Sony DSC-U60 Operating Instructions (primary manual) Operating Instructions Manual

Sony DSC-U60 Operating Instructions (primary manual) Operating Instructions Manual

Digital still camera
Hide thumbs Also See for DSC-U60 Operating Instructions (primary manual):
Table of Contents

Advertisement

Quick Links

Download this manual See also: Service Manual, Operating Instructions
Digital Still Camera

Operating Instructions

Before operating the unit, please read this manual and the separate sheet
"Waterproof specifications" thoroughly, and retain it for future reference.
Owner's Record
The model and serial numbers are located on the bottom. Record the
serial number in the space provided below. Refer to these numbers
whenever you call upon your Sony dealer regarding this product.
Model No. DSC-U60
Serial No.
DSC-U60
© 2003 Sony Corporation
3-078-724-11(1)
Getting started ________________________
Shooting still images __________________
Viewing still images ___________________
Enjoying movies ______________________
Deleting images _______________________
Enjoying images on your computer ______
Troubleshooting ______________________
Additional information _________________
Index ______________________________

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DSC-U60 Operating Instructions (primary manual) and is the answer not in the manual?

Questions and answers

Related Manuals for Sony DSC-U60 Operating Instructions (primary manual)

Summary of Contents for Sony DSC-U60 Operating Instructions (primary manual)

  • Page 1: Operating Instructions

    Owner’s Record The model and serial numbers are located on the bottom. Record the serial number in the space provided below. Refer to these numbers whenever you call upon your Sony dealer regarding this product. Model No. DSC-U60 Serial No.

  • Page 2: Regulatory Information

    (servicing) instructions in the literature accompanying the appliance. If you have any questions about this product, you may call: Sony Customer Information Services Center 1-800-222-SONY (7669) The number below is for the FCC related matters only. Regulatory Information Declaration of Conformity...

  • Page 3: Recycling Nickel Metal Hydride Batteries

    Never use the plug without the fuse cover. If you should lose the fuse cover, please contact your nearest Sony service station. Attention for the Customers in...

  • Page 4: Before Using Your Camera

    • Should you find any evidence of water leaks inside the waterproof cover, stop using the camera at once and contact your Sony dealer or local authorized Sony service facility. • Sony cannot be held responsible for malfunctions or irreparable problems arising from water or foreign objects entering the inside of the camera due to improper handling.

  • Page 5: How To Hold The Camera

    Trademarks • “Memory Stick,” and “MagicGate Memory Stick” are trademarks of Sony Corporation. • “Memory Stick Duo” and are trademarks of Sony Corporation. • “Memory Stick PRO” and are trademarks of Sony Corporation.

  • Page 6: Table Of Contents

    Table of contents Before using your camera ... 4 How to hold the camera ... 5 Identifying the parts ... 8 Getting started Preparing batteries ... 10 Charging the batteries ... 10 Inserting the batteries... 12 Using your camera abroad ... 15 Turning on/off your camera ...
  • Page 7 Troubleshooting Troubleshooting ...61 Warnings and messages ...68 Self-diagnosis display — If a code starting with an alphabet letter appears...70 Additional information Menu items...71 Precautions ...74 On “Memory Stick” ...76 On Nickel-Metal Hydride batteries...78 On the battery charger...79 On the O-ring ...79 Specifications ...82 LCD screen displays ...83 Index...

  • Page 8: Identifying The Parts

    Identifying the parts See the pages in parentheses for details of operation. A Flash (25) B Self-timer lamp (25) C Lens D Hook for hand strap E Inner cover F RESET button (61) (USB) jack (53) H Access lamp (19) I Waterproof cover J O-ring (79) Attaching the hand strap...
  • Page 9 A LCD screen B POWER lamp (15) C POWER button (15) D MENU button (16) E Mode switch : To view images (36) : To shoot still images (22) To shoot five images continuously (33) : To shoot movies (43) F Shutter button (22) (Flash charge) lamp (orange) (26)

  • Page 10: Getting Started

    • You cannot use any battery other than a Nickel- Metal Hydride battery. Also, operations are not guaranteed when using a Nickel-Metal Hydride battery from a manufacturer other than Sony. • Be sure to charge the Nickel-Metal Hydride batteries supplied with your camera before using them for the first time.

