Page 1: Digital Video Camera
Owner’s Record The model and serial numbers are located on the bottom. Record the serial number in the space provided below. Refer to these numbers whenever you call upon your Sony dealer regarding this product. Model No. DCR-TRV30 Serial No.
Page 2: Declaration Of Conformity
Congratulations on your purchase of this Sony Digital Handycam camcorder. With your Digital Handycam, you can capture life’s precious moments with superior picture and sound quality. Your Digital Handycam is loaded with advanced features, but at the same time it is very easy to use.
Page 3 Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions,...
Page 4: Main Features
Main Features Taking moving or still images, and playing them back •Recording a picture (p. 19) •Recording a still image on a tape (p. 36) •Playing back a tape (p. 29) •Recording still images on “Memory Stick”s (p. 114) •Recording moving pictures on “Memory Stick”s (p. 123) •Viewing a still image recorded on “Memory Stick”s (p.
Page 5: Checking Supplied Accessories
Checking supplied accessories Make sure that the following accessories are supplied with your camcorder. 1 Wireless Remote Commander (1) (p. 184) 2 AC-L10A/L10B/L10C AC power adaptor (1), Power cord (1) (p. 13) 3 Size AA (R6) battery for Remote Commander (2) (p. 184) 4 NP-FM50 battery pack (1) (p.
Page 6: Table Of Contents
Table of contents Main Features ... 4 Checking supplied accessories ... 5 Quick Start Guide Getting started Using this manual ... 10 Step 1 Preparing the power supply ... 12 Installing the battery pack ... 12 Charging the battery pack ... 13 Connecting to a wall outlet ...
Page 7 Table of contents Superimposing a still image in a “Memory Stick” on a moving picture – MEMORY MIX ... 129 Copying still images from a tape – Photo save ... 132 Viewing a still image – Memory photo playback ... 134 Viewing a moving picture –...
Page 8: Quick Start Guide
Quick Start Guide Connecting the power cord Use the battery pack when using your camcorder outdoors (p. 12). AC power adaptor (supplied) Inserting a cassette Slide OPEN/ EJECT in the direction of the arrow and open the lid. This chapter introduces you to the basic features of your camcorder.
Page 9 Recording a picture Remove the lens cap. Viewfinder When the LCD panel is closed, use the viewfinder placing your eye against its eyecup. Press OPEN to open the LCD panel. The picture appears on the screen. When you purchase your camcorder, the clock setting is set to off.
Page 10: Getting Started
— Getting started — Using this manual As you read through this manual, buttons and settings on your camcorder are shown in capital letters. e.g. Set the POWER switch to CAMERA. When you carry out an operation, you can hear a beep sound to indicate that the operation is being carried out.
Page 11: Precautions On Camcorder Care
Using this manual Note on TV color systems TV color systems differ from country to country. To view your recordings on a TV, you need an NTSC system-based TV. Copyright precautions Television programs, films, video tapes, and other materials may be copyrighted. Unauthorized recording of such materials may be contrary to the provision of the copyright laws.
Page 12: Step 1 Preparing The Power Supply
Step 1 Preparing the power supply Installing the battery pack We recommend that you use the battery pack when you use your camcorder outdoors. (1) Lift up the viewfinder. (2) Slide the battery pack down until it clicks. To remove the battery pack (1) Lift up the viewfinder.
Page 13: Charging The Battery Pack
Step 1 Preparing the power supply Charging the battery pack Use the battery pack after charging it for your camcorder. Your camcorder operates only with the “InfoLITHIUM” battery pack (M series). See page 166 for details of “InfoLITHIUM” battery pack. (1) Open the DC IN jack cover and connect the AC power adaptor supplied with your camcorder to the DC IN jack with the plug’s v mark facing up.
Page 14: Charging Time
Step 1 Preparing the power supply Remaining battery time indicator The remaining battery time indicator in the display window indicates the approximate recording time with the viewfinder. Until your camcorder calculates the actual remaining battery time “---- min” appears in the display window. Charging time Battery pack NP-FM50 (supplied)
Page 15: Playing Time
“InfoLITHIUM” battery. “InfoLITHIUM” M series battery packs have the mark. SERIES “InfoLITHIUM” is a trademark of Sony Corporation. We recommend charging the battery pack in an ambient temperature of between 10 °C to 30 °C (50 °F to 86 °F).
Page 16: Connecting To A Wall Outlet
DC IN jack, even when the power cord is not plugged into a wall outlet. Using a car battery Use Sony DC Adaptor/Charger (optional). Refer to the operating instractions of the DC Adaptor/Charger for further information.
Page 17: Step 2 Setting The Date And Time
Step 2 Setting the date and time Set the date and time settings when you use your camcorder for the first time. “CLOCK SET” will be displayed each time that you set the POWER switch to CAMERA/ MEMORY unless you set the date and time settings. If you do not use your camcorder for about four months, the date and time settings may be released (bars may appear) because the built-in rechargeable battery installed in your camcorder will have been discharged (p.
Page 18: Step 3 Inserting A Cassette
Step 3 Inserting a cassette Install the power source. (2) Slide OPEN/ The cassette compartment automatically lifts up and opens. (3) Push the middle portion of the back of the cassette to insert. Insert the cassette in a straight line deeply into the cassette compartment with the window facing out.
Page 19: Recording - Basics
— Recording – Basics — Recording a picture Your camcorder automatically focuses for you. (1) Remove the lens cap by pressing both knobs on its sides and attach the lens cap to the grip strap. (2) Install the power source and insert a cassette. See “Step 1” to “Step 3” for more information (p.
Page 20: Adjusting The Lcd Screen
Recording a picture Note on the LOCK switch When you slide the LOCK switch to the right, the POWER switch can no longer be set to MEMORY accidentally. LOCK switch is set to the left as a default setting. To enable smooth transition Transition between the last scene you recorded and the next scene is smooth as long as you do not eject the cassette even if you turn off your camcorder.
Page 21: Adjusting The Brightness Of The Lcd Screen
Recording a picture Adjusting the brightness of the LCD screen To adjust the brightness of the LCD screen, press either of the two buttons on LCD BRIGHT. to dim to brighten BRIGHT After recording (1) Set the POWER switch to OFF (CHG). (2) Close the LCD panel.
Page 22: Adjusting The Viewfinder
Recording a picture Adjusting the viewfinder If you record pictures with the LCD panel closed, check the picture with the viewfinder. Adjust the viewfinder lens to your eyesight so that the indicators in the viewfinder come into sharp focus. Lift up the viewfinder and move the viewfinder lens adjustment lever. Attaching the supplied lens hood To record fine pictures under strong light, we recommend attaching the lens hood.
Page 23: Using The Zoom Feature
Recording a picture Using the zoom feature Move the power zoom lever a little for a slower zoom. Move it further for a faster zoom. Using the zoom function sparingly results in better-looking recordings. “T” side: for telephoto (subject appears closer) “W”...
Page 24 Recording a picture Indicators displayed in the recording mode The indicators are not recorded on tapes. JUL 4 2001 Remaining battery time indicator The remaining battery time indicator roughly indicates the recording time. The indicator may not be correct, depending on the conditions in which you are recording. When you close the LCD panel and open it again, it takes about one minute for the correct remaining battery time in minutes to be displayed.
