LS2 and LR2 Balanced Audio Sender/Receiver
The Sonance LS2 and LR2 form a system designed to send
low-level audio signals long distances and in close proxim-
ity to sources of noise inter ference without inducing noise
or high-frequency roll-of f. As a general rule of thumb, a
balanced signal should be used for anything but shor t
lengths of audio cable (under 20 feet) and wherever the
possibility of signal inter ference is likely (i.e. where the
audio signal passes near dimmers, transformers, fluores-
cent or neon lights, or along the same pathways as house
current). The active LS2 circuitr y conver ts the unbalanced
signal to a balanced configuration and sends the balanced
s i g n a l t o t h e L R 2 , w h i c h c o n v e r t s i t b a c k i n t o a n
Features:
• The LS2 unbalanced input and LR2 unbalanced output
connectors are high-quality gold-plated RCA connectors.
• The LR2 balanced input and LS2 balanced output connectors
are removable quick-toggle RIA connectors.
• The LS2 and LR2 operate on a single-output 12V DC
power supply (included with both units), and can also be
powered directly by 12V sources. The power inputs have
reverse-polarity protection.
• DC In and DC Out connections on both units allow the
installer to power multiple units from a single power supply.
• Recessed mounting holes allow wall mounting.
• Compatible with 3" TK-series SnapTrak

Specifications:

(0dB ref = 0.775V)
THD + Noise: <01%, 20Hz – 20kHz
Signal-to-Noise Ratio: >–100dB (IHF-A wtd)
CMRR (LR2): >98dB (20Hz – 5kHz);
>75dB (5kHz – 20kHz)
Frequency Response: 20Hz – 20kHz ±0.2dB
Input Impedance: 47k ohms (LS2 unbalanced inputs)
Output Impedance: 600 ohms (LR2 unbalanced outputs)
Power Consumption: 55mA ±5% @ 12VDC (LS2);
30mA ±5% @ 12VDC (LR2)
Dimensions (WxHxD): 4" x 2" x 3"
(102mm x 51mm x 76mm)
