Page 2
Warning You are cautioned that any changes or modifications not expressly approved in this manual could void your authority to operate this equipment. This label is located on the bottom of the chassis. CAUTION INVISIBLE LASER RADIATION WHEN OPEN DO NOT STARE INTO BEAM OR VIEW DIRECTLY WITH OPTICAL INSTRUMENTS This label is located on the drive unit’s internal chassis.
Table of Contents Welcome ! ... 4 Precautions ... 4 About this manual ... 7 About discs this player can play ... 7 Resetting the player ... 9 Location of controls ... 10 Operation for Monitor Opening the display monitor ... 12 Selecting the input source ...
Welcome ! Thank you for purchasing this Sony Overhead DVD Entertainment System. You can enjoy its various features even more with: •DVD/Video CD/Audio CD playback. •MP3/JPEG file encoded disc playback. •MP3/JPEG/MPEG1 file encoded “Memory Stick” playback. •Support DTS/Dolby Digital through optical digital output terminal.
Page 5
On heat build-up Heat may build up in the player if it is used for an extended period of time. This, however, is not a malfunction. Moisture condensation On a rainy day or in a very damp area, moisture condensation may occur inside the lenses.
Page 6
If you have any questions or problems concerning your unit that are not covered in this manual, please consult your nearest Sony dealer. Before installing Make sure that the POWER SELECT switch is set to the correct position. A*: If your car has an accessory position on the ignition key.
About this manual The icons below are used in this manual: Icon Meaning Functions available for DVD VIDEOs or DVD-Rs/DVD-RWs in video mode Functions available for Video CDs or CD-Rs/CD-RWs in video CD format Functions available for music CDs or CD-Rs/CD-RWs in music CD format Functions available for files in MP3 format stored on CD-ROMs/CD-...
Page 8
Notes on CD-Rs (recordable CDs)/ CD-RWs (rewritable CDs)/DVD-Rs (recordable DVDs)/DVD-RWs (rewritable DVDs) •Some CD-Rs/CD-RWs/DVD-Rs/DVD-RWs (depending on the equipment used for its recording or the condition of the disc) may not play on this player. •You cannot play a CD-R/CD-RW/DVD-R/ DVD-RW that is not finalized*. •You cannot play a CD-R/CD-RW that is recorded in Multi Session.
Note on DTS-encoded CDs When playing DTS*-encoded CDs, excessive noise will be heard from the analogue stereo outputs. To avoid possible damage to the audio system, the consumer should take proper precautions when the analogue stereo outputs of this player are connected to an amplification system.
8 VOL (+/–) buttons 13, 14 To turn up or down the volume or to select the item during menu operation. XVM-R90D 9 EJECT button 18 Available to eject a disc from the player even when the player is turned off.
Page 11
Card remote commander RM-X137 DISPLAY POWER SEARCH CLEAR TOP MENU SUBTITLE MENU ANGLE ENTER AUDIO SETUP INPUT Refer to the pages listed for details. 1 DISPLAY button 21 To display the time information of the disc. 2 Number buttons (0 to 9) 17, 20, 25, 26 3 TOP MENU button 23, 25 To display the top menu of a recorded DVD.
Operation for Monitor Opening the display monitor OPEN POWER Slide (OPEN) to the front, and open the display monitor. Press (POWER) to turn on the player. If your car has no ACC (accessory) position on the ignition key switch and you set the POWER SELECT switch to the B position, the player does not turn on by pressing (POWER) on the card remote commander (page 6).
Selecting the input source You can select the input source for the monitor. DISPLAY POWER SEARCH CLEAR TOP MENU SUBTITLE MENU ANGLE ENTER AUDIO SETUP INPUT Press (POWER) to turn on the player. The current input source (DVD) appears on the screen for 5 seconds.
Changing the player and monitor settings VOL +/– REVERSE Turning off the speaker sound from the player Press (MENU) repeatedly to select “Speaker.” Each time you press (MENU), the setting screen changes as follows: Speaker t IR HP t FM Modulator t Picture t Brightness t Color t Hue* t Dimmer t Video Adjust t Mode t Blue Back t Menu Off...
Notes • When the output level is set to “High” in step 2, noise may be heard. • If noise is heard due to the interference with the local FM broadcast, change the FM transmission frequency. • When the FM modulator is turned off, you cannot change the frequency setting.
Page 16
When “Mode” is selected; “Full,” “Zoom,” “Normal,” or “Wide” can be set as the screen mode. Mode; Full /– Press or MENU. •“Full” An image with an aspect ratio of 4 to 3 enlarged to the left and right edges of the screen.
Various Playback This chapter describes various functions for playback. Playing a disc DISPLAY POWER DISPLAY POWER SEARCH SEARCH Number CLEAR CLEAR buttons TOP MENU SUBTITLE TOP MENU SUBTITLE MENU ANGLE MENU ANGLE ENTER ENTER AUDIO AUDIO </, ./> SETUP INPUT SETUP INPUT VOL –/+...
Page 18
Operation for playback Do this Stop playback Press x* Press (EJECT) on the Eject the disc player Pause Press u* Press again to resume playback Go to the next chapter, Press > track, or scene Go back to the Press . preceding chapter, track, or scene Fast forward/...
