Guide Before Use To check the accessories Mains lead (1) Remote RM-ED012 (1) Size AA batteries (R6 type) (2) Stand (1) and screws for stand (4) (KDL-46Z4500/KDL-40Z4500 only) To insert batteries into the remote Push and lift the cover to open. •... - Page 5 2: Connecting an aerial/Set Top Box/recorder (e.g. DVD recorder) Connecting a Set Top Box/recorder (e.g. DVD recorder) with SCART ( SMARTLINK ) Scart lead Set Top Box/recorder (e.g. DVD recorder) Connecting a Set Top Box/recorder (e.g. DVD recorder) with HDMI HDMI cable Set Top Box/recorder (e.g.
-
Page 6: Performing The Initial Set- Up
5: Performing the initial set- Connect the TV to your mains socket (220-240V AC, 50Hz). Press 1 on the TV. When you switch on the TV for the first time, the Language menu appears on the screen. Press F/f/G/g to select the language displayed on the menu screens, then press Language English... - Page 7 Scan” is not supported by your cable provider. For further information about supported cable providers, refer to support web site: http://support.sony-europe.com/TV/ DVBC/ Press f to select “Start”, then press The TV starts searching for channels. Do not press any buttons on the TV or remote.
- Page 8 Select language for GUIDE Plus+. This step will be skipped if any one of the following languages is selected in “5: Performing the initial set-up” step 3: “English”, “Deutsch”, “Español”, “Italiano”, “Français” or “Nederlands.” GUIDE Plus+ Data Download. The initial download may take some time, so do not press any buttons on the TV or remote while proceeding.
-
Page 9: Safety Information
Never cover the ventilation holes or insert anything in the cabinet. s Leave space around the TV set as shown below. s It is strongly recommended that you use a Sony wall-mount bracket in order to provide adequate air-circulation. Installed on the wall... - Page 10 If the following problems occur... Turn off the TV set and unplug the mains lead immediately if any of the following problems occur. Ask your dealer or Sony service centre to have it checked by qualified service personnel. When: –...
-
Page 11: Precautions
Precautions Viewing the TV s View the TV in moderate light, as viewing the TV in poor light or during long period of time, strains your eyes. s When using headphones, adjust the volume so as to avoid excessive levels, as hearing damage may result. LCD Screen s Although the LCD screen is made with high-precision technology and 99.99% or more of the pixels are effective,... -
Page 12: Remote And Tv Controls/Indicators
Remote and TV Controls/Indicators Remote and TV controls A button or touch sensors on the TV will work the same as those on the remote. * In the TV menu, these touch sensors will work as • The number 5, N, PROG + and AUDIO buttons on the remote have a tactile dot. - Page 13 Button Description (Info/ In digital mode: Displays details of the programme Text reveal) currently being viewed. In analogue mode: to display the current channel number and screen mode. Press again to display clock information. Press a third time to remove the display from the screen. In Analogue Text mode (page 17): Reveals hidden information (e.g.
- Page 14 • If you turn the TV off, Theatre Mode is also turned off. • “Control for HDMI” (BRAVIA Sync) is only available with the connected Sony equipment that has the BRAVIA Sync or BRAVIA Theatre Sync logo or is compatible with control for HDMI.
- Page 15 Indicators Indicator (Picture Off/Timer indicator) 2 1 (Standby indicator) 3 " (Power indicator) 4 Light Sensor 5 Remote control sensor • Make sure that the TV is completely turned off before unplugging the mains lead. Unplugging the mains lead while the TV is turned on may cause the indicator to remain lit or may cause the TV to malfunction. •...
-
Page 16: Watching Tv
Watching TV Watching TV Press 1 on the TV to switch on the TV. When the TV is in standby mode (the 1 (standby) indicator on the TV (front) is red), press TV "/1 on the remote to switch on the TV. Press DIGITAL to switch to digital mode or ANALOG to switch to analogue mode. - Page 17 To access Digital Text Many broadcasters provide a Digital Text service. Digital Text offers graphically rich contents, compared to Analogue Text. Select a digital channel which provides Digital Text, then press /. When a broadcaster provides a dedicated Digital Text channel, select this channel to access Digital Text.
