Summary of Contents for Opel COMBO

  • Page 1 Owner's Manual...

  • Page 3: Table Of Contents

    Contents Introduction ........2 In brief ..........6 Keys, doors and windows .... 21 Seats, restraints ......46 Storage ........71 Instruments and controls ..... 89 Lighting ........123 Climate control ......132 Driving and operating ....144 Vehicle care ....... 212 Service and maintenance ..

  • Page 4: Introduction

    Introduction Introduction...
  • Page 5 ● This Owner's Manual depicts left- vehicle’s identification plate and prices. Experienced mechanics hand drive vehicles. Operation is national registration documents. trained by Opel work according to similar for right-hand drive specific Opel instructions. vehicles. Introduction The customer literature pack should ●...
  • Page 6 We wish you many hours of Disregarding this information may pleasurable driving. endanger life. Your Opel Team 9 Warning Text marked 9 Warning provides information on risk of accident or injury. Disregarding this information may lead to injury.
  • Page 7 Introduction...

  • Page 8: In Brief

    In brief In brief Vehicle unlocking Tailgate Initial drive information After unlocking, press the tailgate Press c to unlock the vehicle. Open button and open the tailgate. the doors by pulling the handles. Radio remote control 3 22. Central locking system 3 25. Electronic key system 3 23.
  • Page 9 In brief Seat adjustment Backrests inclination Seat height Longitudinal adjustment Push the lever and adjust the Lever pumping motion inclination. Do not lean on backrest : seat higher when adjusting. Pull handle, slide seat, release down : seat lower handle. Try to move the seat back and forth to ensure that the seat is locked in place.
  • Page 10 In brief Head restraint adjustment Seat belt Mirror adjustment Interior mirror Pull out the seat belt and fasten in belt Pull the head restraint upwards or buckle. The seat belt must not be press catch and push it downwards. To adjust the mirror, move the mirror twisted and must fit close against the Head restraints 3 46.
  • Page 11 In brief Exterior mirrors Steering wheel adjustment Select the relevant exterior mirror by Unlock lever, adjust steering wheel, pushing the mirror button to the left or then engage lever and ensure it is right. Adjust respective mirror by the fully locked. Do not adjust steering four-way control.
  • Page 12 In brief Instrument panel overview...
  • Page 13 In brief Electric child locks ....28 Head-up display ....114 24 Electric parking brake ..162 10 Windscreen wiper and 25 Power button ....... 146 Unlocking tailgate ....32 washer, rear wiper and 26 Ignition switch ..... 145 Child safety system for washer .........
  • Page 14 In brief...
  • Page 15 In brief Exterior lighting Headlight flash and high beam Turn lights pull stalk : headlight flash lever up : right turn light AUTO : automatic light control push stalk : high beam lever down : left turn light switches automatically between daytime running High beam 3 124.
  • Page 16 In brief Hazard warning flashers Horn Washer and wiper systems Windscreen wiper Operated by pressing ¨. Press j. Hazard warning flashers 3 126. : fast : slow INT : interval wiping OFF : off For single wipe when the wiper is off, press stalk down to position 1x.
  • Page 17 In brief Windscreen washer Rear window wiper Rear window washer Pull stalk. Turn outer cap to activate the rear Push stalk. window wiper: Windscreen washer system 3 91. Washer fluid is sprayed on the rear OFF : off window and the wiper wipes a few Washer fluid 3 217.
  • Page 18 In brief Climate control Heated exterior mirrors Demisting and defrosting the windows Heated rear window Heating and ventilation system, air conditioning system Depending on the version, heating is operated by pressing e or d. The heating is operated by pressing Heating works with the engine running and is switched off ●...
  • Page 19 In brief Note Electronic climate control system ● Switch on heated If the settings for demisting and windscreen , if available. defrosting are selected, an ● To return to previous mode, Autostop may be inhibited. press h again. If the settings for demisting and Note defrosting are selected while the If V is pressed while the engine is...
  • Page 20 In brief Transmission Automatic transmission Starting off Manual transmission Check before starting off ● tyre pressure 3 232 and condition 3 265 ● engine oil level and fluid levels 3 215 ● all windows, mirrors, exterior lighting and number plates are free from dirt, snow and ice and are operational ●...
  • Page 21 In brief Starting the engine Diesel engine starts after control Start power button indicator ! for preheating Ignition switch extinguishes. Starting the engine 3 148. ● manual transmission: operate clutch and brake pedal ● turn key to position 1 ● automatic transmission: operate ●...
  • Page 22 In brief Stop-start system Parking button. Turn the steering wheel until the steering wheel lock is 9 Warning felt to engage. ● Do not park the vehicle on an ● Lock the vehicle with e on the easily ignitable surface. The radio remote control.

  • Page 23: Keys, Doors And Windows

    Keys, doors and windows Keys, doors and Keys, locks Child surveillance mirror .... 40 Rear view display ...... 40 windows Keys Windows ........41 Windscreen ....... 41 Power windows ......41 Caution Rear windows ......43 Keys, locks ........21 Heated rear window ....

  • Page 24: Radio Remote Control

    Keys, doors and windows Key with foldaway key section Radio remote control Depending on the version, the radio remote control enables a operation of the following functions: ● central locking system 3 25 ● anti-theft locking system 3 35 ● anti-theft alarm system 3 35 ●...

  • Page 25: Electronic Key System

    Keys, doors and windows 3. Replace battery with a battery of Electronic key system the same type. Pay attention to the installation position. 4. Clip the back cover in place. Fault Batteries do not belong in household If the central locking system cannot waste.
  • Page 26 Keys, doors and windows Depending on the version, the 3. Replace battery with a battery of electronic key system enables a the same type. Pay attention to keyless operation of the following the installation position. functions: 4. Clip the cover in place. ●...

  • Page 27: Central Locking System

    Keys, doors and windows Central locking system Graphic Info Display: Switch on Unlocking mode can be set. Two settings are selectable: ignition. Press * more than 2 Unlocks and locks doors, load seconds. An audible signal is given ● All doors and load compartment compartment and fuel filler flap.
  • Page 28 Keys, doors and windows Press N. Unlocking of the rear door. If the vehicle is equipped with a tailgate, press If the driver's door is not closed the tailgate button. properly, the central locking system ● Only the front doors and the fuel will not work.
  • Page 29 Keys, doors and windows Press with a finger or thumb on one vehicle is equipped with electronic Operation with the key in case of of the door handles (at the markings) key system, the fuel filler flap is locked a central locking system fault or press the tailgate button.

  • Page 30: Automatic Locking

    Keys, doors and windows By switching on the ignition, the anti- If one of the doors or the tailgate is Automatic relock after unlocking theft locking system is deactivated. open, the automatic central locking This feature automatically locks all does not take place. This is signalled doors, load compartment and fuel Manual locking by the sound of the locks rebounding,...
  • Page 31 Keys, doors and windows Mechanical child locks Electric child locks Remotely operated system to prevent opening of the rear doors via the interior door handles and the use of the rear power windows. Switching on Press R. The indicator lamp in the button comes on, accompanied by a confirmation message.

  • Page 32: Doors

    Keys, doors and windows Doors Caution Sliding door Ensure the sliding side door is fully closed and secure before driving Opening the vehicle. Caution To avoid damage, do not attempt to operate the sliding side door when the fuel filler flap is open. To open from inside push the handle and slide the door towards the rear 9 Danger...

  • Page 33: Rear Doors

    Keys, doors and windows Rear doors 9 Warning Unlock the rear doors with the remote control or by turning the key in the rear The rear lights may be obscured if door lock cylinder. the rear doors are open and the vehicle is parked on the roadside.

  • Page 34: Load Compartment

    Keys, doors and windows need to be transported. Open the left- 9 Warning Caution hand followed by the right-hand rear door, then close the left-hand rear Ensure extended opening doors Always make sure that the load in door and lock it. are secured when fully opened.
  • Page 35 Keys, doors and windows Closing Depending on the version, press ' to unlock the tailgate. With the electronic key outside the vehicle and within a range of approx. Use the interior handle. one metre of the tailgate, press the After unlocking, press the middle Do not push the middle tailgate button left tailgate button to lock the vehicle.
  • Page 36 Keys, doors and windows Emergency tailgate opening from Opening smelled, could enter the vehicle. inside the vehicle This can cause unconsciousness and even death. Caution Before opening the tailgate, check overhead obstructions, e.g. a garage door, to avoid damage to the tailgate.

  • Page 37: Vehicle Security

    Keys, doors and windows Vehicle security Electronic key: Press twice with a load compartment is self- finger or thumb on one of the door activated 45 seconds after handles (at the markings) within five locking the vehicle by pressing e. Anti-theft locking system seconds ●...
  • Page 38 Keys, doors and windows Note 1. Switch of ignition. Changes to the vehicle interior such 2. Press U within the next 10 as the use of seat covers and open seconds until the LED of the windows, could impair the function button illuminates constantly.

  • Page 39: Immobiliser

    Keys, doors and windows Note deactivated as follows: switch the Immobiliser If the vehicle is unlocked and no door ignition on then off, then disconnect The system is part of the ignition is opened, the vehicle is the vehicle's battery within 15 s. switch and checks whether the automatically relocked after 30 vehicle is allowed to be started with...

  • Page 40: Exterior Mirrors

    Keys, doors and windows Exterior mirrors Folding mirrors Convex shape The shape of the mirror makes objects appear smaller, which will affect the ability to estimate distances. Side blind spot alert 3 194. Electric adjustment Select the relevant exterior mirror by turning the control to left C or right For pedestrian safety, the exterior D mirror symbol .

  • Page 41: Heated Mirrors

    Keys, doors and windows Interior mirrors Electric folding The function can be deactivated in the vehicle personalisation 3 118. Manual anti-dazzle Heated mirrors Pull the mirror button C rearwards. Both exterior mirrors will fold. Pull the mirror button rearwards again To reduce dazzle, adjust the lever on to return both exterior mirrors to their the underside of the mirror housing.