Resume playback During playback, press x to stop. The player memorises the point where playback is stopped. • DVD/Video CD/Audio CD “PRESS PLAY TO CONTINUE” flashes on the screen. Press u to start playback. When resume playback is activated, playback starts from the point where playback is stopped.
To turn off the menu display for MP3/JPEG/ MPEG1* files, set “SMART NAVI” to “NO MENU” (page 34). * Only when a “Memory Stick” is played. Notes • To deactivate the resume function, press x again while playback is stopped or eject the disc from the player.
Note Depending on the recording method and size of data, it may take some time before playback of the first track/file. To eject the “Memory Stick” Push in the “Memory Stick” momentarily, then remove it. Notes • Insert the “Memory Stick” in the correct direction.
• Video CD (when PBC is set to OFF)/CD I NGLE ELA SED 0 : 0 0 : 1 2 S I NGLE REMA I 0 : 0 4 : 4 5 OTAL ELA SED 0 : 0 6 : 3 2 OTAL REMA I N 0 : 4 1 : 1 5 Changing the subtitle...
Using a DVD menu With some DVDs you can use the original menu such as title menu and DVD menu. You can play your favourite scene or song by selecting titles of songs and scenes during a DVD playback. You can select an item, subtitle language, audio language etc.
Changing the audio language Some DVDs have multiple audio languages you can choose from. DISPLAY TOP MENU MENU ENTER INPUT During playback, press (AUDIO) repeatedly to select the desired audio language. The current audio language is displayed at the upper left. Example: an audio language display AUDIO 1/2: Dolby D 5.1 ENGLISH The format of the sound source...
Changing the audio output You can select the desired audio output from “STEREO,” “L-MONO,” “R-MONO,” or “MIX- MONO”during Video CD or Audio CD playback. DISPLAY POWER SEARCH CLEAR TOP MENU SUBTITLE MENU ANGLE ENTER AUDIO INPUT SETUP During playback, press (AUDIO). The current output is displayed at the upper left.
Changing Setup You can set up and adjust this player using the on-screen setup menu. Most settings need to be set when you first use this player. DISPLAY Number buttons TOP MENU MENU ENTER </, INPUT Setting the aspect ratio for the TV screen —...
Displaying the multi-angle notice — ANGLE MARK If various angles (multi-angles) for a scene are recorded on the DVD and you have set the “ANGLE MARK” to “ON,” a notice appears at the scene. Press (SETUP). The main page for setup appears. Press M or m repeatedly to select “GENERAL SETUP,”...
Selecting the audio output mode You can select the audio output setting from “S/PDIF/RAW” or “S/PDIF/PCM.” S/PDIF (Sony/Philips Digital Interface) is a standard of audio transfer file format. S/PDIF allows the transfer of audio, however, signal quality may be degraded.
Selecting the compression setting for the sound — DYNAMIC You can select the compression setting for the sound. If you set the DYNAMIC setting to “OFF” and watch an exciting movie, you can enjoy dynamic sound to its best effect. However, for example, if the sound is too dynamic and loud to hear low level sound such as human voices, try adjusting the...
Selecting the audio language for DVD — AUDIO Some DVDs have multiple audio languages you can select from. Press (SETUP) while playback is stopped. The main page for setup appears. Press M or m repeatedly to select “PREFERENCES,” then press (ENTER). Press M or m repeatedly to select “AUDIO,”...
Selecting the DVD menu language — DISC MENU You can select the display language for the DVD menu. Press (SETUP). The main page for setup appears. Press M or m repeatedly to select “PREFERENCES,” then press (ENTER). Press M or m repeatedly to select “DISC MENU,”...
Page 32
Press the number buttons to enter your password* (the same 4-digit number in step 6) again at “CONFIRM PWD.” * If you enter a wrong number, press (ENTER). All the numbers are cleared. Press (ENTER). Selecting the desired parental setting — PARENTAL Press (SETUP).
Changing your password — PASSWORD You can change your password for parental setting here. Follow the steps below. Press (SETUP). The main page for setup appears. Press M or m repeatedly to select “PREFERENCES,” then press (ENTER). Press M or m repeatedly to select “PASSWORD,”...
Setting the menu display for MP3/JPEG/MPEG1* files — SMART NAVI If you have set “SMART NAVI” to “WITH MENU” and play media containing MP3/ JPEG/MPEG1* files, the menu display for folder names and MP3/JPEG/MPEG1* files names will appear. You can easily search the desired MP3/JPEG/MPEG1* files with the “SMART NAVI”...
Connections Installation diagram Refer to the installation diagram and ask a qualified technician for the installation of the unit. XVM-R90D Rear Left speaker Subwoofer Front Left speaker Tweeter Left Rear Right speaker Be sure to securely fasten all equipment to the car chassis, etc., to prevent them...
Connection diagram Refer to the connection diagram for the proper connections. Note Set the POWER SELECT switch before installing (page 6). From the car aerial Aerial connector* Speaker system (optional) An adapter (optional) may be necessary for your car and car audio system. In such a case, consult your dealer.