Page 25: Shooting Backlit Subjects - Back Light
Recording a picture Shooting backlit subjects – BACK LIGHT When you shoot a subject with the light source behind the subject or a subject with a light background, use the backlight function. In CAMERA or MEMORY mode, press BACK LIGHT. The .
Page 26: Using The Nightshot Light
Recording a picture Using Super NightShot The Super NightShot mode makes subjects more than 16 times brighter than those recorded in the NightShot mode. (1) Slide NIGHTSHOT to ON in CAMERA mode. indicators flash on the screen. (2) Press SUPER NIGHTSHOT. on the screen.
Page 27: Self-Timer Recording
Recording a picture Self-timer recording Recording with the self-timer starts in 10 seconds automatically. You can also use the Remote Commander for this operation. (1) Press (self-timer) in the standby mode. The on the screen. (2) Press START/STOP. Self-timer starts counting down from 10 with a beep sound. In the last 2 seconds of the countdown, the beep sound gets faster, then recording starts automatically.
Page 28: Checking The Recording
Checking the recording – END SEARCH / EDITSEARCH / Rec Review You can use these buttons to check the recorded picture or shoot so that the transition between the last recorded scene and the next scene you record is smooth. END SEARCH You can go to the end of the recorded section after you record.
Page 29: Playback - Basics
— Playback – Basics — Playing back a tape You can monitor the playback picture on the screen. If you close the LCD panel, you can monitor the playback picture in the viewfinder. You can control playback using the Remote Commander supplied with your camcorder. (1) Install the power source and insert the recorded tape.
Page 30: Data Code (P
Playing back a tape To display the screen indicators – Display function Press DISPLAY on your camcorder or the Remote Commander supplied with your camcorder. The indicators appear on the screen. To make the indicators disappear, press DISPLAY again. Using the data code function Your camcorder automatically records not only images on the tape but also the recording data (date/time or various settings when recorded) (Data code).
Page 31: Various Playback Modes
Playing back a tape Recording data Recording data is your camcorder’s information when you have recorded. In the recording mode, the recording data will not be displayed. When you use the data code function, bars (-- -- --) appear if: –...
Page 32 Playing back a tape To view the picture frame-by-frame Press C on the Remote Commander in the playback pause mode. For frame-by-frame playback in the reverse direction, press c. To resume normal playback, press N. To search the last scene recorded (END SEARCH) Press END SEARCH in the stop mode.
Page 33: Viewing The Recording On Tv
Viewing the recording on TV Connect your camcorder to your TV with the A/V connecting cable supplied with your camcorder to watch the playback picture on the TV screen. You can operate the video control buttons in the same way as when you monitor playback pictures on the screen. When monitoring the playback picture on the TV screen, we recommend that you power your camcorder from a wall outlet using the AC power adaptor (p.
Page 34 Viewing the recording on TV Using the AV cordless IR receiver Once you connect the AV cordless IR receiver (optional) to your TV or VCR, you can easily view the picture on your TV. For details, refer to the operating instructions of the AV cordless IR receiver.
Page 35 Viewing the recording on TV If you use a Sony TV •You can turn on the TV automatically when you press SUPER LASER LINK. To do so, make sure you: – Turn the TV’s main switch on. – Set AUTO TV ON to ON in the menu settings.
Page 36: Advanced Recording Operations
Recording a still image on a tape – Tape Photo recording You can record an still image like a photograph. This mode is useful when you want to print a image using a video printer (optional). You can record about 510 images in the SP mode and about 765 images in the LP mode on a 60-minute tape.
Page 37 Recording a still image on a tape – Tape Photo recording Recording images with the flash The flash pops up automatically. The default setting is auto (no indicator). To change the flash mode, press the the screen. (flash) Each press of (flash) changes the indicator as follows: t No indicator Auto red-eye reduction: The flash fires before recording to reduce the red-eye...
Page 38 Recording a still image on a tape – Tape Photo recording Notes •Attaching the lens hood (supplied) or a conversion lens (optional) may block the light from the flash or cause lens shadow to appear. •You cannot use an external flash (optional) and the built-in flash at the same time. •...
Page 39 Recording a still image on a tape – Tape Photo recording Self-timer recording You can record still images on tapes with the self-timer. You can also use the Remote Commander for this operation. (1) Press (self-timer) in the standby mode. The on the screen.
Page 40: Printing The Still Image
Recording a still image on a tape – Tape Photo recording Printing the still image You can print a still image by using the video printer (optional). Connect the video printer using the A/V connecting cable supplied with your camcorder. Connect it to the AUDIO/VIDEO jack and connect the yellow plug of the cable to the video input of the video printer.
Page 41: Adjusting The White Balance Manually
Adjusting the white balance manually You can manually adjust and set the white balance. This adjustment makes white subjects look white and allows more natural color balance. Normally white balance is automatically adjusted. (1) In CAMERA or MEMORY mode, select WHT BAL in (p.
Page 42: Using The Wide Mode
Using the wide mode You can record a 16:9 wide picture to watch on the 16:9 wide-screen TV (16:9WIDE). Black bands appear on the screen during recording in 16:9WIDE mode [a]. The picture during a playback on a normal TV [b] or on a wide-screen TV [c] is compressed in the widthwise direction.
Page 43: Using The Fader Function
Using the fader function You can fade in or out to give your recording a professional appearance. STBY FADER M. FADER (mosaic) BOUNCE* OVERLAP* WIPE* DOT* STBY MONOTONE When fading in, the picture gradually changes from black-and-white to color. When fading out, the picture gradually changes from color to black-and-white. * Fade in only...
Page 44 Using the fader function (1) When fading in [a] In the standby mode, press FADER until the desired fader indicator flashes. When fading out [b] In the recording mode, press FADER until the desired fader indicator flashes. The indicator changes as follows: FADER no indicator T The last selected fader mode is indicated first of all.
Page 45 Using the fader function While using the bounce function, you cannot use the following functions: – Focus – Zoom – Picture effect – Exposure Note on the bounce function The BOUNCE indicator does not appear in the following mode or functions: –...
Page 46: Using Special Effects - Picture Effect
Using special effects – Picture effect You can digitally process images to obtain special effects like those in films or on TV. NEG. ART [a] : The color and brightness of the picture are reversed. SEPIA : B&W : SOLARIZE [b] : The light intensity is clearer, and the picture looks like an illustration. SLIM [c] : STRETCH [d] : The picture expands horizontally.
Page 47: Using Special Effects - Digital Effect
