Sonance Merlot 423M Specifications

Sonance Merlot Series
®
M-Series In-Wall Speakers
T h e t o t a l l y - r e d e s i g n e d
M-Series in-wall speakers bring a new level of
musical performance to smaller living spaces.
These new speakers feature a small footprint
and shallow depth that significantly increase
installation options for newer multi-dwelling
unit buildings as well as
areas (bathrooms, hallways, etc.) in larger
homes. They are also ideal for the smaller living
spaces found in many homes overseas.
Ideal for both multi-channel home theater and
s t e r e o m u s i c a p p l i c a t i o n s , t h e n e w M e r l o t
M-series incorporates high-quality driver materials
a n d p r e c i s i o n e n g i n e e r i n g
star tling musicality from speakers so small.
Sonance Merlot M-series in-wall speakers bring
high-quality enter tainment to life anywhere in
t h e h o m e w h i l e ef for tlessly i n t e g r a t i n g i n t o
almost any lifestyle.
Features:
• Ideal for use in multi-channel home theater
systems and stereo music systems.
• Advanced woofer cone materials produce
robust, low-distortion bass in a ver y small
footprint that increases installation options.
• Pivoting tweeters direct the sound at listeners
for clear sound and improved stereo imaging
even when speaker placement options are
limited.
• A 3-position tweeter adjustment switch lets you
balance the speaker's high-frequency energy to
better compliment your room's setup and
acoustics (423 ).
M
• Exclusive new FastMount
the mounting hole during installation, allowing
installer to let go of the speaker to pick-up
tools or other items.
Sonance Merlot
®
423 Speaker
M
S o n a n c e M e r l o t ®
'space-challenged'
t h a t d e l i v e r
tabs hold speaker in
®

Specifications:

Sonance Merlot 423
Tweeter:
Woofer:
Frequency Response
Impedance
Power Handling
Sensitivity:
Grille Material:
Adjustments:
Dimensions (W x H x D):
Cutout Dimensions (W x H):
Shipping Weight:
Sonance Merlot 422
Tweeter:
Woofer:
Frequency Response
Impedance
Power Handling
Sensitivity:
Grille Material:
Adjustments:
Dimensions (W x H x D):
Cutout Dimensions (W x H):
Shipping Weight:
M
1" (25mm) Silk dome, pivoting
4½" (114mm) Carbon fiber cone
with a rubber surround
55Hz – 20kHz ±3dB
8 ohms nominal; 6 ohms minimum
5 watts minimum; 80 watts maximum
90dB SPL (2.83V/1 meter)
Perforated Aluminum
±3dB Tweeter Level
7 7
5 " x 8 " x 3"
/ /
16 8
(138mm x 225mm x 76mm)
5 1
4 " x 8 " (117mm x 205mm)
/ /
8 16
6 lbs (2.8kg) per pair
M
¾" (19mm) Silk dome, pivoting
4½" (114mm) Polypropylene cone
with a rubber surround
60Hz – 20kHz ±3dB
8 ohms nominal; 6 ohms minimum
5 watts minimum; 60 watts maximum
90dB SPL (2.83V/1 meter)
Perforated Aluminum
None
7 7
5 " x 8 " x 3"
/ /
16 8
(138mm x 225mm x 76mm)
4 5 " x 8 1 " (117mm x 205mm)
/ /
8 16
6 lbs (2.8kg) per pair