Page 37
Black GND (1 m) Black GND (1 m) Yellow Back-up (5 m) Fuse (5 A) Filter box ACC (5 m) Fuse (1 A) Blue POWER REM (5 m) Max. supply current 0.3 A 4 Pin Power connector AUDIO/VIDEO INPUT On AUDIO/VIDEO INPUT connectors You can connect a VTR, etc.
If the fuse blows again after replacement, there may be an internal malfunction. In such a case, consult your nearest Sony dealer. Warning Never use a fuse with an amperage rating exceeding the one supplied with the unit as this could damage the unit.
Notes on discs •To keep the disc clean, do not touch the surface. Handle the disc by its edge. •Keep your discs in their cases or disc magazines when not in use. Do not subject the discs to heat/high temperature. Avoid leaving them in parked cars or on dashboards/rear trays.
About MP3 files MP3 (MPEG 1 Audio Layer-3) is a standard technology and format for compressing a sound sequence. The file is compressed to about 1/10 of its original size. Sounds outside the range of human hearing are compressed while the sounds we can hear are not compressed.
About “Memory Stick” What is a “Memory Stick”? “Memory Stick” is a compact, portable and versatile Integrated Circuit recording medium with a data capacity that exceeds a floppy disk. “Memory Stick” is specially designed for exchanging and sharing digital data among “Memory Stick”...
Page 42
On handling the “Memory Stick” LOCK •When the “Memory Stick” erasure prevention switch is set to “LOCK,” data cannot be recorded, erased or edited. ( B ) •Do not attach any other material than the supplied label on the label space. ( C ) •Attach the label so that it does not stick out from the proper attachment location.
Specifications System Laser Semiconductor laser Signal format system NTSC/PAL Audio characteristics Frequency response 20 Hz to 20 kHz Signal to noise ratio 90 dB (A) Harmonic distortion 0.05 % Dynamic range 90 dB Wow and flutter below measurable limits (±0.001% W PEAK) General Outputs FM output...
If the fuse is blown, replace it with a correctly rated fuse. t If the fuse blows again, consult your nearest Sony dealer. •The player may be overheated. t Make sure that the player is turned off. Wait until the player cools off, then press (POWER) again.
Page 45
Picture There is no picture. •Colour system setting has been changed manually while playing a DVD. t Change the setting according to the colour system of the DVD, turn off the player and turn it on again, or switch the input channel to “VIDEO,” then switch it to “DVD.”...
Error display Error displays The following indications will be displayed for about 8 seconds. POWER OFF ABNORMALITY in TEMP The surrounding temperature is too high or too low. t Operate the player at a temperature of 0 ˚C to 45 ˚C. REGION ERROR The region code of the DVD currently in the player does not conform to the player.
Language Code List The language spellings conform to the ISO 639: 1988 (E/F) standard. Code Language Code Language 6565 Afar 7089 Frisian 6566 Abkhazian 7165 Irish 6570 Afrikaans 7168 Scots/Gaelic 6577 Amharic 7176 Gallcian 6582 Arabic 7178 Guarani 6583 Assamese 7185 Gujarati 6588 Aymara 7265 Hausa...
Page 48
Advertencia Se le advierte de que la realización de cambios o modificaciones no aprobados explícitamente en este manual puede anular su autorización para utilizar este equipo. Esta etiqueta está situada en la parte inferior del chasis. CAUTION INVISIBLE LASER RADIATION WHEN OPEN DO NOT STARE INTO BEAM OR VIEW DIRECTLY WITH OPTICAL INSTRUMENTS Esta etiqueta está...
Page 49
Índice Bienvenido ... 4 Precauciones ... 4 Acerca de este manual ... 7 Discos compatibles con este reproductor ... 7 Reinicio del reproductor ... 9 Ubicación de los controles ... 10 Operación del monitor Apertura de la pantalla del monitor ... 12 Selección de la fuente de entrada ...
Bienvenido Gracias por adquirir este Reproductor suspendido de DVD para el auto de Sony. Disfrutará aún más de sus distintas funciones con: •Reproducción de DVD/Video CD/CD de audio. •Reproducción de discos de archivos MP3/ JPEG codificados. •Reproducción de “Memory Stick” de archivos MP3/JPEG/MPEG1 codificados.
Page 51
Acumulación de calor Se puede acumular calor en el reproductor si se utiliza durante un período de tiempo prolongado. No obstante, no se trata de ningún fallo de funcionamiento. Condensación de humedad En días lluviosos o en zonas muy húmedas, es posible que se condense humedad dentro de las lentes.
Page 52
Si desea realizar alguna consulta o solucionar algún problema relativo a la unidad y que este manual no trate, comuníquese con el proveedor Sony más cercano a su domicilio. Antes de la instalación Asegúrese de que el interruptor POWER SELECT está...
Acerca de este manual En este manual se utilizan los iconos que aparecen a continuación: Icono Significado Funciones disponibles para DVD VIDEO o DVD-R/DVD-RW en modo de video Funciones disponibles para Video CD o CD-R/CD-RW en formato de CD de video Funciones disponibles para CD de música o CD-R/CD-RW en formato de CD de música...