Using special effects – Digital effect You can add special effects to recorded pictures using the various digital functions. The sound is recorded normally. STILL You can record a still image so that it is superimposed on a moving picture. FLASH (FLASH MOTION) You can record still images successively at constant intervals.
Page 48 Using special effects – Digital effect (1) In CAMERA mode, press DIGITAL EFFECT. The digital effect indicator appears. (2) Turn the SEL/PUSH EXEC dial to select the desired digital effect mode. The indicator changes as follows: STILL y FLASH y LUMI. y TRAIL y SLOW SHTR y OLD MOVIE (3) Press the SEL/PUSH EXEC dial.
Page 49 Using special effects – Digital effect Notes •The following functions do not work during digital effect: – Fader – Low lux mode of PROGRAM AE (The low lux indicator flashes.) – Tape photo recording – Super NightShot •The PROGRAM AE function does not work in the slow shutter mode. •The following functions do not work in the old movie mode: –...
Page 50: Using The Program Ae Function
Using the PROGRAM AE function You can select PROGRAM AE (Auto Exposure) mode to suit your specific shooting requirements. Spotlight This mode prevents people’s faces, for example, from appearing excessively white when shooting subjects lit by strong light in the theater. Soft portrait This mode brings out the subject while creating a soft background for subjects such as people or flowers.
Page 51 Using the PROGRAM AE function (1) In CAMERA or MEMORY mode, press PROGRAM AE. The PROGRAM AE indicator appears. (2) Turn the SEL/PUSH EXEC dial to select the desired PROGRAM AE mode. The indicator changes as follows: To cancel the PROGRAM AE function Press PROGRAM AE again.
Page 52 Using the PROGRAM AE function While WHT BAL is set to AUTO in the menu settings The white balance is adjusted even if the PROGRAM AE function is selected. Even if the PROGRAM AE function is selected You can adjust the exposure. If you are recording under a discharge tube such as a fluorescent lamp, sodium lamp or mercury lamp Flickering or changes in color may occur in the following modes.
Page 53: Adjusting The Exposure Manually
Adjusting the exposure manually You can manually adjust and set the exposure. Adjust the exposure manually in the following cases: – The subject is backlit – Bright subject and dark background – To record dark pictures (e.g. night scenes) faithfully (1) In CAMERA or MEMORY mode, press EXPOSURE.
Page 54: Focusing Manually
Focusing manually You can gain better results by manually adjusting the focus in the following cases: •The autofocus mode is not effective when shooting: – subjects through glass coated with water droplets – horizontal stripes – subjects with little contrast with backgrounds such as walls and sky •When you want to change the focus from a subject in the foreground to a subject in the background.
Page 55 Focusing manually To focus precisely It is easier to focus on the subject if you adjust the zoom to shoot at the “W” (wide- angle) after focusing at the “T” (telephoto) position. When you shoot close to the subject Focus at the end of the “W” (wide-angle) position. 9 changes as follows: when recording a distant subject when the subject is too close to focus on...
Page 56: Interval Recording
Interval recording You can make a time-lapse recording by setting the camcorder to automatically record and standby sequentially. You can achieve an excellent recording for flowering, emergence, etc., with this function. [a] Recording time [b]Waiting time (1) Press MENU to display the menu in standby mode. (2) Turn the SEL/PUSH EXEC dial to select (3) Turn the SEL/PUSH EXEC dial to select INT.
Page 57 Interval recording (6) Turn the SEL/PUSH EXEC dial to select ON, then press the dial. (7) Press MENU to erase the menu display. The interval recording indicator flashes. (8) Press START/STOP to start interval recording. The interval recording indicator lights up. I NTERVAL MENU To cancel the interval recording...
Page 58: Frame By Frame Recording - Cut Recording
Frame by frame recording – Cut recording You can make a recording with a stop-motion animated effect using cut recording. To create this effect, alternately move the subject a little and make a cut recording. We recommend that you use a tripod, and operate the camcorder using the Remote Commander after step 6.
Page 59: Advanced Playback Operations
— Advanced Playback Operations — Playing back a tape with picture effects During playback, you can process a scene using the picture effect functions: NEG. ART, SEPIA, B&W and SOLARIZE. (1) In the playback or playback pause mode, select P EFFECT in settings (p.
Page 60: Playing Back A Tape With Digital Effects
Playing back a tape with digital effects During playback, you can process a scene using the digital effect functions: STILL, FLASH, LUMI. and TRAIL. (1) In the playback or playback pause mode, press DIGITAL EFFECT and turn the SEL/PUSH EXEC dial until the desired digital effect mode flashes. The indicator changes as follows: STILL y FLASH y LUMI.
Page 61: Enlarging Images Recorded On Tapes - Tape Pb Zoom
Enlarging images recorded on tapes – Tape PB ZOOM You can enlarge playback images recorded on tapes. You can also dub the enlarged images to tapes or copy to “Memory Stick”s. Besides the operation described here, your camcorder can enlarge still images recorded on “Memory Stick”s (p. 146). (1) In the playback or playback pause mode, press PB ZOOM on your camcorder.
Page 62: Quickly Locating A Scene Using The Zero Set Memory Function
Quickly locating a scene using the zero set memory function Your camcorder goes forward or backward to automatically stop at a desired scene having a tape counter value of “0:00:00”. Use the Remote Commander for this operation. (1) In the playback mode, press DISPLAY. (2) Press ZERO SET MEMORY at the point you want to locate later.
Page 63: Searching The Boundaries Of Recorded Tape By Title - Title Search
Searching the boundaries of recorded tape by title – Title search If you use a tape with cassette memory, you can search for the boundaries of recorded tape by title. Use the Remote Commander for this operation. Before operation Set CM SEARCH in (1) Set the POWER switch to VCR.
Page 64: Searching A Recording By Date - Date Search
Searching a recording by date – Date search You can automatically search for the point where the recording date changes and start playback from that point (Date search). Use a tape with cassette memory for convenience. Use the Remote Commander for this operation. Use this function to check where recording dates change or to edit the tape at each recording date.
Page 65: Searching For The Date Without Using Cassette Memory
Searching a recording by date – Date search Note If one day’s recording is less than 2 minutes, your camcorder may not accurately find the point where the recording date changes. In the mark •The bar in the •The mark in the If a tape has a blank portion between recorded portions The date search function may not work correctly.
Page 66: Searching For A Photo - Photo Search/Photo Scan
Searching for a photo – Photo search/Photo scan You can search for a still image you have recorded on a tape (photo search). You can also search for still images one after another and display each image for 5 seconds automatically regardless of cassette memory (photo scan). Use the Remote Commander for these operations.
Page 67 Searching for a photo – Photo search/Photo scan Searching for a photo without using cassette memory (1) Set the POWER switch to VCR. (2) Set CM SEARCH in (3) Press SEARCH MODE on the Remote Commander repeatedly, until the PHOTO SEARCH indicator appears. The indicator changes as follows: DATE SEARCH t PHOTO SEARCH t PHOTO SCAN t no indicator (4) Press .
Page 68: Editing
Dubbing a tape Using the A/V connecting cable You can dub or edit on the VCR connected to your camcorder using your camcorder as a player. Connect your camcorder to the VCR using the A/V connecting cable supplied with your camcorder. Before operation •...
