- Page 1 Operating Instructions Digitalmanometer Model: PDC...
-
Page 2: Table Of Contents
Content Page 3-16 1. Foreword 2. Digital manometer description 3. Commissioning 4. Pressure Connection 5. Description of Parameters 6. Programming PDC-1 / PDC-2 10 7. Technical data 8. CE-conformity 9. Maintenance 10. Troubleshooting 11. Cleaning 12. Disposal Manufactured and sold by: Kobold Messring GmbH Nordring 22-24 D-65719 Hofheim Tel.: +49(0)6192-2990 Fax: +49(0)6192-23398 E-Mail: info.de@kobold.com Internet: www.kobold.com... -
Page 3: Foreword
1. Foreword Thank you for the confidence that you have shown in Kobold by purcha- sing the PDC digital manometer. Like all other Kobold products, PDC digital manometers are a combi- nation of customer requirements, state-of-the-art technology, modern manufacturing and stringent quality control. - Page 4 • The manometer must only be repaired by Kobold. The accepted technical regulations and all national regulations must always be observed and complied with.
-
Page 5: Digital Manometer Description
Usage for any other purpose than the ones that are mentioned in „Correct purpose of use“ is not permitted. Claims for compensation will only be entertained by Kobold in the event of intent or gross negligence. Responsibility for damage to equipment, systems or the surroundings of the digital manometer will not be accepted. -
Page 6: Commissioning
Open the battery compartment lid on the back of the digital manometer. Replace the batteries with new Mignon cells. Replace the battery compartment lid. PDC K01/007... -
Page 7: Pressure Connection
4. Pressure Connection PDC K01/007... -
Page 8: Description Of Parameters
5. Description of Parameters Display screen PDC-1 Bar graph display Max. value Min. value Full scale Main display Unit LO-BAT Display screen PDC-2 Bar graph display Max. value nd display Min. value Full scale Main display Unit LO-BAT Tare Special function PDC K01/007... - Page 9 This bar segment is also updated to the current measure value when the min./max. value is reset. PDC K01/007...
- Page 10 6. Programming Model PDC-2 PDC K01/007...
- Page 11 PDC K01/007...
- Page 12 . The current measured value will be backed up as tare. The main display and the auxiliary display are set to (0000). Setting the tare value to (0000) resets the tare function in both models. PDC K01/007...
- Page 13 Model PDC-1 PDC K01/007...
-
Page 14: Technical Data
• Password PDC-1: without, PDC-: settable • Tare PDC-1: without, PDC-: 0% of F.S. settable • Automatic PDC-1: without, option factory set: 1, 0, 60, 10 min switch off time PDC-: settable • Measuring unit bar, PSI MPa selectable Illumination of... -
Page 15: Ce-Conformity
The manometer complies with all requirements of EN 61 6 with regard to interference emission and immunity for use in industrial areas. cable routing must be carried out correctly in order to maintain the effective protection from electromagnetic interference. PDC K01/007... -
Page 16: Maintenance
No modifications must be made to the equipment. Only the manufac- turer is allowed to repair the device. 11. Cleaning The exterior of the PDC digital manometer can be cleaned using a soft, moistened cloth. Heavy soiling can be removed using a mild cleaning agent.
