Summary of Contents for ITRON OpenWay OWR-1000-001
- Page 1 OpenWay 2.4ZR-IPP Range Extender Installation Guide DRAFT OpenWay...
- Page 2 All product returns must be shipped by ground transportation. Modification and Repairs To ensure system performance, this device and antenna shall not be changed or modified without the expressed approval of Itron. Any unauthorized modification will void the user’s authority to operate the equipment.
-
Page 3: Table Of Contents
Contents Before You Begin ......................v Chapter 1 Introduction ....................1 Specifications ............................2 Related Documents..........................3 Chapter 2 Installation ....................5 Installation Checklist..........................5 Installation Flowchart ........................5 Configure the 2.4ZR-IPP Range Extender..................6 Reconfigure an Installed 2.4ZR-IPP Range Extender ..............7 Read an Installed 2.4ZR-IPP Range Extender .................8 Select a Mounting Location .........................8 Link to a CENTRON Meter........................8 Link to the 2.4GZ OpenWay Gas Module ..................10... - Page 4 Contents DRAFT OpenWay Installation Guide...
-
Page 5: Before You Begin
Before You Begin Before beginning the installation, verify that you have the following equipment and tools available. Equipment Provided by Itron • 2.4ZR-IPP Range Extender (OWR-1000-001). • Itron magnet (MSE-0159-003). • Bluetooth-enabled FC200 handheld computer (or laptop computer) loaded with Endpoint-Link or Endpoint-Link Pro software version 5.4 or higher. - Page 6 Before You Begin DRAFT OpenWay Installation Guide...
-
Page 7: Chapter 1 Introduction
H A P T E R Introduction Itron's OpenWay® 2.4ZR-IPP (Itron Private Profile) Range Extender is installed when data is not being exchanged between an OpenWay CENTRON® electric meter and a 2.4GZ OpenWay Gas Module. If both the CENTRON meter and the gas module are working properly, there may be radio frequency (RF) signal constraints preventing the meter and the module from communicating with one another. -
Page 8: Specifications
Chapter 1 Introduction The 2.4ZR-IPP Range Extender is configured with the same Itron tools used for programming the 2.4GZ OpenWay Gas Module. When mitigation and installation is complete, a reliable signal path is established between the gas module and the CENTRON meter. -
Page 9: Related Documents
Related Documents Meter compatibility Description Electric meters OpenWay CENTRON Hardware version 1.5 only System release firmware version SR1.6-SR2.0 SP5.1 Gas meters 2.4GZ OpenWay Gas Module Model OWG-5001-xxx or later with IPP Related Documents • 2.4GZ OpenWay Gas Module Installation Guide – Direct Mount (TDC-0816-xxx) •... - Page 10 Chapter 1 Introduction DRAFT OpenWay Installation Guide...
-
Page 11: Chapter 2 Installation
H A P T E R Installation To set up and install the 2.4ZR-IPP Range Extender, perform all of the procedures in the Installation Checklist in the order listed. Installation Checklist Step Procedure Configure the 2.4ZR-IPP Range Extender on page 6. Select a Mounting Location on page 8. -
Page 12: Configure The 2.4Zr-Ipp Range Extender
OpenWay Belt Clip Radio, and the same configuration files used to program the 2.4GZ OpenWay Gas Module during installation. See the Endpoint-Link Endpoint Programming Guide (TDC-0744-xxx) for more complete programming information. An Itron magnet is also required to initiate communication between the range extender and other devices. DRAFT OpenWay Installation Guide... -
Page 13: Reconfigure An Installed 2.4Zr-Ipp Range Extender
Configure the 2.4ZR-IPP Range Extender To configure the 2.4ZR-IPP Range Extender 1. Position and hold the Itron magnet over the label on the side of the range extender for approximately five seconds and then remove the magnet. 2. Watch the red LED blink pattern to verify that the range extender is searching for the configuration devices. -
Page 14: Read An Installed 2.4Zr-Ipp Range Extender
The radio link from the range extender to the CENTRON meter must be established before you establish a link to the gas module. The Itron Private Profile 2.4GZ OpenWay Gas Module does not need to be pointed to a specific CENTRON meter. Any CENTRON meter may be joined to the range extender. - Page 15 Remember that mounting is temporary at this time because the range extender may need to be moved. 2. To activate the radio joining process, hold the Itron magnet on the side of the range extender over the label for approximately five seconds and then remove the magnet.
-
Page 16: Link To The 2.4Gz Openway Gas Module
To set up and verify the radio link to the gas module 1. Go to the gas meter with the 2.4GZ OpenWay Gas Module and use the Itron magnet to activate the gas module's radio joining process. Refer to the 2.4GZ OpenWay Gas Module Installation Guide for complete instructions. - Page 17 Link to the 2.4GZ OpenWay Gas Module # of Definition Action color blinks None The gas module could not join to • If the range extender's install the range extender. window has not yet expired, retry step 1. • If the install window has expired, repeat the procedure Link to a CENTRON Meter...
-
Page 18: Mount The Range Extender
Chapter 2 Installation Mount the Range Extender Note Perform each procedure in the order listed in the Installation Checklist page 5. To permanently mount the range extender, perform the following procedure. To mount the range extender 1. If the permanent mounting location is significantly different from the location first attempted, you may need to perform the procedures Link to a CENTRON Meter page 8 and... -
Page 19: Chapter 3 Troubleshooting
Then, during the install window, the gas module must have a magnet swipe to establish its connection to the range extender. • If communication continues to fail, contact Itron to replace the 2.4ZR-IPP Range Extender. DRAFT OpenWay Installation Guide... - Page 20 Chapter 3 Troubleshooting DRAFT OpenWay Installation Guide...
-
Page 21: Index
• product identification • documents • reading • Endpoint-Link • v, 7, reconfiguring • equipment provided by Itron • related documents • equipment provided by you • requirements • FCC compliance • ii, safety • frequency band •... - Page 22 Index DRAFT OpenWay Installation Guide...