Page 69 Dubbing a tape If your VCR has an S video jack Connect using an S video cable (optional) to obtain high-quality pictures. With this connection, you do not need to connect the yellow (video) plug of the A/V connecting cable. Connect an S video cable (optional) to the S video jacks of both your camcorder and the VCR.
Page 70: Dubbing Only Desired Scenes - Digital Program Editing
Dubbing only desired scenes – Digital program editing You can duplicate selected scenes (programs) for editing onto a tape without operating the VCR. Scenes can be selected by frame. You can set up to 20 programs. Unwanted scene Before operating the Digital program editing Step 1 Connecting the VCR (p.
Page 71: Set The Ir Setup Code
Dubbing only desired scenes – Digital program editing Step 2: Setting the VCR to operate with the A/V connecting cable To edit using the VCR, send the control signal by infrared rays to the remote sensor on the VCR. When you connect using an A/V connecting cable, follow the procedures below, (1) to (4), to send the control signal correctly.
Page 72 The IR SETUP code is stored in the memory of your camcorder. Be sure to set the correct code, depending on your VCR. The default setting is Code number 3. Brand IR SET UP code Sony 1, 2, 3, 4, 5, 6 Admiral (M. Wards) 89 Aiwa...
Page 73 Dubbing only desired scenes – Digital program editing (2) Setting the modes to cancel the recording pause on the VCR 1 Turn the SEL/PUSH EXEC dial to select PAUSEMODE, then press the dial. 2 Turn the SEL/PUSH EXEC dial to select the mode to cancel recording pause on the VCR, then press the dial.
Page 74 Dubbing only desired scenes – Digital program editing (4) Confirming the VCR operation 1 Insert a recordable tape into the VCR, then set to recording pause. 2 Turn the SEL/PUSH EXEC dial to select IR TEST, then press the dial. 3 Turn the SEL/PUSH EXEC dial to select EXECUTE, then press the dial.
Page 75: Dv Connecting Cable
Dubbing only desired scenes – Digital program editing Step 2: Setting the VCR to operate with the i.LINK cable (DV connecting cable) When you connect using i.LINK cable (DV connecting cable) (optional), follow the procedures below. (1) Set the POWER switch to VCR on your camcorder . (2) Turn the power of the connected VCR on, then set the input selector to DV input.
Page 76 Dubbing only desired scenes – Digital program editing Step 3: Adjusting the synchronicity of the VCR You can adjust the synchronicity of your camcorder and the VCR. Have a pen and paper ready for notes. Before operation, eject a cassette from your camcorder. (1) Set the POWER swtich to VCR on your camcorder.
Page 77 Dubbing only desired scenes – Digital program editing O T H E R S E D I T S E T CON T RO L A D J T E S T R E T URN ” CU T - I N ” E X E CU T E ”...
Page 78 Dubbing only desired scenes – Digital program editing Operation 1: Making the program (1) Insert the tape for playback into your camcorder, and insert a tape for recording into the VCR. (2) Press MENU to display the menu. (3) Turn the SEL/PUSH EXEC dial to select (4) Turn the SEL/PUSH EXEC dial to select VIDEO EDIT, then press the dial.
Page 79 Dubbing only desired scenes – Digital program editing Erasing the program you have set Erase OUT first and then IN from of the last program. (1) Turn the SEL/PUSH EXEC dial to select UNDO, then press the dial. (2) Turn the SEL/PUSH EXEC dial to select EXECUTE, then press the dial. The last set program mark flashes, then the setting is cancelled.
Page 80 Dubbing only desired scenes – Digital program editing To stop dubbing during editing Press x using the video operation buttons. To end the Digital program editing function Your camcorder stops when the dubbing is complete. Then the display returns to VIDEO EDIT in the menu settings.
Page 81: Using With Analog Video Unit And Personal Computer - Signal Convert Function
Using with analog video unit and personal computer – Signal convert function You can capture images and sound from an analog video unit connected to your computer which has the i.LINK (DV) jack to your camcorder. Before operation Set DISPLAY to LCD in the menu settings. (The default setting is LCD.) (1) Set the POWER switch to VCR.
Page 82: Recording Video Or Tv Program
Your camcorder works in the commander mode VTR 2. Commander modes 1, 2 and 3 are used to distinguish your camcorder from other Sony VCRs to avoid remote control misoperation. If you use another Sony VCR in the commander mode VTR 2, we recommend changing the commander mode or covering the sensor of the VCR with black paper.
Page 83: Recording Video Or Tv Programs
Recording video or TV programs If your VCR is a monaural type Connect the yellow plug of the A/V connecting cable to the video output jack and the white or the red plug to the audio output jack on the VCR or the TV. When the white plug is connected, the left channel audio is output, and the red plug is connected, the right channel audio is output.
Page 84 Your camcorder works in the commander mode VTR 2. Commander modes 1, 2 and 3 are used to distinguish your camcorder from other Sony VCRs to avoid remote control misoperation. If you use another Sony VCR in the commander mode VTR 2, we recommend changing the commander mode or covering the sensor of the VCR with black paper.
Page 85: Inserting A Scene From A Vcr - Insert Editing
Inserting a scene from a VCR – Insert editing You can insert a new scene from a VCR onto your originally recorded tape by specifying the insert start and end points. Use the Remote Commander for this operation. Connections are the same as on page 82 or 83. Insert a cassette containing the desired scene to insert into the VCR.
Page 86: Inserting A Scene From A Vcr – Insert Editing
Your camcorder works in the commander mode VTR 2. Commander modes 1, 2 and 3 are used to distinguish your camcorder from other Sony VCRs to avoid remote control misoperation. If you use another Sony VCR in the commander mode VTR 2, we recommend changing the commander mode or covering the sensor of the VCR with black paper.
Page 87: Audio Dubbing
Audio dubbing You can record an audio sound to add to the original sound on a tape by connecting audio equipment or a microphone. If you connect the audio equipment, you can add sound to your recorded tape by specifying starting and ending points. The original sound will not be erased.
Page 88 Audio dubbing Connecting the A/V connecting cable to the AUDIO/VIDEO jack Audio equipment LINE OUT AUDIO L AUDIO R Do not connect the video (yellow) plug. : Signal flow Dubbing with the built-in microphone No connection is necessary. Note When dubbing with the AUDIO/VIDEO jack or the built-in microphone, pictures are not output through S VIDEO jack or the AUDIO/VIDEO jack.
Page 89: Adding An Audio Sound On A Recorded Tape
Audio dubbing Adding an audio sound on a recorded tape Choose a connection mentioned before, and connect audio equipment or microphone to your camcorder. Then follow the procedure below. (1) Insert the recorded tape into your camcorder. (2) Set the POWER switch to VCR on your camcorder. (3) Locate the recording start point by pressing N on the Remote Commander.
Page 90 Audio dubbing Notes • New sound cannot be recorded on a tape already recorded in the 16-bit mode (32 kHz, 44.1 kHz or 48 kHz) (p. 103). • New sound cannot be recorded on a tape already recorded in the LP mode (p. 103). •...
Page 91: Superimposing A Title
Superimposing a title If you use a tape with cassette memory, you can superimpose the title. When you play back the tape, the title is displayed for 5 seconds from the point where you superimposed it. You can select one of 8 preset titles and 2 custom titles (p. 94). You can also select the color, size and position of titles.
