ReplayTV 4500
®
U s e r ' s G u i d e

Advertisement

Table of Contents
loading

Related Manuals for Sonic Blue ReplayTV 4500

Summary of Contents for Sonic Blue ReplayTV 4500

  • Page 1 ReplayTV 4500 ® U s e r ’ s G u i d e...
  • Page 2 P a c k a g e C o n t e n t s • ReplayTV Digital Video Recorder • Coaxial cable • Audio/Video cable • S-Video cable • Ethernet cable • Telephone cable • Infrared (IR) blaster cable *Use if the serial cable is not compatible with your satellite receiver.

  • Page 3: Table Of Contents

    1 - G e t t i n g S t a r t e d 1 • Before you Begin...1 • Feature Updates from the ReplayTV Service...1 • Feature Highlights ...2 • Turning on ReplayTV...6 • Putting ReplayTV in Standby Mode ...6 2 - C o n n e c t i o n s 7 •...
  • Page 4 3 - S e t u p 2 1 • ReplayTV Name...23 • Internet Identity and Address Book...23 • Default Record Options...23 • Default Playback Options...23 • Network and Input Settings ...23 • Video Output Settings ...23 • Screen Saver and Pause Screen ...23 •...
  • Page 5 • Resolving Conflicting Recordings ...40 • Replay Channels ...40 • Recording Tips ...42 • Navigating the Replay Guide ...44 • Category Options...44 • Replay Channel Options...44 • Replay Show Options ...45 • Watching a Recorded Show ...45 • Preserving an Episode of a Show ...45 •...
  • Page 6 6 - H e l p 5 7 • Customer Service Information ...57 • Frequently Asked Questions...57 • Warranty ...63 • Privacy Policy Q&A...68 • Important Safety Instructions ...71 • Safety/Regulatory Information...73 • FCC Registration and Requirements ...74 • FCC Rules, Part 15 ...74 •...

  • Page 7: Getting Started

    : : W e l c o m e Congratulations on your purchase of the ReplayTV 4500. In case warranty service is required, please take a moment to attach your receipt to this user’s guide and write down your Serial Number, located on the back panel of the ReplayTV 4500.

  • Page 8: Feature Highlights

    F e a t u r e H i g h l i g h t s • Control live television. Pause, rewind, fast forward, play in slow motion, or watch an instant replay—all without missing a sin- gle scene. See “Controlling Live Television” on page 28. •...
  • Page 9 : : R e m o t e C o n t r o l O v e r v i e w Power ReplayTV on or off. 1 R e p l a y T V ( P O W E R ) Power TV on or off.
  • Page 10 : : F r o n t P a n e l O v e r v i e w Manually switch between On and Standby modes. Blinks while ReplayTV is starting up. Lights red when ReplayTV is on. Lights green after ReplayTV finishes recording a show. Lights green when ReplayTV is playing a show.
  • Page 11 : : R e a r P a n e l O v e r v i e w Connect an antenna, cable TV coaxial cable, or cable box with coaxial cable. Connect to a television VHF/UHF jack with coaxial cable. Connect to a cable box or satellite receiver that has S-Video Out.

  • Page 12: Turning On Replaytv

    : : A b o u t S e r v i c e A c t i v a t i o n There is a one-time service activation fee for you to use your new ReplayTV 4500 Series Digital Video Recorder (“ReplayTV”).

  • Page 13: Connections

    C h a p t e r 2 : : B a s i c C o n n e c t i o n s This chapter describes how to connect ReplayTV to your TV and other devices, including your home network. You will find detailed connection options not found on the Quick Setup Guide.
  • Page 14 If your satellite receiver uses a 15-pin serial cable, you will need to use the 9-pin to 15-pin adapter to connect the satellite receiver to ReplayTV. If you have a satellite receiver that uses telephone cable in place of serial cable, you will need to use the RJH to 9-pin adapter to connect the satellite receiver to ReplayTV.

