Ultimate Sensitivity
Super Vision at Ultra Low Light SHC-745
Thank you for purchasing a SAMSUNG CCD CAMERA.
Before attempting to connect or operate this product,
please read these instructions carefully and save this manual for future use.
P/No. : Z6806085401B
VAN 08. 02
Ultra Clear Image
560TVL
User's Manual
ENGLISH
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Samsung 560TVL
Summary of Contents for Samsung 560TVL
- Page 1 Thank you for purchasing a SAMSUNG CCD CAMERA. Before attempting to connect or operate this product, please read these instructions carefully and save this manual for future use. P/No. : Z6806085401B VAN 08. 02 Ultra Clear Image 560TVL User’s Manual ENGLISH...
-
Page 2: Power Source
Before operating the camera, confirm the camera model and proper input power voltage. In order to that you can understand this manual thoroughly, we'll introduce our model description. ■ SHC-745 SERIES • NTSC MODELS • PAL MODELS SHC-745N SHC-745P SHC-745PH ■... -
Page 3: Table Of Contents
Contents Features Precautions Components and Accessories Overview Front View Side View Bottom View Rear View Installation Procedures Lens • When Using Auto Iris Lens • When Using C/CS Mount Lens Connecting a Monitor Connecting Power Control via RS-485 Interface How to Use the Camera Function Menu Structure How to Set up the Functions LENS... -
Page 4: Features
By adopting a diagonal 8mm(1/3 ) 410,000 pixel signals without any additional external sensors, you ExView Sony CCD, the camera produces clear picture can monitor activity more efficiently by connecting the quality with a horizontal resolution of 560 TV lines for camera to an alarm device. -
Page 5: Precautions
Precautions Do not install under extreme Do not install in high humidity temperature conditions. environment. Use only under temperature conditions May lower image quality. between -10˚C and +50˚C. Provide good ventilation when using in high temperature conditions. Do not install under unstable Avoid touching the camera lens. -
Page 6: Components And Accessories
Components and Accessories 1. Ultra Low Light Color CCD Camera SHC-745 2. Auto Iris Lens Connector Plug 3. C-Mount Adapter 4. Instruction Manual COLOR CCD CAMERA User’s Manual Front View Tripod Mounting Bracket Screw Hole Used to fix the Tripod Mounting Bracket to the top of the camera. C-Mount Lens Adapter Install this adapter to use a C-Mount Lens. -
Page 7: Side View
Overview Side View Auto Iris Lens Connector Used to connect Auto Iris Lens plug. COLOR CCD CAMERA User’s Manual Bottom View Tripod Mounting Bracket Screw Hole Used to fix the camera on a bracket or tripod. The screw sizes for this hole are as follows: 1/4"-20 UNC (20 THREAD) L:4.5mm±0.2mm (ISO standard), or 0.197"... -
Page 8: Rear View
Overview Rear View Function Setup Button SET Button : Displays the menu on the screen. Press this button to confirm status or after changing a selected item. Up and Down Button : Used to move the cursor up or down in the menu screen to select a desired menu item. -
Page 9: When Using C/Cs Mount Lens
Installation Procedures 3. Remove the cover of the auto iris lens connector plug and solder the lens cable to the connector pin of the plug. • For a Video Drive Lens • For a DC Drive Lens Pin 1: Red (Power) Pin 1: Damping - Pin 2: NC Pin 2: Damping +... -
Page 10: Connecting A Monitor
Installation Procedures • When Using a C Mount Lens 1. Remove the protective glass cover at the front of this product and turn the C- Mount Adapter clockwise to install it. 2. Turn the C-Mount lens clockwise to install it. 3. -
Page 11: Connecting Power
