SU LEE MACHINE ST-360.4 Instruction Book And Parts Book

Hide thumbs

Advertisement

Quick Links

Download this manual
ST-260.4
MODEL
ST-360.4
INSTRUCTION BOOK AND PARTS BOOK
SU LEE MACHINE .CO.,LTD.

Advertisement

loading
Need help?

Need help?

Do you have a question about the ST-360.4 and is the answer not in the manual?

Questions and answers

Related Manuals for SU LEE MACHINE ST-360.4

Summary of Contents for SU LEE MACHINE ST-360.4

  • Page 1 ST-260.4 MODEL ST-360.4 INSTRUCTION BOOK AND PARTS BOOK SU LEE MACHINE .CO.,LTD.

  • Page 2: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS When using your cutting machine,basic safety precautions should always be followed,including the following 1. Read all instructions. 2. Use machine only for its intended use a portable cutting machine 3. Turn machine to “OFF” before connecting or disconnecing power cord. 4.
  • Page 3 INSTRUTION MANUAL 1.1 Connect the terminal,grind the knife 2~3times,reser the counter to 0000,counter switch is turn ON. 1.2 See pictuer 1-1,pall cloth to end rail. 1.3 See pictuer 1-2,Lift rail to press clothe. 1.4 See pictuer 1-3,Push button switch on,and pull cutter cut off cloth in a straight line. 1.5 See pictuer 1-4,Lift end rail then put down.
  • Page 4 INSRUCTION AND PROCESS OF INSTALLATION 2.1 Align the right foot rest 263946N-R and the left foot rest 263946N-L and secure both on the cutter. 2.2 Place the right hoist rod 264749N from top to bottom into the pulley groove of the right rest 263946N-R and the left hoist rod 264750N from top to bottom into the pulley groove of the left rest 263946N-L.
  • Page 6 CHECKING (Release connecting plugs) 3.1 Every 24 hours, Clean the Rail bar. 3.2 Every 200 hours, Give oil to roller 2611-BN 3.3 Adjustment of Re-sharpener: While the grinding wheel wears ,loosen stop nut of collar holder and rectify the re-sharpener position so as to the grinding wheel keeps proper contact with the knife edge.
  • Page 11 零件名稱 零件名稱 PART NO. PART NAME PART NO. PART NAME 260110-110 110V Motor 265359-9' 9feet Rail Set 110V馬達組 9呎軌道組 260110-220 220V Motor 220V馬達組 -10' 10feet Rail Set 10呎軌道組 110V 切刀主機 軌道護蓋 260138-110 110V Cutter Head 2655N Rail Guard 220V 切刀主機 長防撞彈簧...
  • Page 12 速利 速利機 機 機 機 械工 速利 速利 械工 械工業 業 業 業 有限公司 械工 有限公司 有限公司 有限公司 SU LEE MACHINE IND.CO.,LTD. 地址: 臺灣省臺北市北投區磺港路 190 號 NO.190,HWANG GANG RD.,BEITOU,TAIBEI,TAIWAN. TEL: (886 2)28914693 28927700 FAX: (886 2)28940855 E-mail: sulee1@ms11.hinet.net Http: www.sule.com.tw...

This manual is also suitable for:

St-260.4
