- Page 1 999807702 07/2017 en-GB The Formwork Experts. Floor props Eco 15 User Information Instructions for assembly and use (Method statement) © by Doka GmbH, A-3300 Amstetten...
-
Page 2: Elementary Safety Warnings
This booklet is aimed at all persons who will be work- This booklet can also be used as a generic method ing with the Doka product or system that it describes. statement or incorporated with a site-specific It contains information on the standard design for method statement. -
Page 3: Rules Applying During All Phases Of The Assignment
Doka verfassten technischen Dokumentationen zu safety inspections. gebrauchen sind. ▪ It is not permitted to modify Doka products; any such ▪ Die Standsicherheit und Tragfähigkeit sämtlicher modifications constitute a safety risk. Bauteile und Einheiten ist in jeder Bauphase sicher- zustellen! ▪... -
Page 4: Transporting, Stacking And Storing
▪ All components must be stored safely, following all the special Doka instructions given in the relevant CAUTION / WARNING / DANGER sections of this booklet! Failure to observe this may lead to material... -
Page 5: Product Description
User Information Floor props Eco 15 Product description Practical examples Doka floor props Eco are extendable floor props made of steel. They are designed for use as vertical props for temporary structures. Dokaflex 15 A Headplate B Inner tube C Fastening clamp... -
Page 6: Instructions For Assembly And Use (Method Statement)
User Information Floor props Eco 15 Instructions for assembly and use (Method statement) ➤ Setting up with tripod With the prop upright, use the adjusting nut for preci- sion adjustment. Applies only for use as free-standing props. Comply with the instructions in the applicable User Information booklet when using the props in combination with a formwork system. -
Page 7: Possible Incorrect Usages
User Information Floor props Eco 15 Possible incorrect usages Do not use as barrier to close off openings. WARNING ➤ The uses illustrated below are prohibited, as are other, similar uses! Use only perfectly upright and Baseplate must make full-sur- plumb. -
Page 8: Technical Condition
User Information Floor props Eco 15 Technical condition Threads The following quality criteria define the extent of dam- age permissible in terms of load-bearing strength. ▪ Use is prohibited if damage is beyond these limits. must be greased over entire length and action must be smooth. -
Page 9: Permitted Carrying Capacity
User Information Floor props Eco 15 Permitted carrying capacity ▪ Permitted load-bearing capacity from tests in accordance with US standards (ANSI) and as non- system-dependent construction prop: 15 kN ▪ Permitted load-bearing capacity as temporary reshores to British standards (BS): 22.5 kN ▪... - Page 10 [kg] Article n° [kg] Article n° Component overview [kg] Article n° Doka floor prop Eco 15 300 10.7 586290000 Length: 172 - 300 cm Doka floor prop Eco 15 350 13.3 586291000 Length: 197 - 350 cm Doka-Deckenstütze Eco 15...
- Page 11 User Information Floor props Eco 15 Component overview 999807702 - 07/2017...
- Page 12 70 countries, the Doka Group has a highly efficient dis- than 6000. tribution network which ensures that equipment and www.doka.com/floor-props Doka GmbH | Josef Umdasch Platz 1 | 3300 Amstetten | Austria | T +43 7472 605-0 | F +43 7472 66430 | info@doka.com | www.doka.com 999807702 - 07/2017...
