I N S T R U C T I O N M A N U A L
V I S U A L P E R F O R M A N C E
6 "
I N - W A L L
Introduction
Thank you for purchasing Sonance Visual Per formance
Series 6" in-wall speakers. When properly installed your
new speakers will give you years of entertainment pleasure.
This manual covers these Visual Performance Series speaker
models: VP69, VP67, VP65, VP65TL.
S
W
:
AFETY
ARNING
T
F
HESE
SPEAKERS
HAVE
AST
SPEAKER FROM FALLING OUT OF THE MOUNTING HOLE DURING THE
.
INSTALLATION PROCESS
T
F
H E EDGES OF THE
AST
U
S E CAUTION WHEN HANDLING THE SPEAKER

Box Contents

Each Sonance Visual Performance Series in-wall speaker box
contains 2 Visual Performance Series in-wall speakers, 2 Paint
plugs (installed on the fronts of the speakers), 2 Paintable grilles
and 1 Mounting cutout template.

Speaker Placement

Home Theater Speaker Placement
Left, Center & Right Channels
• Place the left & right speakers on either side of the video
screen, anywhere from 6 feet to 10 feet apart and 38 – 42
inches from the floor.
• If possible, locate the center speaker at the same height as the
left & right channel speakers (38 – 42 inches from the floor).
• If you must place the center speaker above or below a video
screen, place it no more than 2 feet above or below the center
of the left and right speakers. This will maintain consistent
tonality between all 3 front channel speakers.
• The main listening position should be between 8 and 12 feet
away from the speakers.
Use Figure 1 as a guide.
18"
From Side
Wall
2'
(max.)
F
1: L
, C
IGURE
EFT
H
T
OME
HEATER
®
S E R I E S
S P E A K E R S
M
®
OUNT
TABS
THAT
PREVENT
M
OUNT TABS ARE VERY SHARP
.
6' – 10'
18"
Apart
From Side
Wall
& R
C
ENTER
IGHT
HANNEL
S
P
PEAKER
LACEMENT
Surround
Speakers (5.1-
®
Channel System)
Locate
the
surround
channel speakers on
the side walls 2 – 6
feet behind the listen-
ing position, at least 5
feet from the floor. Use
THE
Figure 2 as a guide.
Surround
.
Speakers (7.1-
Channel System)
• L
&
R
E F T
S
S
U R R O U N D
P E A K E R S
Place the left and right surround speakers directly to the sides
of the listening position, at least 5 feet from the floor.
• S
B
S
URROUND
ACK
the rear wall, between 3 feet and 6 feet apart and at least
5 feet from the floor.
Use Figure 3 as a guide.
Right
Front
Speaker
Video
Screen
Center
Speaker
Left
Front
Speaker
F
3: 7.1-C
IGURE
Stereo (2-Channel) Placement
• Place the left and right speakers anywhere from 6 feet to 10
feet apart, with the main listening position as close to midway
between the speakers as possible.
• The speakers should be at least 2 feet away from the side walls.
• The main listening position should be between 4 and 10 feet
away from the speakers.
• In most cases pivoting the tweeter of each speaker directly
towards the main listening position will help maximize the
stereo soundstage.
Use the left and right speaker placement in Figure 1 as a guide.
2' – 6'
F
2: 5.1-C
IGURE
T
S
HEATER
URROUND
P
LACEMENT
I G H T
:
: Place the surround back speakers in
PEAKERS
Right Surround
Speaker
Left Surround
Speaker
H
T
S
HANNEL
OME
HEATER
PEAKER
5' – 7'
H
HANNEL
OME
S
PEAKER
Right
Surround Back
Speaker
Left
Surround Back
Speaker
P
LACEMENT