Page 54
Notas acerca de los discos CD-R (CD grabables)/CD-RW (CD regrabables)/ DVD-R (DVD grabables)/DVD-RW (DVD regrabables) •Es posible que algunos discos CD-R/CD- RW/DVD-R/DVD-RW no se reproduzcan en este reproductor, según el equipo utilizado para la grabación o el estado del disco. •No pueden reproducirse discos CD-R/ CD-RW/DVD-R/DVD-RW que no estén finalizados.*...
Nota acerca de los CD con codificación DTS Al reproducir un CD con codificación DTS*, se escuchará un exceso de ruido en las salidas analógicas estéreo. Para evitar posibles daños en el sistema de audio, tome las precauciones necesarias cuando las salidas analógicas estéreo del reproductor estén conectadas a un sistema de amplificación.
8 Botones VOL (+/–) 13, 14 Para subir o bajar el volumen, o para seleccionar el elemento durante las funciones de menú. XVM-R90D 9 Botón EJECT 18 Para expulsar un disco del reproductor aunque el reproductor esté apagado. q; Ranura para “Memory Stick” 20 qa Botón x (detener) 18, 21...
Page 57
Mando a distancia de tarjeta RM-X137 DISPLAY POWER SEARCH CLEAR TOP MENU SUBTITLE MENU ANGLE ENTER AUDIO SETUP INPUT Consulte las páginas indicadas para obtener información detallada. 1 Botón DISPLAY 21 Para mostrar la información de tiempo del disco. 2 Botones numéricos (0 a 9) 17, 20, 25, 26 3 Botón TOP MENU 23, 25 Para mostrar el menú...
Operación del monitor Apertura de la pantalla del monitor OPEN POWER Deslice (OPEN) hacia delante y abra la pantalla del monitor. Presione (POWER) para encender el reproductor. Sugerencia Si su auto no tiene posición ACC (accesorio) en el interruptor de la llave de encendido y ajusta el selector POWER SELECT en la posición B, el reproductor no se encenderá...
Selección de la fuente de entrada Seleccione la fuente de entrada del monitor. DISPLAY POWER SEARCH CLEAR TOP MENU SUBTITLE MENU ANGLE ENTER AUDIO SETUP INPUT Presione (POWER) para encender el reproductor. La fuente de entrada actual (DVD) aparecerá en la pantalla durante 5 segundos.
Modificación de los ajustes del reproductor y el monitor VOL +/– REVERSE Desactivación del sonido del altavoz desde el reproductor Presione (MENU) varias veces para seleccionar “Speaker”. Cada vez que presione (MENU), la pantalla de ajustes cambiará de la forma siguiente: Speaker (Altavoz) t IR HP t FM Modulator (Modulador de FM) t Picture (Imagen) t Brightness (Brillo) t...
Notas • Si el nivel de salida se ajustó en “High” en el paso 2, es posible que se oiga ruido. • Si se oye ruido debido a la interferencia con la emisión de FM local, cambie la frecuencia de transmisión de FM.
Page 62
Cuando “Mode” está seleccionado; Es posible ajustar los valores “Full”, “Zoom”, “Normal”, o “Wide” como el modo de pantalla. Mode; Full /– Press or MENU. •“Full” Imagen con una relación de aspecto de 4 a 3 aumentada hacia los lados izquierdo y derecho de la pantalla.
Diversas funciones de reproducción En este capítulo se describen diversas funciones de reproducción. Reproducción de discos DISPLAY POWER DISPLAY POWER SEARCH SEARCH Botones CLEAR CLEAR numéricos TOP MENU SUBTITLE TOP MENU SUBTITLE MENU ANGLE MENU ANGLE ENTER ENTER AUDIO AUDIO </, ./>...
Page 64
Operación de reproducción Para Haga lo siguiente Detener la reproducción Presione x* Presione (EJECT) en Expulsar el disco el reproductor Insertar una pausa Presione u* Vuelva a presionarlo para reanudar la reproducción Pasar al capítulo, Presione > pista o escena siguiente Retroceder al capítulo, Presione .
Page 65
Reanudación de la reproducción Presione x durante la reproducción para detenerla. La unidad memorizará el punto en el cual detuvo la reproducción. • DVD/Video CD/CD de audio “PRESS PLAY TO CONTINUE” parpadea en la pantalla. Presione u para iniciar la reproducción. Cuando está...
Para desactivar la pantalla de menú para archivos MP3/JPEG/MPEG1*, ajuste “SMART NAVI” en “NO MENU” (página 34). * Sólo si se reproduce un “Memory Stick”. Notas • Para desactivar la función de reanudación, vuelva a presionar x mientras la reproducción está detenida o expulse el disco del reproductor.
Nota Según el método de grabación y el tamaño de los datos, la reproducción de la primera pista o el primer archivo puede demorar un poco. Para expulsar el “Memory Stick” Empuje hacia dentro el “Memory Stick” un momento y, a continuación, extráigalo. Notas •...
• Video CD (si PBC se ajustó en OFF)/CD I NGLE ELA SED 0 : 0 0 : 1 2 S I NGLE REMA I 0 : 0 4 : 4 5 OTAL ELA SED 0 : 0 6 : 3 2 OTAL REMA I N 0 : 4 1 : 1 5 Cambio del idioma de los...
