HDMI Fiber Optic Extender (Daisy chain model)
OPF-TH1000D / OPF-RH1000D
User's Guide Ver.1.0.0
O PTICAL DAISYCHAIN Tx for HDMI
OPF-TH 1000D
クラス 1 レーザ製品
CLASS 1 LASER PRO DUCT
O PTICAL DAISYCHAIN Rx for HDMI
OPF-RH 1000D
クラス 1 レーザ製品
CLASS 1 LASER PRO DUCT
Tx
STATUS
POW ER
H DCP
K EY LOCK
SET
＋
－
Rx
STATUS
POW ER
H DCP
• Thank you for choosing this IDK product.
• To ensure the best performance of this product, please read this User's Guide fully and carefully before
using it and keep this manual beside this product.
IDK Corporation

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the OPF-TH1000D and is the answer not in the manual?

Questions and answers

Related Manuals for IDK OPF-TH1000D

Summary of Contents for IDK OPF-TH1000D

  • Page 1 STATUS POW ER H DCP • Thank you for choosing this IDK product. • To ensure the best performance of this product, please read this User’s Guide fully and carefully before using it and keep this manual beside this product.
  • Page 2 OPF-TH1000D/OPF-RH1000D User’s Guide Trademarks  The terms HDMI and HDMI High-Definition Multimedia Interface, and the HDMI Logo are trademarks or registered trademarks of HDMI Licensing, LLC in the United States and other countries.  All other company and product names mentioned in this manual are either registered trademarks or...
  • Page 3 • Some of the contents in this User’s Guide such as appearance diagrams, menu operations, communication commands, and so on may differ depending on the version of the extender. • This User’s Guide is subject to change without notice. You can download the latest version from IDK’s website at: http: //www.idk.co.jp/en/index.html The lasers in this product meet Class 1 Laser Safety per FDA/CDRH and クラス...
  • Page 4 OPF-TH1000D/OPF-RH1000D User’s Guide Safety instructions Read and understand all safety and operating instructions before using this product. Follow all instructions and cautions as detailed in this document. Enforcement Symbol Description Indicates the presence of a hazard that may result in death or serious...
  • Page 5 The product is intended to be installed by skilled technicians. For installation, please contact a system integrator or IDK. Otherwise, it may cause fire, electric shock, injury, or property damage. Set the power plug in a convenient place to unplug easily.
  • Page 6 OPF-TH1000D/OPF-RH1000D User’s Guide Caution Do not place the product in any place where it will be subjected to high temperatures. If the product is subjected to direct sunlight or high temperatures, it may cause fire. Do not place the product in humid, oil smoke, or dusty place.

  • Page 7: Table Of Contents

    OPF-TH1000D/OPF-RH1000D User’s Guide Altitude: Do not place the product at elevations of 2,000 meters (6562 feet) or higher above sea level. Failure to do so may shorten the life of the internal parts and result in malfunctions. Instruction Table of Contants Included items ............................
  • Page 8 OPF-TH1000D/OPF-RH1000D User’s Guide Command ..............................40 Command outline ..........................40 Command list ............................40 Command description ......................... 41 8.3.1 Error status ..........................41 8.3.2 Setting command ........................42 8.3.3 Status acquisition command ....................... 43 Specification ............................. 45 Pin assignments ..........................45 9.1.1...

  • Page 9: Included Items

    Make sure all items below are included in the package. If any items are missing or damaged, please contact IDK. “OPF-H1000D” mentioned in this manual refers to OPF-TH1000D and OPF-RH1000D set. ■ Transmitter (OPF-TH1000D) ● OPF-TH1000D (main unit) x 1 ●...

  • Page 10: Product Outline

    OPF-TH1000D/OPF-RH1000D User’s Guide 2 Product outline Caution: The OPF-H1000D outputs continuous invisible light, which may be harmful to your eyes. Please follow the cautions below. ● Do not look into the rear panel fiber optic cable connectors or into the fiber optic cables themselves.

  • Page 11: Features

    OPF-TH1000D/OPF-RH1000D User’s Guide 3 Features Input signals are transmitted without quality deterioration since they are not compressed or processed. The OPF-H1000D also supports RS-232C serial one-way communication, and the transmitter outputs HDMI embedded audio as analog audio. ■ Video ● Maximum resolution: WUXGA (RB)*/1080p ●...

  • Page 12: Part Names And Descriptions

    OPF-TH1000D/OPF-RH1000D User’s Guide 4 Part names and descriptions 4.1 Transmitter ④ ⑦ OPTICAL DAISYCHAIN Tx for HDMI OPF-TH1000D ③ クラス 1 レーザ製品 CLASS 1 LASER PRODUCT ① ⑥ ⑤ ② ⑧ ⑨ STATUS POWER HDCP KEY LOCK ＋ － ⑫...
  • Page 13 OPF-TH1000D/OPF-RH1000D User’s Guide Part name Description ⑩ Menu operation Sets I/O settings of the transmitter and locks menu operation buttons ● Use “SET”, “+”, and “-” buttons to set I/O settings of the transmitter. buttons ● Press and hold the “SET” button in order to lock those buttons.