-
Page 18: Using Guide Plus+™ System And The Digital Electronic Programme Guide (Epg)
Information panels • Image shown above varies depending on country/region. • Information panels is not Sony provided, adverts from Branding Partner. • The function of action bar varies with cursor location and when in settings. Press GUIDE. Perform the desired operation as shown in the following table or displayed on the screen. - Page 19 Set a programme to be displayed automatically on the screen when it starts – Reminder Menu bar Search a programme – Search Search your own keyword – My Choice Set a Profile and receive recommendations according to your preferences – My TV Delete and edit reminder –...
- Page 20 Configure the GUIDE Plus+ system according to your personal situation – Set-up Do this Highlight “Set-up” on menu bar. Press F/f for you to select below items you want to configure. “Personal Preferences”: You can change the on screen language, change reminder timing and set overnight download.
- Page 21 Previous Next 30 min View ** This function may not be available in some countries/regions. To switch the GUIDE (Sony Guide or GUIDE Plus+), see page 50. Watch a programme Turn off the Guide Sort the programme information by category –...
-
Page 22: Using The Digital Favourite List
Using the Digital Favourite List Homes Under the Hammer 10:30 - 11:00 Digital favourite list * This function may not be available in some countries/regions. Create your favourite list for the first time Watch a channel Turn off the favourite list Add or remove channels in the currently edited favourite list Remove all channels from the current... -
Page 23: Using Optional Equipment
Using Optional Equipment Connecting Chart You can connect a wide range of optional equipment to your TV. Connecting cables are not supplied. ( SMARTLINK ) COMPONENT IN DMPORT DC 5V 0.7A MAX PC IN (Continued) - Page 24 For PC video inputs, see page 55. • Be sure to use only an authorised HDMI cable bearing the HDMI logo.We recommend that you use a Sony HDMI cable (high speed type). • When connecting an audio system that is compatible with control for HDMI, be sure to also connect it to the DIGITAL AUDIO OUT (OPTICAL) socket.
- Page 25 • CAM is not supported in all countries. Please check with your authorised dealer. You can enjoy photo/music files stored in a Sony digital still camera or camcorder through a USB cable or USB storage device on your TV (page 27).
-
Page 26: Viewing Pictures From Connected Equipment
Viewing Pictures from Connected Equipment Switch on the connected equipment, then perform one of the following operation. For equipment connected to the scart sockets using a fully-wired 21-pin scart lead Start playback on the connected equipment. The picture from the connected equipment appears on the screen. -
Page 27: Playing Back Photo/Music Via Usb
“Audio Swap” from the Options menu. Playing Back Photo/Music via USB You can enjoy photo/music files stored in a Sony digital still camera or camcorder through a USB cable or USB storage media on your Connect a supported USB device to the Press HOME. - Page 28 – Do not remove the USB device. The data on the USB device may be damaged. • Sony will not be held liable for any damage to, or loss of, data on the recording media due to a malfunction of any connected devices or the TV.
- Page 29 • A map can be displayed in the case of photograph’s EXIF data includes a date information, and the associated longitude and latitude information (“Log files”) has been recorded using a Sony GPS unit. Follow the procedure described below. Connect the GPS unit to the USB port. Press HOME.
-
Page 30: Using Bravia Sync With Control For Hdmi
• Adjusts the volume (2 +/–) and mutes the sound (%) of a connected audio system. • You can operate the connected Sony equipment that has the BRAVIA Sync logo by the TV remote by pressing: – N/x/X/m/M to operate the connected equipment directly. -
Page 31: Operating Optional Equipment Using The Tv Remote
Displays the top menu of the TOP MENU BD/DVD disc. Programming the remote This remote is preset to operate Sony TVs, and most Sony Blu-ray disc players, DVD players, DVD recorders, and audio systems (Home Theatre, etc.). To control Blu-ray disc players, DVD players,... - Page 32 Note that the list may not include codes for all models of all brands. To return to normal TV operation Press the TV function button. Manufacturer’s codes DVD players Manufacturer SONY AIWA AKAI DENON GRUNDIG HITACHI KENWOOD LOEWE...