  • Page 11: Charging Time

    Charging time Nickel-Metal Hydride Charging time battery NH-AAA-DA × 2 (supplied) Approx. 6 hours This represents the time required to charge fully depleted Nickel-Metal Hydride batteries using the supplied battery charger in an environment where the ambient temperature is 25°C (77°F). •...

  • Page 12: Inserting The Batteries

    Inserting the batteries , Slide the lock switch and the OPEN button in the direction of the arrow and open the waterproof cover. The waterproof cover opens toward you. • Before opening the waterproof cover, be sure to rinse off any sand and completely wipe away any water that may be present on the camera body.
  • Page 13 , Close the inner cover and slide it in the direction of the arrow to lock it. Close the inner cover while holding the batteries in. Make sure the cover is closed securely. To remove the batteries Perform steps 1 and 2 and remove the batteries.

  • Page 14: Viewing Still Images

    Battery remaining indicator (When using Nickel-Metal Hydride batteries) As the battery power decreases with use, the battery remaining indicator displays the amount of power remaining using the following symbols. Battery Battery remaining remaining guidelines indicator Sufficient power remaining Battery half full Battery low, recording/ playback will stop soon.

  • Page 15: Using Your Camera Abroad

    Using your camera abroad Power sources You can use your camera in any country or region with the supplied battery charger within 100 V to 240 V AC, 50/60 Hz. Use a commercially available AC plug adaptor [a], if necessary, depending on the design of the wall outlet (wall socket) [b].

  • Page 16: How To Use The Buttons

    How to use the buttons Control MENU buttons EXEC To change the current settings of the camera, bring up the menu, and use the control buttons to make the changes. For each item, press MENU to display the menu and press the control buttons v/V to select the desired value, then press EXEC to make the setting.
  • Page 17 DATE&TIME SET Y / M / D 2003 12:00 EXEC , Set the numeric value with the control buttons v/V, then press EXEC. The item to be set is indicated with v/V. After entering the number, v/V moves to the next item. Repeat this step until all of the items are set.

  • Page 18: Shooting Still Images

    Inserting and removing a “Memory Stick” , Slide the lock switch and the OPEN button in the direction of the arrow and open the waterproof cover. The waterproof cover opens toward you. • Before opening the waterproof cover, be sure to rinse off any sand and completely wipe away any water that may be present on the camera body.
  • Page 19 Access lamp , Close the inner cover and slide it in the direction of the arrow to lock it. Make sure the cover is closed securely. To remove a “Memory Stick” Perform steps 1 and 2, and push the “Memory Stick” to pop it out. When doing so, be careful not to drop the “Memory Stick.”...

  • Page 20: Setting The Still Image Size

    Setting the still image size RETURN SIZE BURST • FOCUS AUTO SELFTIMER P.EFFECT MENU , Set the mode switch to , and turn on the power, then press MENU. The menu appears on the LCD screen. RETURN SIZE BURST 2.0M 2.0M 2.0M •...

  • Page 21: Image Size

    8MB 16MB 32MB 64MB 128MB MSX-256 MSX-512 MSX-1G Image size 2.0M • When the images recorded using earlier Sony models are played back, the image size indication may be different from the actual image size. • Images viewed on the LCD screen of the camera all appear the same size.

  • Page 22: Basic Still Image Shooting - Using Auto Adjustment Mode

    Basic still image shooting — Using auto adjustment mode , Set the mode switch to , and turn on the power. The name of the folder where the image will be recorded appears on the LCD screen for approximately five seconds. •...

