Sensing output operation mode (L/D)
When the mode indicator L /D (yellow) is ON, you can switch from Light-ON
mode to Dark-ON mode and vice versa (also during IO-Link communica-
tion).
1. Press the MODE key. The L/D indicator lights
up and the current mode setting is displayed.
2. Press the UP key to select Dark-ON mode or
the DOWN key to select Light-ON mode.
3. Press the SET key to save the setting.
11
Light sensitivity setting mode
● When the mode indicator CUST. (yellow) lights up, the light sensitivity
setting can be displayed (also during the IO-Link communication).
● Press the UP or DOWN key to change the setting.
● Press the SET key to save the setting.
12

PRO mode (PRO)

● When the mode indicator PRO (yellow) is ON, you can scroll through
the PRO menu (Pro1 to Pro3) and make advanced settings (also dur-
ing IO-Link communication).
● If you change settings, press the SET key before you turn the power
OFF. Otherwise your changes will be lost.
● If settings are configured simultaneously on the main unit side and on
the IO-Link communication side, the settings that are applied last will
be used.
SET key (confirm)
UP key (+) DOWN key (–) (select)
(select)
MODE key (select,
cancel)
MODE indicator: PRO (yellow)
SET Press the SET key
+, – Press the UP (+) or DOWN
key (–)
Device moves automati-
Automatic
cally to the next item
Procedure
Response time
<PRO1> setting (note 1)
SET
+, -
Timer setting
+, -
+, -
Shift amount
setting
Teaching lock
setting
<PRO2>
SET
+, -
Digital display
setting
+, -
+, -
Setting of digital
display turning
+, -
Eco setting
Display adjustment
setting
<PRO3>
+, -
Reset setting
+, -
Interference
prevention setting
+, -
+, -
Setting of threshold
value tracking
<PRO1>
4
≤250μs ≤2ms
SET +, -
+, -
OFF-delay
No timer
timer
SET +, -
+, -
When the timer is used, set the timer time (Notes 2)
Displayed in Digit display
percentage (note 3)
SET +, -
Lock OFF Lock ON
SET +, -
Incident light Displayed in
intensity percentage
SET +, -
+, -
When peak/bottom value is selected, set the time period hold setting
(Notes 4)
Time period
SET Hold OFF
hold setting
Turning OFF Turning ON
SET +, -
Eco OFF Eco ON
SET +, -
+, -
Confirm
+, -
SET
SET SET
Blink Blinks 3 times
SET
+, -
Different Emitting
frequency setting frequency 1
SET
+, -
+, -
Ambient environment Emitting
resistance setting frequency 4
Setting of threshold
tracking cycle OFF
SET
SET
+, -
Sensing output
OFF
setting
SET
+, -
Storage cycle
setting
OFF
SET
+, -
Algorithm setting
Limit teaching
(note 5)
SET
≤4ms
+, -
+, -
+, -
≤24ms
ON-delay
timer
+, -
+, -
+, -
One-shot
timer
Timer time
SET
Peak /
bottom value
+, -
Hold ON
+, -
Full
+, -
Automatic
<RUN mode>
Emitting
frequency 2
+, -
+, -
Emitting
frequency 3
1s
+, -
ON
+, -
1 time
+, -
Full auto teaching
+, -
