Using the CamExpert Tool

The CamExpert application uses various panels to simplify choosing and configuring camera files or
acquisition parameters for the installed devices. Features include:
Supports all Teledyne DALSA hardware currently supported by Sapera LT.
Creates and modifies camera configuration (.ccf files.
Supports Teledyne DALSA GigE Vision cameras such as the Genie series by presenting the
camera Features controls as defined by the camera's XML file.
Groups acquisition parameters into related categories for easier access to any specific
parameter.
Intelligent editing of video timings through a locking mechanism that allows explicit
modification of some values and automatic recalculation of the remaining ones.
Live acquisition display window which allows immediate verification of timing or control
parameters without the need to run a separate acquisition program
Device
Selector
Configuration
menu
Detection
Commands
Parameters
Output
Message tab
Device Selector: The Device menu allows you to view and select from any installed Sapera
acquisition device. After a device is selected, CamExpert only presents acquisition parameters
applicable to that device.
The Configuration menu allows selecting any camera file that is included with the Sapera
installation. Only camera files supported by the selected acquisition device are displayed. When
there is more than one acquisition server, such as monochrome and RGB, selecting an
inappropriate camera file will produce a message prompting you to select the correct acquisition
server.
The Detection command buttons allow you to detect cameras that comply with the GenICam
GenCP protocol or Teledyne DALSA cameras that use the three letter protocol. Clicking the
Settings button allows you to set the camera detection communication settings.
Sapera LT Getting Started Manual
Video Status
bar
Display
Window
Camera Link
Command
Quick Start Guide • 19
Serial
tab