- Page 33 SAMSUNG 339 – 341, 345 SANYO 335, 336 SHARP THOMSON 319, 350, 365 TOSHIBA DAV Home Theatre Systems Manufacturer Code SONY (DAV) 401 – 404 AV receivers Manufacturer Code SONY 451 – 454 Digital terrestrial receivers Manufacturer Code SONY 501 – 504...
-
Page 34: Using Network Features
Using Network Features With this TV, you can enjoy contents stored on DLNA-compatible devices on the home network. Devices that store and provide contents, such as photo/music files, is called “server.” The TV receives the photo/music files from the server via the network, and you can enjoy them on the TV even in other rooms. - Page 35 Depending on the network device, the file format may be converted before transfer. In such cases, the file format resulting after conversion is used for playback. For details, see the instruction manual for the network device being used. Even files conforming to one of the file formats given above cannot be played in some cases.
-
Page 36: Checking The Network Connection
Checking the Network Connection Enter the respective (alphanumeric) values for your router. The items that need to be set may differ, depending on the Internet service provider or the router. For details, refer to the instruction manuals that have been provided by your Internet service provider or supplied with the router. - Page 37 If you cannot connect to your home network The TV can check if the server is being correctly recognised. Press HOME. Press G/g to select “Settings.” Press F/f to select “Network Settings”, then press Select “Server Diagnostics”, then press Select “Yes”, then press The server diagnostic starts.
-
Page 38: Using Menu Functions
Using MENU Functions Navigating through TV Home Menu (XMB™) The XMB™ (XrossMediaBar) is a menu of BRAVIA features and input sources displayed on the TV screen. The XMB™ is an easy way to select programming and adjust settings on your BRAVIA Press HOME. -
Page 39: Settings
Settings Picture Picture Mode Selects the picture mode except for PC input source. “Picture Mode” includes options best suited for video and photographs, respectively. The options that can be selected differ depending on the input source. Vivid Standard Cinema Photo-Vivid Photo-Standard For viewing photographs. - Page 40 MPEG Noise Reduces picture noise in MPEG-compressed videos. This is effective when viewing a DVD or digital broadcast. Reduction Advanced Settings Allows you to set “Picture” settings in more detail. These settings are not available when “Picture Mode” is set to “Vivid”(or “Photo-Vivid”). Adv.
- Page 41 • Be sure not to put anything over the sensor, as its function may be affected. See page 15 for the location of the light sensor. Logo Illumination Lights up and turns off the Sony logo on the front of the TV. Panel Key Auto Illumination For a stereo broadcast.
- Page 42 Turns off the “Film Mode” feature. Sets suitable image quality, depending on the input source, video data or photograph data when directly connecting Sony HDMI output-capable equipment that supports “Video-A” mode. Produces suitable image quality for moving pictures.
- Page 43 Timer Settings Sets the timer to turn on/off the TV. Sleep Timer On Timer Settings Clock Set Set-up Auto Start-up Starts the “first time operation menu” to select the language, country and location, and tune in all available digital and analogue channels. Usually, you do not need to do this operation because the language and country/region will have been selected and channels already tuned when the TV was first installed (page 6).
- Page 44 PC Settings Screen Format Reset Auto Adjustment Automatically adjusts the display position, phase and pitch of Phase Pitch Horizontal Shift Power Management AV Set-up AV Preset Selects a screen format for displaying input from your PC. Full 1 Enlarges the picture to fill the vertical display area, keeping its original horizontal-to-vertical aspect ratio.
- Page 45 AV2 Input Sets a signal to be input through the socket labelled AV2 on the rear of the TV. Auto S Video Composite AV2 Output Sets a signal to be output through the socket labelled AV2 on the rear of the TV. If you connect a VCR/ DVD recorder or other recording equipment to the equipment connected to other sockets of the TV.