Uso de un menú DVD Con algunos DVD se puede utilizar el menú original, como sería el menú de títulos y menú DVD. Puede reproducir su escena o canción favoritas seleccionando títulos de canciones y escenas durante la reproducción de un DVD. Puede elegir un elemento, el idioma de los subtítulos, el idioma del audio, etc.
Cambio del idioma del audio Algunos DVD permiten escuchar el sonido en varios idiomas. DISPLAY TOP MENU MENU ENTER INPUT Presione (AUDIO) varias veces durante la reproducción para seleccionar el idioma del audio que desea. El idioma del audio actual se muestra en la parte superior izquierda de la pantalla.
Cambio de la salida de audio Puede seleccionar la salida de audio que desea entre las opciones “STEREO”, “L-MONO”, “R-MONO” o “MIX-MONO” durante la reproducción de un Video CD o CD de audio. DISPLAY POWER SEARCH CLEAR TOP MENU SUBTITLE MENU ANGLE ENTER...
Cambio de la configuración Puede configurar y ajustar el reproductor con el menú de ajustes en pantalla. La mayoría de los ajustes deben configurarse la primera vez que utilice el reproductor. DISPLAY Botones numéricos TOP MENU MENU ENTER </, INPUT Ajuste del formato de la pantalla del televisor —...
Visualización del aviso de varios ángulos — ANGLE MARK Si se grabaron varios ángulos para una escena en un DVD y la opción “ANGLE MARK” se ajustó en “ON”, aparecerá un aviso en la escena. Presione (SETUP). Aparecerá la pantalla principal de ajustes. Presione M o m varias veces para seleccionar “GENERAL SETUP”...
Puede configurar el ajuste de salida de audio en “S/PDIF/RAW” o “S/PDIF/PCM”. S/PDIF (Interfaz digital de Sony/Philips) es un estándar de formato de archivo de transferencia de audio. S/PDIF permite la transferencia de audio, aunque es posible que la calidad de la señal se deteriore.
Selección del ajuste de compresión del sonido — DYNAMIC Puede seleccionar el ajuste de compresión del sonido. Si ajusta la opción DYNAMIC en “OFF” y mira una película con mucha acción, podrá disfrutar de los mejores efectos del sonido dinámico. No obstante, si el sonido es demasiado dinámico y alto para percibir sonidos más bajos, como las voces humanas, es conveniente que ajuste el rango dinámico.
Selección del idioma del audio de un DVD — AUDIO Algunos DVD ofrecen una amplia selección de idiomas de audio. Presione (SETUP) mientras la reproducción está detenida. Aparecerá la pantalla principal de ajustes. Presione M o m varias veces para seleccionar “PREFERENCES”...
Selección del idioma del menú DVD — DISC MENU Puede seleccionar el idioma de visualización del menú DVD. Presione (SETUP). Aparecerá la pantalla principal de ajustes. Presione M o m varias veces para seleccionar “PREFERENCES” y, a continuación, presione (ENTER). Presione M o m varias veces para seleccionar “DISC MENU”...
Page 78
Presione los botones numéricos para ingresar el número de 4 dígitos que desea en “NEW PASSWORD”. Presione los botones numéricos para ingresar nuevamente la contraseña* (el mismo número de 4 dígitos del paso 6) en “CONFIRM PWD”. * Si ingresa un número equivocado, presione (ENTER).
Cambio de la contraseña — PASSWORD Puede cambiar su contraseña para la función de control de bloqueo. Siga los pasos que se muestran a continuación. Presione (SETUP). Aparecerá la pantalla principal de ajustes. Presione M o m varias veces para seleccionar “PREFERENCES”...
Ajuste de la pantalla de menú para archivos MP3/ JPEG/MPEG1* — SMART NAVI Si ajustó la opción “SMART NAVI” en “WITH MENU” y reproduce un soporte que contiene archivos MP3/JPEG/MPEG1*, aparecerá la pantalla de menú de nombres de carpetas y nombres de archivos MP3/JPEG/MPEG1*.
Conexiones Diagrama de instalación Consulte el diagrama de instalación y acuda a un técnico calificado para instalar la unidad. XVM-R90D Altavoz posterior izquierdo Altavoz potenciador de graves Altavoz de agudos Altavoz frontal izquierdo izquierdo Unidad principal Altavoz posterior derecho Fije el equipo con firmeza en el chasis del vehículo, etc.
Diagrama de las conexiones Consulte el diagrama de las conexiones para hacerlas correctamente. Nota Ajuste el selector POWER SELECT antes de realizar la instalación (página 6). Desde la antena del auto Conector de la antena* Sistema de altavoces (opcional) Puede que sea necesario un adaptador (opcional) para el auto y el equipo de sonido de su auto.
Page 83
Negro GND (1 m) Negro GND (1 m) Amarillo Respaldo (5 m) Fusible de 5 A Caja de filtros Rojo ACC (5 m) Fusible de 1 A Azul POWER REM (5 m) Corriente máxima de 0,3 A Conector de alimentación de 4 pines AUDIO/VIDEO INPUT Conectores AUDIO/VIDEO INPUT Puede conectar una videograbadora, etc.
