Panasonic TC-15DT2 Service Manual

Panasonic TC-15DT2 Service Manual

Combination 15.2" lcd tv/dvd player, lv1m chassis
Hide thumbs Also See for TC-15DT2:
Table of Contents

Advertisement

Quick Links

Download this manual
Power Source
AC 120V, 60Hz
Power Consumption
Average use: 54.2W (Maximum Current 3.62A)
Stand-by condition: 0.45 W
LCD
TFT 15.2-inch, 16:9 aspect ratio, 854 x 480 dots, 409.920
pixel
Screen Size
13.19" (335mm)(W) x 7.4" (188mm)(H) x 15.12"(384mm)
(DIAGONAL)
Channel Capability-181
VHF-12: UHF-56: Cable-125
Sound
Speaker
3" 5/32 (8cm) x 2
Audio Output
6W [3W+3W] (10%THD) Power Frequency Response
35Hz~16kHz
Headphones
M3(3.5 mm) Jack (16Ω ~ 32Ω)
FEATURES
DVD Player
CLOSED CAPTION
Disc Played
DVD-VIDEO/DVD-AUDIO disc
12cm single-sided, single-layer
12cm single-sided, dual-layer
12cm double-sided, single-layer
8cm single-sided, single-layer
8cm single-sided, dual-layer
3D Y/C FILTER
V-Chip
Combination 15.2" LCD TV/DVD Player
TC-15DT2
LV1M Chassis
8cm double-sided, single-layer
COMPACT disc (CD-DA, VIDEO CD)
12cm disc
8cm disc
Accessories Supplied
Remote control Transmitter
TNQE262
AAA (R03) Battery x 2
Operating Conditions
Temperature: 34°F - 104°F(5°C - 35°C)
Humidity: 20% - 80% (non-condensing)
Connection Terminals
VIDEO INPUT
S-VIDEO (Mini DIN 4-pin)
VIDEO (Pin Jack)
AUDIO L-R (Pin Jack x2) 0.5 Vrms (TV/Video)
AUDIO OUT
5.1ch SURROUND AUDIO OUT
FRONT L/R: STEREO M3 JACK
SURROUND L/R: STEREO M3 JACK
CENTER/SUBWOOFER: STEREO M3 JACK
Dimensions (W x H x D)
15.24" (387mm) x 14.69" (373mm) x 8.9"(226mm)
Weight (Mass)
21.19lb. (about 9.6kg) Net
Note:
Design and Specifications are subject to change without notice.
Weight and Dimensions shown are approximate.
© 2000 Matsushita Electric Industrial Co., Ltd. All
rights
distribution is a violation of law.
ORDER NO. ITD0011014C1
Y:1Vp-p(75Ω)
C: 0.286Vp-p(75Ω)
1Vp-p(75Ω)
2.0 Vrms (DVD/CD)
reserved.
Unauthorized
copying
B05
and