  • Page 14: Receiver

    OPF-TH1000D/OPF-RH1000D User’s Guide 4.2 Receiver ④ ⑦ OPTICAL DAISYCHAIN Rx for HDMI OPF-RH1000D ③ クラス 1 レーザ製品 CLASS 1 LASER PRODUCT ① ⑥ ⑤ ⑧ ② ⑨ STATUS POWER HDCP ⑩ ⑪ Panel drawing (Receiver) Part name Description ① RS-232C port Port for RS-232C signals (only output) ②...
  • Page 15 OPF-TH1000D/OPF-RH1000D User’s Guide Part name Description ⑦ SIGNAL LED Lights in green when vertical synchronous signals are input from the I/O connector for extension. ⑧ AC adapter connector Connector for the attached AC adapter. ⑨ Frame ground ■ POWER ⑩...

  • Page 16: Connection

    OPF-TH1000D/OPF-RH1000D User’s Guide 5 Connection 5.1 Preparation Before connecting to external devices, such as source devices and sink devices, prepare the following cables: ● HDMI cable (Type A (19 pin) plug, 5 m/16.4 ft. or shorter) ● Fiber optic cable (LC connector) ●...

  • Page 17: Precautions

    If you have to install the product to an EIA rack mount in closed space, add a ventilation to keep the ambient temperature of 40 degrees C/104 degrees F or less. (Exception: Installing to IDK’s Quarter rack, RM-42HQ) If inadequately vented, the life of parts may be shortened and operations may be affected.
  • Page 18 OPF-TH1000D/OPF-RH1000D User’s Guide ● Pull the lever of the SFP module in order to remove it. Lock the lever and push it into until it clicks to attach the module. Lever SFP module...

  • Page 19: Application Example

    You can control peripheral devices (such as projectors) by using a control device (such as PCs). Note: The OPF-TH1000D must be paired with OPF-RH1000D. The OPF-H1000D cannot be connected to an I/O slot board of the FDX series or other models of the OPF series.

  • Page 20: Basic Operation

    OPF-TH1000D/OPF-RH1000D User’s Guide 6 Basic operation 6.1 Menu operation buttons Setting input and output of the transmitter using the menu operation buttons. To use menu operation buttons: Select the menu number first and then select the setting number. Use a thin stick to press buttons.

  • Page 21: Locking Menu Operation Buttons

    OPF-TH1000D/OPF-RH1000D User’s Guide 6.2 Locking menu operation buttons Press and hold the “SET” button for a few seconds in order to lock the menu operation buttons. You can release the lock by pressing the button again. KEY LOCK KEY LOCK...

  • Page 22: Setting Transmitter And Receiver Using Setting Mode

    OPF-TH1000D/OPF-RH1000D User’s Guide 6.4 Setting transmitter and receiver using setting mode The OPF can be set and I/O statuses can be acquired with serial communication commands by setting RS-232C communication mode to the setting mode. You can set RS-232C to the setting mode by setting [C90] to “01”...

  • Page 23: Setting Transmitter

    OPF-TH1000D/OPF-RH1000D User’s Guide 6.4.1 Setting transmitter OPTICAL DAISYCHAIN Tx for HDMI OPF-TH1000D クラス 1 レーザ製品 CLASS 1 LASER PRODUCT Laptop STATUS POWER HDCP KEY LOCK ＋ － Setting how maintenance Set “C90” to “01” (9600 bps) menu is displayed Setting transmitter If devices other than devices on the figure above, settings of those devices will not be affected.

  • Page 24: Setting Receiver

    OPF-TH1000D/OPF-RH1000D User’s Guide 6.4.2 Setting receiver OPTICAL DAISYCHAIN Rx for HDMI OPF-RH1000D クラス 1 レーザ製品 CLASS 1 LASER PRODUCT Laptop STATUS POWER HDCP Set DIP SW1 to “ON”. Setting receiver If devices other than devices on the figure above, settings of those devices will not be affected.

