The CDX-424RF is a compact disc changer
system comprised of the remote commander, the
hideaway (modulator) unit and the CD changer.
The hideaway unit modulates the audio signal
from the CD changer into the RF (Radio
Frequency) signal that can be received by the
existing FM tuner of your car audio. Therefore
you can enjoy CD playback with your car audio
even if it has no input terminals for a compact
disc player.
•Compact and space saving CD changer for
vertical, horizontal, suspended or inclined
installation in your car.
•Supplied wired remote enables you to control
the CD changer even if it is installed in the
trunk of your car.
•Repeat play function for playing a track or a
disc repeatedly.
•Shuffle play function for playing tracks of
one disc or of all discs in random order.
Specifications
CD changer (CDX-424RF)
System
Compact disc digital audio
system
Laser Diode Properties
Material: GaAlAs
Wavelength: 780 nm
Emission
Duration: Continuous
Laser out-put Power: Less
than 44.6 µW*
* This output is the value measured at a distance of
200 mm from the objective lens surface on the
Optical Pick-up Block.
Frequency response
10 – 20,000 Hz
Wow and flutter
Below than the measurable
limit
Signal-to-noise ratio
94 dB
Output terminals
BUS control output terminal
(8 pin)
Analog audio output
terminal (RCA pin)
Current drain
800 mA (at playback)
800 mA (at disc loading/
ejecting)
Operating temperature
–10 °C to +55 °C
(14 °F to 131 °F)
Dimensions
Approx. 262
90
181.5 mm
3
5
1
(10
/
3
/
7
/
in.)
8
8
4
(w/h/d)
Mass
Approx. 2.1 kg (4 lb. 10 oz.)
Hideaway unit/
Wired remote (RM-X64)
Frequency
88.3 MHz/88.5 MHz/
88.7 MHz/88.9 MHz/
89.1 MHz/89.3 MHz/
89.5 MHz/89.7 MHz/
89.9 MHz (switchable)
Dimensions
Hideaway unit:
Approx. 124.8 30.0
99.8
mm (5
1
3
/
4 in.)
16
(w/h/d)
Wired remote:
Approx. 148
30 15 mm
7
3
19
(5
/
1
/
/
in.)
8
16
32
(w/h/d)
Mass
Hideaway unit:
Approx. 330 g (11.64 oz.)
Wired remote:
Approx. 120 g (4.2 oz.)
Supplied accessories
Disc magazine (1)
Parts for installation and
connections (1 set)
Optional accessories
CD single adaptor CSA-8
Disc magazine XA-250
Design and specifications subject to change without
notice.
Caractéristiques
Le système CDX-424RF comprend une
télécommande, un modulateur et un changeur
de CD. Le modulateur transforme le signal
audio du changeur de CD en un signal de
fréquence radio (RF) qui peut être reçu par le
tuner FM de votre autoradio. Ainsi, vous
pouvez écouter des disques compacts en voiture
même si votre autoradio n'est pas équipé de
bornes d'entrée pour lecteur de CD.
•Chargeur de CD compact et peu encombrant
pouvant être installé verticalement,
horizontalement, en suspension ou en oblique
dans votre voiture.
•Télécommande fournie qui permet de
commander le changeur de CD installé dans le
coffre de la voiture.
•Lecture répétée pour écouter plusieurs fois
une plage ou un disque.
•Lecture aléatoire pour écouter les plages d'un
disque ou de tous les disques dans un ordre au
hasard.
Spécifications
Changeur de CD (CDX-424RF)
Système
Système audionumérique à
disque compact
Réponse en fréquence
10 – 20,000 Hz
Pleurage et scintillement Inférieurs à la limite
mesurable
Rapport signal sur bruit
94 dB
Bornes de sortie
Sortie de commande BUS
(8 broches)
Sortie audioanalogique
(broches RCA)
Consommation de courant
800 mA (lecture)
800 mA (charge/éjection de
disque)
Température de fonctionnement
–10 °C à + 55 °C
(14 °F à 131 °F)
Dimensions
Env. 262
90 181,5 mm
3
5
1
(10
/
3
/
7
/
po.)
8
8
4
(l/h/p)
Poids
Env. 2,1 kg (4 liv. 10 on.)
Modulateur/
télécommande à fil (RM-X64)
Fréquence
88,3 MHz/88,5 MHz/
88,7 MHz/88,9 MHz/
89,1 MHz/89,3 MHz/
89,5 MHz/89,7 MHz/
89,9 MHz (réglable)
Dimensions
Modulateur:
Env. 124,8 30,0
99,8 mm
(5
1
3
/
4 po.) (l/h/p)
16
Télécommande à fil:
Env. 148
30
15 mm
7
3
19
(5
/
1
/
/
po.)
8
16
32
(l/h/p)
Poids
Modulateur:
Env. 330 g (11,64 on.)
Télécommande à fil:
Env. 120 g (4,2 on.)
Accessoires fournis
Chargeur de disques (1)
Pièces de montage et de
raccordement (1 jeu)
Accessoires en option
Adaptateur pour CD de 8 cm
CSA-8
Chargeur de disques XA-250
La conception et les spécifications sont modifiables
sans préavis.
Compact Disc
Changer System

Operating Instructions

Mode d'emploi
Owner's Record
The model and serial numbers are located at the rear of the CD changer.
Record the serial number in the space provided below.
Refer to these numbers whenever you call upon your Sony dealer regarding this
product.
Model No. CDX-424RF Serial No.
For installation and connections, see the supplied installation/connections
manual.
En ce qui concerne l'installation et les connexions, consulter le manuel
d'installation/connexions fourni.
CDX-424RF
Sony Corporation
1999
For the customers in the USA
WARNING
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates,
uses, and can radiate radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications. However, there is
no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the interference by
one or more of the following measures:
— Reorient or relocate the receiving antenna.
— Increase the separation between the equipment and receiver.
— Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
— Consult the dealer or an experienced radio/TV technician for help.
You are cautioned that any changes or modifications not expressly approved in this manual
could void your authority to operate this equipment.
CAUTION
The use of optical instruments with this product will increase eye hazard.
3-867-072-11 (1)
Printed in Thailand

Advertisement

Table of Contents

   Related Manuals for Sony CDX-424RF Operating Instructions (primary manual)

   Summary of Contents for Sony CDX-424RF Operating Instructions (primary manual)

  • Page 1: Operating Instructions

    The model and serial numbers are located at the rear of the CD changer. Record the serial number in the space provided below. Refer to these numbers whenever you call upon your Sony dealer regarding this product. Model No. CDX-424RF Serial No.
  • Page 2 8 cm CD. • N’introduisez pas l’adaptateur CD Sony CSA-8 • Do not insert the Sony CD adapter CSA-8 in the dans le chargeur sans disque, car vous risquez magazine without a disc, malfunction may sinon de provoquer un dysfonctionnement.
  • Page 3 Operation Precautions •This system cannot be used with a car audio without an FM tuner. •If your car was parked in direct sunlight resulting in a considerable rise in temperature inside the car, allow the system to cool off before operating it. •If no power is being supplied to the system, check the connections first.
  • Page 4 The disc is inserted upside down. The CD changer cannot be operated because of some problem. If the solutions mentioned above do not improve the situation, consult your nearest Sony dealer. Nomenclature Wired remote (RM-X64)/Télécommande à fil (RM-X64) REP 12...
