Sony AC-VQV10 Operating Instructions

Ac adaptor/charger
Hide thumbs


Advertisement

4-172-847-12(1)
AC Adaptor/Charger
Adaptateur/Chargeur CA
Operating Instructions
Mode d'emploi
AC-VQV10
© 2010 Sony Corporation Printed in Japan
VCR/CAMERA
WAITING
BATTERY LIFE
WARNING
TIME TO CHG
NORMAL FULL
h
m
2
3
4
1 1
To remove
The contents of the display window change each time you press
the DISPLAY change button.
1
2
1
2
1
2
1
2
1
2
1
2
2
3
1
4
5
English
Thank you for purchasing the Sony AC Adaptor/Charger.
Before operating the unit, please read this manual thoroughly and retain it for future
reference.
Owner's Record
The model and serial numbers are located on the bottom of the unit.
Record the serial number in the space provided below.
Refer to these numbers whenever you call upon your Sony dealer regarding this
product.
Model No. AC-
Serial No.
WARNING
To reduce fire or shock hazard, do not expose the unit to rain or moisture.
Do not expose the batteries to excessive heat such as sunshine, fire or the like.
To avoid electrical shock, do not open the cabinet.
Refer servicing to qualified personnel only.
The AC Power cord must only be changed at a qualified service shop.
CAUTION
Replace the battery with the specified type only. Otherwise, fire or injury may result.
PRECAUTION
The set is not disconnected from the AC power source (mains) as long as it is
connected to the wall outlet, even if the set itself has been turned off.
NOTICE FOR THE CUSTOMERS IN THE U.S.A.
CAUTION
You are cautioned that any changes or modifications not expressly approved in this
manual could void your authority to operate this equipment.
Note:
This equipment has been tested and found to comply with the limits for a Class
B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause
harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the user
is encouraged to try to correct the interference by one or more of the following
measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
NOTICE FOR THE CUSTOMERS IN THE U.S.A. AND CANADA
IMPORTANT SAFETY
INSTRUCTIONS
SAVE THESE INSTRUCTIONS.
DANGER - TO REDUCE THE RISK OF
FIRE OR ELECTRIC SHOCK, CAREFULLY
FOLLOW THESE INSTRUCTIONS.
 This power unit is intended to be correctly orientated in a vertical or floor mount position.
 For connection to a supply not in the U.S.A., use an attachment plug adapter of the proper configuration for
the power outlet.
Battery to be recharged for this product is follows
Brand Name
Sony
Battery Type
NP-FV30
NP-FV50
NP-FH50
NP-FV70
NP-FV100
Rating
DC 7.2 V
DC 6.8 V
DC 6.8 V
DC 6.8 V
DC 6.8 V
(Typical Capacity)
3.6 Wh
7.0 Wh
6.1 Wh
14.0 Wh
26.5 Wh
(500 mAh)
(1030 mAh)
(900 mAh)
(2060 mAh)
(3900 mAh)
Representative plug of power supply cord of countries/regions
around the world.
A type
B type
BF type
B3 type
C type
SE type
O type
(British Type)
(British Type)
(British Type)
(CEE Type)
(CEE Type)
(Ocean Type)
(American Type)
The representative supply voltage and plug type are described in this chart.
Depend on an area, Different type of plug and supply voltage are used.
Attention: Power cord meeting demands from each country shall be used.