Si el fusible se funde de nuevo después de sustituirlo, es posible que exista algún problema de funcionamiento interno. En tal caso, consulte a su distribuidor Sony más cercano. Advertencia No use nunca un fusible cuyo amperaje supere al del suministrado con la unidad porque puede dañarse la unidad.
Notas sobre los discos •Para mantener limpios los discos, no toque su superficie. Sujételos por los bordes. •Guarde los discos en sus cajas o en los cargadores de discos cuando no los use. No someta los discos al calor ni a altas temperaturas.
Acerca de los archivos MP3 (MPEG 1 Audio Layer-3) es una tecnología y un formato estándar para la compresión de una secuencia de sonido. El archivo se comprime a casi 1/10 de su tamaño original. Se comprimen los sonidos que no percibe el oído humano, mientras que los que sí...
Acerca del “Memory Stick” ¿Qué es un “Memory Stick”? “Memory Stick” es un soporte de grabación con circuito integrado portátil y versátil con una capacidad de datos que excede la de un disco flexible. El “Memory Stick” está especialmente diseñado para intercambiar y compartir datos digitales entre productos compatibles con “Memory Stick”.
Page 88
Sobre la manipulación del “Memory Stick” LOCK •Cuando el interruptor de protección contra borrado del “Memory Stick” se encuentra en la posición “LOCK” (Bloqueado), no podrán grabarse, borrarse ni editarse los datos. ( B ) •No adjunte ningún otro material en el espacio para la etiqueta que no sea la etiqueta suministrada.
Especificaciones Sistema Láser Láser semiconductor Sistema de NTSC/PAL formato de señales Características de audio Respuesta de frecuencia De 20 Hz a 20 kHz Relación señal-ruido 90 dB (A) Distorsión armónica 0,05% Rango dinámico 90 dB Fluctuación y trémolo Por debajo de límites medibles (±0,001% W PEAK) Generales...
Si el fusible está fundido, reemplácelo con otro fusible de las características adecuadas. t Si el fusible se funde de nuevo, póngase en contacto con el distribuidor de Sony más próximo. •Es posible que el reproductor se haya recalentado.
Page 91
Imagen No hay imagen. •El ajuste del sistema de color se ha cambiado manualmente durante la reproducción del DVD. t Cambie el ajuste en función del sistema de color del DVD, apague el reproductor y vuelva a encenderlo, o bien cambie el canal de entrada a “VIDEO”...
Indicaciones de error Indicaciones de error Las siguientes indicaciones se mostrarán durante unos 8 segundos. POWER OFF ABNORMALITY in TEMP La temperatura ambiente es demasiado alta o baja. t Utilice el reproductor a una temperatura que oscile entre 0 °C y 45 °C. REGION ERROR El código de región del DVD que contiene el reproductor no es compatible con el...
Page 109
各种播放 本章说明各种播放功能。 播放光碟 DISPLAY POWER DISPLAY POWER SEARCH SEARCH CLEAR CLEAR 数字按钮 TOP MENU SUBTITLE TOP MENU SUBTITLE MENU ANGLE MENU ANGLE ENTER ENTER AUDIO AUDIO </, ./> SETUP INPUT SETUP INPUT VOL –/+ 1 按 (POWER) 按钮开启播放机。 显示器打开,播放机上 POWER 按钮的绿色 灯亮起。...
Page 114
• Video CD(PBC 设定为 OFF)/CD I NGLE ELA SED 0 : 0 0 : 1 2 S I NGLE REMA I 0 : 0 4 : 4 5 OTAL ELA SED 0 : 0 6 : 3 2 OTAL REMA I N 0 : 4 1 : 1 5 改变字幕语言 ...
Page 115
使用 DVD 菜单 对于某些 DVD,您可以使用 Title 菜单和 DVD 菜单等初始菜单。播放 DVD 时,您可以通过选 择歌曲和场面的标题来播放您喜爱的场面或歌 曲。您可以用 DVD 菜单选择项目、字幕语言、 音频语言等。标题菜单和 DVD 菜单的内容视 DVD 的不同而异。某些 DVD 可能未录制菜单。 DISPLAY POWER SEARCH CLEAR TOP MENU SUBTITLE TOP MENU MENU ANGLE MENU ENTER AUDIO SETUP INPUT 使用 TOP MENU(顶部菜单)按钮 某些 DVD 有标题菜单。您可以从标题菜单中选择 标题进行播放。标题是 DVD 中最长的图像或音乐 部分,例如电影,或音频软件的整个文件夹等。 TOP MENU 按钮可用于显示初始菜单屏幕。 在播放 DVD 时, 按 (TOP MENU) 按钮。 显示顶部菜单(标题)*。 * 顶部菜单的内容视 DVD 的不同而异。 按 M/,/m/< 选择想要的标题。 按 (ENTER) 按钮。 开始播放您选择的标题。 使用 MENU(菜单)按钮 某些 DVD 有包含音频语言、字幕语言、标题和 章等项目的更为广泛的菜单。...