Page 92 Superimposing a title If you set the write-protect tab of the tape to lock You cannot superimpose or erase the title. Slide the write-protect tab to release the write protection. To use the custom title If you want to use the custom title, select If the tape has a blank portion You cannot superimpose a title on the portion.
Page 93: Erasing A Title
Superimposing a title Erasing a title (1) Set the POWER switch to CAMERA or VCR and then press MENU to display the menu. (2) Turn the SEL/PUSH EXEC dial to select the dial. (3) Turn the SEL/PUSH EXEC dial to select TITLEERASE, then press the dial. Title erase display appears.
Page 94: Making Your Own Titles
Making your own titles You can make up to 2 titles and store them in cassette memory. Each title can have up to 20 characters. (1) Press MENU to display the menu in the standby or VCR mode. (2) Turn the SEL/PUSH EXEC dial to select (3) Turn the SEL/PUSH EXEC dial to select TITLE, then press the dial.
Page 95: To Change A Title You Have Stored
Making your own titles To change a title you have stored In step 3, select CUSTOM1 SET or CUSTOM2 SET, depending on which title you want to change, then press the SEL/PUSH EXEC dial. Turn the SEL/PUSH EXEC dial to select [C], then press the dial to delete the title.
Page 96: Labeling A Cassette
Labeling a cassette If you use a tape with cassette memory, you can label a cassette. The label can consist of up to 10 characters and is stored in cassette memory. When you insert the labelled cassette and turn the power on, the label is displayed for about 5 seconds.
Page 97 Labeling a cassette To erase the label you have made In step 6 turn the SEL/PUSH EXEC dial to select [C], then press the dial. The last character is erased. To change the label you have made Insert the cassette to change the label, and operate in the same way to make a new label. If you set the write-protect tab of the tape to lock You cannot label the tape.
Page 98: Customizing Your Camcorder
— Customizing Your Camcorder — Changing the menu settings To change the mode settings in the menu settings, select the menu items with the SEL/ PUSH EXEC dial. The default settings can be partially changed. First, select the icon, then the menu item and then the mode. (1) In CAMERA, MEMORY or VCR mode, press MENU.
Page 99 Changing the menu settings Menu items are displayed as the following icons: MANUAL SET CAMERA SET VCR SET LCD/VF SET MEMORY SET PRINT SET CM SET TAPE SET SETUP MENU OTHERS Selecting the mode setting of each item Menu items differ depending on the position of the POWER switch. The screen shows only the items you can operate at the moment.
Page 100 Changing the menu settings Icon/item Mode FRAME REC z OFF INT. REC z OFF FLASH LVL z NORMAL HiFi SOUND z STEREO AUDIO MIX A/VtDV OUT z OFF LCD B. L. z BRT NORMAL LCD COLOR z BRT NORMAL VF B.L. Notes on LCD B.L.
Page 101 Changing the menu settings Icon/item Mode STILL SET PIC MODE z SINGLE NORMAL HIGH SPEED MULTI SCRN QUALITY z SUPER FINE FINE STANDARD IMAGESIZE z 1360 1020 MOVIE SET IMAGESIZE z 320 REMAIN z AUTO Note on IMAGESIZE for STILL SET If you set PIC MODE to HIGH SPEED or MULTI SCRN or you set the POWER switch to VCR, IMAGESIZE is automatically set to 640 480.
Page 102 Changing the menu settings Icon/item Mode PRINT MARK z OFF PROTECT z OFF SLIDE SHOW DELETE ALL FORMAT z RETURN PHOTO SAVE 9PIC PRINT z RETURN DATE/TIME z OFF Notes on formatting • Supplied “Memory Stick”s have been formatted at factory. Formatting with this camcorder is not required.
Page 103 When you play back the tape on other camcorders or VCRs, noise may occur in pictures or sound. •When you record in the LP mode, we recommend using a Sony Excellence/Master cassette so that you can get the most out of your camcorder.
Page 104 To set the date or time (p. 17). — To automatically turn on a Sony TV when using the laser link function (P. 34). To switch the video input on a Sony TV when VIDEO2 using the laser link function (P. 34). VIDEO3 —...
Page 105 Changing the menu settings Icon/item Mode DATA CODE z DATE/CAM DATE WORLD TIME —— BEEP z MELODY NORMAL COMMANDER z ON DISPLAY z LCD V-OUT/LCD REC LAMP z ON VIDEO EDIT —— EDIT SET —— Note If you press DISPLAY with DISPLAY set to V-OUT/LCD in the menu settings, the picture from a TV or VCR will not appear on the LCD screen even when your camcorder is connected to outputs on the TV or VCR.
Page 106: Memory Stick" Operations
— “Memory Stick” Operations — Using a “Memory Stick” – introduction You can record and play back images on a “Memory Stick” supplied with your camcorder. You can easily play back, record or delete images. You can exchange image data with other equipment such as your computer etc., using the USB cable for “Memory Stick”...
Page 107 •Macintosh and Mac OS, QuickTime are trademarks of Apple Computer, Inc. •All other product names mentioned herein may be the trademarks or registered trademarks of their respective companies. •Furthermore, “™” and “®” are not mentioned in each case in this manual. are trademarks of Sony Corporation.
Page 108 Using a “Memory Stick” – introduction Inserting a “Memory Stick” Lift up the viewfinder, and insert a “Memory Stick” in the “Memory Stick” slot as far as it can go with the v mark facing up as illustrated. “Memory Stick” slot v mark Ejecting a “Memory Stick”...
Page 109: Selecting Still Image Quality Mode
Using a “Memory Stick” – introduction Selecting still image quality mode You can select image quality mode in still image recording. The default setting is SUPER FINE. (1) Set the POWER switch to MEMORY or VCR. Make sure that the LOCK switch is set to the left (unlock) position.
Page 110: Image Quality Settings
Using a “Memory Stick” – introduction Image quality settings Setting SUPER FINE (SFN) FINE (FINE) STANDARD (STD) Note In some cases, changing the image quality mode may not affect the image quality, depending on the types of images you are shooting. Differences in image quality mode Recorded images are compressed in JPEG format before being stored in memory.
Page 111: Movie Set
Using a “Memory Stick” – introduction (4) Turn the SEL/PUSH EXEC dial to select STILL SET (still image) or MOVIE SET (moving picture), then press the dial. (5) Turn the SEL/PUSH EXEC dial to select IMAGESIZE, then press the dial. (6) Turn the SEL/PUSH EXEC dial to select the desired image size, then press the dial.
Page 112 Using a “Memory Stick” – introduction Image size settings Setting 1360 1020 640 480 320 240 160 112 Maximum recording time of moving pictures Image size 320 240 160 112 Approximate number of still images you can record on a “Memory Stick”...
Page 113 Using a “Memory Stick” – introduction 32MB type (optional): Image size SUPER FINE (SFN) FINE (FINE) STANDARD (STD) 64MB type (optional): Image size SUPER FINE (SFN) FINE (FINE) STANDARD (STD) 128MB type (optional): Image size SUPER FINE (SFN) FINE (FINE) STANDARD (STD) Approximate time of moving pictures you can record on a “Memory Stick”...
Page 114: Recording Still Images On "Memory Stick"S - Memory Photo Recording
Recording still images on “Memory Stick”s – Memory Photo recording You can record still images on “Memory Stick”s. Before operation Insert a “Memory Stick” into your camcorder. (1) Set the POWER switch to MEMORY. Make sure that the LOCK switch is set to the left (unlock) position.
Page 115: Recording Images Continuously
Recording still images on “Memory Stick”s – Memory Photo recording While you are recording a still image You can neither turn off the power nor press PHOTO. When you press PHOTO on the Remote Commander Your camcorder immediately records the image that is on the screen when you press the button.
