Connecting to a Telephone Line

Connect the system to a telephone line if the system configuration includes an internal
modem (identical for configuration A and B).
1. Connect the incoming telephone line to the LINE terminal.
2. Connect a telephone on the premises to the SET terminal.
NOTE: To ensure line seizure capability, and comply with FCC part 68 regulations, the
equipment must be connected directly to the Phone company lines ('CO'). Whether
connected via RJ11, RJ31, the line port must be connected to the CO lines without any other
phones or other telecom equipment between them. Other telecom equipment can be
connected only after (in series) the alarm panel.
Figure 6: Telephone Line Wiring