For only the United States
Use a UL Listed, 1.8-3 m (6-10 ft), Type SPT-2 or NISPT-2, AWG no. 18 power
supply cord, rated for 125V 7A, with a NEMA 1-15P plug rated for 125V 15A. "
Europe
Countries/Regions
Voltage
Frequency (Hz)
Plug type
Austria
230
50
C
Belgium
230
50
C
Czech
220
50
C
Denmark
230
50
C
Finland
230
50
C
France
230
50
C
Germany
230
50
C
Greece
220
50
C
Hungary
220
50
C
Iceland
230
50
C
Ireland
230
50
C/BF
Italy
220
50
C
Luxemburg
230
50
C
Netherlands
230
50
C
Norway
230
50
C
Poland
220
50
C
Portugal
230
50
C
Romania
220
50
C
Russia
220
50
C
Slovak
220
50
C
Spain
127/230
50
C
Sweden
230
50
C
Switzerland
230
50
C
UK
240
50
BF
Asia
Countries/Regions
Voltage
Frequency (Hz)
Plug type
China
220
50
A
Hong Kong
200/220
50
BF
India
230/240
50
C
Indonesia
127/230
50
C
Japan
100
50/60
A
Korea (rep)
220
60
C
Malaysia
240
50
BF
Philippines
220/230
60
A/C
Singapore
230
50
BF
Taiwan
110
60
A
Thailand
220
50
C/BF
Vietnam
220
50
A/C
Oceania
Countries/Regions
Voltage
Frequency (Hz)
Plug type
Australia
240
50
O
New Zealand
230/240
50
O
North America
Countries/Regions
Voltage
Frequency (Hz)
Plug type
Canada
120
60
A
USA
120
60
A
Central America
Countries/Regions
Voltage
Frequency (Hz)
Plug type
Bahamas
120/240
60
A
Costa Rica
110
60
A
Cuba
110/220
60
A/C
Dominican (rep)
110
60
A
El Salvador
110
60
A
Guatemala
120
60
A
Honduras
110
60
A
Jamaica
110
50
A
Mexico
120/127
60
A
Nicaragua
120/240
60
A
Panama
110/220
60
A
South America
Countries/Regions
Voltage
Frequency (Hz)
Plug type
Argentina
220
50
C/BF/O
Brazil
127/220
60
A/C
Chile
220
50
C
Colombia
120
60
A
Peru
220
60
A/C
Venezuela
120
60
A
Middle East
Countries/Regions
Voltage
Frequency (Hz)
Plug type
Iran
220
50
C/BF
Iraq
220
50
C/BF
Israel
230
50
C
Saudi Arabia
127/220
50
A/C/BF
Turkey
220
50
C
UAE
240
50
C/BF
Africa
Countries/Regions
Voltage
Frequency (Hz)
Plug type
Algeria
127/220
50
C
Congo (dem)
220
50
C
Egypt
220
50
C
Ethiopia
220
50
C
Kenya
240
50
C/BF
Nigeria
230
50
C/BF
South Africa
220/230
50
C/BF
Tanzania
230
50
C/BF
Tunisia
220
50
C
NOTICE FOR THE CUSTOMERS IN THE UNITED KINGDOM
A moulded plug complying with BS 1363 is fitted to this equipment for your safety
and convenience.
Should the fuse in the plug supplied need to be replaced, a fuse of the same rating as
the supplied one and approved by ASTA or BSI to BS1362 (i.e., marked with
or
mark) must be used.
If the plug supplied with this equipment has a detachable fuse cover, be sure to
attach the fuse cover after you change the fuse. Never use the plug without the
fuse cover. If you should lose the fuse cover, please contact your nearest Sony
service station.
<Notice for the customers in the countries applying EU Directives>
The manufacturer of this product is Sony Corporation, 1-7-1 Konan Minato-ku
Tokyo, 108-0075 Japan. The Authorized Representative for EMC and product safety
is Sony Deutschland GmbH, Hedelfinger Strasse 61, 70327 Stuttgart, Germany.
For any service or guarantee matters please refer to the addresses given in separate
service or guarantee documents.
For the Customers in Europe
Disposal of Old Electrical & Electronic Equipment (Applicable
in the European Union and other European countries with
separate collection systems)
This symbol on the product or on its packaging indicates that this
product shall not be treated as household waste. Instead it shall
be handed over to the applicable collection point for the recycling
of electrical and electronic equipment. By ensuring this product
is disposed of correctly, you will help prevent potential negative
consequences for the environment and human health, which
could otherwise be caused by inappropriate waste handling of this
product. The recycling of materials will help to conserve natural
resources. For more detailed information about recycling of this
product, please contact your local Civic Office, your household
waste disposal service or the shop where you purchased the
product.
Notes on Use
This unit does not have dust-proof, splash-proof or waterproof
specifications.
Charging
Designed for use with compatible Sony battery packs.
Only charge recommended battery packs with this unit.
Attach the battery pack firmly.
Charging temperature
To provide maximum battery efficiency, the recommended temperature range
when charging is 10 °C to 30 °C (50 °F to 86 °F).
This unit provides quick charging, but charging outside the recommended
temperature range leads to longer charging times in order to protect the
battery pack. Once the charging time has been extended, it will not return to
quick charging even if the temperature is brought within the recommended
temperature range. Reattach the battery pack and then recharge it.