  • Page 15: Incorporating Replaytv Into Your Entertainment System

    : : P l a n n i n g y o u r S e t u p Read this section before incorporating ReplayTV into your entertainment system. I n c o r p o r a t i n g R e p l a y T V i n t o y o u r E n t e r t a i n m e n t S y s t e m ReplayTV controls and records the television signals you receive (satellite, cable, antenna, or a combination of all three).

  • Page 16: Connecting Replaytv To A Vcr

    C o n n e c t i n g R e p l a y T V t o a V C R Connect ReplayTV to a VCR if you want to watch or save your record- ings on videotape. Deleting recordings from the Replay Guide will pre- serve hard drive space.
  • Page 17 If the infrared detector on the unit is not labeled, follow these steps: Refer to the owner’s manual of your cable box or satellite receiver. It may be shown there. Look for an area of dark, nearly opaque plastic on the front of the unit. If you find this area, look closely into it.

  • Page 18: Completing The On-Screen Setup

    If you have a home network, you can connect ReplayTV to it using the ETHERNET connection. This connection will allow you to send recordings to other ReplayTV 4000 and 4500 users, watch shows recorded on another ReplayTV in your home, and transfer photos from your PC to ReplayTV.
  • Page 19 C o n n e c t i n g R e p l a y T V t o a C a b l e M o d e m Using a router to connect ReplayTV to your cable modem is recommended. The router will allow you to share your cable modem without needing additional IP addresses from your Internet Service Provider (ISP).
  • Page 20 If you are connecting ReplayTV directly to a hub or switch that is connected to your cable modem, you will need an IP address from your ISP for ReplayTV. Before setting up ReplayTV, you should verify with your ISP that a device like ReplayTV is supported. You may need to specify the IP address on ReplayTV.

  • Page 21: Router Setup

    C o n n e c t i n g R e p l a y T V t o a D S L M o d e m Connecting ReplayTV to a DSL modem is the same as connecting it to a cable modem with a few exceptions. Refer to “Connecting ReplayTV to a Cable Modem”...
  • Page 22 When you first go to the ReplayTV Internet Address Book, you are asked to open a port number on your router. This is only required if you will be sending recordings to other ReplayTVs. The port number must be associated with the IP address of ReplayTV.

  • Page 23: Using Replaytv With Firewall Software

    U s i n g R e p l a y T V w i t h F i r e w a l l S o f t w a r e Sending recording to other ReplayTVs requires a port to be forwarded through your router (or firewall) for incoming network con- nections.

  • Page 24: Determining The Replaytv Mac (Media Access Control) Address

    D e t e r m i n i n g t h e R e p l a y T V M A C ( M e d i a A c c e s s C o n t r o l ) A d d r e s s Every Ethernet device has a unique hardware number.

  • Page 25: Finding Your Computer's Network Information

    If your home network does not have a DHCP server (a router, for example), you will need to manually set the IP address on ReplayTV. You can use the network information from your computer to determine what the IP address should be. Following are steps to find this information for common computer systems.

  • Page 27: S E T U

    C h a p t e r 3 : : A b o u t M e n u N a v i g a t i o n The following keys are used to display and navigate ReplayTV menus: Press to move up the list of menu items.
  • Page 28 : : M a i n M e n u Use the Main Menu to access ReplayTV’s main fea- tures. Press the MENU button to display the Main Menu. Channel Guide: The Channel Guide is ReplayTV’s on-screen program guide. The Channel Guide provides 12 days of current television listings for all of the TV channels you receive.

  • Page 29: Replaytv Name

    You can also choose this option to change between use of a phone line and Ethernet connection. (For example, if you purchased your ReplayTV 4500 and use the telephone line to receive Channel Guide listings and then later add a broadband network to your home.) Choose Switch Connection from the Setup Summary screen if you switch from modem to Ethernet use.