  • Page 23: Auto Focus

    2.0M 2.0M 2.0M , Press the shutter button fully down. A beep sounds. When “RECORDING” disappears from the LCD screen, recording is complete. The image will be recorded in the “Memory Stick,” and you can shoot the next image. • If you do not operate the camera for about three minutes during recording or playback, the camera turns off automatically to prevent wearing down the batteries (page 15).

  • Page 24: Using The Self-Timer

    LCD screen display during shooting You can use [DISPLAY] under [ MENU and the control buttons v/V to turn the display on and off. This is useful when recording under conditions where it is difficult to check the image on the LCD screen.

  • Page 25: Selecting A Flash Mode

    SELFTIMER 2.0M 2.0M 2.0M O F F EXEC , Select [ON] with the control button v, then press EXEC. When you press MENU, the menu disappears and the (self-timer) indicator appears on the LCD screen. • When placing the camera in a standing position, make sure the LCD screen is level.

  • Page 26: Red-Eye Reduction

    • You cannot use the flash in the Burst mode. • If the menu is currently displayed, press MENU first so that the menu disappears. • The recommended shooting distance using the flash is approximately 0.5 m to 1.9 m (1 foot 7 3/4 inches to 6 feet 2 3/4 inches).

  • Page 27: Creating A New Folder

    Creating a new folder RETURN SIZE BURST • 2.0M 2.0M 2.0M FOCUS AUTO SELFTIMER P.EFFECT MENU , Set the mode switch to , then press MENU. The menu appears on the LCD screen. • You can also carry out this operation when the mode switch is set to RETURN FORMAT...

  • Page 28: Selecting The Recording Folder

    Selecting the recording folder RETURN SIZE BURST • FOCUS SELFTIMER P.EFFECT MENU , Set the mode switch to then press MENU. The menu appears on the LCD screen. • You can also carry out this operation when the mode switch is set to RETURN 2.0M 2.0M...
  • Page 29 CHANGE REC. FOLDER : 102MSDCF C A N C E L EXEC , Select [OK] with the control button v, then press EXEC. When you press MENU, the menu disappears and the selected folder is displayed. To cancel changing the recording folder Select [CANCEL] in step 4.

  • Page 30: Shooting According To Scene Conditions - Scene Selection

    Shooting according to scene conditions — Scene Selection When shooting underwater, moving subjects, portraits, people at night, night scenes, or landscapes, use the modes below to improve the quality of your images. Underwater mode This mode is used when shooting underwater where there is sunlight (up to depths of 1.5 m (5 feet)).

  • Page 31: Twilight Mode

    Twilight mode This mode lets you shoot night scenes at far distances without losing the dark atmosphere of the surroundings. • Note that as shutter speeds decrease, shaking increases. • The focus setting changes to [ • The flash cannot be used in this mode. •...

  • Page 32: Setting The Distance To The Subject - Focus Preset

    Setting the distance to the subject — Focus preset 0.5 m 0.2 m When shooting an image using a previously set distance to the subject, or when shooting a subject through a net or window glass, it is difficult to achieve a proper focus using the auto focus function.

  • Page 33: Shooting Five Images Continuously - Burst

    FOCUS AUTO 0.2m 0.5m 1.0m EXEC , Select the desired focus setting with the control buttons v/V, then press EXEC. You can select from the following distance settings: AUTO (No indicator), 0.2 m, 0.5 m, 1.0 m, and (infinity) When you press MENU, the menu disappears and the indicator is displayed on the LCD screen.

  • Page 34: Press The Shutter Button

    SIZE • BURST 2.0M 2.0M 2.0M 2.0M BURST EXEC , Select [BURST] with the control button V, then press EXEC. Press MENU so that the menu disappears from the LCD screen. 2.0M , Press the shutter button halfway down, then hold the shutter button fully down.
  • Page 35 RETURN SIZE BURST • 2.0M 2.0M 2.0M FOCUS AUTO SELFTIMER P.EFFECT MENU , Set the mode switch to , and press MENU. The menu appears on the LCD screen. • You can also carry out this operation when the mode switch is set to RETURN SIZE BURST •...

