Summary of Contents for Magnavox MD695
-
Page 2: Risk Of Electric Shock Do Not Open
IMPORTANT SAFETY INSTRUCTIONS CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT EMOVE COVER (OR BACK). NO USER-SERVICEABLE ART NSIDE EFER SERVICING T UALIFIED ERVICE PERSONNEL. The lightning flash with arrowhead symbol FCC NOTICE: within an equilateral triangle is intended to alert This equipment has been tested and found to comply... -
Page 3: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS Before using the unit, be sure to read all operating instructions carefully. Please note that these are general precautions and may not pertain to your unit. For example, this unit may not have the capability to be connected to an outdoor antenna. 1) Read these instructions. - Page 4 IMPORTANT SAFETY INSTRUCTIONS 17) Overloading Do not overload wall outlets and extension cords as this can result in a risk of fire or electric shock. 18) Object and liquid entry Never push objects of any kind into the product through openings as they may touch dangerous voltage points or short out parts that could result in fire or electric shock.
-
Page 5: Location Of Controls
Location of Controls Turntable 1. Turntable spindle 2. Tray for 45 RPM adapter storage 3. Lever 4. Tone arm holder 5. Speed selector 6. Tone arm 7. Stylus cartridge 8. Turntable platter Front View 9. Speakers 10. Function selector 11. Radio tuning knob 12. -
Page 6: Power Source
Power Source 1. Connect the small plug from the supplied AC/DC Adaptor to the DC IN jack on the rear of unit. 2. Connect the AC/DC Adapter into a conveniently located AC outlet having AC 100-240V~, 50/60Hz. AC/DC Adapter To AC outlet DC IN DC IN 9V,1500mA... - Page 7 6. Release the metallic holder as the illustrated below then close top cover.
- Page 8 4. During playback, using the controls on the paired BT Device to skip the tracks; pause; play... etc. Notes: When the external BT player searched the unit, our model number “ MD695 ” will appear on the display of external BT Device.
-
Page 9: Listening To A Record
Listening to a Record 1. In first time use, take off the protective cover from the stylus as the illustrated below: Plastic white color protective cover 2. Place the Record on the center spindle. Note: If you are playing a 45 RPM Single (small size record), place the supplied 45 RPM adapter to the center spindle then place the record on it. -
Page 10: Listening To The Radio
Listening to the Radio 1. Power on the unit and turn the Function selector to the AM or FM position as the instructed earlier as desired. 2. Turn the Radio tuning knob to received the desired radio station. Note: When the unit received a stereo FM station in FM mode, it will play it in stereo mode automatically. Antenna: - This unit has a built-in ferrite rod antenna, which provides adequate reception in most areas. -
Page 11: Other Connections
Other Connections AUX IN: LINE OUT: Listen music from the external audio player as follows: To listening from external audio amplifier: 1. Connect one end of the supplied audio connection 1. Connect one end of the RCA audio connection cable cable to the Phones jack;... - Page 12 Records Handling Do not touch the record's grooves. Only handle records, by the edges or the label. Make sure your hands are clean. Skin oils from even clean hands can leave a residue on the record surface that will gradually deteriorate the quality of your record.
-
Page 13: Troubleshooting Guide
Troubleshooting Guide Symptom Possible Cause Solution Power AC/DC Adaptor had not Connected the AC/DC connected to unit or wall Adaptor to the unit outlet wall outlet Turn the Power ON-OFF/ No power Volume control knob Power ON-OFF/Volum e control clockwise to power on knob is on power off position the unit and set the volume to the desired... -
Page 14: General Specifications
General Specifications Power Source: 9V, 1500mA, Audio Power: W (RMS) x 2 Impendence of Speakers: 4 Ohm; 3W x 2 BT Version: BT Effective Range: 32 feet in open area ≤ Radio Frequency: AM 530-1710kHz FM 87.5-108MHz Turntable: Speed: 33; 45; 78 rpm selectable Type of Stylus: CSC-015 Accessories...