  • Page 30: Parental Control

    P a r e n t a l C o n t r o l Parental Control offers you the ability to block video and audio of live TV shows or recorded shows based on the show rating or content. In addition, it allows blocking of specific channels. Once you access Parental Control, a screen will be displayed where you will be able to create or edit your 4-digit PIN (Personal Identification Number).

  • Page 31: System Information

    S y s t e m I n f o r m a t i o n View the system information for your ReplayTV. This screen lists: • the version of software your ReplayTV is using • the Serial Number of your ReplayTV •...

  • Page 32: Remote Control Setup

    R e m o t e C o n t r o l S e t u p Follow these steps to program the remote control to operate your television. The ReplayTV remote will only control your TV’s power and volume. Even if your television is not listed, try the codes anyway. You should be able to turn your TV on and off when the correct code is used.

  • Page 33: B A S I C O P E R A T I O N

    C h a p t e r 4 : : B a s i c O p e r a t i o n s ReplayTV gives you the power to watch television the way you have always wanted. Create your own channels, watch only what you want to watch, and do it all on your own schedule–not someone else’s.

  • Page 34: Pausing Live Tv And Recorded Shows

    : : C o n t r o l l i n g L i v e T e l e v i s i o n The moment you turn on ReplayTV and your TV, ReplayTV automatically begins recording and temporarily preserves the record- ing on its hard drive.

  • Page 35: Using Multispeed Slow Motion

    To use Fast Forward while watching a show: Press FF (Fast Forward) for 1x fast forward. Press FF again for 2x fast forward. Press FF again for 4x fast forward. Press FF again for 16x fast forward. Press FF again for 20x fast forward. Press PLAY, STOP, or REW (Rewind) to stop fast forwarding.

  • Page 36: Using Instant Replay

    To stop Frame Advance: Press PLAY to resume playback at normal speed. Press RETURN TO LIVE to return to the live broadcast. The Instant Replay feature lets you jump back seven seconds during a live or recorded show. It’s the perfect way to ensure you don’t miss a single word of dialogue in your favorite movie, or if you want to watch a great play over again at the touch of a button.
  • Page 37 : : A c c e s s i n g t h e C h a n n e l G u i d e The Channel Guide is an interactive, on-screen program guide that lists 12 days of television programming for all of the channels you receive.

  • Page 38: Using The Channel Guide

    Press CHANNEL GUIDE on the ReplayTV remote control. Press MENU, then select Channel Guide. Navigate through the Channel Guide by pressing the UP, DOWN, LEFT and RIGHT ARROW buttons. Notice the program infor- mation changes to display the information for the currently highlighted show. •...
  • Page 39 C h a n n e l G u i d e O p t i o n s Depending on the type of channel you have selected, the following options may be available when you press SELECT with a future show (green) highlighted: Record this show: Schedule the selected show to record.
  • Page 40 : : R e c o r d i n g S h o w s T o r e c o r d t h e l i v e s h o w y o u a r e w a t c h i n g Press RECORD on the ReplayTV remote control.

  • Page 41: Setting Record Options

    S e t t i n g R e c o r d O p t i o n s There may be times when you want to adjust the Record Options for a specific show. For example, you might want to record action movies or sporting events at higher quality than television shows.
  • Page 42 : : F i n d S h o w s ReplayTV can search through the Channel Guide for shows so you don’t have to. Find Shows is the perfect feature for those times when there is a show you want to record, but don’t know what time or channel it is on. You can also use it to find when your favor- ite show will air next.

  • Page 43: To Record A Show From A Replay Zone

    : : R e p l a y Z o n e s You can quickly and easily find what’s on TV, organized in user-friendly categories, using Replay Zones. Zone-based channels can hold a specific amount of programming (1/2 hour, 2 hours, etc.). Non-guaranteed Zone-based channels behave exactly like guaranteed Zone-based channels except: •...

  • Page 44: Changing The Default Record Options

    See “Sending Recordings to other ReplayTVs” on page 49 to send your home videos to other ReplayTV 4000 and 4500 owners. C h a n g i n g t h e D e f a u l t R e c o r d O p t i o n s If ReplayTV does not require you to set record options when you schedule a show recording, the show will be recorded using your Default Record Options.