  • Page 42: Automatic Anti-Dazzle

    Keys, doors and windows Automatic anti-dazzle Child surveillance mirror Rear view display Dazzle from following vehicles is A child surveillance mirror allows to The rear view display shows standard automatically reduced, when driving observe the rear seats. The mirror rear view. This view is displayed by in the dark.

  • Page 43: Windows

    ● passenger side view 3 195 assistance systems, it is very important that any windscreen replacement is performed accurately according to Opel specifications. Otherwise, these systems may not work properly and there is a risk of unexpected behaviour and / or messages from...
  • Page 44 Keys, doors and windows Safety function Child safety system for rear windows This function depends upon version. If the window glass encounters resistance above the middle of the window during automatic closing, it is immediately stopped and opened again. Override safety function In the event of closing difficulties due to frost or the like, switch on the ignition, then pull the switch to the first...

  • Page 45: Rear Windows

    Keys, doors and windows Initialising the power windows Rear windows If the windows cannot be closed automatically (e.g. after disconnecting the vehicle battery), a warning message is displayed in the Driver Information Centre. Vehicle messages 3 117. Activate the window electronics as follows: 1.

  • Page 46: Heated Windscreen

    Keys, doors and windows This function heats the windscreen Pressing , again switches off the along its bottom and along the driver's heating operation. LED in button is side of the windscreen. extinguished. Thus, the function allows a fast Sun visors detaching of the windscreen wiper blades if they are frozen to the The sun visors can be folded down or...

  • Page 47: Roof

    Keys, doors and windows Roof To reduce sunlight at the second row seats, pull the blind upwards using the grip and engage it at the top of the Glass panel door frame. Sunblind Press N at the rear: the sunblind is opened as long as the switch is operated.

  • Page 48: Seats, Restraints

    Seats, restraints Seats, restraints Head restraints Adjustment Head restraints on front seats Position Head restraints ......46 9 Warning Front seats ........47 Seat position ......47 Only drive with the head restraint Seat adjustment ......48 set to the proper position. Seat folding .......

  • Page 49: Front Seats

    Seats, restraints Front seats Head restraints on rear seats Seat position 9 Warning Only drive with the seat correctly adjusted. 9 Warning Never adjust seats while driving as ● Sit with buttocks as far back they could move uncontrollably. against the backrest as possible. Height adjustment Adjust the distance between the Pull the head restraint upwards or...

  • Page 50: Seat Adjustment

    Seats, restraints ● Sit with shoulders as far back Seat adjustment against the backrest as possible. Drive only with engaged seats and Set the backrest rake so that it is backrests. possible to easily reach the steering wheel with arms slightly Longitudinal adjustment bent.

  • Page 51: Seat Folding

    Seats, restraints Push the lever, adjust inclination and Lumbar support Push head restraints down or remove release the lever. Do not lean on it before folding backrest 3 46. backrest when adjusting. Depending on version, remove the armrest 3 51. Seat height Turn the handwheel to suit personal requirements.
  • Page 52 Seats, restraints Folding bench seat front Fold down the outer backrest by To restore the seat cushion to the pulling the loop. Swing the backrest original position, push the lever and passenger side forwards until the seat is lowered on lower the seat cushion till it is the vehicle floor.

  • Page 53: Armrest

    Seats, restraints Armrest To remove the armrest fold it up then Seat heating is operational when push and turn it to the position shown engine is running and during an in the picture. Then pull off the Autostop. armrest from the backrest. Stop-start system 3 149.

  • Page 54: Rear Seats

    Seats, restraints Rear seats 4. Depending on version, fold down the centre backrest by pulling the loop. Second row seats Depending on the equipment, the rear seat backrest is divided into two or three parts. All parts can be folded down.

  • Page 55: Third Row Seats

    Seats, restraints folded with considerable power. Third row seats Risk of injury, particularly to children. 9 Warning Ensure that nothing is attached to the rear seats or located on the When rear seats or backrests are seat cushion. being adjusted or folded, keep hands and feet away from the moving area.
  • Page 56 Seats, restraints 2. Pull the lever and fold down the 4. Secure the folded seat in the 9 Warning backrest onto the seat cushion. upright position by attaching the strap to one of the pillars of the Always make sure that the load in head restraint in front of the folded the vehicle is securely stowed.
  • Page 57 Seats, restraints Installing the seats Longitudinal seat adjustment 3. Pull the loop to disengage the locks and remove the seat 1. Pull the loop and attach the seat Pull the handle, slide the seat, then assembly from the floor anchor assembly front supports to the release the handle.

  • Page 58: Seat Belts

    Seats, restraints Seat belts Seat belts are designed to be used by Belt pretensioners only one person at a time. In the event of a head-on, rear-end or Child restraint system 3 65. side-on collision of a certain severity, Periodically check all parts of the belt the front and rear seat belts are system for damage, soiling and tightened.

  • Page 59: Three-Point Seat Belt

    Seats, restraints modifications to belt pretensioner Unfasten components as this will invalidate the operating permit of your vehicle. Three-point seat belt Fasten Loose or bulky clothing prevents the belt from fitting snugly. Do not place To release belt, press red button on objects such as handbags or mobile belt buckle.
  • Page 60 Seats, restraints Insert lower latch plate into left-hand 9 Warning buckle (1) at the centre seat. Guide the upper latch plate with the belt over The lap belt must be positioned as the lap area and the shoulder (do not low as possible across the pelvis twist) and insert it into right-hand to prevent pressure on the...

  • Page 61: Airbag System

    Seats, restraints Airbag system Control indicator v for airbag systems airbag sensing and diagnostic 3 103. module, steering wheel, instrument panel, inner door seals The airbag system consists of a Child restraint systems on front including the speakers, any of the number of individual systems passenger seat with airbag airbag modules, ceiling or pillar...
  • Page 62 Seats, restraints geschützt ist, da dies den TOD oder NL: Gebruik NOOIT een achterwaarts PT: NUNCA use um sistema de SCHWERE VERLETZUNGEN DES gericht kinderzitje op een stoel met retenção para crianças voltado para KINDES zur Folge haben kann. een ACTIEVE AIRBAG ervoor, om trás num banco protegido com um DODELIJK of ERNSTIG LETSEL van AIRBAG ACTIVO na frente do...
  • Page 63 Seats, restraints TR: Arkaya bakan bir çocuk emniyet AKTIVNO ČELNO ZRAČNO acest lucru poate duce la DECESUL sistemini KESİNLİKLE önünde bir BLAZINO, saj pri tem obstaja sau VĂTĂMAREA GRAVĂ a AKTİF HAVA YASTIĞI ile nevarnost RESNIH ali SMRTNIH COPILULUI. korunmakta olan bir koltukta POŠKODB za OTROKA.

  • Page 64: Front Airbag System

    Seats, restraints ET: ÄRGE kasutage tahapoole Front airbag system 9 Warning suunatud lapseturvaistet istmel, mille The front airbag system consists of ees on AKTIIVSE TURVAPADJAGA one airbag in the steering wheel and Optimum protection is only kaitstud iste, sest see võib one in the roof on the front passenger provided when the seat is in the põhjustada LAPSE SURMA või...

  • Page 65: Curtain Airbag System

    Seats, restraints The side airbag system consists of an 9 Warning airbag in each front seat backrest. This can be identified by the word Keep the area in which the airbag AIRBAG. inflates clear of obstructions. The side airbag system is triggered in the event of a side impact of a certain Note severity.

  • Page 66: Airbag Deactivation

    Seats, restraints Airbag deactivation Use the ignition key to choose the position: The front passenger airbag system OFF* : front passenger airbag is must be deactivated for child restraint deactivated and will not system on the passenger seat inflate in the event of a according to the instructions in the collision, control indicator table 3 68.

  • Page 67: Child Restraints

    Seats, restraints Child restraints Consult a workshop immediately if Before fastening a child seat adjust neither of the two control indicators the head restraint 3 46. are illuminated. Child restraint systems When a child restraint system is being In the event of a fault a warning used, pay attention to the following message is displayed in the Driver usage and installation instructions...
  • Page 68 Seats, restraints ISOFIX brackets All i-size child restraint systems can be used on any vehicle seat suitable for i-size, i-size table 3 68. Either a Top-tether strap or a support leg must be used in addition to the ISOFIX mounting brackets. In addition to the ISOFIX mounting i-size child seats and vehicle seats brackets, fasten the Top-tether strap...
  • Page 69 Seats, restraints child's backbone, which is still very Ensure that the mounting location of weak, is under less strain in the event the child restraint system within the of an accident. vehicle is correct, see following tables. Suitable are child restraint systems that comply with valid UN ECE Allow children to enter and exit the regulations.

  • Page 70: Child Restraint Installation Locations

    Seats, restraints Child restraint installation locations Permissible options for fastening a child restraint system with a three-point seat belt On front passenger seat On outboard On centre seat seats in the in the second On seats in Weight class activated airbag deactivated airbag second row the third row Group 0, Group 0+: up to 13 kg X...
  • Page 71 Seats, restraints Permissible options for fitting an ISOFIX child restraint system with ISOFIX brackets On the seats in the second On the seats in the Weight class Size class Fixture On front passenger seat third row Group 0: up to 10 kg G ISO/L2 ISO/L1 ISO/R1...
  • Page 72 Seats, restraints ISOFIX size class and seat device A – ISO/F3 : forward-facing child restraint system for children of maximum size in the weight class 9 to 18 kg B – ISO/F2 : forward-facing child restraint system for smaller children in the weight class 9 to 18 kg B1 –...

  • Page 73: Storage

    Storage Storage Storage compartments The glovebox should be closed whilst driving. Cupholders 9 Warning Storage compartments ....71 Front cupholder Glovebox ........71 Do not store heavy or sharp Cupholders ........ 71 objects in the storage Front storage ......72 compartments.