Page 116 Recording still images on “Memory Stick”s – Memory Photo recording (1) Set the POWER switch to MEMORY. Make sure that the LOCK switch is set to the left (unlock) position. (2) Press MENU to display the menu. (3) Turn the SEL/PUSH EXEC dial to select (4) Turn the SEL/PUSH EXEC dial to select STILL SET, then press the dial.
Page 117 Recording still images on “Memory Stick”s – Memory Photo recording If the capacity of the “Memory Stick” becomes full ” FULL” appears on the screen, and you cannot record a still image on this “Memory Stick.” Continuous shooting settings Setting Meaning (indicator on the screen) SINGLE Your camcorder shoots 1 image at a time.
Page 118 Recording still images on “Memory Stick”s – Memory Photo recording The flash is adjusted to the appropriate brightness through the photocell window for the flash. You can also change FLASH LVL to the desired brightness in the menu settings (p. 100). Try recording various images to find the most appropriate setting for FLASH LVL.
Page 119: Self-Timer Memory Photo Recording
Recording still images on “Memory Stick”s – Memory Photo recording Self-timer memory photo recording You can record images on “Memory Stick”s with the self-timer. You can also use the Remote Commander for this operation. (1) Set the POWER switch to MEMORY. Make sure that the LOCK switch is set to the left (unlock) position.
Page 120: Recording An Image From A Tape As A Still Image
Recording an image from a tape as a still image Your camcorder can read moving picture data recorded on a tape and record it as a still image on a “Memory Stick”. Your camcorder can also take in moving picture data through the input connector and record it as a still image on a “Memory Stick.”...
Page 121 Recording an image from a tape as a still image Sound recorded on a tape You cannot record the audio from a tape. Titles have already recorded on tapes You cannot record the titles on “Memory Stick”s. The title does not appear while you are recording a still image with PHOTO.
Page 122: Recording A Still Image From Other Equipment
Recording an image from a tape as a still image Recording a still image from other equipment Before opration Set DISPLAY to LCD in the menu settings. (The default setting is LCD.) (1) Set the POWER switch to VCR. (2) Play back the recorded tape, or turn the TV on to see the desired program. The image of the other equipment is displayed on the screen.
Page 123: Recording Moving Pictures On "Memory Stick"S - Mpeg Movie Recording
Recording moving pictures on “Memory Stick”s – MPEG movie recording You can record moving pictures with sound on “Memory Stick”s. Before operation Insert a “Memory Stick” into your camcorder. (1) Set the POWER switch to MEMORY. Make sure that the LOCK switch is set to the left (unlock) position.
Page 124 Recording moving pictures on “Memory Stick”s – MPEG movie recording When recording in MEMORY mode The angle of view is a little increased than one in CAMERA mode. When selecting HIGH SPEED Flickering or changes in color may occur. Also, your camcorder prevents focusing on near objects.
Page 125: Recording A Picture From A Tape As A Moving Picture
Recording a picture from a tape as a moving picture Your camcorder can read moving picture data recorded on a tape and record it as a moving picture on a “Memory Stick.” Your camcorder can also take in moving picture data through the input connector and record it as a moving picture on a “Memory Stick.”...
Page 126 Recording a picture from a tape as a moving picture Notes •Sound recorded in 48 kHz is converted to one in 32 kHz when recording images from a tape to “Memory Stick”s. •Sound recorded in stereo is converted to monaural sound when recording from tapes. When the access lamp is lit or flashing Do not shake or strike the unit.
Page 127: Recording A Moving Picture From Other Equipment
Recording a picture from a tape as a moving picture Recording a moving picture from other equipment Before operation Set DISPLAY to LCD in the menu settings. (The default setting is LCD.) (1) Set the POWER switch to VCR. (2) Play back the recorded tape, or turn the TV on to see the desired program. The image of the other equipment is displayed on the screen.
Page 128 Recording a picture from a tape as a moving picture Note The “ ” flashes in the following instances. If this happens, eject and insert “Memory Stick“ again, and record distortion-free images. – When recording on a tape in a poor recording state, for example, on a tape that has been repeatedly used for dubbing –...
Page 129: Superimposing A Still Image In A "Memory Stick" On A Moving Picture - Memory Mix
Superimposing a still image in a “Memory Stick” on a moving picture – MEMORY MIX You can superimpose a still image you have recorded on a “Memory Stick” on the top of the moving picture you are recording. M. CHROM (Memory chromakey) You can swap a blue area of a still image such as an illustration or a frame with a moving picture.
Page 130 Superimposing a still image in a “Memory Stick” on a moving picture – MEMORY MIX Before operation •Insert a tape for recording into your camcorder. •Insert a recorded “Memory Stick” into your camcorder. (1) Set the POWER switch to CAMERA or MEMORY. Make sure that the LOCK switch is set to the left (unlock) position.
Page 131 Superimposing a still image in a “Memory Stick” on a moving picture – MEMORY MIX Items to be adjusted M. CHROM The color (blue) scheme of the area in the still image which is to be swapped with a moving picture M.
Page 132: Copying Still Images From A Tape - Photo Save
Copying still images from a tape – Photo save Using the search function, you can automatically take in only still images from tapes and record them on a “Memory Stick” in sequence. Before operation • Insert a recorded tape into your camcorder and rewind the tape. •...
Page 133 Copying still images from a tape – Photo save To stop or end copying Press MENU. When the memory of the “Memory Stick” is full MEMORY FULL appears on the screen, and the copying stops. Insert another “Memory Stick” and repeat the procedure from step 2. Image size of still images Image size is automatically set to 640 480.
Page 134: Viewing A Still Image - Memory Photo Playback
Viewing a still image – Memory photo playback You can play back still images recorded on a “Memory Stick.” You can also play back 6 images including moving pictures in order at a time by selecting the index screen. Before operation Insert a “Memory Stick”...
Page 135 Viewing a still image – Memory photo playback Recording data When you press DATA CODE, you can see the recording data (date/time or various settings when recorded). Recording data are also recorded on “Memory Stick.” When no image is recorded on the “Memory Stick” The message “...
Page 136 Viewing a still image – Memory photo playback Playing back 6 recorded images at a time (index screen) You can play back 6 recorded images at a time. This function is especially useful when searching for a particular image. (1) Set the POWER switch to MEMORY or VCR. Make sure that the LOCK switch is set to the left (unlock) position.
Page 137: Viewing A Moving Picture - Mpeg Movie Playback
Viewing a moving picture – MPEG movie playback You can play back moving pictures recorded on a “Memory Stick.” You can also play back 6 images including still images in order at a time by selecting the index screen. Before operation Insert a “Memory Stick”...
Page 138 Viewing a moving picture – MPEG movie playback Screen indicators during moving picture playback Remaining battery time indicator Image size Picture number/Total number of recorded pictures 2 / 2 0 MO V 0 0 0 0 1 MEMOR Y P L A Y 0 : 1 2 Memory playback indicator Protect indicator...
Page 139: Viewing Images Using Computer