  • Page 45: Cancelling A Recording

    C a n c e l l i n g a R e c o r d i n g To cancel a recording before it starts: Press CHANNEL GUIDE on the ReplayTV remote. Highlight the show you want to cancel. You will know it’s set to record because at least one red dot will appear next to the show.

  • Page 46: Resolving Conflicting Recordings

    R e s o l v i n g C o n f l i c t i n g R e c o r d i n g s ReplayTV allows you to choose what will be recorded when attempting to record a show at the same time as a previously scheduled recording.
  • Page 47 ings park in reserved spots, but they will be promptly towed if a guaranteed recording needs to park. After all, the non-guaranteed recording was parking in the guaranteed recording’s spot. If you have created many Replay channels, it is possible that eventually two scheduled recordings will conflict with each other. The following recording priorities are numbered from highest priority to lowest: Guaranteed Single-record and Show-based recordings If a change in television schedules puts guaranteed Show-based channels into a recording conflict with each other, the Replay...

  • Page 48: Recording Tips

    If you set a Show-based channel to record all episodes, the oldest episode will be recycled to make room for a new episode when the channel is full. Guaranteed Theme-based channels are designed to hold a specific amount of programming (1/2 hour, 2 hours, etc.). Twenty-four hours after being recorded, the oldest program will be recycled to make room for a new program when the channel is full.
  • Page 49 : : U s i n g t h e R e p l a y G u i d e Think of the Replay Guide as your personal television station, broadcasting only the shows you want to watch. You can find every show that ReplayTV has recorded in the Replay Guide.

  • Page 50: Navigating The Replay Guide

    N a v i g a t i n g t h e R e p l a y G u i d e Press REPLAY GUIDE on the ReplayTV remote control. Press MENU, then select Replay Guide. Navigate through the Replay Guide by pressing the UP, DOWN, LEFT and RIGHT ARROW buttons. Press the FF and REW but- tons from anywhere within the Replay Guide to view the next or previous category.

  • Page 51: Replay Show Options

    R e p l a y S h o w O p t i o n s Play: Play the show from its current point. Play from beginning: Play the show from the start. Preserve this episode: Save the show in the Replay Guide. See “Preserving an Episode of a Show” below. Save to VCR: Save the show to a videotape.

  • Page 52: Saving Recordings To Videotape

    S a v i n g R e c o r d i n g s t o V i d e o t a p e ReplayTV is not intended to be used as a long-term storage device. You can free up more recording space by transferring your recordings to videotape and watching them on your VCR.

  • Page 53: A D V A N C E D F E A T U R E

    C h a p t e r 5 : : W a t c h i n g S h o w s R e c o r d e d o n o t h e r R e p l a y T V s By connecting ReplayTV to your home network, you can watch a show in the bedroom that was recorded in the living room.

  • Page 54: Selecting Local/Remote Replay Guides

    S e l e c t i n g L o c a l / R e m o t e R e p l a y G u i d e s If more than one ReplayTV exists on the network, you will see left and right arrows next to the ReplayTV name in the upper right hand corner of the Replay Guide.

  • Page 55: Adding Other Replaytv Users To Your Internet Address Book

    ReplayTV allows you to send recordings including shows you record and home videos – can send a recording to a maximum of 15 ReplayTVs. To send a recording to another ReplayTV user you must first enter their Internet Serial Number in your Internet Address Book. A d d i n g o t h e r R e p l a y T V u s e r s t o y o u r I n t e r n e t A d d r e s s B o o k Get the Internet Serial Number from the other user.

  • Page 56: Using The Received Category

    U s i n g t h e R e c e i v e d C a t e g o r y Shows that have been sent to you from other users are stored in the Received category. Selecting a show will display the sender’s name and information about the show.