  • Page 74: Front Storage

    Storage Additional cup holders may be Front storage located in the foldaway tables on the backrests of the front seats. Fold up the table. Do not place any hard or heavy objects on the table. Cupholders may be located in the centre console.

  • Page 75: Overhead Console

    Storage Folding the centre seatback Overhead console A storage compartment is located above the Instrument cluster. The front centre passenger seat Store only lightweight items such as backrest has a document tray. paperwork or maps. Seat folding 3 49. 9 Warning When the front centre passenger seat is in the folded position, the front passenger airbag system...

  • Page 76: Underseat Storage

    Storage The separation of the four Underseat storage compartments can be taken out. Underseat drawer The maximum permitted load is 6 kg. 9 Warning Secure objects to prevent them from falling out and causing injury. Pull handle to open. Close whilst driving. The maximum permitted load is 10 kg.

  • Page 77: Centre Console Storage

    Storage Storage box Centre console storage Vehicle tools may be located in the stowage compartments underneath There may be a storage box under the A storage box may be located in the the front seats 3 230. centre bench seat. Lift up the seat centre console.

  • Page 78: Load Compartment

    Storage Load compartment Depending on version, there are two Opening the ladder flap stowage compartments in the rear footwell. Depending on version, the load compartment area can be increased by folding up or removing the third row seats. The seat backrests of the second row can be folded forward separately.

  • Page 79: Load Compartment Cover

    Storage Closing the ladder flap 1. Check that the support bar is properly locked. 2. Lower the ladder flap. 3. Fix the spring clip in its retainer. Load compartment cover Rear luggage cover Do not place any objects on the cover. 3.
  • Page 80 Storage Opening the cover Removing the cover Stowing in the load compartment Remove load compartment cover Open the load compartment cover. If the load compartment cover is not from side brackets. Guide the cover used, stow it in the load compartment. Compress the load compartment until it is fully rolled up.
  • Page 81 Storage Rear parcel shelf Lifting the rear parcel shelf Stowing in the load compartment Do not place any excessively heavy or sharp-edged objects on the rear parcel shelf. The maximum load permissible is 25 kg. With high loads install the safety net behind the rear seats 3 81.

  • Page 82: Lashing Eyes

    Storage Lashing eyes Lashing eyes may be located on the There may be a flap in the partition vehicle floor and / or in the sidewall. behind the passenger seat which can The number and location of the be removed to accommodate long lashing eyes may vary depending on objects.

  • Page 83: Safety Net

    Storage Turn the locking device upwards. 2. Attach the four snap hooks of the 5. Pass the strap of the cover around Put the hinges of the flap in their cover on the corresponding the head restraint. Tension the housing, lift the flap and close the lashing eye.
  • Page 84 Storage Installation Behind the front seats Behind the rear seats ● Attach the hooks of safety net straps in the lashing eyes behind ● There are installation openings the rear seats. on both sides in the roof frame ● There are installation openings above the front seats.

  • Page 85: Load Compartment Grille

    Storage Load compartment grille The partition can be placed behind the front or rear seats. ● Wind one strap around the bar located under the front driver seat cushion. The other one wind Depending on version a partition There is a flap in the partition which around the bar of the passenger protects the driver and passengers can be opened to accommodate long...
  • Page 86 Storage Moving the partition 3. Move the partition and lock the 2. Release the locking device of the four locking devices on the top flap and open the flap. 1. Release the four locking devices and the bottom. The red indicators on the top and the bottom of the are no longer visible.
  • Page 87 Storage Closing the flap 1. Fix the rod in the bracket. 1. Attach the four snap hooks of the 4. Pass the strap of the cover around cover on the corresponding the head restraint. Tension the lashing eye. strap by pulling at the loose end. 2.

  • Page 88: Warning Triangle

    Storage Roof rack system side pass one strap on each head First aid kit restraint. Roof rack With fitted protective cover the maximum load on each of the folded For safety reasons and to avoid backrests is 100 kg. damage to the roof, the vehicle approved roof rack system is Warning triangle recommended.

  • Page 89: Loading Information

    Storage Loading information Mounting points are located at the ● Do not place any objects on the bottom of the roof railing. rear luggage cover or the instrument panel, and do not Fasten the roof rack according to the cover the sensor on top of the installation instructions delivered with instrument panel.
  • Page 90 Storage To calculate the payload, enter ● 80 kg for vehicles with roof the data for your vehicle in the railing weights table at the front of this ● 100 kg for vehicles without manual. roof railing and with two roof The EC kerb weight includes racks weights for the driver (68 kg),...

  • Page 91: Instruments And Controls

    Instruments and controls Instruments and Engine oil level monitor ... 101 Exterior light ......109 Service display ......102 High beam ....... 109 controls Control indicators ....102 Low beam ........ 109 Turn lights ........ 103 High beam assist ..... 109 Seat belt reminder ....

  • Page 92: Controls

    Instruments and controls Controls Steering wheel controls Heated steering wheel Steering wheel adjustment Cruise control and speed limiter are Activate heating by pressing *. operated via the controls on the left Activation is indicated by the LED in side of the steering wheel. the button.

  • Page 93: Horn

    Instruments and controls Horn Windscreen wiper and To activate interval wiping mode the next time ignition is switched on, washer press the lever downwards to position OFF and back to INT. Windscreen wiper with adjustable wiper interval Adjustable wiper interval Press j.
  • Page 94 Instruments and controls Windscreen wiper with rain sensor switched on, press the lever downwards to position OFF and back to AUTO. For a single wipe when the windscreen wiper is off, press the lever downwards to position 1x. Do not use if the windscreen is frozen. Switch off in car washes.

  • Page 95: Rear Window Wiper And Washer

    Instruments and controls Pull lever. Washer fluid is sprayed Switch off in car washes. The rear window washer system is onto the windscreen and the wiper deactivated when the fluid level is The rear window wiper comes on wipes a few times. low.

  • Page 96: Clock

    Instruments and controls A 12 V power outlet is located behind 9 Warning the storage cover. Push cover upwards to open. The road surface may already be Depending on the version, the 12 V icy even though the display power outlet may be freely indicates a few degrees above accessible.

  • Page 97: Inductive Charging

    Instruments and controls Do not connect any current-delivering A further USB port may be located in accessories, e.g. electrical charging the rear console. devices or batteries. The USB ports are prepared for Do not damage the outlet by using charging external devices and unsuitable plugs.

  • Page 98: Cigarette Lighter

    Instruments and controls To charge a mobile device: Cigarette lighter 9 Warning 1. Remove all objects from the charging device. Remove any metal objects from 2. Place the mobile device with the the charging device before charging a mobile device, as these display facing upwards on the charging device in the storage.

  • Page 99: Ashtrays

    Instruments and controls Warning lights, gauges Ashtrays and indicators Caution Instrument cluster To be used only for ash and not for Depending on the version, the Driver combustible rubbish. Information Centre may vary. A portable ashtray can be placed in the cupholders.
  • Page 100 Instruments and controls...

  • Page 101: Speedometer

    Instruments and controls Overview Electronic Stability Control Rear fog light 3 109 ø and Traction Control system Turn signal 3 103 Rain sensor 3 109 < 3 107 Side blind spot alert 3 110 Seat belt reminder 3 103 Preheating 3 107 Cruise control 3 109 Airbag and belt tensioners Exhaust filter 3 107...

  • Page 102: Odometer

    Instruments and controls Odometer Trip odometer Tachometer The total recorded distance is displayed in km. Driver Information Centre The recorded distance since the last Displays the engine speed. reset is displayed in the Driver Drive in a low engine speed range for Information Centre.

  • Page 103: Fuel Gauge

    Instruments and controls Fuel gauge Engine coolant temperature Caution gauge If engine coolant temperature is too high, stop vehicle, switch off engine. Danger to engine. Check coolant level. Engine oil level monitor The state of the engine oil level is displayed in the Driver Information Centre for a few seconds following the service information after switching...

  • Page 104: Service Display

    Instruments and controls Service display Overdued service is indicated by a Retrieving service information message in the Driver Information The service system informs when to Centre which indicates the overdued change the engine oil and filter or a distance. < flashes and then lights up vehicle service is required.

  • Page 105: Turn Lights

    Instruments and controls ignition is switched on, most control Seat belt reminder cluster and the symbols in the indicators will illuminate briefly as a roof console illuminate until seat X illuminates or flashes in the functionality test. belt is fastened. instrument cluster.

  • Page 106: Airbag Deactivation

    Instruments and controls workshop. The airbags and belt Airbag deactivation Illuminates when the engine is pretensioners may fail to trigger in the running event of an accident. Stop, switch off engine. Vehicle Deployment of the belt pretensioners battery is not charging. Engine or airbags is indicated by continuous cooling may be interrupted.

  • Page 107: Service Vehicle Soon

    Instruments and controls Flashes when the engine is Illuminates together with other control 9 Warning indicators, accompanied by a warning running chime and a corresponding message Stop. Do not continue your Fault that could lead to catalytic in the Driver Information Centre. journey.

  • Page 108: Electric Parking Brake Fault

    Instruments and controls Antilock brake system Iluminates green 9 Warning (ABS) The system is switched on and ready Have the cause of the fault to operate. u illuminates yellow. remedied immediately by a Illuminates for a few seconds after the Flashes green workshop.

  • Page 109: Electronic Stability Control And Traction Control System

    Instruments and controls Electronic Stability Control Illuminates when the engine is Continue driving until the control indicator extinguishes. running and Traction Control system Illuminates temporarily Stop, switch off engine. b illuminates or flashes yellow. Start of saturation of the exhaust filter. Illuminates Caution Start cleaning process as soon as...

  • Page 110: Deflation Detection System

    Instruments and controls AdBlue 3 154. Illuminates when the engine is Do not remove key until vehicle is running stationary, otherwise the steering Deflation detection system wheel lock could engage Caution unexpectedly. w illuminates or flashes yellow. Engine lubrication may be Keep engine turned off and let the Illuminates interrupted.

