Ascotel® IntelliGate® Communications Systems
Ascotel® IntelliGate® A150/300 as of I7.6
System Manual
A150
A300

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Ascotel Intelligate A150 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Aastra Ascotel Intelligate A150

Summary of Contents for Aastra Ascotel Intelligate A150

  • Page 1 A150 Ascotel® IntelliGate® Communications Systems A300 Ascotel® IntelliGate® A150/300 as of I7.6 System Manual...

  • Page 2: Table Of Contents

    Ascotel® IntelliGate® A150/300 Content Safety Information ......... .8 1.
  • Page 3 Ascotel® IntelliGate® A150/300 Installation ..........51 4.
  • Page 4 Ascotel® IntelliGate® A150/300 4. 7. 2. 2 Network interfaces a/b......... . .85 4.
  • Page 5 Ascotel® IntelliGate® A150/300 5. 5. 3 Import / Export Data ......... . . 138 5.
  • Page 6 Ascotel® IntelliGate® A150/300 6. 3. 4. 1 Change Defective DSP Module ....... . . 158 6.
  • Page 7 Ascotel® IntelliGate® A150/300 7. 4 Technical Data ..........202 7.

  • Page 8: Safety Information

    Ascotel® IntelliGate® A150/300 Safety Information This chapter provides you with information about Ascotel® IntelliGate® products and the symbols used in this document. Information about commissioning, operation and data protection are other topics in this chapter. 1. 1 About the products Purpose and function Ascotel®...

  • Page 9: About This Document

    Italian. You can download this document as well as related documents and help systems with further information (see page 207) at http://www.aastra.com/docfinder. More information on the system can be found at http://www.aastra.com or in your dealer’s documentation and homepage. It is your responsibility to inform yourself about the project planning, expansion stages, system limits, installation, functional scope, operation, running and maintenance.
  • Page 10 Ascotel® IntelliGate® A150/300 General Considerations Special symbols for additional information and document references. Note Failure to observe information identified in this way can lead to equip- ment faults or malfunctions or affect the performance of the system. Additional information on the handling or alternative operation of equip- ment.

  • Page 11: Commissioning

    Ascotel® IntelliGate® A150/300 1. 3 Commissioning Completeness Check for completeness when unpacking the delivered system. Complaints are to be settled within an appropriate period. Damaged Components Check the components for damage. Damaged systems or components must not be put into operation. Foreign Matter in the Hardware If objects or liquids have penetrated the equipment and/or modules, said equip- ment and/or modules must not be put into operation.

  • Page 12: During Operation

    Ascotel® IntelliGate® A150/300 Hazard: Explosion hazard through operation in areas subject to explosion haz- ards. Do not install the systems in areas subject to explosion hazards. Installation Instructions Observe the installation instructions precisely with regard to the components in- stalled, the earthing concept and the connection of the system. Observe the electrical limiting values specified in the System Manual when con- necting third-party equipment such as switchgears, music sources, etc., to the sys- tem.

  • Page 13: Data Protection

    Ascotel® IntelliGate® A150/300 1. 5 Data protection During operation the system records and stores personal customer data (call log- ging). Take the following precautionary measures: • During configuration, always keep the configuration / planning data contained on the relevant data carriers under supervision. •...

