Table 28: Digital phosphor spectrum processing (DPX) (cont.)
Characteristics
Span accuracy
Amplitude accuracy

Table 29: Controller

Characteristics
Controller
CPU
DRAM
OS
System bus
Storage medium
Hard disk
Floppy disk
Interface
Printer port
GPIB
LAN
Mouse
Keyboard
Monitor out

Table 30: External output connector

Characteristics
Preamp power connector
Connector type
Pin assignment
RSA3408B Digital I/Q output (Option 05)
RSA3303B, RSA3308B, and RSA3408B User Manual
Description
±0.3%
±0.5 dB
Description
Intel Celeron 1.2 GHz (RSA3408B)
Intel Pentium III 850 MHz (RSA3300B
512 MB DIMM (RSA3408B
256 MB DIMM (RSA3300B)
Windows XP
PCI
≥40 GB, 2.5 inch IDE (RSA3408B
≥20 GB, 2.5 inch IDE (RSA3300B)
1.44 MB 3.5 inch
USB
IEEE 488.2
10/100 BASE-T (IEEE 802.3)
USB
USB
VGA (D-SUB 15 pins)
Description
LEMO 6 poles
Pin 1: NC, Pin 2: ID1, Pin 3: ID2, Pin 4: -12 V, Pin 5: GND, Pin 6: +12 V
Appendix A: Specifications