Page 116
改变音频语言 某些 DVD 中有多种音频语言可供选择。 DISPLAY POWER SEARCH CLEAR TOP MENU SUBTITLE MENU ANGLE ENTER AUDIO INPUT SETUP 播放期间,反复按 (AUDIO) 按钮选择所需 的音频语言。 当前的音频语言显示在左上角。 例如,显示音频语言 AUDIO 1/2: Dolby D 5.1 ENGLISH 可能会出现声源格式(Dolby D、DTS 或 LPCM)。 出现语言代码显示时,请输入所需语言的语言 代码(第 47 页)。当显示相同的语言显示两 次或多次,则此 DVD 是以多音频格式录制。 注意 • 仅当 DVD 上录制有多种音频语言时,您才可以切换 音频语言。 • 您还可以用 DVD 菜单(第 23 页)或设定屏幕* (第 30 页)改变音频语言。 * 您可以用设定屏幕改变为特定的音频语言(仅限于 光碟和设定屏幕中都包含有的语言)。 •...
Page 117
改变音频输出 播放 VCD 或音频 CD 时,您可以选择想要的音 频输出:“STEREO”(立体声)、“L-MONO” (左单声道)、“R-MONO”(右单声道)或 “MIX-MONO”(混合单声道)。 DISPLAY POWER SEARCH CLEAR TOP MENU SUBTITLE MENU ANGLE ENTER AUDIO SETUP INPUT 1 播放期间,按 (AUDIO) 按钮。 当前输出显示在左上角。 例如,显示音频输出 L - M O N O 2 显示输出时,请按 (AUDIO) 按钮选择想要 的输出:“STEREO”、“L-MONO”、“R- MONO”或“MIX-MONO”。 您每按一下 (AUDIO) 按钮,输出将改变。 使用 PBC(播放控制)功 能 播放 PBC 相容的 VCD 时,您可以显示 PBC 菜 单并从菜单中选择项目。 DISPLAY 数字按钮 TOP MENU TOP MENU MENU AUDIO...
Page 118
改变设定 您可以用屏幕设定菜单设定并调整本播放机。 第一次使用本播放机时,大多数设定值都需要 设定。 DISPLAY 数字按钮 TOP MENU MENU ENTER </, INPUT 设定电视机屏幕高宽比 — TV SCREEN 当您将播放机与电视机连接以便在电视机屏幕 上观看 DVD 时,请根据电视机屏幕的类型进行 此设定。 1 按 (SETUP) 按钮。 出现设定主页面。 “PREFERENCES”才可用。 SETUP MENU -- MAIN PAGE GENERAL SETUP SPEAKER SETUP AUDIO SETUP PREFERENCES EXIT SETUP GENERAL SETUP 2 反复按 M 或 m 选择“GENERAL SETUP” (一般设定),然后按 (ENTER) 按钮。...
Page 119
显示多角度提示 — ANGLE MARK 如果 DVD 上有录制了各种角度(多角度)的场 面,且您已将“ANGLE MARK”设定为“ON”, 则场面上将出现提示。 1 按 (SETUP) 按钮。 出现设定主页面。 2 反复按 M 或 m 选择“GENERAL SETUP” (一般设定),然后按 (ENTER) 按钮。 3 反复按 M 或 m 选择“ANGLE MARK”(角 度标记),然后按 ,。 -- GENERAL PAGE - - TV DISPLAY ANGLE MARK SCR SAVER MAIN PAGE TURN ANGLE MARK OFF 4 反复按 M 或 m 选择“ON”。 5 按 (ENTER) 按钮。 “ANGLE MARK ON”(角度标记开启)显示 在监视器的左下角。 要关闭多角度提示,请在步骤 4 中选择 “OFF”。 要返回到正常的播放屏幕,任何时候都可按...
Page 120
选择扬声器模式 — SPEAKER SETUP 您可以将扬声器模式设定选择为“LT/RT”或 “STEREO”。此声道合并功能可用于从音源的 5 个以上的独立数字信号创造立体声(双声 道)信号。 LT-RT:影院声道合并模式。 STEREO:立体声声道合并模式。 1 按 (SETUP) 按钮。 出现设定主页面。 2 反复按 M 或 m 选择“SPEAKER SETUP” (扬声器设定),然后按 (ENTER) 按钮。 3 反复按 M 或 m 选择“DOWNMIX”(声道合 并),然后按 ,。 -- SPEAKER SETUP PAGE - - DOWNMIX MAIN PAGE SET STEREO DOWNMIX 4 反复按 M 或 m 选择想要的项目 (“STEREO”或“LT/RT”)。 5 按 (ENTER) 按钮。 例如,如果您在步骤 4 中选择了 “LT/RT”,则“LT/RT DOWNMIX”显示在监 视器的左下角。 要返回到正常的播放屏幕,任何时候都可按 (SETUP) 按钮。 注意...
