Page 1 3-865-708-11(2) CD Radio Cassette-Corder Operating Instructions CFD-ZW700 CFD-ZW705 CFD-ZW750 CFD-ZW770 1999 by Sony Corporation...
Page 2 CD radio cassette-corder and the serial number is located in the battery compartment. Record these numbers in the spaces provided below. Refer to these numbers whenever you call upon your Sony dealer regarding this product. Model No. _______________________ Serial No. ________________________ About This Manual...
Page 3: Table Of Contents
Table of contents Basic Operations Playing a CD Listening to the radio Playing a tape 10 Recording on a tape The CD Player 12 Using the display 13 Locating a specific point in a track 14 Playing tracks repeatedly (Repeat Play) 15 Playing tracks in random order (Shuffle Play) 16 Creating your own program...
Page 4: Basic Operations
Basic Operations Playing a CD Basic Operations For hookup instructions, see pages 25 – 27. Push 6 PUSH OPEN/CLOSE down to open the CD compartment and place the CD on the CD compartment. With the label side up Close the lid of the CD compartment.
Page 5 Next time you want to listen to a CD, just press ^. The player turns on automatically and starts playing the CD. Use these buttons for additional operations POWER 6 PUSH OPEN/CLOSE adjust the volume stop playback pause playback go to the next track go back to the previous track remove the CD turn on/off the player...
Page 6: Listening To The Radio
Listening to the radio Basic Operations For hookup instructions, see pages 25 – 27. Press RADIO BAND until the band you want appears in the display (direct power-on). Hold down TUNE•TIME SET + or – (TUNE + or – on the remote, CFD-ZW750/ZW770 only) until the frequency digits begin to change in the display.
Page 7 Tips • If the FM broadcast is noisy, press MODE until “Mono” appears in the display and radio will play in monaural. • Next time you want to listen to the radio, just press RADIO BAND. The player turns on automatically and starts playing the previous station.
Page 8: Playing A Tape
Playing a tape Basic Operations For hookup instructions, see pages 25 – 27. Press p6 to open the tape compartment and insert a recorded tape. Use TYPE I (normal) tape only. Close the compartment. With the side you want to play facing you Press (.
Page 9 Note During playback, do not press buttons on the other deck. Otherwise the playback speed may change. Next time you want to listen to a tape, just press (. The player turns on automatically and starts playing the tape. Use these buttons for additional operations VOLUME +, –...
Page 10: Recording On A Tape
Recording on a tape Basic Operations For hookup instructions, see pages 25 – 27. Press p6 to open the tape compartment on deck B and insert a blank tape. Use TYPE I (normal) tape only. With the side you want to record on facing you Select the program source you want to record.
Page 11 Deck B Start recording. To record from the CD player and the radio, press r on deck B (( is depressed automatically). To record from the tape, press r Deck A on deck B ((is depressed automatically). Then press ( on deck A.
Page 12: The Cd Player
The CD Player Using the display You can check information about the CD using the display. The CD Player Checking the total track numbers and playing time Press DISPLAY ENT MEM in stop mode. If the CD has more than 12 tracks, “OVER 12” appears in the display.
Page 13: Locating A Specific Point In A Track
Locating a specific point in a track You can quickly find a specific point in a track while playing a CD. You can also locate any track using the number buttons on the remote (CFD- ZW750/ZW770 only). Note CFD-ZW750/ZW770 only: You cannot locate a specific track if “SHUF”...
Page 14: Playing Tracks Repeatedly
Playing tracks repeatedly (Repeat Play) You can play tracks repeatedly in normal, shuffle or program play modes (see pages 15 and 16). On the remote (CFD- ZW750/ZW770 only) • Use ( instead of • When you have selected “REP 1”, select the track by pressing the number buttons.
Page 15: Playing Tracks In Random Order
Playing tracks in random order (Shuffle Play) You can play tracks in random order. On the remote (CFD- ZW750/ZW770 only) Use ( instead of ^. MODE Press p. “Cd” appears in the display. Press MODE until “SHUF” appears in the display. Press ^ to start shuffle play.
Page 16: Creating Your Own Program
Creating your own program (Program Play) You can make a program of up to 20 tracks in the order you want them to be played. On the remote (CFD- ZW750/ZW770 only) 1 Press p. 2 Press MODE until “PGM” appears in the display.
Page 17 Tips • You can play the same program again, since the program is saved until you open the disc compartment. • You can record your own program. After you’ve created the program, insert a blank tape into deck B and press r on deck B to start recording.
Page 18: Enjoying Sound Effects
Enjoying sound effects (LOOP/FLASH) You can repeat part of a CD (LOOP) and can “flash” the CD sound (FLASH) during playback. The CD Player Play a CD. Press and hold LOOP or FLASH at the point you want to start the function. repeat a selected part of a CD “flash”...
Page 19: The Radio
The Radio Presetting radio stations You can store radio stations into the player’s memory. You can preset up to 20 radio stations, 10 for each band in any order. On the remote (CFD- ZW750/ZW770 only) 1 Press BAND to select the band.