Where not to put this unit
Do not put this unit in any of the following places, whether it is in use or in storage.
Doing so may lead to a malfunction.
Where it is extremely hot
Near a heater or in direct sunlight such as on a dashboard. This unit may become
deformed or malfunction.
Where there is excessive vibration
Where there is strong electromagnetism or radiation
Where there is excessive sand
Protect this unit from sand and dust in places such as the seashore and other
sandy areas or where dust clouds occur, as there is risk of malfunction.
Precautions on Use
Do not place objects filled with liquids, such as vases, on the apparatus.
Do not use the unit placed in a narrow space, such as between a wall and
furniture.
The nameplate indicating operating voltage, power consumption, etc. is located on
the bottom.
Attach the battery pack firmly to this unit when charging the battery pack.
The battery terminal may be damaged if the battery pack is not attached correctly.
Do not use this unit where there are strong radio waves or radiation. Video
cameras etc. may not be able to record or play back correctly.
To protect the battery pack, remove it from this unit when charging is completed.
Do not drop or apply mechanical shock to this unit.
Keep this unit away from TVs or AM receivers. Noise from this unit may enter the
TV or radio if placed nearby.
Connect this unit to an available wall outlet. Even when the CHARGE lamp of
this unit is off, the power is still connected. If any trouble occurs while this unit is
in use, unplug it from the wall outlet to disconnect the power.
Be sure that nothing metallic comes into contact with the metal parts of this unit
or connecting cord. If it does, a short may occur and this unit may be damaged.
Do not connect this unit to a voltage adaptor (travel converter) for overseas travel.
This may result in overheating or another malfunction.
This unit gets warm during use. This is not a malfunction.
Unplug this unit from the wall outlet after use. To disconnect the cord, pull it out
by the plug. Never pull the cord itself.
Remove the battery from this unit when charging is complete. Keeping the battery
attached may decrease the battery life.
Maintenance
If this unit gets dirty, wipe it using a soft dry cloth.
If this unit gets very dirty, wipe it using a cloth with a little neutral solvent added,
and then wipe it dry.
Do not use thinners, benzine, alcohol, etc., as they will damage the surface of this
unit.
When using a chemical cleaning cloth, refer to its instruction manual.
Spraying with a volatile solvent such as an insecticide or prolonged contact with
rubber or vinyl may cause deterioration or damage to this unit.
Troubleshooting
Symptom
Cause/Solution
Video equipment
The power plug is disconnected from the wall outlet.
does not work
Insert into a wall outlet.
The connector cable is not properly connected.
Connect properly.
The mode switch is set to CHARGE.
Set the mode switch to VCR/CAMERA.
The battery pack is
The mode switch is set to VCR/CAMERA.
not charged
Set the mode switch to CHARGE.
Power immediately
Run down the battery pack and then fully charge it again.
turns off even though
The battery life will be correctly displayed.
there is sufficient
battery life, or the
displayed battery
life differs from the
actual battery life
The display is not
Refer to "Notes on the BATTERY LIFE indicator and the
changed
Battery remaining % indication".
Quick charging is not
The temperature of the battery pack is too high or too low.
performed
The display shown below may appear if a battery
pack with a high or low temperature is attached, or
if charging is performed outside the recommended
charging temperature range of 10 °C to 30 °C (50 °F
to 86 °F). Although charging can still be performed in
these cases, quick charging is not performed in order
to protect the battery pack.
SYSTEM
VTR/カメラ
SYSTEM
VTR/カメラ
充電異常
使用可能時間
充電異常
使用可能時間
実用満充電
実用満充電
 終了まで
時間
 終了まで
時間
Symptom
Cause/Solution
When the CHARGE lamp blinks, read the following and take suitable action
depending on how the CHARGE lamp blinks.
The CHARGE lamp blinks in the following two ways.
Blinks quickly: Turns on and off repeatedly every 0.15 seconds
Blinks slowly: Turns on and off repeatedly every 1.5 seconds
When the CHARGE lamp
Charging is temporarily stopped. This unit is
keeps blinking slowly and
in the standby state.
"WAITING" is displayed in the
If the room temperature or the battery
display window.
temperature is out of the appropriate
temperature range, charging stops
automatically.
