Sonance MARINERSST Instruction Manual

INTRODUCTION

Thank you for purchasing Sonance Symphony
When properly installed your new speakers will give you years of entertainment
pleasure. This manual covers the following speaker models: Symphony S623
Symphony S621 , Symphony S623
SSTR SST

SAFETY WARNING:

These speakers have FastMount tabs that prevent the speaker from falling out
®
of the mounting hole during the installation process.
The edges of the FastMount tabs are very sharp.
Use caution when handling the speaker.

BOX CONTENTS

Sonance Symphony SSTR and SST speaker boxes contain (1) Symphony speaker, (1)
plastic paint plug (installed on the front of the speaker), (1) paintable grille and
(1) mounting cutout template (in packaging).
Sonance Symphony SRS1 speaker boxes contain (2) Symphony speakers, (2) paint
plugs (installed on the fronts of the speakers), (2) paintable grilles and (1) mount-
ing cutout template (in packaging).

SPEAKER PLACEMENT

S623 /S623 /S621
SST SSTR
Sonance Symphony Single Stereo Technology
use in hallways, bathrooms, closets, or in any location where a pair of stereo speak-
ers would be impractical. Because a single Symphony SST/SSTR speaker reproduces
both stereo channels from a single location, it will deliver outstanding perform-
ance from an extremely wide variety of mounting locations. The chart in Figure 1
shows how far apart the speakers can be placed at different ceiling heights while
still providing good coverage for distributed audio (as shown in Figure 2 ).
Speaker Spacing (in feet) for a Distributed Audio System
Standing Listener Seated Listener
8-foot ceiling
10-foot ceiling
12-foot ceiling
14-foot ceiling
F 1 : D
I G U R E I S T R I B U T E D
C
OVERAGE
A
REA
F 2 : D
I G U R E I S T R I B U T E D
SSTR/SST/SRS1-series speakers.
®
and Symphony SRS1.
SSTR
SST and SSTR speakers are ideal for
®
5.7' 9.5'
9.7' 13.5'
13.7' 17.5'
17.7' 21.5'
A S S
U D I O P E A K E R P A C I N G
S
PEAKER
S
PACING
C
OVERAGE
A
REA
A C A
U D I O O V E R A G E R E A
I N S T R U C T I O N M A N U A L
S O N A N C E S Y M P H O N Y
S S T R / S S T / S R S 1
IN-CEILING/IN-WALL SPEAKERS
SRS1: 5.1-Channel Home Theater System
Locate the left and right SRS1 surround speakers on the ceiling between 2 feet
and 6 feet behind the listening position. The speakers should be between 6 feet
and 10 feet apart. Orient the speakers so the tweeters face the front and rear
;
SSTR
walls of the room. Use Figure 3 as a guide.
TV
F 3 : 5 . 1 - C
I G U R E H A N N E L
SRS1: 7.1-Channel Home Theater System
Left & Right Surround Speakers:
ers directly to the sides of the listening position, between 6 feet and 10 feet apart.
Surround Back Speakers:
and 6 feet behind the listening position. The surround back speakers should be
closer together than the left and right surround speakers — between 3 feet and
6 feet apart.
Use Figure 4 as a guide.
TV
F 4 : 7 . 1 - C
I G U R E H A N N E L
Left & Right
Surround
Speakers
2' – 6'
H T S P
O M E H E A T E R P E A K E R L A C E M E N T
Place the left and right surround speak-
Place the surround back speakers between 2 feet
Left & Right
Surround Speakers
Surround
Back
Speakers
2' – 6'
H T S P
O M E H E A T E R P E A K E R L A C E M E N T
®
6' – 10'
apart
3' – 6'
apart
