NXP Semiconductors Freedom FRDM-KV11Z User Manual

NXP Semiconductors
Application Note
Freedom FRDM-KV11Z Development Board
User's Guide

1. Introduction

The Freedom development board is a set of software
and hardware tools for evaluation and development. It is
ideal for rapid prototyping of microcontroller-based
applications. The Freedom KV11 hardware,
FRDMKV11Z, is a simple, yet sophisticated design
featuring a Kinetis V series microcontroller, built on the
ARM Cortex -M0+ core, and a perfect solution for
® ®
BLDC and PMSM motor control applications. FRDM-
KV11Z can be used to evaluate the KV1x Kinetis V
series devices. It is based on the MKV11Z128VLF7
microcontroller, running up to 75MHz with hardware
square root and divide capability and featuring dual 16-
bit analog-to-digital controllers (ADCs) sampling at up
to 1.2 mega samples per second (MS/s) in 12-bit mode,
multiple motor control timers, 128KB of flash and
16KB of RAM memories and CAN interface. It is
supported by a comprehensive enablement suite from
NXP and its third-party resources including reference
designs, software libraries, and motor configuration
tools. The FRDM-KV10Z hardware is form-factor
compatible with the Arduino® R3 pin layout, providing
a broad range of expansion board options. Board
embeds a 6-axis digital sensor, combining
accelerometer and magnetometer, an analog thermistor,
a RGB LED and two user push-buttons. The
FRDMKV11Z platform includes the OpenSDA, the
NXP open-source hardware for embedded serial and
debug adapter, programmed with an open-source
bootloader. This circuit offers several options for serial
communication, flash programming, and run-control
© 2016 NXP B.V.
PRELIMINARY
Document Number: FRDMKV11ZUG
Contents
1. Introduction ........................................................................ 1
2. FRDM-KV11Z Hardware Overview.................................. 2
3. FRDM-KV11Z Hardware Description ............................... 4
3.1. Power supply .......................................................... 4
3.2. Measuring MCU current ......................................... 5
3.3. Debug interface ....................................................... 6
3.4. OpenSDA ................................................................ 6
3.5. Cortex debug connector .......................................... 6
3.6. Virtual mass storage device programming .............. 7
3.7. Virtual serial port .................................................... 9
4. Microcontroller .................................................................. 9
5. Clock source .................................................................... 10
6. Accelerometer and magnetometer .................................... 11
7. Thermistor ........................................................................ 12
8. RGB LED ........................................................................ 13
9. CAN serial interface ........................................................ 14
10. Reset ................................................................................ 14
11. Push button switches ........................................................ 15
12. Input/output connectors .................................................... 16
13. Arduino Compatibility ..................................................... 17
14. References ........................................................................ 17
15. Revision history ............................................................... 18
Rev. 1 , 5/2019