Page 121
选择声音压缩设定 — DYNAMIC 您可以选择声音的压缩设定。如果您将 DYNAMIC 设定设置为“OFF”且正在观看激动人 心的电影,则可以欣赏到效果最佳的动态声 音。但是,例如,如果声音的动态效果太强且 声音太大以致于无法听到低电平声音(如人的 声音),请调整动态范围。 1 按 (SETUP) 按钮。 出现设定主页面。 2 反复按 M 或 m 选择“AUDIO SETUP”(声 音设定),然后按 (ENTER) 按钮。 3 反复按 M 或 m 选择“DYNAMIC”(动 态),然后按 ,。 -- AUDIO SETUP - - AUDIO OUT DYNAMIC MAIN PAGE DYNAMIC RNG COMPRESSION OFF 4 反复按 M 或 m 选择想要的项目 (“FULL”、“HIGH”、“MID”或 “LOW”)。 5 按 (ENTER) 按钮。 要关闭声音音量的动态范围,请在步骤 4 中选 择“OFF”。 要返回到正常的播放屏幕,任何时候都可按...
Page 122
选择 DVD 音频语言 — AUDIO 某些 DVD 中有多种音频语言可供选择。 1 播放停止时按 (SETUP)。 出现设定主页面。 2 反复按 M 或 m 选择“PREFERENCES”(喜 好设定),然后按 (ENTER) 按钮。 3 反复按 M 或 m 选择“AUDIO”(声音), 然后按 ,。 -- PREFERENCES PAGE - - COLOR SYSTEM AUDIO SUBTITLE DISC MENU PARENTAL PASSWORD DEFAULTS SMART NAVI SET PREFERENCE TO ENGLISH 4 反复按 M 或 m 选择想要的项目 (“ENGLISH”(英语)、“FRENCH”(法 语)、“SPANISH”(西班牙语)或 “JAPANESE”(日语))。 如果您选择“OTHERS”(其它),请输入 “语言代码一览表”(第 47 页)中的语言 代码。...
Page 123
选择 DVD 菜单语言 — DISC MENU 您可以为 DVD 菜单选择需要的语言。 1 按 (SETUP) 按钮。 出现设定主页面。 2 反复按 M 或 m 选择“PREFERENCES”(喜 好设定),然后按 (ENTER) 按钮。 3 反复按 M 或 m 选择“DISC MENU”(光碟 菜单),然后按 ,。 -- PREFERENCES PAGE - - COLOR SYSTEM AUDIO SUBTITLE DISC MENU PARENTAL PASSWORD DEFAULTS SMART NAVI SET PREFERENCE TO ENGLISH 4 反复按 M 或 m 选择想要的项目 (“ENGLISH”(英语)、“FRENCH”(法 语)、“SPANISH”(西班牙语)或 “JAPANESE”(日语))。 如果您选择“OTHERS”(其它),请输入 “语言代码一览表”(第 47 页)中的语言 代码。...
Page 124
7 按数字按钮,在“CONFIRM PWD.”(确认密 码)中再次输入您的密码*(与步骤 6 中相 同的 4 位数号码)。 * 如果输入错误,请按 (ENTER) 按钮。所有的数 字都被清除。 8 按 (ENTER) 按钮。 选择想要的视听者设定 — PARENTAL 1 按 (SETUP) 按钮。 出现设定主页面。 2 反复按 M 或 m 选择“PREFERENCES”(喜 好设定),然后按 (ENTER) 按钮。 3 反复按 M 或 m 选择“PARENTAL”(视听 者控制),然后按 ,。 -- PREFERENCES PAGE - - COLOR SYSTEM AUDIO SUBTITLE DISC MENU PARENTAL PASSWORD DEFAULTS SMART NAVI SET TO NO_PARENTAL 4...
Page 125
更改密码 — PASSWORD 您可以改变视听者设定的密码。请按照以下步 骤操作。 1 按 (SETUP) 按钮。 出现设定主页面。 2 反复按 M 或 m 选择“PREFERENCES”(喜 好设定),然后按 (ENTER) 按钮。 3 反复按 M 或 m 选择“PASSWORD”(密 码),然后按 ,。 -- PREFERENCES PAGE - - COLOR SYSTEM AUDIO SUBTITLE DISC MENU PARENTAL PASSWORD DEFAULTS SMART NAVI CHANGE PASSWORD 4 按 , 选择“CHANGE”,然后按 (ENTER)。 5 按数字按钮依次输入您的旧密码,新密码, 然后再次输入新密码进行确认。 PASSWORD CHANGE PAGE OLD PASSWORD: NEW PASSWORD: CONFIRM PWD:...
Page 126
设定 MP3/JPEG/MPEG1* 文 件的菜单显示 — SMART NAVI 如果您已将“SMART NAVI”设置为“WITH MENU”并且播放包含 MP3/JPEG/MPEG1* 文件的 媒体时,将出现文件夹名和 MP3/JPEG/MPEG1* 文件名的菜单显示。您可以用“SMART NAVI” 菜单显示方便地搜索想要的 MP3/JPEG/MPEG1* 文件。 1 按 (SETUP) 按钮。 出现设定主页面。 2 反复按 M 或 m 选择“PREFERENCES”(喜 好设定),然后按 (ENTER) 按钮。 3 反复按 M 或 m 选择“SMART NAVI”,然 后按 ,。 -- PREFERENCES PAGE - - COLOR SYSTEM AUDIO SUBTITLE DISC MENU PARENTAL PASSWORD DEFAULTS SMART NAVI MENU MODE 4 按 , 选择“WITH MENU”。 5...