  • Page 25: Menus

    OPF-TH1000D/OPF-RH1000D User’s Guide 7 Menus The following three menu types can be set in the transmitter: • Setting input and output in normal use: setup menu • Verifying operations: maintenance menu • Displaying I/O status: status display menu Note: Since the maintenance menu and status display menu are not used normally, they are not displayed.
  • Page 26 OPF-TH1000D/OPF-RH1000D User’s Guide List of maintenance menu Settings Menu Function Page number Setting value Default HDCP input setting On (HDCP enabled)/oFF HDCP disabled Forced color conversion output oFF (automatic)/d (DVI)/RGB/422 (YCbCr422)/444 (YCbCr444) RS-232C communication mode 00 (communication mode)/ 01 (setting mode; 9600 bps)

  • Page 27: Setting Input And Output (Setting Menu)

    OPF-TH1000D/OPF-RH1000D User’s Guide 7.2 Setting input and output (Setup menu) [ ] to the left of the each section title shows its menu name. 7.2.1 [F10] EDID resolution From the built-in EDID, you can select an EDID to be sent from the transmitter to the source device.
  • Page 28 OPF-TH1000D/OPF-RH1000D User’s Guide Maximum resolution and EDID supported pixel EDID supported 1024 1280 1280 1280 1280 1280 1360 1366 1400 1440 1600 1600 1680 1920 1920 pixel 1024 1050 1200 1050 1080 1200 Max. resolution 1080p(59.94/60) 720p 1080i 1080p (24/25/30p/50p)

  • Page 29: F16] No-Signal Input Monitoring Time

    OPF-TH1000D/OPF-RH1000D User’s Guide 7.2.2 [F16] No-signal input monitoring time You can set the monitoring time for when the source device does not output video signals due to the changes of transmitter EDID or turning on/off the transmitter or source device.

  • Page 30: F22] Pcm Audio

    OPF-TH1000D/OPF-RH1000D User’s Guide 7.2.3 [F22] PCM Audio You can set the maximum sampling frequency of PCM Audio output from the source device. Setting value 32: 32 kHz 44: 44.1 kHz 48: 48 kHz [Default] 88: 88.2 kHz 96: 96 kHz 192: 192 kHz Note: For LCD monitors and the like, some audio formats are not supported.

  • Page 31: F28] Dolby Digital Plus Audio

    OPF-TH1000D/OPF-RH1000D User’s Guide 7.2.6 [F28] Dolby Digital Plus Audio You can set the maximum sampling frequency of Dolby Digital Plus Audio that is output from the source device. Setting value 32: 32 kHz 44: 44.1 kHz 48: 48 kHz oFF: OFF [Default] Note: For LCD monitors and the like, some audio formats are not supported.

  • Page 32: F34] Dolby Truehd Audio

    OPF-TH1000D/OPF-RH1000D User’s Guide 7.2.9 [F34] Dolby TrueHD Audio You can set the maximum sampling frequency of Dolby TrueHD Audio that is output from the source device. Setting value 44: 44.1 kHz 48: 48 kHz 88: 88.2 kHz 96: 96 kHz 176: 176.4 kHz...

  • Page 33: F65] Audio Output

    OPF-TH1000D/OPF-RH1000D User’s Guide 7.2.11 [F65] Audio output You can set ON/OFF of audio output from the output connector for extension. Setting value on: ON [Default] oFF: OFF Note: Even if you set this menu to “oFF”, audio is output from the audio output connector.

  • Page 34: Verifying Operation (Maintenance Menu)

    OPF-TH1000D/OPF-RH1000D User’s Guide 7.3 Verifying operation (Maintenance menu) You can set the required items for operation verification. Set [F99] to “ALL” or “on” in order to enable the maintenance menu. 【See 7.2.14 [F99] Maintenance/status display menu】 7.3.1 [C06] HDCP input setting You can set whether the transmitter encrypts HDCP to the source device.

  • Page 35: C55] Forced Color Conversion Output

    OPF-TH1000D/OPF-RH1000D User’s Guide 7.3.2 [C55] Forced color conversion output You can set the color space to be sent to the sink device. Normally the sink device automatically select a proper color space for display according to the color space of input video.

  • Page 36: Displaying I/O Status (Status Display Menu)

    OPF-TH1000D/OPF-RH1000D User’s Guide 7.4 Displaying I/O status (status display menu) Displaying I/O status of the transmitter. This menu is valid if [F99] is set to “on” or “ALL”. Press the “SET” button in order to finish the operation. 【See 7.2.14 [F99] Maintenance/status display menu】...
  • Page 37 OPF-TH1000D/OPF-RH1000D User’s Guide Menu number Value Description Audio input format (2 digits from left) and the number of channels (1 digit from right) X= the number of channels:1 = 2 channels, 2 = 2.1 channels, 5 = 5.1 channels, 7 = 7.1 channels...
  • Page 38 OPF-TH1000D/OPF-RH1000D User’s Guide Menu number Value Description Audio input status No audio input Being detected the input Normal input - - - Nothing is input...

  • Page 39: L50] Displaying Information About Output

    OPF-TH1000D/OPF-RH1000D User’s Guide 7.4.2 [L50] Displaying information about output Output information of transmitter Menu number Value Description Color space and output status RGB output YCbCr422 output YCbCr444 output - - - Not connected...