  • Page 111: Exterior Light

    Instruments and controls Exterior light Front fog lights Adaptive cruise control 8 illuminates green. > illuminates green. m illuminates white or green. The exterior lights are on 3 123. The front fog lights are on 3 127. C illuminates in the Driver Information Centre.

  • Page 112: Side Blind Spot Alert

    Instruments and controls Displays Side blind spot alert Speed limiter B illuminates continously green in the ß illuminates in the Driver Driver Information Centre instrument cluster. Information Centre when speed limiter is active. Set speed is indicated The Driver Information Centre is The system is active 3 194.
  • Page 113 Instruments and controls Trip / fuel information menu, Midlevel display Turn the adjuster wheel to select a Press CHECK to switch between the page in the trip / fuel information respective menus. menu. Vehicle messages 3 117. Select the required page: Press SET / CLR to confirm or reset a function.
  • Page 114 Instruments and controls Average speed Trip / fuel information menu, When the level in the fuel tank is low, a message appears on the display Display of average speed. The Uplevel display and the control indicator o in the fuel measurement can be reset at any gauge illuminates 3 108.

  • Page 115: Info Display

    Instruments and controls Display of average speed. The Blank page ● date 3 94 measurement can be reset at any No trip/fuel information is displayed. ● Infotainment system, see time. description in the Infotainment AdBlue Average fuel consumption manual Press CHECK repeatedly until the Display of average consumption.

  • Page 116: Head-Up Display

    Instruments and controls Graphic Info Display Colour Info Display Touch required menu display icon or a function with the finger. Selecting menus and settings Confirm a required function or There are three options to operate the selection by touching. display: Touch r on the display to exit a ●...
  • Page 117 Instruments and controls 9 Warning If the head-up display image is too bright or too high in your field of view, it may obstruct your view when it is dark outside. Be sure to keep the head-up display image dim and placed low in your field of view.

  • Page 118: Rear View Display

    Instruments and controls Language If the head-up image is not correct for Selecting a view other reasons, contact a workshop. Preferred language can be set in vehicle personalisation menu 3 118. Rear view display Units The rear view display is located at the position of the interior mirror.

  • Page 119: Vehicle Messages

    Instruments and controls Vehicle messages Messages in the ● If a warning message appears in the Driver Information Centre. Colour Info Display ● If the electronic key is not in the Messages are indicated in the Driver Some important messages may passenger compartment.

  • Page 120: Vehicle Personalisation

    Instruments and controls Vehicle personalisation When the vehicle is being driven, the Select Personalisation-configuration, load reduction function temporarily I OK. deactivates certain functions, such as The vehicle's behaviour can be Unit settings the air conditioning, the heated rear personalised by changing the settings Select Display configuration, I OK.
  • Page 121 Instruments and controls ● Comfort Colour Info Display Multimedia Driving function Press Í. Ambient lighting: Adjusts the brightness of the ambient Select Driving function. lighting. In the corresponding submenus the Rear wiper in reverse gear: following settings can be changed: Activates or deactivates ●...
  • Page 122 Instruments and controls Vehicle settings ● Headlights Driver’s attention warning: Activates or deactivates the Guide-me-home lighting: driver drowsiness system. Activates or deactivates the function and adjusts its duration. Colour Info Display Welcome lighting: Activates or Multimedia Navi Pro deactivates the function and adjusts its duration.
  • Page 123 Instruments and controls Language settings Vehicle settings ● Headlights Select Languages. Guide-me-home lighting: Activates or deactivates the Change language by touching the function and adjusts its duration. respective entry. Welcome lighting: Activates or Confirm with G. deactivates the function and Driving functions adjusts its duration.
  • Page 124 Instruments and controls Driver’s attention warning: Activates or deactivates the driver drowsiness system.

  • Page 125: Lighting

    Lighting Lighting Exterior lighting Lighting features ......130 Centre console lighting .... 130 Light switch Entry lighting ......130 Exit lighting ......130 Exterior lighting ......123 Vehicle locator lighting .... 131 Light switch ......123 Peripheral lighting ....131 Automatic light control .....

  • Page 126: Automatic Light Control

    Lighting Tail lights Automatic headlight activation High beam assist This feature automatically activates Tail lights are illuminated together During poor lighting conditions the the high beam at night when vehicle with low/high beam and sidelights. headlights are switched on. is faster than 25 km/h. Additionally, headlights are switched Automatic light control It switches automatically back to low...

  • Page 127: Headlight Flash

    Lighting Activation Deactivation Headlight flash Turn signal lever with f button With high beam on, pull the turn signal lever once to deactivate high beam assist. If a headlight flash is activated when the high beam is off, the high beam assist will remain activated.

  • Page 128: Headlight Range Adjustment

    Lighting Headlight range adjustment Headlights when driving Activated at a speed of up to 40 km/h when turning off. Depending on the abroad Manual headlight range steering angle or the activation of the When driving in countries where turn lights the front fog light illuminate adjustment traffic drives on the opposite side of the direction of travel.

  • Page 129: Turn Lights

    Lighting Hazard warning flashers are switched Constant flashing is activated when Front fog lights on automatically in the following the stalk is being moved beyond the situations: resistance point. It is deactivated when the steering wheel is moved in ● Braking in an emergency the opposite direction or stalk is (depending on the force of manually moved back to its neutral...

  • Page 130: Rear Fog Light

    Lighting Rear fog light Parking lights Reversing lights The reversing light comes on when the ignition is on and reverse gear is selected. Misted light covers The inside of the light housing may mist up briefly in poor, wet and cold weather conditions, in heavy rain or after washing.

  • Page 131: Interior Lighting

    Lighting Interior lighting Interior lights Reading lights During entry and exit of the vehicle, Instrument panel the front and rear courtesy lights illumination control automatically switch on and then off after a delay. Note In the event of an accident with airbag deployment the courtesy lights are turned on automatically.

  • Page 132: Sunvisor Lights

    Lighting Lighting features Illustration shows rear courtesy lights. This function can be activated or deactivated in the vehicle personalisation 3 118. Sunvisor lights Centre console lighting The following lights will additionally Illuminates when the cover is opened. A spotlight integrated in the overhead switch on when the driver's door is console illuminates the centre opened:...

  • Page 133: Vehicle Locator Lighting

    Lighting Activating Vehicle locator lighting This function allows you to locate your vehicle, e.g., in weak lighting conditions using the remote control. The headlights come on and the turn lights flash for 10 seconds. Press N on the remote control. The vehicle must be locked more than 5 seconds.

  • Page 134: Climate Control

    Climate control Climate control Climate control systems Temperature Adjust the temperature by turning n to Heating and ventilation the desired temperature. system HI : warm Climate control systems ..... 132 LO : cold Heating and ventilation system 132 Air conditioning system ... 133 Heating will not be fully effective until Electronic climate control the engine has reached normal...

  • Page 135: Air Conditioning System

    Climate control clockwise : increase ● Press l: the air distribution is windows may mist up from inside. anticklockwise : decrease directed towards the windscreen. The quality of the passenger ● Set temperature controller n to compartment air deteriorates, Air recirculation system u warmest level.

  • Page 136: Heating Will Not Be Fully Effective Until

    Climate control ● cooling A/C Fan speed x the freezing point. Therefore, condensation may form and drip from ● air recirculation u Adjust the air flow by turning x to the under the vehicle. ● heated rear window and exterior desired speed.
  • Page 137 Climate control Maximum cooling Demisting and defrosting the 9 Warning windows The exchange of fresh air is reduced in air recirculation mode. In operation without cooling the air humidity increases, so the windows may mist up from inside. The quality of the passenger compartment air deteriorates, which may cause the vehicle occupants to feel drowsy.

  • Page 138: Electronic Climate Control System

    Climate control Note Controls for: The electronic climate control system If the settings for demisting and is only fully operational when the ● manual air recirculation u defrosting are selected, an engine is running. ● air distribution w Autostop may be inhibited. Automatic mode AUTO ●...
  • Page 139 Climate control ● Air conditioning must be Fan speed rs Air distribution w activated for optimal cooling and demisting. Press A/C to switch on air conditioning. The LED in the button indicates activation. ● Set the preselected temperatures for driver and front passenger using the left and right rotary ring.
  • Page 140 Climate control To return to automatic air distribution, Note Air conditioning A/C press AUTO. If A/C is switched on, reducing the set cabin temperature can cause the Temperature preselection engine to restart from an Autostop or inhibit an Autostop. Stop-start system 3 149. Dual zone temperature synchronisation MONO Press MONO to link passenger side...
  • Page 141 Climate control Manual air recirculation u ● Air conditioning and automatic compartment air deteriorates, mode are automatically switched which may cause the occupants to on. The LED in the button A/C feel drowsy. illuminates, AUTO is shown in the display. In warm and very humid ambient air ●...

  • Page 142: Parking Heater

    Climate control Deactivation of electronic climate Additionally, the parking heater can control system be switched on and off using a remote control. Graphic Info Display Press MENU to open the menu page. Press Heating or Ventilation. Press H or I to select the desired timer.

  • Page 143: Air Vents

    Climate control Air vents Press ü to save the settings and set the timer. Adjustable air vents Parking heater via remote control Centre air vents in the instrument The parking heater can be switched panel on using a remote control. 1.

  • Page 144: Fixed Air Vents

    Climate control Outer air vents in the instrument Rear air vents in the centre Fixed air vents panel console Additional air vents are located beneath the windscreen, the door To activate the distribution of windows and in the foot wells. climatised / heated air via the rear air vents, press E.

  • Page 145: Maintenance

    Climate control Maintenance Air conditioning regular operation Air intake In order to ensure continuously efficient performance, cooling must be operated for a few minutes once a month, irrespective of the weather and time of year. Operation with cooling is not possible when the outside temperature is too low.

  • Page 146: Driving And Operating

    Driving and operating Driving and Fuel for diesel engines .... 205 Manual transmission ....160 Refuelling ........ 206 operating Brakes ........161 Trailer hitch ........ 208 Antilock brake system ..... 161 General information ....208 Parking brake ......162 Driving characteristics and Brake assist ......