-
Page 46: Analogue Set-Up
However, power consumption in standby mode is higher than usual. If the specific Sony equipment that is compatible with “Control for HDMI” is connected, this setting is applied to the connected equipment automatically when the “Control for HDMI” is set to “On”... - Page 47 Manual Programme Before selecting “Label/AFT/Audio Filter/LNA/Skip/Decoder”, press PROG +/– to select the programme number with the channel. You cannot select a programme Preset number that is set to “Skip” (page 44). System/Channel Presets programme channels manually. Label Audio Filter Press F/f to select the programme number you want to manually tune (if tuning a VCR/ DVD recorder, select channel 00), then press Press F/f to select “System”, then press...
-
Page 48: Digital Set-Up
Skip Decoder Confirm Digital Set-up Digital Tuning Digital Auto Tuning Programme Sorting Digital Manual Tuning Improves the picture quality for individual channels in the case of very weak broadcast signals (noisy picture). If you cannot see any improvement in the picture quality even if you set to “On”, set this option to “Off”... - Page 49 Subtitle Set-up Subtitle Setting Subtitle Language Audio Set-up Audio Type Audio Language Selects the language used for a programme. Some digital Audio Description Mixing Level* Dynamic Range Compensates for differences in the audio level between Optical Out * This option is only available when “Audio Description” is set to “On.” Radio Display Displays the screen wallpaper when you listen to a radio broadcast.
-
Page 50: Network Settings
The time is displayed according to the time difference set by “Time Zone.” You can switch GUIDE (Sony Guide or GUIDE Plus+). If you change Sony Guide to GUIDE Plus+ programme, see page 18. Condition that this feature is displayed is following: –... - Page 51 Server Display Displays the connected server list and allows you to select the server you want to display on the Home Menu. Settings Server Diagnostics Diagnoses whether the TV can connect to each server on the home network. Renderer Function Enables playback of photos or music on the TV through other control devices on the network, such as a digital still camera or mobile phone.
-
Page 52: Additional Information
Sufficient expertise is required for installing this product, especially to determine the strength of the wall for withstanding the TV’s weight. Be sure to entrust the attachment of this product to the wall to Sony dealers or licensed contractors and pay adequate attention to safety during the installation. Sony is not liable for any damage or injury caused by mishandling or improper installation. -
Page 53: Tv Installation Dimensions Table
TV installation dimensions table Screen centre point Model Name KDL-52Z4500 KDL-46Z4500 KDL-40Z4500 Figures in the above table may differ slightly depending on the installation. WARNING The wall that the TV will be installed on should be capable of supporting a weight of at least four times that of the TV. -
Page 54: Specifications
Specifications Model name System Panel system TV system Colour/video system Channel coverage Sound output Input/Output jacks Aerial (SMARTLINK) COMPONENT IN HDMI IN 1, 2, 3 PC IN DMPORT Power and others Power requirements Screen size (measured diagonally) Display resolution Power in “Home”/ consumption “Standard”... - Page 55 Model name Mass (Approx.) with Table-Top Stand without Table-Top Stand Supplied accessories Optional Wall-Mount accessories Bracket Colour Variation Unit * Specified standby power is reached after the TV finishes necessary internal processes. PC Input Signal Reference Chart for Resolution Signals Horizontal ×...
-
Page 56: Troubleshooting
Press 1 on the top edge of the TV to turn it off, disconnect the mains lead, and inform your dealer or Sony service centre of how the indicator flashes (number of flashes). When it is not flashing Check the items in the tables below. - Page 57 Condition There is a significant difference in the output volume level between DIGITAL MEDIA PORT input and TV or other equipment input. Connection Diagnostic Results “Connection successful.”does not appear. Home Network The server cannot be found, a list cannot be retrieved, and playback fails.
- Page 58 • Check that your equipment is “Control for HDMI” compatible equipment. • Check support web site for cable provide information. http://support.sony-europe.com/TV/DVBC/ • If any “Control for HDMI” compatible audio equipment is connected to the TV, you cannot select “Off” in this menu. If you want to change the audio output to the TV speaker, select “TV Speaker”...
- Page 59 Condition The speaker grille has come Explanation/Solution • To attach the speaker grille, first turn off the TV, then unplug the mains lead. Then follow the procedure below. Orient the speaker grille so that the location of the marks on the speaker grille and TV match, insert the protrusions on the speaker grille into the holes on the TV, and support gently.