When the room temperature returns to the
appropriate range, the CHARGE lamp lights
up and charging restarts.
We recommend charging the battery pack at
10 °C to 30 °C (50 °F to 86 °F).
WAITING
WAITING
When the CHARGE
A battery that has not been used for a long time
lamp blinks quickly and
may lack the minimum required remaining
"WARNING" is displayed in
capacity for this unit and battery pack to
the display window
recognize each another. In this case, remove the
The battery pack is being
battery pack from the unit and then install and
charged after a long period of
charge it again.
non-use.
If "WARNING" is still displayed, check
according to the following procedure.
Remove the battery pack from this unit and then reinstall it.
The CHARGE lamp blinks again:
The CHARGE lamp lights up and
Install another battery pack.
does not blink again:
If the CHARGE lamp goes out
because the charging time has
passed, there is no problem.
The CHARGE lamp blinks again:
The CHARGE lamp lights up and
The problem is with this unit.
does not blink again:
If the CHARGE lamp goes out
because the charging time has
passed, the problem is with the
battery pack first installed.
Please contact your nearest Sony dealer regarding a product that may have a
problem.
Specifications
AC-VQV10
Input
100 V - 240 V AC 50/60 Hz 26 W
Output
8.4 V DC 1.7 A (VCR)
8.4 V DC 2.2 A (BATT)
Operating temperature
0 °C to 40 °C (32 °F to 104 °F)
Storage temperature
–20 °C to +60 °C (–4 °F to +140 °F)
Dimensions
Approx. 100 × 67 × 111 mm (w/h/d)
(excluding the projecting
(4 × 2 3/4 × 4 3/8 in.)
parts)
Mass
Approx. 330 g (11.7 oz)
Included items
AC Adaptor/Charger (AC-VQV10) (1)
AC Power cord (1)
Connecting cord (DK-225) (1)
Set of printed documentation
Design and specifications are subject to change without notice.
Note
Use a commercially available AC plug Adaptor (not supplied), if necessary,
depending on the design of the wall outlet.
Wall outlet
AC-VQV10
AC plug Adaptor (not supplied)
Do not connect this unit to a voltage Adaptor (travel converter) for overseas
travel. This may result in overheating or other malfunction.
The AC-VQV10 AC Adaptor/Charger can be
used as follows
For operating Sony equipment (video cameras etc.) using the connection cords
included with this unit.
For charging Sony rechargeable battery packs (V series, H series, P series). The
following functions are available when charging an "InfoLITHIUM" battery pack.
With an "ActiFORCE" battery pack, even more advanced control is possible.
Quick charging
(Faster than charging with your video camera, etc.)
Approximate charging time and battery life can be displayed.
For charging lithium ion battery packs. Cannot be used to recharge Ni-Cd or
Ni-MH batteries.
Cannot be used with some model video cameras or other equipment. Confirm
the compatibility of your equipment before use.
What is "InfoLITHIUM"?
"InfoLITHIUM" is a lithium ion battery pack which can exchange data on battery
consumption with compatible electronic equipment. We recommend that you use an
"InfoLITHIUM" battery pack (V series, H series, P series) with electronic equipment
that has the
mark.
"InfoLITHIUM" is a trademark of Sony Corporation.
What is "ActiFORCE"?
"ActiFORCE" is the function name for next generation power systems.
"ActiFORCE" has higher capacity, quicker recharge, and faster and more accurate
calculation of remaining battery capacity compared to our existing "InfoLITHIUM"
battery pack P series power system.
"ActiFORCE" is a trademark of Sony Corporation.
Notes on the BATTERY LIFE indicator and the
Battery remaining % indication (Read carefully
before use)
While charging the battery pack, this unit shows the battery life and the remaining
battery capacity if used with your video camera, etc. so long as the following
conditions are met.
You are using an "InfoLITHIUM" battery pack.
You are using a video camera, etc. with the
mark.
Check the battery pack has the
mark. Check in the operating
instructions supplied with your video equipment whether it is "InfoLITHIUM"
compatible.
If you use the battery pack with more than one video camera, etc. with the
mark, the remaining battery time shown is if using with the equipment last attached to the
battery pack.
Compensation for Recorded Content
Sony will not provide compensation for any failure to record or play back images,
sound or other content due to a malfunction of the battery pack or AC adaptor/
charger.