  • Page 147: Driving Hints

    Driving and operating Driving hints Starting and operating Use only floor mats, which fit properly and are fixed by the retainers on the driver side. Control of the vehicle New vehicle running-in Do not brake unnecessarily hard for Steering Never coast with engine not the first few journeys.

  • Page 148: Power Button

    Driving and operating Ignition on power mode without 9 Danger starting the engine Press Start/Stop without operating Never remove the key from clutch or brake pedal. Control ignition switch during driving as indicators illuminate and most this will cause steering wheel lock. electrical functions are operable.

  • Page 149: Power Saving Mode

    Driving and operating Hold the electronic key with buttons Changing into power saving 9 Warning outside at the marking on the steering mode column cover as shown in the If the vehicle battery is discharged, When power saving mode is illustration.

  • Page 150: Starting The Engine

    Driving and operating Starting the engine Turn key briefly to position 2 and ● Manual transmission: operate release after engine has been clutch and brake pedal. Vehicles with ignition switch started. ● Automatic transmission: operate Manual transmission: during an brake pedal and move selector Autostop, the engine can be started lever to P or N.

  • Page 151: Overrun Cut-Off

    Driving and operating Emergency shut off during driving Starting the vehicle at low Turbo engine warm-up temperatures If the engine needs to be switched off Upon start-up, engine available during driving in case of emergency, torque may be limited for a short time, Starting the engine without additional press Start/Stop for five seconds.
  • Page 152 Driving and operating Activation Autostop Indication The stop-start system is available as Vehicles with manual transmission soon as the engine is started, the An Autostop can be activated at a vehicle starts-off and the conditions standstill or at a speed below as stated below in this section are 20 km/h.
  • Page 153 Driving and operating ● The engine exhaust temperature Vehicle battery discharge protection Vehicles with automatic transmission is not too high, e.g. after driving To ensure reliable engine restarts, The engine is restarted if with high engine load. several vehicle battery discharge ●...

  • Page 154: Parking

    Driving and operating ● The charging level of the vehicle ● If the vehicle is on a level Caution battery is below a defined level. surface or uphill slope, engage ● The brake vacuum is not first gear or set the selector After running at high engine sufficient.

  • Page 155: Engine Exhaust

    Driving and operating Engine exhaust In countries with extreme cold As soon as the traffic conditions temperatures it may be necessary to permit, regenerate the filter by driving park the vehicle without applied at a vehicle speed of at least 60 km/h parking brake.

  • Page 156: Catalytic Converter

    Driving and operating Catalytic converter AdBlue Caution The catalytic converter reduces the General information amount of harmful substances in the Avoid contact of the paintwork with exhaust gases. AdBlue. The selective catalytic reduction (BlueInjection) is a method to In case of contact, rinse off with Caution substantially reduce the nitrogen water.
  • Page 157 Driving and operating When switching on the ignition, completely empty. Otherwise, a Information Centre. The messages this warning will show up once restart of the engine will not be and the restrictions are a legal briefly with the calculated range. possible.
  • Page 158 R and Z will illuminate and a If AdBlue must be refilled at stations and can be purchased e.g. chime will sound. temperatures below -11 °C, the at Opel dealers and other retail Consult a workshop for refilling of AdBlue may not be outlets. assistance.

  • Page 159: Automatic Transmission

    Driving and operating Automatic transmission The vehicle must be parked on a level 4. Unscrew protective cap from the surface. filler neck. The filler neck for AdBlue is located 5. Open AdBlue canister. The automatic transmission permits behind the fuel filler flap, which is automatic gearshifting (automatic 6.

  • Page 160: Selector Lever

    Driving and operating In automatic mode, the driving P : park position, front wheels are Engine braking programme is indicated by D. locked, engage only when the To utilise the engine braking effect, vehicle is stationary and the In manual mode, M and the number select a lower gear when driving parking brake is applied of the selected gear is indicated.

  • Page 161: Electronic Driving Programmes

    Driving and operating Pull right paddle + to shift to a higher Electronic driving gear. programmes Pull left paddle - to shift to a lower ● Following a cold start, the gear. operating temperature Multiple pulls allow gears to be programme increases engine skipped.

  • Page 162: Fault

    Driving and operating Manual transmission Fault This mode adjusts the settings of the systems for a more economic fuel In the event of a fault a message is consumption, e.g. by optimising the displayed in the Driver Information automatic transmission shift points Centre.

  • Page 163: Brakes

    Driving and operating Brakes When clutch slip is detected for a specific time, the engine power will be reduced. A warning is displayed in the The brake system comprises two Driver Information Centre. Release independent brake circuits. the clutch. If a brake circuit fails, the vehicle can still be braked using the other brake Caution circuit.

  • Page 164: Parking Brake

    Driving and operating ABS starts to regulate brake pressure Fault Manual parking brake as soon as a wheel shows a tendency to lock. The vehicle remains 9 Warning steerable, even during hard braking. ABS control is made apparent If there is a fault in the ABS, the through a pulse in the brake pedal wheels may be liable to lock due and the noise of the regulation...
  • Page 165 Driving and operating the electric parking brake is activated. To reduce the operating forces of 3 105. The electric parking brake It is not possible when switch m is the parking brake, depress the operates automatically with pulled at the same time. foot brake at the same time.
  • Page 166 Driving and operating Automatic release: instrument cluster 3 105. The electric indicators i and J illuminate in the parking brake can only be applied and instrument cluster. In this case, ● Parking brake releases released manually. stability can only be provided by automatically after moving off.

  • Page 167: Brake Assist

    Driving and operating Ride control systems Control indicator m flashes: electric When releasing the brake pedal after stopping on an incline, brakes remain parking brake is not fully applied or on for further 2s. The brakes release released. When continuously Electronic Stability Control automatically as soon as the vehicle flashing, release electric parking...

  • Page 168: Descent Control System

    Driving and operating individually. This considerably Deactivation ESC and TC are also reactivated the improves the driving stability of the next time the ignition is switched on. vehicle on slippery road surfaces. Fault If there is a fault in the system, the control indicator b illuminates continuously and a message appears in the Driver Information Centre.
  • Page 169 Driving and operating ● If the gearbox is in first or second Caution gear, the speed decreases and the control indicator in the Use only when descending steep instrument cluster flashes grades while driving off-road. Do rapidly. not use when driving on normal ●...

  • Page 170: Selective Ride Control

    Driving and operating Depressing the foot brake or as rocks among others and on accelerator will also cause the system terrain with steep inclines and to be deactivated. poor grip. If the speed exceeds 70 km/h, the Do not cross waters. system is automatically deactivated.
  • Page 171 Driving and operating available traction. Recommended in ESC off mode 9 Caution cases of deep snow and steep The ESC and Traction Control are inclines. Do not use the other modes on deactivated in this mode. This mode is active up to a speed of sand as the vehicle may become An LED in the button a illuminates.

  • Page 172: Driver Assistance Systems

    Driving and operating Driver assistance Deviations from the stored speeds Switching on the system may occur when driving uphill or systems downhill. The system maintains the vehicle speed at the preset speed by the 9 Warning driver, without any action on the accelerator pedal.
  • Page 173 Driving and operating Accelerate to the desired speed and Adopting speed by the speed limit recognition press thumb wheel once briefly to RES/+ or SET/-. The current speed is The intelligent speed adaptation stored and maintained. Accelerator informs the driver when a speed limit pedal can be released.

  • Page 174: Speed Limiter

    Driving and operating Press MEM on the steering wheel to Cruise control is deactivated Fault request saving of the suggested automatically: In the event of a cruise control fault, speed. ● The brake pedal is depressed. the speed is cleared resulting in Press MEM on the steering wheel ●...
  • Page 175 Driving and operating Switching on the system Press thumb wheel once briefly to RES/+ or SET/-. Following the preset speed can be set by pressing thumb wheel to RES/+ to increase or SET/- to decrease the desired maximum speed. Short press changes preset speed in small steps, long press in large steps.

  • Page 176: Adaptive Cruise Control

    Driving and operating assistant. The detected speed limit This speed is the new value for the Switching off the system can be used as new value for the speed limiter. Press ß, the speed limiter mode is speed limiter. Exceeding the speed limit deselected and the speed limit Using a camera at the top of the indication extinguishes in the Driver...
  • Page 177 Driving and operating the windscreen and camera sensors The adaptive cruise control can store 9 Warning to detect the vehicles ahead. If no set speeds for manual transmission. vehicle is detected in the driving path, If the vehicle ahead is moving too The complete driver attention is the adaptive cruise control will slowly and the selected following...
  • Page 178 Driving and operating If the set speed is exceeded, the indicated speed setting flashes in the Driver Information Centre and a warning message appears. 9 Warning Accelerating by the driver deactivates automatic braking by the system. This is indicated as a pop-up warning in the Driver Information Centre.
  • Page 179 Driving and operating Resuming stored speed In the Driver Information Centre, If the stopped vehicle ahead was speed limit sign is shown in the stopped for a longer time and then Move the thumb wheel to RES/+ at a display and MEM illuminates for a few begins to move forward, the green speed above 30 km/h.
  • Page 180 Driving and operating Press Ö again to change the following Deactivation of the functionality start moving. Be always prepared distance: The new setting is to manually apply the brake to hold displayed in the Driver Information the vehicle stationary. Centre. Do not leave the vehicle while it is The selected following distance is being held at a stop by adaptive...
  • Page 181 Driving and operating ● The electric parking brake is ● Do not use the system on ● The adaptive cruise control applied. slippery roads as it can create considers stopped vehicles only rapid changes in tyre traction at low speed. ●...
  • Page 182 Driving and operating longer detects any vehicle ahead, collision with a much slower vehicle or Hill considerations then control indicator A will after a lane change. This is particularly true while driving fast or if extinguish. the visibility is reduced due to weather If the centrifugal force is too high in a conditions.