  • Page 14: System Overview

    Ascotel® IntelliGate® A150/300 System Overview This chapter provides a brief overview of the Ascotel® IntelliGate® with its system termi- nals and application possibilities. In addition, installation versions and positioning in relation to other Ascotel® products are shown. Finally, we talk about the topics of net- working possibilities, application interfaces, and connection possibilities.
  • Page 15 Ascotel® IntelliGate® A150/300 Basic Systems Ascotel® IntelliGate® 150/300 is a family of communication systems. While the A150 and A300 are based on the same fundamental system, they differ in their expan- sion possibilities. All the connections and control elements are accessible from the front. The display elements are arranged so that they remain visible whatever the installation posi- tion.
  • Page 16 Ascotel® IntelliGate® A150/300 Terminals The system terminals are characterised by an attractive design, ergonomic opera- tor convenience and customer-oriented functionality. The broad range of products ensures there is a suitable model for every use. Among corded terminals the choice ranges from the cost-effective basic model to the fully equipped added-feature model.
  • Page 17 Ascotel® IntelliGate® A150/300 Installation versions Ascotel® IntelliGate® 150 and Ascotel® IntelliGate® 300 are suitable for both desk- top installation, wall mounting and installation in a 19" rack system. Covers for con- necting cables and special installation covers for rack installation are available sep- arately.
  • Page 18 Ascotel® IntelliGate® A150/300 Positioning Applications range from very small offices and branches (A150) to small and me- dium-sized companies (A300). The diagram below shows the positioning in relation to the number of subscribers compared with other Ascotel® products. The information relates to non-networked stand-alone systems.
  • Page 19 Ascotel® IntelliGate® A150/300 Networking Possibilities The networking of several systems is possible both in a private network (PISN) and in an Ascotel® IntelliGate® Net (AIN). It is possible to combine systems of the family Ascotel® IntelliGate® 2025/2045/2065 and Ascotel® IntelliGate® 150/300. Ascotel®...
  • Page 20 Ascotel® IntelliGate® A150/300 Application interfaces The most important interface for own and third-party applications is the interface of the Open Interfaces Platform (OIP). This open interface allows the applications to be deeply integrated with telephony. The user is then able to benefit from a highly convergent complete system (telephony and IT system).
  • Page 21 Digital paging system with S-bus interface (2B+D) Fax server S extern Fax 1..3 IP Terminals Office 1560 Office 1600 Aastra 2380ip S external Ethernet Office 1560IP Office 1600IP SW IP phones Office IP phones HW IP phones Analogue Telephony Pulse dialling / DTMF...

  • Page 22: Expansion Stages And System Limits

    Ascotel® IntelliGate® A150/300 Expansion Stages and System Limits Within the system limits the basic systems can be expanded using interface cards, sys- tem modules and licences. To adapt the system ideally to suit the customer require- ments, the available expansion possibilities and system limits need to be known. With the project data the optimum hardware configuration is easily determined using the Project Manager.

  • Page 23: Basic Systems

    Ascotel® IntelliGate® A150/300 3. 2 Basic systems Ascotel® IntelliGate® 150and Ascotel® IntelliGate® 300 are based on the same basic system, they differ in terms of the components fitted to the mainboard, the expan- sion possibilities and the system limits. The basic systems consists of the following components: •...
  • Page 24 Ascotel® IntelliGate® A150/300 The diagram below shows the position of all the interfaces and slots on the main- board and front panel. Mainboard EIM card holder Connector for fan (A300) (A300) (A300) (A300) Interfaces internal Ethernet (A300) (A300) LED display LINK / (A300) AUDIO...

  • Page 25: Basic Functions

    Ascotel® IntelliGate® A150/300 3. 2. 2 Basic functions The basic functions of the systems depend first and foremost on the available DSP resources (DSP = Digital Signal Processor). The DSP chip on the mainboard pro- vides signal processing functions for conference circuits, DTMF sender and receiver, compression of voice data, etc.
  • Page 26 Ascotel® IntelliGate® A150/300 Selectable additional functions of the basic systems The basic systems provide expanded additional functions as indicated in the fol- lowing table. Only one of the listed additional functions or combinations of func- tions can be selected. For this the DSP on the mainboard has to be loaded with dif- ferent firmware.

  • Page 27: Expansion With Cards And Modules

    Ascotel® IntelliGate® A150/300 3. 3 Expansion with cards and modules A basic system can be individually expanded using interface cards and system modules. The number of available expansion slots depends on the basic system (see "Interfaces", page 23). 3. 3. 1 Interface cards Interface cards provide network interfaces and/or user-network interfaces or spe- cial interfaces.

  • Page 28: Trunk Cards

    Ascotel® IntelliGate® A150/300 3. 3. 1. 1 Trunk cards The trunk cards contain interfaces for connection to the analogue public network (POTS), the digital public network (ISDN) or for networking systems to create a pri- vate telephony network (PISN). The trunk cards can be used and operated on any slots for interface cards.

  • Page 29: Subscriber Cards

    Ascotel® IntelliGate® A150/300 3. 3. 1. 2 Subscriber cards Subscriber cards are used for connecting digital and analogue voice and data ter- minals such as: The ratio of S interfaces to T interfaces is determined by the type and plug-in orien- tation of the Wiring Adapters (see "Wiring Adapter", page 71).