  • Page 36: Viewing Still Images On The Lcd Screen

    Viewing still images on the LCD screen Single (single- Index (four-image) image) screen screen 2.0M 2.0M 2.0M 101-0007 2003 7 4 12:00 You can view images shot with your camera almost immediately on the LCD screen. You can select the following two methods for viewing images.

  • Page 37: Viewing An Index Screen (Four-Image)

    Viewing an index screen (four-image) RETURN DELETE DELETE IN FOLDER INDEX DPOF MENU , Set the mode switch to , and press MENU. The menu appears on the LCD screen. RETURN DELETE DELETE IN FOLDER INDEX DPOF EXEC , Select [ ] with the control button v, then press EXEC.

  • Page 38: Selecting The Folder And Playing Back Images - Folder

    Selecting the folder and playing back images — Folder RETURN DELETE DELETE IN FOLDER INDEX DPOF MENU , Set the mode switch to then press MENU. The menu appears on the LCD screen. RETURN FORMAT CHANGE FOLDER EXEC , Select [ ] with the control button V, then press EXEC.
  • Page 39 CHANGE FOLDER : 102MSDCF C A N C E L EXEC , Select [OK] with the control button v, then press EXEC. When you press MENU, the menu disappears and the selected folder is displayed. To cancel the selection Select [CANCEL] in step 4. When multiple folders are created in the “Memory Stick”...

  • Page 40: Enlarging An Image - Enlarged Playback

    Enlarging an image — Enlarged playback You can zoom in on an image shot with your camera to enlarge it to 2.5 or 5 times the original size. 1× (normal) 2.5× 5× 2.0M 2.0M 2.0M 101-0007 2003 7 4 1:30 , Set the mode switch to , and select the image you want to...

  • Page 41: Choosing Images To Print - Print (Dpof) Mark

    Choosing images to print — Print (DPOF) mark You can mark still images shot with your camera that you want to have printed. This function is convenient when you have images printed at a shop or using a printer that conforms with the DPOF (Digital Print Order Format) standard.
  • Page 42 RETURN DELETE DELETE IN FOLDER INDEX DPOF EXEC , Select [DPOF] with the control button V, then press EXEC. DPOF EXEC , Select [ON] with the control button v, then press EXEC. When you press MENU, the menu disappears and the mark is marked on the displayed image.

  • Page 43: Enjoying Movies

    Shooting movies STBY 5:10 , Set the mode switch to , and turn on the power. • Sound cannot be recorded in movies. 0/15s , Press the shutter button fully down. “REC” appears on the LCD screen and the camera starts recording the image. The maximum recording time is 15 seconds per recording.

  • Page 44: Shooting Time

    Shooting time The shooting time is different, depending on the capacity of the “Memory Stick.” Refer to the following chart when you choose a “Memory Stick.” • The maximum shooting time is 15 seconds per recording. • The shooting time may vary, depending on the shooting conditions.
  • Page 45 0:05 101 – 0016 EXEC , Press EXEC. The movie is played back. To stop playback Press EXEC. Indicators while viewing movies Indicators on the LCD screen are not recorded. You can use [DISPLAY] under ] with MENU and the control buttons v/V to turn the display on and off (page 24).

  • Page 46: Deleting Images

    Deleting images 2.0M 2.0M 2.0M 101-0007 2003 7 4 12:00 , Set the mode switch to , and turn on the power. Press the control buttons v/V to select the image you want to delete. RETURN DELETE DELETE IN FOLDER INDEX DPOF EXEC...

