Yoke Mounting Quick Start Guide
The term "WARNING!" indicates instructions regarding personal safety. If the instructions are not followed the result may be bodily injury or death.
The term "CAUTION!" indicates instructions regarding possible damage to physical equipment. If these instructions are not followed, it may result
in damage to the equipment that may not be covered under the warranty.
The term "IMPORTANT!" indicates instructions or information that are vital to the successful completion of the procedure.
The term "NOTE" is used to indicate additional useful information.
The intent of the lightning flash with arrowhead symbol in a triangle is to alert the user to the presence of un-insulated "dangerous"
voltage within the product's enclosure that may be of sufficient magnitude to constitute a risk of electric shock to humans.
The intent of the exclamation point within an equilateral triangle is to alert the user to the presence of important safety, and operating
and maintenance instructions in this manual.
WARNRNG!: These mounting brackets shall only be used with CP Series loudspeakers. Use with other apparatus could
result in instability and possible injury.
1.
Read these instructions.
2.
Keep these instructions.
3.
Heed all warnings.
4.
Follow all instructions.
5.
Only use attachments/accessories specified by the manufacturer.
6.
Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way, or has
been dropped.
7.
Adhere to all applicable, local codes.
8.
Consult a licensed, professional engineer when any doubt or questions arise regarding a physical equipment installation.
9.
Before placing or installing any loudspeaker product, inspect all hardware, cabinets, transducers, brackets and associated equipment for
damage. Any missing, corroded, deformed, or non-load rated component could significantly reduce the strength of the installation and
should be immediately corrected. Use only hardware which is rated for the loading conditions of the installation and any possible short-term
unexpected overloading. Never exceed the rating of the hardware or equipment.
Warranty
For a copy of the QSC Limited Warranty, visit the QSC website at www.qsc.com
TD-001570-01-A
*TD-001570-01*
EXPLANATION OF SYMBOLS
IMPORTANT SAFETY INSTRUCTIONS
