PPA SLIDING User Manual

User manual
OPERATOR FOR
SLIDING
Position the QR
code reader of
your smarthphone
and obtain more
information at
PPA website.
Before using the OPERATOR, carefully read and follow all instructions in
this manual.
This appliance is not intended for use by persons (including children) with reduced physical,
sensory or mental capabilities or by persons lacking experience and knowledge, unless instructed to
use the appliance or under the supervision of a person Responsible for their safety. It is recommended
that children are guided and supervised to ensure that they do not play with the product.
It is important for people's safety to follow all instructions. Keep these
instructions.
- For correct use, read this user manual carefully.
- All data provided in this manual is for information only. PPA reserves the
right to modify these information without previous notice.

IMPORTANT SAFETY INSTRUCTIONS

WARNING: Important safety instructions. Follow all instructions in this
manual. Incorrect installation can lead to serious injury.
- Do not allow children to handle the equipment remote control. Keep the remote
control away from children, avoiding unnecessary openings and, consequently,
decreasing the safety of the place;
- Do not operate the system unless you are certain that there are no children,
animals, objects or obstacles in or near the gate path;
- Do not automate gates that have wicket doors;
- Disconnect the mains (power supply) when performing cleaning or any
maintenance. The maintenance / installation of the operator system must be executed by a
specialized technician;
- Oftenly check the installation, safety system, fixing brackets, mechanical wear, damage or
imbalance, good mechanical condition (proper opening and closing). Perform a periodic cleaning
on the gate guide to prevent rusting which requires more power from the operator. Do not perform

ATTENTION

Do not operate the equipment without
first reading the instruction manual.
GATE
repairs or adjustments on your own. Look for a qualified technician to perform the repairs, as
improper installation or repair failure can cause injury to the user;
- This appliance is considered suitable for use in countries with a hot weather and constant
humidity. It can also be used in other countries as long as the temperature range described in the
technical specifications in the technical manual (available at www.ppa.com.br) is respected;
- It is very important to wait until the operator stops moving and to keep people away until the
gate is completely open or closed;
- If the power cord is damaged, ask a technician to replace it in order to avoid risks. The use of
grounding wire is required;
- Before installation, it is necessary to check, on the identification label, whether the temperature
range of the equipment is suitable for the installation site.
- Caution when using the operator unlock system for a manual gate drive;
- Operators must be installed internally and shall not advance over public ways.

IDENTIFICATION OF EQUIPMENT

For additional user safety, PPA operators have identification and instruction marking labels.
Identification label
ATTENTION
Always check the condition of the labels. If adhesives become damaged or
illegible, purchase another ones from a PPA Representative.

SHUTDOWN MEANS

For complete shutdown of the operator, it is necessary to use a shutdown device that must be
incorporated into fixed wiring and located near the operator.
Examples of total shutdown devices: Circuit breakers, ON / OFF switch, etc.
Note: The total shut-off device incorporated in the fixed wiring must guarantee the
disconnection of all the conductors of the electrical network, except the GND.

REMOTE CONTROL

The PPA remote control is made of special and resistant material. When it is not responding
to the commands and the LED intensity is reduced or, depending on the model, the LED changes
to red, it may be necessary to replace the battery.
When inserting the new battery, note the polarity (+ and -) indicated on the base of the
transmitter.
Remote control functions:
Command
Button 1
Note: In order to configure a new the remote control, consult a qualified technician.
Manual Unlocking Label
Manual Unlocking
Insert the key into the
Pull the lever
lever and turn it all the way
Conduit
Shutdown
device
Command
Button 2
