Summary of Contents for Sonance MERLOT SSMR-SERIES
- Page 1 ® ONANCE ERLOT MR/SSMR - SERIES EILING PEAKERS INSTRUCTION MANUAL...
-
Page 3: Safety Warning
® MR/SSMR Introduction Thank you for purchasing Sonance Merlot When properly installed your new speakers will give you years of entertainment pleasure. This manual will teach you all about your new speakers’ many innovative features and will show you how to get the very best performance from them. -
Page 4: Speaker Placement
(distributed audio, 2-channel stereo or home theater) and aesthetic values. Your local authorized Sonance dealer is an expert in audio/video system planning and installation. We strongly recommend that you work with your dealer to ensure that your system is properly planned, assembled and installed. - Page 5 Place the left & right speakers from 1 foot to 2 feet in front of the video screen, anywhere from 6 feet to 10 feet apart, with the center channel speaker as close to midway between the left and right speakers as possible.
-
Page 6: Preparing The Installation Location
Building a Back Box into the Wall Stud Bay Sonance Merlot MR-series speakers are designed to provide exceptionally musical performance in a wide variety of enclo- sure volumes. You can get the very best performance from your speakers by partitioning a section of the stud bay to form a sealed back box with a specific internal volume. -
Page 7: Installing The Speakers
The FlexBracket has perforated wings that can be positioned anywhere around the bracket, and is nailed or screwed to the ceiling joists. This serves as a guide for the drywaller so that the speaker hole will be in the desired location once the drywall is installed. -
Page 8: Installation
2. Run speaker wire from each speaker to the amplifier location. 3. Strip ¼” – ½” of insulation from each speaker lead. Twist the strands or tin the exposed wire with solder to ensure that there are no stray strands. (Stray strands that touch each other can cause a short-circuit that can damage your amplifier.) 4. - Page 9 You can also paint the speakers after installation, but before the grilles are attached. All Sonance Merlot speakers come from the factory fitted with a plastic ‘paint plug’ that protects the speaker drivers while the mounting flange is being painted.
-
Page 10: Speaker Adjustments
Speaker Adjustments Pivoting Tweeter The Merlot 422 speaker has a pivoting tweeter that allows you to direct sound towards or away from the listening area, depending on how the speakers are being used: • If you’re using the speakers in stereo or as the front left/center/right speakers in a home theater, pivot the tweeter directly towards the listening area. -
Page 11: Specifications
SONANCE MERLOT ® MR/SSMR Specifications 422MR Tweeter: ¾" (19mm) silk dome, pivoting Woofer: 4½" (114mm) Black polypropylene cone with a rubber surround Frequency Response: 60Hz – 20kHz ±3dB Impedance: 8 ohms nominal; 6 ohms minimum Power Handling: 5 watts minimum; 60 watts maximum Sensitivity: 90dB (2.83V/1 meter) -
Page 12: Technical Assistance And Service
S S O O N N A A N N C C E E ! ! 3. If you’re directed to return the unit to Sonance for repair, pack the unit in its original shipping carton. If needed, you can obtain replacement packaging from us for a small charge. Note: it is best if you place the box into an additional outer “overcarton”... -
Page 13: Exclusions And Limitations
If this model is no longer available and can not be repaired effectively, Sonance, at is sole option, may replace the unit with a current model of equal or grater value. In some cases where a new model is substituted, a modification to the mounting surface may be required. -
Page 14: System Notes
SONANCE MERLOT ® MR/SSMR System Notes:... - Page 16 ©2006 Sonance. All rights reserved. Sonance, Sonance Merlot, RotoLock, Sonafill, MedialinQ and FastMount are registered trademarks of Dana Innovations. Due to continuous product improvement, all features and specifications are subject to change without notice. For the latest Sonance product specification information visit our website: www.sonance.com SONANCE •...