  • Page 183: Forward Collision Alert

    Driving and operating Fault If a vehicle directly ahead is Activation approached too quickly, a warning In the event of a fault with the adaptive Forward collision alert detects chime and alert in the Driver cruise control, you are alerted by the vehicles and operates automatically Information Centre is provided.

  • Page 184: Active Emergency Braking

    Driving and operating In the following cases, forward applicable traffic rules, weather 9 Warning collision alert may not detect a vehicle and road conditions etc. at all ahead or sensor performance is times. Forward collision alert is just a limited: warning system and does not ●...
  • Page 185 Driving and operating Forward collision alert 3 181 Functionality Emergency automatic braking Front pedestrian protection 3 185 Active emergency braking is After activation of brake preparation The feature uses various inputs (e.g. equipped with a front camera and system and just before the imminent camera sensor, brake pressure, operates in forward gear above collision, this function automatically...
  • Page 186 Driving and operating Emergency automatic braking may System limitations Complete attention is always required slow the vehicle to a complete stop to while driving, and you should be In some cases, the active emergency try to avoid a potential crash. ready to take action and apply the braking system may provide an brakes and / or steer the vehicle to...

  • Page 187: Front Pedestrian Protection

    Driving and operating Fault Front pedestrian alert 9 Danger In case the system requires a service, When approaching a detected Front pedestrian braking does not pedestrian too quickly, a warning m is illuminated in the instrument provide an alert or automatically message is displayed in the Driver cluster, a message is displayed in the brake the vehicle, unless it detects...

  • Page 188: Parking Assist

    Driving and operating ● the sensor in the windscreen is Rear parking assist Graphic Info Display: The system is blocked by snow, ice, slush, mud, ready to operate when the LED in the The system warns the driver with dirt etc. parking assist button ¼...
  • Page 189 Driving and operating Graphic Info Display: The system is Graphic Info Display: The system is switched off when the LED in the ready to operate when the LED in the parking assist button ¼ is illuminated. parking assist button ¼ is not illuminated.
  • Page 190 Driving and operating Graphic Info Display: The system is Graphic Info Display: The system is switched off when the LED in the ready to operate when the LED in the parking assist button ¼ is illuminated. parking assist button ¼ is not illuminated.
  • Page 191 Driving and operating Colour Info Display: Deactivate the Caution parking assist in the vehicle personalisation 3 118. Performance of the system can be reduced when sensors are System limitations covered, e.g. by ice or snow. In the event of a fault or if the system Performance of the parking assist does not work temporarily, e.g.

  • Page 192: Advanced Parking Assist

    Driving and operating Advanced parking assist The driver must control acceleration, For entering into a parallel parking braking and gear shifting, while slot, the minimum length of the slot steering is done automatically. The must be equal to the length of your 9 Warning driver can take control at any time by vehicle plus 0.6 m.
  • Page 193 Driving and operating Select parking side by switching on vehicle, select reverse gear, release the turn light on the respective side. the steering wheel and start moving without exceeding 7 km/h. The allowed parallel distance between the vehicle and a row of parked cars is between 0.5 m and 1.5 m.
  • Page 194 Driving and operating Exiting a parallel parking slot Move forwards and backwards while Deactivation observing the warnings of the Parking The current park assist manoeuvre is Activation assist until the end of manoeuvre is cancelled via the button to return to Colour Info Display: when exiting a indicated.
  • Page 195 Driving and operating ● after ten manoeuvres for entering Objects with a very small reflection 9 Warning or exiting a parallel parking slot cross-section, e.g. objects of ● on opening a door or the load narrow size or soft materials, may Under certain circumstances, compartment not be detected by the system.

  • Page 196: Side Blind Spot Alert

    Driving and operating will start a parking manoeuvre. Take Functionality ● vehicles outside the side blind care regarding the availability of the zones which may be rapidly suggested parking slot. approaching Surface irregularities, e.g. on ● pedestrians, cyclists or animals construction zones, are not detected Before changing a lane, always by the system.

  • Page 197: Passenger Side Camera

    Driving and operating Operation conditions No alert will be given in the following The state of the system is stored situations: when switching off the ignition. The following conditions must be ● in the presence of non-moving The system is automatically fulfilled for proper operation: objects, e.g.

  • Page 198: Panoramic View System

    Driving and operating Guidelines The system uses: ● rear camera, installed in the tailgate ● ultrasonic parking sensors in the rear bumper The camera is mounted at the bottom of the exterior mirror on the The line represents a distance of passenger side.
  • Page 199 Driving and operating Activation The state of the system is not kept in distances of about 1 and 2 m beyond memory when the ignition is switched the edge of your vehicle's rear Panoramic view system is activated off. bumper. This view is available in AUTO Mode Rear view / Standard view ●...
  • Page 200 Driving and operating Rear side view / 180° view Deactivation Always check the surrounding of the vehicle before driving. Panoramic view system is deactivated when: Displayed images may be further or closer than they appear. The ● driving faster than 10 km/h area displayed is limited and ●...

  • Page 201: Rear View Camera

    Driving and operating The panoramic view system may not The view of the camera is displayed 9 Warning operate properly when: in the Info Display 3 113. ● The surrounding is dark. The area displayed by the camera is The rear view camera does not limited.
  • Page 202 Driving and operating Trajectory lane of the vehicle is When operating with a trailer, the shown in accordance with the close rear view is no longer operable. steering angle. Guidelines Switching off The lower horizontal line represents a The camera is switched off when a distance of about 30 cm beyond the forward gear is engaged.

  • Page 203: Lane Keep Assist

    Driving and operating ● weather limits visibility, such as system steers not sufficient. Turn ● the change of trajectory is not fog, rain, or snow steering wheel gently into opposite accompanied by operation of the direction, if lane change is intended. turn signals ●...
  • Page 204 Driving and operating Activation If the driver wishes to maintain the Deactivation trajectory of the vehicle, he can To deactivate the system, press and prevent the correction by keeping a hold Ó. Deactivation of the system is firm grip on the steering wheel, e.g. confirmed by the illuminated LED in during an avoiding manoeuvre.

  • Page 205: Driver Alert

    Driving and operating Fault Switch off the system if the system is vehicle and is always required to disturbed by tar marks, shadows, keep the hands on the steering In the event of a fault, a and H road cracks, temporary or wheel while driving.
  • Page 206 Driving and operating Activation or Deactivation The counting of driving time alert is driver, the system triggers the first reset if one of the following conditions level of alert. The driver is notified by The system can be activated or is met: a message and an audible signal is deactivated in the vehicle...

  • Page 207: Fuel

    Driving and operating Fuel ● dazzle caused by headlamps of oncoming vehicles, low sun, reflections on damp roads, Fuel for petrol engines leaving a tunnel, alternating The petrol engines are compatible shade and light etc. with bio-fuels that conform to current ●...

  • Page 208: Refuelling

    Driving and operating Refuelling Caution 9 Danger The use of any other type of (bio) fuel (vegetable or animal oils, pure Before refuelling, switch off or diluted, domestic fuel etc.) is ignition and any external heaters strictly prohibited (risk of damage with combustion chambers.
  • Page 209 Driving and operating Petrol and diesel refuelling Caution Caution Depending on the version, place the In case of misfuelling, do not key in the lock and unlock the cap. Wipe off any overflowing fuel switch on ignition. immediately. To open, turn the cap slowly anticlockwise.

  • Page 210: Trailer Hitch

    Driving and operating Trailer hitch Driving characteristics and Trailer towing towing tips Trailer loads General information Before attaching a trailer, lubricate The permissible trailer loads are Only use towing equipment that has the coupling ball. However, do not do vehicle and engine-dependent been approved for your vehicle.

  • Page 211: Towing Equipment

    Driving and operating The permissible gross train weight permissible rear axle load is 1. Move the lever to the rear must not be exceeded. This weight is exceeded, a maximum speed of position. specified on the identification plate 100 km/h applies. 3 257.
  • Page 212 Driving and operating 3. Insert the coupling ball bar in the opening and push firmly up to the stop. Secure the coupling ball bar correctly by moving the lever to the locked position, shown in the picture. 4. Attach the trailer. 5.

  • Page 213: Trailer Stability Assist

    Driving and operating Type B Type C 3. Attach the trailer, close the towing ring and fix the splint. 1. Connect the trailer plug to the 1. Remove the safety splint. 4. Connect the trailer plug to the socket and fasten the breakaway socket and attach the breakaway stopping cable to the eye on the stopping cable to the eye on the...

  • Page 214: Vehicle Care

    Tyre repair kit ......236 units) may invalidate the warranty Vehicle battery ......217 Wheel changing ....... 239 offered by Opel. Furthermore, such Diesel fuel system bleeding ..219 Spare wheel ......240 changes may affect driver assistance Wiper blade replacement ..219 Jump starting ......

  • Page 215: Vehicle Storage

    Vehicle care Vehicle storage ● Open the bonnet, close all doors Caution and lock the vehicle. Storage for a long period of time ● Disconnect the clamp from the When transporting the vehicle on negative terminal of the vehicle a train or on a recovery vehicle, the If the vehicle is to be stored for several battery.

  • Page 216: End-Of-Life Vehicle Recovery

    Vehicle care Vehicle checks End-of-life vehicle recovery 9 Danger Information on end-of-life vehicle Performing work recovery centres and the recycling of The ignition system uses end-of-life vehicles is available on our extremely high voltage. Do not website, where legally required. Only touch.

  • Page 217: Engine Oil

    Vehicle care Closing Before closing the bonnet, press the support into the holder. Lower the bonnet and let it fall into the latch from a low height (20-25 cm). Check that the bonnet is engaged. Caution Do not press the bonnet into the latch to avoid dents.

  • Page 218: Engine Coolant

    Vehicle care Different dipsticks are used Caution depending on engine variant. Overfilled engine oil must be drained or suctioned out. If the oil exceeds the maximum level, do not start the vehicle and contact a workshop. Capacities 3 265. Fit the cap on straight and tighten it. Engine coolant If the cooling system is cold, the coolant level should be above the...