  • Page 47: Formatting A "Memory Stick

    DELETE C A N C E L EXEC , Select [OK] with the control button v, then press EXEC. When the message “MEMORY STICK ACCESS” disappears, the image has been deleted. To cancel deleting Select [CANCEL] in step 4. Formatting a “Memory Stick” , Insert the “Memory Stick”...
  • Page 48 RETURN FORMAT CHANGE FOLDER EXEC , Select [ ] with the control button V, then press EXEC. Select [FORMAT] with the control buttons v/V, then press EXEC. • The term “formatting” means preparing a “Memory Stick” to record images; this process is also called “initialization.”...

  • Page 49: Enjoying Images On Your Computer

    When neither a USB connector nor a “Memory Stick” slot is provided, you can copy images using an additional device. See the Sony Website for details. http://www.sony.net/ Contents of the CD-ROM x USB Driver This driver is needed in order to connect the camera to a computer.

  • Page 50: Installing The Usb Driver

    Installing the USB driver When using Windows XP, you need not install the USB driver. Once the USB driver is installed, you need not install the USB driver again. a Start up your computer, and insert the supplied CD-ROM into the CD-ROM drive. Do not connect your camera to your computer at this time.

  • Page 51: Installing "Image Transfer

    Installing “Image Transfer” You can use the “Image Transfer” software to copy images to your computer automatically when you connect the camera to your computer with the supplied USB cable. a Click [Cyber-shot] on the model selection screen. The installing menu screen appears. b Click [Image Transfer] on the installing menu screen.

  • Page 52: Installing "Imagemixer

    Follow the instructions that appear on the screen. Installing “ImageMixer” You can use the “ImageMixer Ver.1.5 for Sony” software to copy, view and edit images. For details, see the software’s help files. a Click [ImageMixer] on the installing menu screen.

  • Page 53: Connecting The Camera To Your Computer

    Connecting the camera to your computer a Insert the “Memory Stick” with the images you want to copy into the camera, then close the inner cover. • The camera can receive power supply from most of the computers that are recommended for use through the USB connection (USB Bus Powered), so in this case there is no need to insert batteries into the camera.

  • Page 54: Copying Images Using "Image Transfer

    For Windows 2000, Me, or XP users 1 Double-click on the tasktray. 2 Click (Sony DSC), then click [Stop]. 3 Confirm the device on the confirmation screen, then click [OK]. 4 Click [OK]. Step 4 is unnecessary for Windows XP users.

  • Page 55: Changing "Image Transfer" Settings

    2 Confirm if other devices are already installed. 1 Click [Device Manager]. 2 Confirm if there is a “ Sony DSC” with a mark. 3 If you find either of the devices above, follow the steps below to delete them.

  • Page 56: Viewing Images On Your Computer

    “My Documents” folder. • When using Windows XP, click [Start] t [My Documents] in that order. • You can use the “ImageMixer Ver.1.5 for Sony” software to view and edit images on your computer. For details, see the software’s help files.

  • Page 57: Image File Storage Destinations And File Names

    Image file storage destinations and file names Image files recorded with your camera are grouped as folders in the “Memory Stick.” Example: For Windows Me users Folder containing image data recorded using a camera without the folder creation function Folder containing image data recorded with this camera When no new folders have been created, this is only “101MSDCF”...

  • Page 58: Copying Images To Your Computer - For Macintosh Users

    When neither a USB connector nor a “Memory Stick” slot is provided, you can copy images using an additional device. See the Sony Website for details. http://www.sony.net/ Steps required by your OS Follow the steps below, according to your...

  • Page 59: Installing The Usb Driver

    • Close down all applications running on the computer before installing the USB driver and application. • You can use the “ImageMixer Ver.1.5 for Sony” software to copy images to your computer and to view images on your computer. See the...

  • Page 60: Creating A Video Cd Using "Imagemixer

    Creating a Video CD using “ImageMixer” You can create a Video CD using “ImageMixer Ver.1.5 for Sony.” You can play back created Video CDs on a Video CD-compatible DVD player, or on a computer using Video CD application software. a Start “ImageMixer.”...