  • Page 57: Setting Commercial Advance Default

    If you ever wanted to watch TV without commercials, then COMMERCIAL ADVANCE is what you’ve been waiting for. COMMERCIAL ADVANCE is a feature that allows you to choose whether to skip most commercial messages dur- ing playback of recorded shows. Commercials are still recorded with COMMER- CIAL ADVANCE enabled, though you now have the choice to watch them or not—automatically.

  • Page 58: Installing Replaytv Photo Transfer

    To switch between skipping and viewing commercials while watch- ing a show, press the button on the remote control. Keep in mind that the following still apply: Commercials will not be skipped during the first and last two min- utes when playing back a recorded show. Shows delayed within a few minutes of the live broadcast will not skip commercials.

  • Page 59: Using The Photo Viewer

    To transfer your photos to ReplayTV, simply copy your photos into the folders that you have created. Each folder (and its accompa- nying photos) is considered a separate slide show and can be named appropriately: for example, “Fishing” or “Vacation.” The slide show feature is controlled with the Photo Viewer, accessed from the Main Menu.

  • Page 60: Show-Watching Shortcuts

    : : R e m o t e C o n t r o l S h o r t c u t s S h o w - w a t c h i n g S h o r t c u t s •...

  • Page 61: Find Shows On-Screen Keyboard Shortcuts

    • To move to the next screen after typing a keyword, press the REC button. • To erase a character, press the REW button. • To insert a space, press the FF button. S l i d e S h o w C o n t r o l S h o r t c u t s •...
  • Page 63 : : T r o u b l e s h o o t i n g The FAQs below will help you solve common issues with your ReplayTV 4500. If you do not find the answers you need here, you...
  • Page 64 When I select a channel in the Chan- • If you are using an IR blaster connection to control channel changing, verify that the IR blaster cable is securely nel Guide, the channel number does attached to the IR BLASTER jack on ReplayTV, and that you have affixed the IR emitter directly over the IR not change on my satellite receiver detector on your cable box or satellite receiver.
  • Page 65 A “Please Wait” message displays ReplayTV might not be communicating with your network. This may be caused by ReplayTV receiving non-standard more than 2-5 minutes during first DHCP information. time Quick Setup. • Unplug ReplayTV from both your network and electrical outlet. Disable DHCP on your network •...
  • Page 66 DHCP (Dynamic Host Configuration Protocol) - This is the method by which computers, and ReplayTV, automatically get IP addresses. By default, the ReplayTV 4500 will attempt to get its IP address automatically when it’s starting up. It will attempt to renew this IP address every 24hrs.
  • Page 67 MAC Address (Media Access Control) - address of a network device in order to automatically assign it an IP address. Router - In order for you computer to communicate to the Internet using a broadband connection, it not only requires a physical connection but also an IP address.
  • Page 68 : : T e c h n i c a l S p e c i f i c a t i o n s VHF/UHF IN/OUT (RF) VIDEO/AUDIO IN (STEREO) (RCA) VIDEO/AUDIO OUT (STEREO) (RCA) S-VHS IN/OUT (S-JACK) TELEPHONE JACK (RJ-11) IR BLASTER PORT ETHERNET PORT IR BLASTER...
  • Page 69 • By phone: 1-800-933-5899 By email: techsupport@replaytv.com SONICblue Incorporated (“SONICblue”) warrants your 4500 series ReplayTV (the “ReplayTV”) and any included ReplayTV accessories against defects in material or workmanship as follows: LABOR: For a period of one (1) year from the date of purchase (“Warranty Period”), if the ReplayTV is determined to be defective, SONICblue will repair or replace the unit, at its option, at no charge, or pay the labor charges to any ReplayTV authorized service facility.
  • Page 70 must furnish a valid credit card number and expiration date. Otherwise, a replacement ReplayTV will be shipped upon receipt of the defective unit. In addition, all accessories must be returned with the defective ReplayTV. A new or factory refurbished set of accessories will be furnished with the replacement ReplayTV.
  • Page 71 odically update, modify or enhance the Software remotely through the RTVS, and that any registration or other information pro- vided by you may be used or disclosed by SONICblue pursuant to the terms of SONICblue’s ReplayTV Privacy Policy, as that policy may be modified by SONICblue from time to time.