  • Page 30: Option Card

    Ascotel® IntelliGate® A150/300 3. 3. 1. 3 Option card The ODAB options card contains relays, control inputs and an analogue subscriber circuit for connecting a door intercom (TFE). The I/Os of the options card are partly configurable and can be used for the following purposes: •...

  • Page 31: System Modules

    Ascotel® IntelliGate® A150/300 3. 3. 2 System modules System modules expand the resources of the basic systems, allowing the system to be expanded step by step in line with requirements. 3. 3. 2. 1 DSP module Some system functions require additional signal processing capacity. This is achieved using DSP modules (DSP stands for Digital Signal Processor).
  • Page 32 Ascotel® IntelliGate® A150/300 Allocatable functions System functions can be allocated to the individual DSP chips on the DSP modules. For this the DSP chips have to be loaded with different firmware. The DSP resources can be used for DECT telephony, Voice-over-IP, Voice Mail, hands-free operation, in- tegrated GSM subscribers or fax transmissions.
  • Page 33 Ascotel® IntelliGate® A150/300 The allocatable functions are determined under CM_1_1_2 in the AIMS Configura- tion Manager. Tab. 10 Allocatable functions per DSP chip Function 1 / Function 2 Max. number of simultaneously usable... A150 A300 DECT / – DECT channels 8 / –...

  • Page 34: Lan Switch Module

    Ascotel® IntelliGate® A150/300 3. 3. 2. 2 LAN switch module The LAN switch module SM-LAN8 can be used to set up a compact data network capable of connecting up to 8 users. The module has the following features: • 10/100 Mbit/s •...
  • Page 35 Ascotel® IntelliGate® A150/300 Example: The schematic diagram shows an A300 fitted with two LAN switch modules and three AD2 subscriber cards (the greyed LAN switch modules represent alternative component configurations). This means that the front panel provides 16 RJ45 sock- ets connected with Ethernet and AD2 interfaces.

  • Page 36: Wiring Adapter

    Ascotel® IntelliGate® A150/300 3. 3. 3 Wiring Adapter The wiring adapters route the interfaces of the various interface cards with the right connection diagram to the RJ45 sockets on the front panel. The adapters are fitted to WA1...WA4 sockets. WA-TS0 WA-TS1 WA-2W Fig.

  • Page 37: Expansion To An Isylink System

    Ascotel® IntelliGate® A150/300 3. 4 Expansion to an isyLink system 3. 4. 1 What’s isyLink? Ascotel® IntelliGate® isyLink (IntelliGate System Link) allows you to easily couple two Ascotel® IntelliGate® systems via a RJ45 patch cable and, thus, increase the number of connection ports for digital and analogue terminals. The isyLink connection between the systems is an IP connection.

  • Page 38: Application Possibilities

    Ascotel® IntelliGate® A150/300 3. 4. 2 Application possibilities Ascotel® IntelliGate® isyLink can be used with the systems Ascotel® IntelliGate® 150 (A150) and Ascotel® IntelliGate® 300 (A300). The following combinations are possi- ble: Tab. 13 Possible isyLink combinations isyMaster isySatellite Combination 1: isyLink (A300+A300) A300 A300...

  • Page 39: Isylink Set H

    Ascotel® IntelliGate® A150/300 3. 4. 3. 2 isyLink set H This set is suitable for hybrid systems which besides G.711 also require the coding method according to the G.729 standard, e. g. for remote IP terminals or for con- nection to an IP provider. This set comprises: •...

  • Page 40: System Limits

    Ascotel® IntelliGate® A150/300 3. 5 System Limits System limits are defined on the one hand by the existing hardware with its expan- sion possibilities and on the other by the limits set in the software. The software limits can be enabled in part by licences. 3.

  • Page 41: Network Interfaces

    Ascotel® IntelliGate® A150/300 Ascotel® Ascotel® isyLink AIN with Max. number... Intelli- Intelli- A300 + A300 as Gate® 150 Gate® 300 A300 Master Subscribers per user group with global call distribution Subscribers per user group without global call distribu- tion Abbreviated dialling numbers + PISN subscribers 1500 1500 1500...

  • Page 42: Terminals

    Ascotel® IntelliGate® A150/300 Limited by the maximum number of subscribers Licences required 3. 5. 2 Terminals Tab. 15 Maximum number of terminals per system and interface isyLink per AIN Inter- Terminal type System Terminals A300 + with A300 inter- face A150 A300 A300...