  • Page 40: Command

    OPF-TH1000D/OPF-RH1000D User’s Guide 8 Command You can set the transmitter and receiver using the RS-232C connector. Setting mode need to be set for the target device (transmitter or receiver); see “6.4 Setting transmitter and receiver using setting mode” for details.

  • Page 41: Command Description

    OPF-TH1000D/OPF-RH1000D User’s Guide 8.3 Command description 8.3.1 Error status @ERR Error status Function Acquisition Format Only return value Return value @ERR, error format Parameter error: error status 1 = There is an error in the parameter format or value. 2 = Undefined command or there is an error in the command format.

  • Page 42: Setting Command

    Example @GIV Acquires the version information of the firmware. @GIV,OPF-RH1000D ,1.00 The firmware version of the OPF-RH1000D is ver.1.00. (for transmitter, the firmware version of the “OPF-TH1000D” will be returned.) Related info. 7.2.13 [F90] Version...

  • Page 43: Status Acquisition Command

    OPF-TH1000D/OPF-RH1000D User’s Guide 8.3.3 Status acquisition command @GIS Acquiring input status Function Acquisition Format @GIS, mode Return value @GIS, mode (, status1, status2, status3, status4, status5, status6, status7, status8, format status9, status10, status11) Parameter mode: selecting item 0 = selecting all items (information of status1 to status11)
  • Page 44 OPF-TH1000D/OPF-RH1000D User’s Guide @GOS Acquiring output status Function Acquisition Format @GOS, mode Return value @GOS, mode (, status1, status2, status3, status4, status5, status6, status7) format Parameter mode: selecting item 0 = selecting all items (information of status1 to status7) 1 to 7 = selecting items from status1 to status7 status1: Deep Color of the sink device 8bit/10bit/12bit/16bit/－...

  • Page 45: Specification

    OPF-TH1000D/OPF-RH1000D User’s Guide 9 Specification 9.1 Pin assignments 9.1.1 HDMI Type A connector Pin # Signal name Pin # Signal name TMDS data 2+ TMDS clock+ TMDS data 2 shield TMDS clock shield TMDS data 2- TMDS clock TMDS data 1+ TMDS data 1 shield spare (N.C.*)
  • Page 46 OPF-TH1000D/OPF-RH1000D User’s Guide ■ Connecting to an IDK’s product Make sure to use a cross cable in order to connect to an IDK’s product. OPF-H1000D IDK’s product Pin No. Signal Signal N.C. N.C. (No connection) (RX data) (TX data) N.C.

  • Page 47: Product Specification

    OPF-TH1000D/OPF-RH1000D User’s Guide 9.2 Product specification 9.2.1 OPF-H1000D Item Description Model number OPF-TH1000D (Transmitter) OPF-RH1000D (Receiver) 1 input / HDMI (*1) - HDCP: Pass through Number / Signal - CEC: Pass through 1 input / Optical signal for extension - TMDS Single Link...
  • Page 48 OPF-TH1000D/OPF-RH1000D User’s Guide up to 8 channels - Sampling frequency: 32 kHz to 192 kHz - Sample size: 16 bit to 24 bit - Reference level:-20 dBFS - Max. input level: 0 dBFS Connector 1 LC connector 1 female HDMI Type A (*2)

  • Page 49: Standard Sfp

    OPF-TH1000D/OPF-RH1000D User’s Guide 9.2.2 Standard SFP Item Multimode fiber Singlemode fiber Connector 2 LC connectors (Duplex) Wave length 850 nm (Oxide VCSEL Laser (*8)) 1310 nm (Fabry-Perot laser (*8)) Max. extension distance OM3: 985 ft. (approx.) <300 m> OS1: 2.92 miles (approx.) <4.7 km>...

  • Page 50: Troubleshooting

    OPF-TH1000D/OPF-RH1000D User’s Guide 10 Troubleshooting In case this device does not work correctly, please check the following items first. Refer to manuals of connected devices as well, since they may possibly be the cause of the problem. • Are this device and the connected devices turned on normally? •...
  • Page 51 Ver.1.0.0 Issued on: 11 June 2015 Headquarters IDK Corporation 7-9-1 Chuo, Yamato-shi, Kanagawa-pref. 242-0021 JAPAN TEL: +81-46-200-0764 FAX: +81-46-200-0765 Email: idk_eng@idk.co.jp URL: http: //www.idk.co.jp/en/index.html Product information Arvanics Corporation Support 3-8-3-3F Yamato Higashi, Yamato-shi, Kanagawa-pref. 242-0017 JAPAN TEL: +81-46-259-6920 FAX: +81-46-259-6920 Email: info@arvanics.com URL: http: //www.arvanics.com...