Page 20: Playing Preset Radio Stations
Playing preset radio stations Once you have preset the stations, use PRESET +/– on the player or the number buttons on the remote (CFD- ZW750/ZW770 only) to tune in to your favorite stations. On the remote (CFD- ZW750/ZW770 only) 1 Press BAND to select the band.
Page 21: The Timer
The Timer Setting the clock “--:--” indication appears in the display until you set the clock. The time display system of this player is the 12-hour system: AM12:00 = midnight PM12:00 = noon CLOCK Before you set the clock, connect the power source (pages 25 - 27).
Page 22: Waking Up To Music
Waking up to music You can wake up to music or a radio program at a preset time. Make sure you have set the clock (“Setting the clock” on page 21). The Timer TIMER STANDBY Before you begin, make sure the t (clock) indication is not lit in the display.
Page 23 Tips • To exit the standby mode, press STANDBY to make the t indication disappear from the display. • The preset settings remain until you reset them. • CFD-ZW770 only: The backlight in the display does not light while the waking up timer is on.
Page 24: Falling Asleep To Music
Falling asleep to music You can set the player to turn off automatically after 10, 20, 30, 60, 90, and 120 minutes, allowing you to fall asleep while listening to music. Tips • When you are playing radio or CD, make sure that ( of the tape player is not depressed.
Page 25: Setting Up
Setting Up Hooking up the system Make sure you turn off the power before making any connections. Tips • To detach the speakers, unlock speaker (see B on the diagram) and slide the speaker box all the way up and away from the player.
Page 26: Inserting Batteries Into The Remote
Hooking up the system (continued) Setting Up Connect the black wires to (–) minus and the red wires to (+) plus terminals; the right speaker wires to the R and the left speaker wires to the L terminals. 3 Connecting the AC power cord Insert one end of the supplied AC power cord to the AC IN socket located at the rear of the player, and the other end to the wall outlet.
Page 27: Using The Player On Batteries
Note CFD-ZW750/ZW770 only: When you operate the player on batteries: – you cannot turn on the player using the remote. – the backlight in the display does not light (CFD-ZW770 only). Replace the batteries when the OPR/BATT indicator dims or when the player stops operating.
Page 28: Selecting The Audio Emphasis
Selecting the audio emphasis (Sound Mode/MEGA BASS/ 5 BAND GRAPHIC EQUALIZER) You can adjust the audio emphasis of the sound you are listening to. Setting Up MEGA BASS Selecting the sound characteristic Press one of the SOUND buttons to select the sound characteristic you want.
Page 29 Note When adjusting the 5 BAND GRAPHIC EQUALIZER, be sure to press the MANUAL button. The graphic equalizer will not work in any other position. If you have selected MANUAL on page 28, slide 5 BAND GRAPHIC EQUALIZER to select the audio emphasis you want.
Page 30: Additional Information
• If the player has not been used for a long time, set it in the playback mode to warm it up for a few minutes before inserting a cassette. If you have any questions or problems concerning your player, please consult your nearest Sony dealer.
Page 31 Notes on CDs • Before playing, clean the CD with a cleaning cloth. Wipe the CD from the center out. • Do not use solvents such as benzine, thinner, commercially available cleaners or anti-static spray intended for vinyl LPs. • Do not expose the CD to direct sunlight or heat sources such as hot air ducts, nor leave it in a car parked in direct sunlight as there can be a...
Page 32: Troubleshooting
Troubleshooting Symptom The power is not on. There is no audio. “no disc“ lights in the display even when a CD is in place. The CD does not play. The sound drops out. The audio is weak or has poor quality.
Page 33 After all the indications in the display disappear, plug the power cord and insert the batteries again. If the problem persists, please consult your nearest Sony dealer. Remedy • Close the cassette compartment securely.
Page 34: Maintenance
Maintenance Cleaning the lens If the lens becomes dirty, it may cause a skipping of sound during CD operation. Clean with a commercially available blower. Cleaning the tape heads and tape path Wipe the heads, the pinch rollers and the capstans with a cleaning swab slightly moistened with cleaning fluid or alcohol after every 10 hours of operation for optimum playback and recording...
Page 35: Specifications
FM: Telescopic antenna AM: Built-in ferrite bar antenna Cassette-corder section Recording system 4-track 2 channel stereo Fast winding time Approx. 120 s (sec.) with Sony cassette C-60 Frequency response TYPE I (normal): 80 - 12,500 Hz General Speaker CFD-ZW700/ZW705/ZW750: Full range: 10 cm (4 in.) dia., 3.2 ohms, cone type (2)
Page 36 AC power cord 26 Creating your own program 16 D, E Demagnetizing the tape heads 34 Display 12 FLASH 18 Sony Corporation Printed in China Additional Information G, H GRAPHIC EQUALIZER I, J, K Improving broadcast reception 7 Listening to the radio 6...
