SERVICE MANUAL
Ver 1.1 2001.08
This set is automatic electrical adjustment.
System
Mini disc digital audio system
Laser Diode Properties
Material: GaAlAs
Wavelength: 780nm
Emission Duration: Continuous
Laser out-put Power: Less than 44.6 W*
* This output is the value measured at a distance
of 200 mm from the objective lens surface on
the Optical Pick-up Block.
Frequency response
20–20,000 Hz
Wow and flutter
Below measurable limit
Signal-to-noise ratio
95 dB
Output
Bus control output (8 PIN)
Analog audio output (RCA PIN)
Sony Corporation
9-925-528-12
2001H0500-1
e Vehicle Company
C 2001.8
Shinagawa Tec Service Manual Production Group
MDX-61
Model Name Using Similar Mechanism
Base Mechanism Type
Optical Pick-Up Name
SPECIFICATIONS
Current drain
300 mA (MD playback)
600 mA (during loading or ejecting a disc)
Dimensions Approx. 176 83.5 125 mm
(7 3
3
/
8
not incl. projecting parts and controls
Mass
Approx. 1.1 kg (2 lb. 7 oz.)
Power requirement
12 V DC car battery
(negative ground)
Supplied accessories
Mounting hard ware (1 set)
Bus cable 5.5 m (1)
RCA pin cord 5.5 m (1)
U.S. and foreign patents licensed from Dolby Laboratories
Licensing Corporation.
Design and specifications subject to change without notice.
US Model
Canadian Model
AEP Model
UK Model
E Model
5 in.) (w/h/d)
– Continued on next page –
MINIDISC CHANGER
MDX-60
MG-798-133
KMS-193C/J2N