  • Page 219: Washer Fluid

    Vehicle care the coolant concentration checked Caution and have the cause of the coolant loss remedied by a workshop. Only washer fluid with a sufficient antifreeze concentration provides Washer fluid protection at low temperatures or a sudden drop in temperature. Washer fluid 3 255.
  • Page 220 Vehicle care When the vehicle battery is being Warning label replaced, please ensure that there are no open ventilation holes in the vicinity of the positive terminal. If a ventilation hole is open in this area, it must be closed off with a dummy cap, and the ventilation in the vicinity of the Batteries do not belong in household negative terminal must be opened.

  • Page 221: Diesel Fuel System Bleeding

    Vehicle care ● See the Owner's Manual for Wiper blade replacement Rear window further information. Windscreen ● Explosive gas may be present in the vicinity of the vehicle battery. Diesel fuel system bleeding If the tank has been run dry, the diesel fuel system must be bled.

  • Page 222: Bulb Replacement

    Vehicle care Bulb replacement 1. Remove the protective cover by pulling the tab. Switch off the ignition and switch off the relevant switch or close the doors. Only hold a new bulb at the base. Do not touch the bulb glass with bare hands.
  • Page 223 Vehicle care 3. Detach the bulb from the bulb socket and replace the bulb. 4. Insert the bulb socket into the reflector housing. 5. Fit the cap on. High beam (2) 3. Detach the bulb from the bulb 2. Disengage the spring clip from the socket and replace the bulb.

  • Page 224: Led Headlights

    Vehicle care Sidelight / daytime running light Have lights repaired by a workshop in case of failure. with bulbs Front fog lights 2. Remove the bulb from the socket by pulling. 3. Replace and insert the new bulb 1. Rotate the bulb socket into the socket.

  • Page 225: Front Turn Lights

    Vehicle care 3. Turn the bulb socket Front turn lights anticlockwise and remove it from the light assembly. 2. Unscrew and remove the two screws and remove the light 1. Rotate the bulb socket assembly to the front. anticlockwise to disengage and 4.

  • Page 226: Tail Lights

    Vehicle care 2. Slightly press down the bulb, turn it anticlockwise and remove it from the socket. 3. Replace and insert the new bulb into socket by turning clockwise. 4. Insert the bulb socket into the reflector and turn clockwise. Tail lights Light assembly in the body 2.
  • Page 227 Vehicle care 5. Push the bulb slightly down, turn 1. Unscrew and remove the two it and remove it from the bulb screws. carrier. Replace the bulb: Fog light (1) Reversing light (2) Turn light / hazard warning flasher Tail light / brake light (4) 6.

  • Page 228: Side Turn Lights

    Vehicle care Tail light / brake light (1) Side turn lights Turn light / hazard warning flasher To replace the bulb, remove the lamp (2) outer bulb housing: Reversing light (3) inner bulb Rear fog light (4) 6. Attach the bulb carrier to the light assembly.

  • Page 229: Number Plate Light

    Vehicle care Electrical system Number plate light 2. Pull the bulb from the bulb holder and replace it. Fuses 3. Attach the cover. Data on the replacement fuse must Interior lights match the data on the defective fuse. Have the following bulbs replaced by There are two fuse boxes in the a workshop: vehicle:...

  • Page 230: Engine Compartment Fuse Box

    Vehicle care Engine compartment fuse The fuse box is in the front left of the engine compartment. Disengage the cover and remove it. Place the fuse extractor on the Fuse extractor various types of fuse from the top or A fuse extractor is located at the cover side, and withdraw fuse.

  • Page 231: Instrument Panel Fuse Box

    Vehicle care Instrument panel fuse box Remove the cover by pulling at the top left, then at the right side. The fuse box is located behind a cover in the instrument panel at the left side. Circuit Front fog lights No.

  • Page 232: Vehicle Tools

    Vehicle care Vehicle tools No. Circuit No. Circuit 12 Diagnostic connector, power 24 Parking assist, Infotainment Tools supply transformer system, rear view camera, side blind spot camera Vehicles with spare wheel 13 Head-up display, climate control, Infotainment system 25 Airbag 14 Anti-theft alarm system, tele‐...

  • Page 233: Wheels And Tyres

    Vehicle care Wheels and tyres The jack is located in the stowage compartment underneath the right front seat. Tyre condition, wheel condition Vehicles without spare wheel Drive over edges slowly and at right angles if possible. Driving over sharp edges can cause tyre and wheel damage.

  • Page 234: Tyre Designations

    Vehicle care Tyre designations Directional tyres The tyre pressure information label on the left door frame indicates the E.g. 225/55 R 18 98 V Directional tyres should be mounted original equipment tyres and the so that they rotate in the correct 225 : tyre width, mm correspondent tyre pressures.

  • Page 235: Tyre Deflation Detection System

    Vehicle care The driver is responsible for correct information label and tyre pressure After adjusting tyre pressure initialise adjustment of tyre pressure. chart are valid for cold tyres, which system to extinguish the control means at 20 °C. indicator and restart system. 9 Warning The pressure increases by nearly Caution...

  • Page 236: Tread Depth

    Vehicle care 1. Always ensure that all four tyres After initialisation system For safety reasons, it is have correct tyre pressure automatically calibrates to new tyre recommended that the tread depth of 3 265. pressures during driving. After longer the tyres on one axle should not vary drive the system will adopt and by more than 2 mm.

  • Page 237: Changing Tyre And Wheel Size

    Vehicle care Tyres age, even if they are not used. Wheel covers Tyre chains We recommend tyre replacement Wheel covers and tyres that are every six years. factory approved for the respective vehicle and comply with all of the Changing tyre and wheel relevant wheel and tyre combination size requirements must be used.

  • Page 238: Tyre Repair Kit

    Vehicle care Temporary spare wheel The use of tyre chains is not permitted on the temporary spare wheel. Tyre repair kit Minor damage to the tyre tread can be repaired with the tyre repair kit. Do not remove foreign bodies from the tyres.
  • Page 239 Vehicle care 4. Screw the compressor air hose to 9. Connect the compressor plug to 11. The compressor pressure gauge the connection on the sealant the power outlet or cigarette briefly indicates up to bottle. lighter socket. 600 kPa (6 bar) whilst the sealant bottle is emptying (approx.
  • Page 240 Vehicle care Repeat the checking procedure once more after driving further 10 km but no more than ten minutes to check that there is no more loss of pressure. If the tyre pressure has fallen below 150 kPa (1.5 bar), the vehicle must not be used.

  • Page 241: Wheel Changing

    Vehicle care Replace the used sealant bottle. ● Never crawl under a jacked-up Dispose of the bottle as prescribed vehicle. by applicable laws. ● Do not start the vehicle when it is The compressor and sealant can be raised on the jack. used from approx.

  • Page 242: Spare Wheel

    Vehicle care The front arm position of the lifting 1. Depending on the version, open platform is centrically under the the tailgate or the rear doors 3 31, relevant vehicle jacking point. 3 32. Spare wheel The spare wheel can be classified as a temporary spare wheel depending on the size compared to the other mounted wheels and country...
  • Page 243 Vehicle care 5. Change the wheel. ● If necessary, place a chock under the wheel diagonally opposite the 6. Position the damaged wheel with wheel to be changed. the outside down in the spare wheel holder. ● Apply the parking brake and engage first gear, reverse gear or 7.
  • Page 244 Vehicle care ● Before screwing in the wheel ● Note that the spare wheel is securely and loosen each wheel bolts, clean them. secured by the conical contact of nut by half a turn. each bolt if the wheel bolts for the The wheels might be protected by 9 Warning alloy wheels are used.
  • Page 245 Vehicle care Ensure that the edge of the body sequence. Tightening torque is fits into the notch of the jack. 115 Nm. If the vehicle is equipped with alloy wheels, note that the wheel bolts can also be used for the steel spare wheel.

  • Page 246: Jump Starting

    Vehicle care Jump starting ● A discharged vehicle battery can ● The vehicles must not come into already freeze at a temperature contact with each other during of 0 °C. Defrost the frozen battery the jump starting process. Do not start with quick charger. before connecting jump leads.

  • Page 247: Towing

    Vehicle care Towing 3. Connect the black lead to the negative terminal of the booster battery. Towing the vehicle 4. Connect the other end of the black lead to a vehicle grounding point of your vehicle in the engine compartment. Route the leads so that they cannot catch on rotating parts in the engine compartment.

  • Page 248: Towing Another Vehicle

    Vehicle care Towing another vehicle Caution Caution Deactivate the driver assistance Drive slowly. Do not drive jerkily. systems like active emergency Excessive tractive force can braking 3 182, otherwise the damage the vehicle. vehicle may automatically brake during towing. When the engine is not running, considerably more force is needed to brake and steer.

  • Page 249: Appearance Care

    Vehicle care Appearance care Caution Exterior care Drive slowly. Do not drive jerkily. Excessive tractive force can Locks damage the vehicle. The locks are lubricated at the factory After towing, unscrew the towing eye. using a high quality lock cylinder grease.
  • Page 250 Vehicle care If using a vehicle wash, comply with Do not clean the engine compartment Paintwork polish with silicone forms a the vehicle wash manufacturer's with a steam-jet or high-pressure jet protective film, making waxing instructions. The windscreen wiper cleaner. unnecessary.

  • Page 251: Interior Care

    Vehicle care Ice residues, pollution and continuous Underbody For painting work and when using a wiping on dry windows will damage or drying booth at a temperature above Some areas of the vehicle underbody even destroy the wiper blades. 60 °C, the liquid gas tank must be have a PVC undercoating while other removed.
  • Page 252 Vehicle care Clean fabric upholstery with a Plastic and rubber parts vacuum cleaner and brush. Remove Plastic and rubber parts can be stains with an upholstery cleaner. cleaned with the same cleaner as Clothing fabrics may not be used to clean the body. Use interior colourfast.