  • Page 61: Troubleshooting

    Replace the batteries with new ones. — p Charge the batteries (page 10). p Replace the batteries with new ones. 3 Should your camera still not work properly, consult your Sony dealer or local authorized Sony service facility.

  • Page 62: Shooting Still Images/Movies

    Symptom Cause You cannot turn on the • The batteries are not installed correctly. camera. • The batteries are discharged. • The batteries are dead (page 78). The power turns off • If you do not operate the camera for about three suddenly.
  • Page 63 Symptom Cause Your camera cannot record • No “Memory Stick” is inserted. images. • The capacity of the “Memory Stick” is insufficient. • The write-protect switch on the “Memory Stick” is set to the LOCK position. • You cannot shoot while the flash is charging. •...
  • Page 64 Symptom Cause Your camera cannot • Enlarged playback is not available for files perform enlarged playback. created or processed using other devices. You cannot display a print • You cannot display print (DPOF) marks on (DPOF) mark. movies. Deleting images Symptom Cause Your camera cannot delete...
  • Page 65 Follow the designated copy procedure for your OS (pages 54, 55 and 59). p If you are using the “Image Transfer” software, see page 54. p If you are using the “ImageMixer Ver.1.5 for Sony” application software, click on HELP. p Select [Launch Image Transfer automatically when the camera, etc., is connected.] at [Basic] setting (page 55).
  • Page 66 Copy the movie to the hard disk of your computer and then play back the movie from the hard disk (pages 54, 55 and 59). p Check the printer settings. p Click on HELP for the “ImageMixer Ver.1.5 for Sony” application software. p Set the computer display as follows: Windows: 800 ×...
  • Page 67 Others Symptom Cause Your camera does not work. • The battery level is low. (The E indicator appears.) • The USB cable is connected. The power is on, but the • The built-in microcomputer is not working camera does not work. properly.

  • Page 68: Warnings And Messages

    Warnings and messages The following messages appear on the LCD screen. Message Meaning/Corrective Action NO MEMORY STICK • Insert a “Memory Stick” (page 18). SYSTEM ERROR • Turn the power off and on again (page 15). MEMORY STICK ERROR • The inserted “Memory Stick” cannot be used in your camera (page 76). •...
  • Page 69 Message Meaning/Corrective Action ENLARGED PLAYBACK ERROR • You are attempting to perform enlarged playback for a file created using other devices. • Enlarged playback is not available for images processed using a computer. • An error occurred while your camera was performing enlarged playback.

  • Page 70: Self-Diagnosis Display - If A Code Starting With An Alphabet Letter Appears

    If you are unable to solve the problem even after trying the corrective actions a few times, repairs may be necessary. Contact your Sony dealer or local authorized Sony service facility and inform them of the 5- digit code. Example: E:61:10 Countermeasure •...

  • Page 71: Additional Information

    Menu items Menu items that can be modified differ depending on the position of the mode switch. The LCD screen shows only the items you can operate at the moment. Factory settings are indicated with x. When the mode switch is set to Item Setting SIZE·BURST...
  • Page 72 When the mode switch is set to Item Setting FORMAT OK / CANCEL CREATE FOLDER OK / CANCEL CHANGE FOLDER OK / CANCEL When the mode switch is set to Item Setting DELETE OK / CANCEL DELETE IN OK / CANCEL FOLDER INDEX / SINGLE —...
  • Page 73 The following menus are available no matter what position the mode switch is in. When [ ] is selected in the menu settings Item Setting xON / OFF LCD LIGHT DISPLAY When [ ] is selected in the menu settings Item Setting CLOCK SET...

  • Page 74: Precautions

    Precautions Do not leave the camera in the following places • In extremely hot place, such as in a car parked in the sun. The camera body may become deformed or this may cause a malfunction. • Under direct sunlight or near a heater. The camera body may become deformed or this may cause a malfunction.

