Testing S equence
Dock T est
The f irst t est w ill c heck a ll l ightning p ort l ines f or c onnection. T here i s n o f urther a nalysis i nvolved.
If t his f ails, y ou n eed t o c lean o r r eplace t he l ightning p ort a ssembly o r t here i s a p roblem w ith t he
onboard d ock c onnector o r o ne o f t he r ails i s b roken.
Tristar / H ydra T est
If t he p retest p asses, t he t esting s equence s tarts. T he t ester w ill p ut a r eference v oltage t hrough
each p in a nd m easure t he b ehaviour o f t he t ested r ail. I f a d evice i s o kay, t he t est w ill b e
completed i n a round 2 0-­‐30 s econds. E very f aulty r ail w ill h owever t ake l onger t o t est ( up t o 1 5
seconds p er r ail) a s t he t ester g ives e ach r ail t he c hance t o s ettle a nd p ass b efore f ailing i t.
Battery P resence T est
This t est c hecks f or b attery p resence.
This is not a real battery test, so this test will not tell you if the battery is
good or bad. It can only find disconnected or completely discharged
batteries. A lso, s ome m odels -­‐ m ainly i Pads -­‐ a re n ot s upported.
Possible t est r esults:
ERROR
PRESENT
MISSING
Ambiguous R esults W arning
Tristar t ester t ries t o i nterpret t esting r esults b y c omparing m easured d ata t o i t's e mbedded
database. I n s ome c ases, r esults a re a mbiguous a nd a w arning w ill a ppear, r ecommending t o
retake t he t est w ith a k nown-­‐good D ock f lex a ssembly.
If t he w arning p ersists e ven a fter r eplacing t he D ock f lex a ssembly, p lease i gnore t his m essage.
© 2018 smartmod GmbH, Germany
Battery p resence t est c ould n ot b e c ompleted. T his u sually o ccurs i f t here i s
a s hort i n T ristar/Hydra
A b attery h as b een d etected
No b attery h as b een d etected o r
battery i s c ompletely d ischarged o r
target d evice d oes n ot s upport t his t est