  • Page 253: Service And Maintenance

    Service and maintenance Service and maintenance General information ....252 Service information ....252 Recommended fluids, lubricants and parts ........255 Recommended fluids and lubricants ........ 255...

  • Page 254: General Information

    Service and maintenance General information the service display. Contact a workshop for customised service schedules. Service information Service display 3 102. In order to ensure economical and safe vehicle operation and to maintain the value of your vehicle, it is of vital importance that all maintenance work is carried out at the proper intervals as specified.
  • Page 255 Service and maintenance Service intervals – Combo Life DV5RC DV5RD Engine code EB2ADT DV5RE DV6D Country group 1 25,000 km / 1 year 30,000 km / 1 year Country group 2 15,000 km / 1 year 30,000 km / 1 year...
  • Page 256 Service and maintenance DV5RC DV5RD DV6FE Engine code EB2ADT DV5RE DV6FD DV6D Country group 4 15,000 km / 1 year 15,000 km / 1 year 15,000 km / 1 year 15,000 km / 1 year Country group 5 10,000 km / 1 year 10,000 km / 1 year 10,000 km / 1 year 10,000 km / 1 year...

  • Page 257: Recommended Fluids, Lubricants And Parts

    Service and maintenance Recommended fluids, Dexos is the newest engine oil quality Use of engine oils for all petrol that provides optimum protection for engines with only ACEA quality is lubricants and parts petrol and diesel engines. If it is prohibited, since it can cause engine unavailable, engine oils of other listed damage under certain operating...
  • Page 258 Service and maintenance All of the recommended viscosity Washer fluid grades are suitable for high ambient Use only washer fluid approved for temperatures. the vehicle to prevent damage of Coolant and antifreeze wiper blades, paintwork, plastic and rubber parts. Consult a workshop. Use only organic acid type-long life coolant (LLC) antifreeze approved for Brake and clutch fluid...

  • Page 259: Technical Data

    Technical data Technical data Vehicle identification Identification plate Vehicle Identification Number Vehicle identification ....257 Vehicle Identification Number .. 257 Identification plate ....257 Engine identification ....258 Vehicle data ....... 259 Recommended fluids and lubricants ........ 259 Engine data ......262 Vehicle dimensions ....

  • Page 260: Engine Identification

    Technical data Information on identification label: Specifications in the vehicle documents always have priority over 1 : manufacturer those given in this manual. 2 : type approval number 3 : vehicle identification number Engine identification 4 : permissible gross vehicle weight rating in kg The technical data tables show the 5 : permissible gross train weight...

  • Page 261: Vehicle Data

    Technical data Vehicle data Recommended fluids and lubricants Service interval group 1 Required engine oil quality All countries listed in group 1 3 252 Engine oil quality Petrol engines Diesel engines (including CNG, LPG, E85) dexos1 Gen2 ✔ – dexos2 –...
  • Page 262 Technical data Service interval groups 2 and 3 Required engine oil quality Countries included in groups 2 and 3 3 252 Engine oil quality Petrol engines Diesel engines (including CNG, LPG, E85) dexos1 Gen2 ✔ – dexos2 – ✔ In case dexos quality is unavailable you may use the oil qualities listed below: Countries included in groups 2 and 3 3 252 Engine oil quality Petrol engines...
  • Page 263 Technical data Countries included in groups 2 and 3 3 252 below -25 °C SAE 0W-30 SAE 0W-30 or SAE 0W-40 down to -20 °C SAE 5W-30 SAE 10W-30 or SAE 10W-40 Permitted, but usage of oils with dexos quality is recommended.

  • Page 264: Engine Data

    Technical data Engine data Engine identifier code D12XHL D15DTL D15DT D15DTH Sales designation 1.2 Turbo 1.5 Turbo 1.5 Turbo 1.5 Turbo Engineering code EB2ADT DV5RE DV5RD DV5RC 1199 1499 1499 1499 Piston displacement [cm Engine power [kW] at rpm 5500 3500 3500 3750...
  • Page 265 Technical data Engine identifier code A16DT B16DTL B16DT Sales designation 1.6 Turbo 1.6 Turbo 1.6 Turbo Engineering code DV6D DV6FE DV6FD 1560 1560 1560 Piston displacement [cm Engine power [kW] at rpm 4000 3500 3750 Torque [Nm] at rpm 1750 1750 1750 Fuel type...

  • Page 266: Vehicle Dimensions

    4753 Width without exterior mirrors [mm] 1848 1848 Width with exterior mirrors [mm] 2107 2107 Combo LIFE 1800 - 1807 1812 - 1818 Height without roof railing [mm] Combo LIFE 1837 - 1844 1843 - 1849 Height with roof railing [mm]...

  • Page 267: Capacities

    Engine oil Engine DV5RC EB2ADT DV6D DV5RD DV6FE DV5RE DV6FD including filter [l] 3.75 3.95 between MIN and MAX [l] Combo LIFE Combo Fuel tank Petrol / diesel, refilling quantity [l] 50 / 60 AdBlue tank AdBlue, refilling quantity [l]...

  • Page 268: Tyre Pressures

    Technical data Tyre pressures Combo Payload 650 kg Vehicle with up to 3 people With full load Tyres front rear front rear [kPa/bar] ([psi]) [kPa/bar] ([psi]) [kPa/bar] ([psi]) [kPa/bar] ([psi]) 195/65 R16 260/2,6 (38) 290/2,9 (42) 260/2,6 (38) 320/3,2 (46)
  • Page 269 205/60 R16 250/2,5 (36) 290/2,9 (42) 250/2,5 (36) 290/2,9 (42) 215/65 R16 260/2,6 (38) 280/2,8 (41) 260/2,6 (38) 300/3,0 (44) Combo LIFE Vehicle with up to 3 people With full load Tyres front rear front rear [kPa/bar] ([psi]) [kPa/bar] ([psi])

  • Page 270: Customer Information

    Maximum output: 4 dBm following internet address: (RFID) ........275 www.opel.com/conformity. Infotainment system Multimedia Importer is Robert Bosch Car Multimedia GmbH Opel / Vauxhall, Bahnhofsplatz, Robert-Bosch-Straße 200, 31139 65423 Ruesselsheim am Main, Hildesheim, Germany Germany. Operation Maximum output Infotainment system...
  • Page 271 Customer information 28221 Beck Road, Unit A-21 Maximum output: 16 dBµA/m @ 10 m Wixom, MI 48394, USA Operation frequency: N/A Electronic key transmitter Maximum output: N/A Valeo ASK Automotive Pvt. Ltd. 43 Rue Bayen, 75017 Paris, France Unit 2 Plot No. 30-31, Fathepur- Operation frequency: 433.92 MHz Nawada, Manesar, Gurugram, Maximum output: 10 dBm...
  • Page 272 Customer information Jack...

  • Page 273: Reach

    Type/GM part number: 3637376 and Wheel Systems can be posed by chemicals. Visit Type/PSA part number: 9649243380 Adam Opel AG www.opel.com for further information is in compliance with the provisions of and for access to the Article 33 D-65423 Rüsselsheim Directive 2006/42/EC.

  • Page 274: Vehicle Data Recording And Privacy

    Customer information Vehicle data recording Google Inc. Operating data in the vehicle Android™ and Google Play™ Store and privacy Control units process data for are trademarks of Google Inc. operation of the vehicle. Verband der Automobilindustrie e.V. Event data recorders This data includes, e.g.: AdBlue ®...
  • Page 275 Customer information Depending on technical equipment breakdown services) can read the Comfort and infotainment level, the data stored is as follows: data from the vehicle. The same functions applies to warranty work and quality ● system component operating Comfort settings and custom settings assurance measures.
  • Page 276 Customer information ● input destinations this includes data such as position Online services data, day / night mode and other ● data on the use of online services If your vehicle has a radio network general vehicle information. For more This data for comfort and connection, this allows data to be information, please see the operating...

  • Page 277: Radio Frequency Identification (Rfid)

    / unlocking and services such as an emergency and starting. RFID technology in Opel communication system. vehicles does not use or record Third party services personal information or link with any...

  • Page 278: Index

    Index Accessories and vehicle Battery discharge protection ..131 modifications ......212 Battery voltage ......117 Active emergency braking. . 110, 182 BlueInjection....... 154 Adaptive cruise control..109, 174 Bonnet ........214 AdBlue........ 107, 154 Brake and clutch fluid....255 Adjustable air vents ....
  • Page 279 Climate control systems..... 132 Exterior lighting ....13, 123 Clock..........94 Exterior mirrors......38 Eco mode........160 Colour Info Display..... 118 Electric adjustment ...... 38 Control indicators......102 Electrical system......227 Fault ........... 160 Control of the vehicle ....145 Electric parking brake.
  • Page 280 Glass panel ........45 Indicators........99 Load compartment grille....83 Glovebox ........71 Inductive charging......95 Loading......49, 52, 53 Glovebox cooler ......142 Info Display......... 113 Loading information ..... 87 Graphic Info Display....118 Installing seats......53 Low beam........109 Instrument cluster ......
  • Page 281 Parking assist ......186 Refuelling ........206 Side turn lights ......226 Parking brake..... 105, 162 Registered trademarks....271 Sliding door ........30 Parking heater......140 Removing seats......53 Sliding side door......30 Parking lights ......128 Reversing lights ......128 Spare wheel .......
  • Page 282 Towing another vehicle ..... 246 Vehicle data recording and Towing equipment ..... 209 privacy........272 Towing the vehicle ..... 245 Vehicle detected ahead....109 Trailer coupling......208 Vehicle dimensions ....264 Trailer stability assist ....211 Vehicle Identification Number ..257 Trailer towing ......
  • Page 283 Copyright by Opel Automobile GmbH, Rüsselsheim, Germany. The information contained in this publication is effective as of the date indicated below. Opel Automobile GmbH reserves the right to make changes to the technical specifications, features and design of the vehicles relative to the information in this publication as well as changes to the publication itself.

Table of Contents

Save PDF
