VS300 Series Quick Reference Guide
The VS 300 is a complete video microscope system in a handheld and directly
viewed package. The VS 300 view safe microscope removes concerns for
eye safety while inspecting optical fiber connectors. The design of this video
microscope eliminates the optical path to the eye by utilizing a miniature
camera and a state-of-the-art microdisplay that achieves unparalleled clarity
and resolution.
Magnification of the VS 300 inspection scope is equivalent to 400X (23-
degree field of view comparable to an 8" monitor viewed at a distance of 20")
and provides 600X when images are displayed on a 12" monitor connected to
the VS 300. The VS 300 video microscope uses thread-on adapter caps and
has an energy saving automatic shutoff.
The VS 300 is supplied with a 2.5mm Universal adapter cap and neck strap.
For greatest inspection flexibility additional adapter cap styles are available
from Noyes. For a list of available adapter caps contact Noyes, or visit our web
at www.AFLtele.com/go/Noyes.
Optical ports and connector end faces must be kept free from dirt or other
contaminates to ensure accurate measurements and operation. For cleaning
connector end faces on test jumpers and in fiber frames or adapters, use
optical quality cleaning fluid such as AFL FCC2 connector cleaning fluid and
AFL CCT molded cleaning tips. For cleaning the lenses and adapter caps, use
lint-free optical cleaning wipes such as AFL FiberWipes and optical quality
cleaning fluid such as AFL FCC2 connector cleaning fluid (or IPA - reagent
grade isopropyl alcohol 99% or better).
Visit our web at www.AFLtele.com/go/Clean for more information.