To Operate Video Equipment
See illustration .
For details of connection, refer to the operating instructions of the video camera etc.
1 Set the mode switch to VCR/CAMERA.
2 Connect the AC power cord to this unit.
3 Connect the AC power cord to a wall outlet.
There is a beep and the display window comes on.
4 Connect the connecting cord to the DC OUT connector of this unit.
5 Connect the connecting cord to the video camera.
For the direction in which to fit the connecting cord, refer to the operating
instructions of video camera etc.
Notes
Setting the mode switch to CHARGE while operating the video camera etc. cuts
the power supply to the video camera.
You cannot charge a battery pack installed in this unit when this unit is in VCR/
CAMERA mode.
Keep this unit away from your video camera etc. if the image is distorted.
The illustration shows connection to an HDR-CX550V digital HD video camera
recorder.
To Charge the Battery Pack
See illustration -.
Also refer to the operating instructions of your device (video camera etc,)
and battery pack.
1 Set the mode switch to CHARGE.
2 Connect the AC power cord to this unit.
3 Connect the AC power cord to a wall outlet.
There is a beep and the display window comes on.
4 Install the battery pack.
Refer to "To install the battery pack". When charging starts, the battery mark in
the display window blinks in sequence and the CHARGE lamp lights up.
5 When charging is complete, remove the battery pack.
There are two levels of charge completion: "Normal charge" and "Full charge".
Normal charge
When charge is completed, the battery mark is
displayed as illustrated on the right.
Full charge
If you continue to charge after normal charging
is complete until the battery mark shows "FULL",
the battery pack can be used slightly longer than
when in the normal charged state.
Refer to "To remove the battery pack" when removing the battery pack.
Installing two battery packs simultaneously
You can install two battery packs in this unit at the same time. Charging starts with
the battery pack installed in Slot .
When two battery packs are installed but not simultaneously, charging starts with
the battery pack installed first regardless of whether it is in Slot  or .
Note
This unit can be installed with two battery packs but cannot charge both
simultaneously.
To install the battery pack
See illustration -.
 Place the battery pack on this unit with the  mark facing the
terminal.
 Slide the battery pack in the direction of the arrow.
To remove the battery pack
See illustration -.
Slide the battery pack in the direction of the arrow and lift it straight out.
Notes
Do not pick up this unit by holding the battery pack.
Be particularly careful not to hit the battery pack when installing it.
Be careful not to pinch your fingers while installing or removing the battery pack.
Charging time
The following tables show the charging time for a main battery pack that has been
completely discharged.
Quick Charge
"InfoLITHIUM" battery pack V series
NP-FV100
NP-FV70
NP-FV50
125 min
70 min
55 min
Normal charge
Full charge
185 min
130 min
115 min
"InfoLITHIUM" battery pack H series
NP-FH100
NP-FH70
NP-FH50
130 min
65 min
55 min
Normal charge
Full charge
190 min
125 min
115 min
"InfoLITHIUM" battery pack P series
NP-FP90
NP-FP71
NP-FP50
Normal charge
115 min
80 min
65 min
Full charge
175 min
140 min
125 min
The charging time may differ depending on the condition of the battery pack and
the ambient temperature.
The times shown are for charging an empty battery pack which has been run
down with a video camera etc., using this unit at an ambient temperature of 25 °C
(77 °F).
To use the battery pack quickly
You can use the battery pack even if you remove it from this unit before charging is
completed. However, a shorter charging time means a shorter useable time.
Charging time and "10-minute charging/approx.
55-minute recording"
The times shown are the approximate continuous recording times at an ambient
temperature of 25 °C (77 °F) when using an NP-FV70 rechargeable battery pack (sold
separately) and a video camera that has a power consumption of 1.8W when used
without its LCD display.
This is when using a battery pack immediately after running it down with a video
camera. It does not include a battery pack that has deteriorated, for example because
it has not been used for a long time.
There are two kinds of charging, normal charge and full charge.
Generally, the charging time and available recording time vary depending on the
battery pack and conditions of use.
Notes
If the mode switch is set to VCR/CAMERA during charging, charging stops.
If the CHARGE lamp does not light up or blink, check that the battery pack is
correctly attached to the AC Adaptor/Charger. If it is not correctly attached, it will
not be charged.