Viewing images using computer You can view data recorded on the “Memory Stick” using your computer. On file format Data recorded on the “Memory Stick” is stored in the following formats. Make sure that applications that support these file formats are installed on your computer. •Still images: •Moving images/audio: MPEG format ActiveMovie Player (DirectShow) must be installed (to play back moving pictures).
Page 140: Installing The Usb Driver
(5) Move the following 2 files from the window opened in step 3 to the System Folder icon in the window opened in step 4 (drag and drop). • Sony Camcorder USB Driver • Sony Camcorder USB Shim (6) When “Put these items into the Extensions folder?” appears, click OK.
Page 141: Viewing Images
Viewing images using computer Viewing images For Windows 98 users (1) Turn on the power of your computer and allow Windows 98 to load. (2) Connect one end of the USB cable to the USB jack on the camcorder and the other end to the USB connector on your computer.
Page 142 Viewing images using computer Unplug the USB cable/Eject the “Memory Stick” To unplug the USB cable or eject the “Memory Stick”, follow the procedure below. For Windows 2000, Windows Me users (1) Move the cursor to the “Unplug or Eject Hardware” icon on the Task Tray and click to cancel the applicable drive.
Page 143 Viewing images using computer Notes on using your computer “Memory Stick” •“Memory Stick” operations on your camcorder cannot be assured if the “Memory Stick” has been formatted on your computer. •Do not optimize the “Memory Stick” on a Windows machine. This will shorten the “Memory Stick”...
Page 144: Copying The Image Recorded On "Memory Stick"S To Tapes
Copying the image recorded on “Memory Stick”s to tapes You can copy images or titles recorded on “Memory Stick” and record them to a tape. Before operation •Insert a tape for recording into your camcorder. •Insert a “Memory Stick” into your camcorder. (1) Set the POWER switch to VCR.
Page 145 Copying the image recorded on “Memory Stick”s to tapes During copying You cannot operate the following buttons: – MEMORY PLAY – MEMORY INDEX – MEMORY DELETE – MEMORY +/– – MEMORY MIX Note on the index screen You cannot record the index screen. If you press EDITSEARCH during pause mode Memory playback stops.
Page 146: Enlarging Still Images Recorded On "Memory Stick"S - Memory Pb Zoom
Enlarging still images recorded on “Memory Stick”s – Memory PB ZOOM You can enlarge still images recorded on a “Memory Stick.” You can select and view the desired part from the enlarged still image. Also you can copy the desired part of the enlarged still image to tapes or “Memory Stick”.
Page 147 Enlarging still images recorded on “Memory Stick”s – Memory PB ZOOM In the PB ZOOM mode The digital effect function does not work. The PB ZOOM function is cancelled when the following buttons are pressed: – MENU – MEMORY PLAY –...
Page 148: Playing Back Images In A Continuous Loop - Slide Show
Playing back images in a continuous loop – SLIDE SHOW You can automatically play back images in sequence. This function is useful especially when checking recorded images or during a presentation. Before operation Insert a “Memory Stick” into your camcorder. (1) Set the POWER switch to MEMORY.
Page 149: Preventing Accidental Erasure - Image Protection
Preventing accidental erasure – Image protection To prevent accidental erasure of important images, you can protect selected images. Before operation Insert a “Memory Stick” into your camcorder. (1) Set the POWER switch to MEMORY or VCR. Make sure that the LOCK switch is set to the left (unlock) position.
Page 150: Deleting Images
Deleting images You can delete images stored in a “Memory Stick.” You can delete all images or selected images. Deleting selected images Before operation Insert a “Memory Stick” into your camcorder. (1) Set the POWER switch to MEMORY or VCR. Make sure that the LOCK switch is set to the left (unlock) position.
Page 151: Deleting All The Images
Deleting images Deleting all the images You can delete all the unprotected images in a “Memory Stick.” Before operation Insert a “Memory Stick” into your camcorder. (1) Set the POWER switch to MEMORY. Make sure that the LOCK switch is set to the left (unlock) position.
Page 152: Writing A Print Mark - Print Mark
Writing a print mark – PRINT MARK You can specify the recorded still image to print out by putting marks. This function is useful for printing out still images later. Your camcorder conforms with the DPOF (Digital Print Order Format) standard for specifying the still images to print out.
Page 153 Writing a print mark – PRINT MARK If the write-protect tab on the “Memory Stick” is set to LOCK You cannot write print marks on still images. Moving pictures You cannot write print marks on moving pictures. While the file name is flashing You cannot write a print mark on the still image.
Page 154: Using The Printer (Optional)
Using the printer (optional) You can use the printer (optional) on your camcorder to print images on the print paper. For details, refer to the operating instructions of the printer. There are various ways of printing still images. The following, however, describes how to print by selecting Before operation •Insert a recorded “Memory Stick”...
Page 155: Troubleshooting
If you run into any problem using your camcorder, use the following table to troubleshoot the problem. If the problem persists, disconnect the power source and contact your Sony dealer or local authorized Sony service facility. If “C:ss:ss” appears on the screen, the self-diagnosis display function has worked. See page 148.
Page 156 Types of trouble and their solutions Symptom The picture is recorded in incorrect or unnatural colors. The picture appears too bright, and the subject does not appear on the screen. The click of the shutter does not sound. Black bands appear when you record TV or computer screen.
Page 157 Types of trouble and their solutions In the recording and playback modes Symptom The power does not turn on. The end search function does not work. The end search function does not work correctly. The battery pack is quickly discharged. The battery remaining indicator does not indicate the correct time.
Page 158 Types of trouble and their solutions When operating using the “Memory Stick” Symptom The “Memory Stick” does not function. Recording does not function. The image cannot be deleted. You cannot format the “Memory Stick”. Deleting all the images cannot be carried out.
Page 159 Check the connection and set the input selector on the VCR again. (p. 68, 69) • The camcorder is connected to DV equipment of other than Sony. c Set it to IR. (p. 71) • Setting program on a blank portion of the tape is attempted.
Page 160 • The battery pack is not properly installed. c Install it properly. (p. 12) • Something is wrong with the battery pack. c Contact your Sony dealer or local authorized Sony service facility. • The POWER switch is not set to OFF (CHG).
Page 161: Self-Diagnosis Display
C:32:ss E:61:ss E:62:ss E:91:ss If you are unable to rectify the problem even if you try corrective actions a few times, contact your Sony dealer or local authorized Sony service facility. LCD screen, Viewfinder or Display window Self-diagnosis display •C:ss:ss You can service your camcorder yourself.
Page 162: Warning Indicators And Messages
Warning indicators and messages If indicators and messages appear on the screen, check the following: See the page in parentheses “( )” for more information. Warning indicators 100-0001 Warning indicator as to file Slow flashing: •The file is corrupted. •The file is unreadable. •You are trying to carry out MEMORY MIX function on moving picture.
Page 163: Warning Messages