Installation Procedures Connecting Power Since power specifications differ depending on the model, make sure to check your model name and specifications before connecting power. You can connect power as shown in the following figure. For AC / DC power • Since the power specification supports both AC and DC, connect AC 24V, 500mA Adaptor or DC 12V, 500mA Adaptor. -
Page 12: How To Use The Camera
How to Use the Camera Function Menu Structure Setup Menu LENS • DC • VIDEO EXPOSURE • SHUTTER • AGC • RETURN WHITE BALANCE • ATW • MANUAL • OUTDOOR • INDOOR BACKLIGHT • OFF • BLC SSNR • ON •... -
Page 13: Lens
How to Use the Camera MAIN SETUP 1.LENS Select the function using the UP or DOWN button. 2.EXPOSURE 3.WHITE BAL 4.BACKLIGHT 5.SSNR 6.DAY/NIGHT AUTO 7.IMAGE ADJ 8.SPECIAL 9.EXIT 3. Set up a selected item by using the Left and Right buttons. 4. -
Page 14: Exposure
How to Use the Camera EXPOSURE MAIN SETUP 1.LENS 2.EXPOSURE 3.WHITE BAL 4.BACKLIGHT 5.SSNR 6.DAY/NIGHT AUTO 7.IMAGE ADJ 8.SPECIAL 9.EXIT 1. When the SETUP menu screen is displayed, select EXPOSURE by using the Up and Down buttons so that the arrow indicates EXPOSURE . 2. -
Page 15: White Balance
How to Use the Camera White Balance (White Bal.) Use the White Balance function to adjust the screen color. 1. When the SETUP menu screen is displayed, select ‘White Bal.’ by using the Up and Down buttons so that the arrow indicates ‘White Bal.’ . 2. -
Page 16: Ssnr
How to Use the Camera BLC : Enables a user to directly select a desired area from a picture, and to view the area more clearly. BLC ON BLC OFF HLC (High Light Compensation) : If there is a high light installed in a limited environment such as an apartment parking garage or gas station entrance, removing the high light makes it possible to view car license plates efficiently. - Page 17 How to Use the Camera 3. Set the SSNR mode to ‘ON’ and press the SET button. Then you can adjust the noise reduction level. Notes • You cannot set the SSNR to ‘ON’ or ‘OFF’ when the AGC mode of the EXPOSURE menu is ‘OFF’.
-
Page 18: Image Adj
How to Use the Camera IMAGE ADJ. 1. When the SETUP menu screen is displayed, select ‘IMAGE ADJ.’ by using the Up and Down buttons so that the arrow indicates IMAGE ADJ. MAIN SETUP 1.LENS 2.EXPOSURE 3.WHITE BAL 4.BACKLIGHT 5.SSNR 6.DAY/NIGHT AUTO 7.IMAGE ADJ... -
Page 19: Cam Title
How to Use the Camera SPECIAL 1. When the SETUP menu screen is displayed, select ‘SPECIAL’ by using the Up and Down buttons so that the arrow indicates ‘SPECIAL’. MAIN SETUP 1.LENS 2.EXPOSURE 3.WHITE BAL 4.BACKLIGHT 5.SSNR 6.DAY/NIGHT AUTO 7.IMAGE ADJ 8.SPECIAL 9.EXIT 2. -
Page 20: Motion Det
How to Use the Camera Enter a title, move the cursor to ’POS’ and press the SET button. The entered title appears on the screen. Select the position to display the title on the screen by using the 4 direction buttons and press the SET button. When the position is determined, select ’END’... -
Page 21: Exit
How to Use the Camera - MASK COLOR : Determine area color. You can select Gray, Green, Red, Blue, Black, White. - TRANSP : Determine the transparency of selected area as controlling number from 0 to 3. - RETURN : Select this to save the PRIVACY menu settings and return to the SPECIAL menu. -
Page 22: Troubleshooting
Troubleshooting If you have trouble operating your camera, refer to the following table. If the guidelines do not enable you to solve the problem, contact an authorized technician. Problem Solution Nothing appears on • Check that the power cord and line connection the screen. -
Page 23: Specifications
Specifications SHC-745N SHC-745P Input Voltage AC24V / DC12V POWER Power Consumption 4.0W Size Diagonal 8mm (1/2 ) Sony Exview HAD CCD Total Pixels 811(H) X 508(V) Effective Pixels 768(H) X 494(V) Scanning System 2:1 Interlace Synchronization Internal / Line Lock Sync Horizontal : 15.734 KHz,... - Page 24 MEMO...