If anything goes wrong during charging, the charge lamp blinks and "WARNING"
appears on the display. For details, see "Troubleshooting".
To Check Charging
See illustration .
When charging starts, the battery life or the battery remaining % indication* lights
up in the display window (*when using the battery pack V series). The battery
life displayed is the approximate time remaining for recording images using the
viewfinder. The battery life is shorter if the LCD display is used.
The battery life may not be displayed with certain video cameras. For details, refer to
"Notes on the BATTERY LIFE indicator and the Battery remaining % indication".
Press DISPLAY during charging.
During charging, the contents of the display window change each time you press
the DISPLAY change button. The slot indicator lamp shows the slot number for the
battery information displayed. When two battery packs are installed simultaneously,
the time display of the battery pack not being charged returns automatically after
about 10 seconds to the time display of the battery pack being charged.
Here is an example of installing a battery pack in Slot  followed by another in Slot
.
The slot indicator lamp corresponds to the slot number.
 Battery life if the first installed battery pack is installed in your
"InfoLITHIUM" electronic equipment.
 Remaining time until normal charging of the first installed battery
pack is complete.
The normal charge time is not displayed after full charging is complete.
 Remaining time until full charging of the first installed battery pack
is complete.
The full charge time is not displayed after full charging is complete.
This is not displayed when two battery packs are installed simultaneously.
 Battery life if the last installed battery pack is installed in your
"InfoLITHIUM" electronic equipment.
 Remaining time until normal charging of the last installed battery
pack is complete.
The normal charge time is not displayed after full charging is complete.
 Remaining time until full charging of the last installed battery pack
is complete.
The full charge time is not displayed after full charging is complete.
Notes
The time display or the remaining battery capacity when charging at 25 °C (77 °F)
are approximate. They may differ from the actual time and remaining battery
capacity depending on the environment of use.
It may take some time after pressing DISPLAY for the time to be displayed.
The time display of the battery pack on the side not being charged may take some
time to appear.
To display the battery life of a new battery pack, first install it in your video
camera recorder and use it for about 20 seconds, and then charge it with this unit.
If you install a fully charged battery pack in this unit, "TIME TO CHG FULL 1h"
may appear on the display. This is not a malfunction.
The time display may show "– – – –" in the following cases. This is not a
malfunction.
There is a difference between the time display and actual charging time. Even if
this happens, continue charging.
When charging a battery other than an "InfoLITHIUM" battery pack (Battery
life display and other functions are not available.)
In the following cases, there may be some deviation in the time display. This is not
a malfunction.
If the battery pack is removed from this unit after normal charge is finished but
before full charge is finished. (It takes about one hour from when normal charge
is complete to when full charge is complete.)
When charging a battery pack that has not been use for a long time. (Fully
charge once first.)
When charging a P series "InfoLITHIUM" battery pack, it may take about one
minute after installing the battery pack for the time to appear in the display
window.
Full charging requires about one hour after normal charging is complete.
When charging a battery pack that has not been used for a long time, the displayed
battery life and full charge time sometimes differ from the actual times. This is not
a malfunction. If this happens, fully charge the battery pack. The correct times can
then be displayed.
Identifying the parts
See illustration .
Display window
Slot 
Mode switch
"InfoLITHIUM" indicator
DISPLAY change button
WAITING indicator
CHARGE lamp 
WARNING indicator
DC OUT connector
TIME TO CHG (charge) indicator
Slot 
Time indicator
CHARGE lamp 
BATTERY LIFE indicator
Display window
VCR/CAMERA indicator
Slot indicator lamp
Battery remaining % indication
Normal charge indicator
Full charge indicator
Battery life indicator

Advertisement

Table of Contents
loading

  Summary of Contents for Sony AC-VQV10

  • Page 1: Important Safety Instructions

    If the plug supplied with this equipment has a detachable fuse cover, be sure to attach the fuse cover after you change the fuse. Never use the plug without the fuse cover. If you should lose the fuse cover, please contact your nearest Sony service station.
  • Page 2  Pour charger des batteries rechargeables Sony (série V, série H, série P). Les fonctions suivantes sont disponibles lors de la charge d’une batterie « InfoLITHIUM ». Avec une batterie « ActiFORCE », un contrôle encore plus précis est possible.