  • Page 72 dance with Federal Acquisition Regulation (“FAR”) 12.212 for civilian agencies and Defense Federal Acquisition Regulation Sup- plement (“DFARS”) 227.7202 for military agencies. This agreement shall in all respects be governed by the laws of the State of California without reference to its principles of conflicts of laws.
  • Page 73 : : P r i v a c y P o l i c y Personal television and digital video recording are radically improving the way you watch TV. You are now in charge of your own television viewing experience. Along with that, we want you to know how important your privacy is to us.
  • Page 74 Q: What information does SONICblue collect from the www.sonicblue.com/replaytv Web site? A: When you visit certain areas of www.sonicblue.com/replaytv, we may ask you to register by providing Personal Information. For example, if you buy a product, enter a contest, or subscribe to a mailing list from our site, we will ask you for certain Personal Infor- mation in connection with that transaction.
  • Page 75 use this information to determine what television channels and schedule are available to you. Each day, the ReplayTV digital video recorder contacts SONICblue to download a current TV schedule for you. Q: How does SONICblue use the information it collects about my digital video recorder use? A: Personal Information collected during registration of your ReplayTV digital video recorder may be used for diagnostic purposes.
  • Page 76 or Anonymous Information to them at its discretion when it appears that individuals using our products or services are engaged in activities that are illegal or violate the ReplayTV Service Terms of Service. Should SONICblue merge with or be acquired by another company, or if the business unit providing your service were sold to another company, then customer information maintained by SONICblue, including Personal and Anonymous Information, may be transferred to and used by the resulting combined company.
  • Page 77 : : S a f e t y All the safety and operating instructions should be read before the product is operated. The safety and operating instructions should be retained for future reference. All warnings on the product and in the operating instructions should be adhered to. All operating and use instructions should be followed.
  • Page 78 The product is equipped with an attachment plug having overload protection. This is a safety feature. See Instruction Manual for replacement or resetting of protective device. If replacement of the plug is required, be sure the service technician has used a replacement plug specified by the manufacturer that has the same overload protection as the original plug.
  • Page 79 When replacement parts are required, be sure the service technician has used replacement parts spec- ified by the manufacturer or have the same characteristics as the original part. Unauthorized substitutions may result in fire, electric shock, or other hazards. Upon completion of any service or repairs to this product, ask the service technician to perform safety checks to determine that the product is in proper operating condition.
  • Page 80 This section describes the requirements for compliance with Federal Communications Commission (FCC) Rules and Industry Can- ada CS-03 standard. The following paragraphs describe requirements and information based on FCC rules. This equipment has been tested and found to comply with the limits for a class B digital device, pursuant to Part 15 of the FCC Rules.
  • Page 81 This equipment complies with FCC Rules, Part 68. On this equipment is a label which contains, among other information, the FCC Part 68 registration number. The Federal Communications Commission (FCC) has established Rules which permit this device to be directly connected to the telephone network.
  • Page 83 Connecting ReplayTV to an Add or Remove Channels existing network Connecting the IR blaster Connecting the serial cable Basic operations Customer Service Informa- tion Cable overview Cancel recording Category options Default Record Options Channel Guide Closed captioning COMMERCIAL VANCE Fast forward Connecting a Video Cam- Feature highlights era or VCR...
  • Page 84 Save to videotape Single recording 23, 52 Screen saver Slow Motion Sending Recordings System Information Service Activation Setup Menu Technical specifications Show-based recording Theme-based channels Troubleshooting Turning on ReplayTV V-Chip Video Output Settings Watch a recorded show Zone-based channels...
  • Page 86 2841 Mission College Blvd. Santa Clara, CA 95054-1838...