Warning indicators and messages Warning messages •CLOCK SET •FOR “InfoLITHIUM” BATTERY ONLY • CLEANING CASSETTE** • FULL • 16BIT • REC MODE • TAPE • “i.LINK” CABLE • FULL • • NO FILE • NO MEMORY STICK • AUDIO ERROR •...
Page 164: Additional Information
Usable cassettes Selecting cassette types You can use the Hi8, Betamax, * There are two types of mini DV cassettes: with cassette memory and without cassette memory. Tapes with cassette memory have We recommend that you use the tape with cassette memory. The IC memory is mounted on this type of cassette.
Page 165: Audio Mode
Usable cassettes Audio mode 12-bit mode: The original sound can be recorded in stereo 1, and the new sound in stereo 2 in 32 kHz. The balance between stereo 1 and stereo 2 can be adjusted by selecting AUDIO MIX in the menu settings during playback. Both sounds can be played back.
Page 166: About "Infolithium" Battery
About the “InfoLITHIUM” battery pack What is the “InfoLITHIUM” battery pack? The “InfoLITHIUM” battery pack is a lithium-ion battery pack that has functions for communicating information related to operating conditions between the battery pack and your camcorder or an AC power adaptor. The “InfoLITHIUM”...
Page 167: Battery Life
About the “InfoLITHIUM” battery pack Battery life •The battery life is limited. Battery capacity drops little by little as you use it more and more, and as time passes. When the available battery time is shortened considerably, a probable cause is that the battery pack has reached the end of its life. Please buy a new battery pack.
Page 168: About I.link
About the Name “i.LINK” i.LINK is a more familiar term for IEEE 1394 data transport bus proposed by SONY, and is a trademark approved by many corporations. IEEE 1394 is an international standard standardized by the Institute of Electrical and Electronic Engineers.
Page 169 DV jacks, see page 69, 83. This unit can also be connected to other i.LINK (DV) compatible equipment made by SONY (e.g. VAIO series personal computer) other than video equipment. Before connecting this unit to a personal computer, make sure that application software supported by this unit is already installed on the personal computer.
Page 170: Using Your Camcorder Abroad
Using your camcorder abroad Using your camcorder abroad You can use your camcorder in any country or area with the AC power adaptor supplied with your camcorder within 100 V to 240 V AC, 50/60 Hz. When charging the battery pack, use a commercially available AC plug adaptor [a], if necessary, depending on the design of the wall outlet [b].
Page 171: Maintenance Information And Precautions
Maintenance information and precautions Moisture condensation If your camcorder is brought directly from a cold place to a warm place, moisture may condense inside your camcorder, on the surface of the tape, or on the lens. In this condition, the tape may stick to the head drum and be damaged or your camcorder may not operate correctly.
Page 172 If the above problem, [a], [b] or [c] occurs, clean the video heads for 10 seconds with the Sony DVM-12CLD cleaning cassette (optional). Check the picture and if the above problem persists, repeat cleaning.
Page 173 •If any solid object or liquid get inside the casing, unplug your camcorder and have it checked by a Sony dealer before operating it any further. •Avoid rough handling or mechanical shock. Be particularly careful of the lens. •Keep the POWER switch set to OFF (CHG) when you are not using your camcorder.
Page 174: About Care And Storage Of The Lens
Maintenance information and precautions AC power adaptor •Unplug the unit from the wall outlet when you are not using the unit for a long time. To disconnect the power cord, pull it out by the plug. Never pull the power cord itself. •Do not operate the unit with a damaged cord or if the unit has been dropped or damaged.
Page 175 •If you touch the liquid, wash it off with water. •If the liquid get into your eyes, wash your eyes with a lot of water and then consult a doctor. If any problem occurs, unplug your camcorder and contact your nearest Sony dealer.
Page 176: Specifications
Specifications Video camera recorder System Video recording system 2 rotary heads Helical scanning system Audio recording system Rotary heads, PCM system Quantization: 12 bits (Fs 32 kHz, stereo 1, stereo 2), 16 bits (Fs 48 kHz, stereo) Video signal NTSC color, EIA standards Usable cassette Mini DV cassette with the mark printed...
Page 177: Battery Pack
Specifications AC power adaptor Power requirements 100 – 240 V AC, 50/60 Hz Power consumption 23 W Output voltage DC OUT: 8.4 V, 1.5 A in the operating mode Operating temperature 0 °C to 40 °C (32 °F to 104 °F) Storage temperature –20 °C to + 60 °C (–4 °F to + 140 °F)
Page 178: Quick Reference
The lens for your camcorder was developed jointly by Carl Zeiss, in Germany, and Sony Corporation. It adopts the MTF* measurement system for video camera and offers a quality as the Carl Zeiss lens. * MTF is an abbreviation of Modulation Transfer Function.
Page 179 Identifying the parts and controls MEMORY EJECT Lever (p. 108) qh PHOTO button (p. 36, 114) qj LOCK switch (p. 19) qk DC IN jack (p. 13) ql START/STOP button (p. 19) w; EDITSEARCH button (p. 28) wa NIGHTSHOT switch (p. 25) ws SUPER NIGHTSHOT button (p.
Page 180 Identifying the parts and controls wh Intelligent accessory shoe (p. 87) wj Power zoom lever (p. 23) wk BATT release button (p. 12) wl Hooks for shoulder strap e; POWER switch (p. 13) (USB) jack (p. 140, 141) Notes on the intelligent accessory shoe •The intelligent accessory shoe supplies power to optional accessories such as a video light or microphone.
Page 181 Identifying the parts and controls eh DISPLAY button (p. 30) ej DATA CODE button (p. 30, 135, 137) ek LCD screen (p. 20) el LCD BRIGHT +/– buttons (p. 21) r; END SEARCH button (p. 28) ra PB ZOOM button (p. 61, 146) rs DIGITAL EFFECT button (p.
Page 182 Identifying the parts and controls SELFTIMER button (p. 27, 39, 119) rh OPEN button (p. 19) rj VOLUME buttons (p. 29) rk RESET button rl MEMORY operation buttons MPEG N X button (p. 137) MEMORY PLAY button (p. 137) MEMORY INDEX button (p. 136) MEMORY DELETE button (p.
Page 183 Identifying the parts and controls tf Battery pack (p. 12) tg OPEN/ EJECT lever (p. 18) th Tripod receptacle Make sure that the length of the tripod screw is less than 6.5 mm (9/32 inch). Otherwise, you cannot attach the tripod securely and the screw may damage your camcorder.
Page 184: Remote Commander
•Your camcorder works in the commander mode VTR 2. Commander modes 1, 2 and 3 are used to distinguish your camcorder from other Sony VCRs to avoid remote control misoperation. If you use another Sony VCR in the commander mode VTR 2, we recommend changing the commander mode or covering the sensor of the VCR with black paper.
Page 185: Operation Indicators
Identifying the parts and controls Operation indicators LCD screen and Viewfinder 1 2 0 min S T B Y – S T I L L 1 6 : 9 W I D E N E G A R T A U T O 6 0 A W B F 1 8 1 Cassette memory indicator (p.
Page 186: Index
Index A, B AC power adaptor ... 13 Adjusting viewfinder ... 22 Audio dubbing ... 87 AUDIO MIX ... 100 Audio mode ... 103 Auto red-eye reduction .. 37, 117 AUTO SHUTTER ... 99 A/V connecting cable ... 33, 40, 68, 82, 122, 127 BACK LIGHT ...
Page 188 Sony Corporation Printed in Japan...

Sony DCR-TRV30 Operating Instructions Manual

Quick Start Guide

Getting Started

Recording - Basics

Playback - Basics

Advanced Recording Operations

Advanced Playback Operations

Editing

Customizing Your Camcorder

?Memory Stick” Operations

Table of Contents

Troubleshooting

Additional Information

Quick Reference

Quick Links

Operating Instructions

Related Manuals for Sony DCR-TRV30

Summary of Contents for Sony DCR-TRV30

Table of Contents