  • Page 75: On Moisture Condensation

    • When the O-ring or the O-ring mating surface is extremely dirty, consult your Sony dealer or local authorized Sony service facility. On storage Avoid storage in hot, cold or humid places,...

  • Page 76: On "Memory Stick

    On internal rechargeable button battery This camera has an internal rechargeable button battery for maintaining the date and time and other settings regardless of whether the power is on or off. This rechargeable button battery is continually charged as long as you are using the camera.
  • Page 77 • Do not remove the “Memory Stick” while reading or writing data. • Data may be corrupted in the following cases. – When the “Memory Stick” is removed or the camera is turned off during read or write operation – When the “Memory Stick” is used in locations subject to static electricity or electrical noise •...

  • Page 78: On Nickel-Metal Hydride Batteries

    On Nickel-Metal Hydride batteries Effective use of the battery • Battery performance decreases in low- temperature surroundings, and the battery life is shortened under such circumstances. To use the battery longer, we recommend you keep the battery in its case in a pocket close to your body to warm it, and insert it in your camera just before you start shooting.

  • Page 79: On The Battery Charger

    On the battery charger • Do not charge any other batteries except Sony Nickel-Metal Hydride batteries in the battery charger supplied with your camera. If you try to charge any other type of battery (e.g., manganese batteries, alkaline dry cells, primary lithium...
  • Page 80 Inspecting the O-ring and the O-ring mating surface Inspect the O-ring and the O-ring mating surface in a location that is free from sand, dust or moisture. a Before opening the waterproof cover, rinse off any sand and completely wipe away any water that may be present on the camera body.
  • Page 81 O- ring with a new one after approximately two years of use. • Consult your Sony dealer or local authorized Sony service facility for replacement of O-rings. Order the following parts number when purchasing...

  • Page 82: Specifications

    Specifications x Camera [System] Image device 6.72 mm (1/2.7 type) color CCD Primary color filter Total pixels number of camera Approx. 2 112 000 pixels Effective pixels number of camera Approx. 2 020 000 pixels Lens Single focal lens f = 5.0 mm (7/32 inches) (35 mm camera conversion: 33 mm (1 5/16 inches)) F2.8...

  • Page 83: Lcd Screen Displays

    LCD screen displays When shooting still images 2.0M 2.0M 2.0M C:32:ss SLRZ A Image size indicator (20, 33) B Battery remaining indicator (14) C Flash mode indicator (25)/ Red-eye reduction indicator (26) D Focus preset indicator (32) E Picture effect indicator (34) F Scene Selection indicator (30) G AE/AF lock indicator (22) H Recording folder indicator (26)
  • Page 84 When playing back still images 2.0M 2.0M 2.0M 101 - 0012 2003 9:30 A Image size indicator (20, 33) B Print (DPOF) mark indicator (41) C Enlarged playback/Enlargement level indicator (40) D Folder-file name (57) E Playback folder indicator (38) F Image number/Number of images recorded in selected folder...

  • Page 85: Index

    Index Index Access lamp ...19 AE/AF lock indicator ...22 Auto adjustment mode ...22 Auto Focus ...23 Auto power-off function ...15 Battery battery life ...14 charging time ...11 preparing batteries ...10 remaining indicator ...14 Beep/shutter sound ...73 Burst ...33 CD-ROM ...49 Changing the recording folder ...28 Charging batteries ...10...
  • Page 86 MENU ... 16 Menu settings ... 71 Mode switch ... 9, 20 Moisture condensation ... 75 Movie delete ... 46 shooting movies ... 43 shooting time ... 44 viewing images on your computer ... 56, 59 viewing movies on the LCD screen ... 44 MPG ...
  • Page 88 Printed on 100% recycled paper using VOC (Volatile Organic Compound)-free vegetable oil based ink. Sony Corporation Printed in Japan Additional information on this product and answers to frequently asked questions can be found at our Customer Support Website.
