Sonance LCR Speaker Specification Sheet

Sonance Cinema Select
®
Sonance Cinema Select® LCR Cabinet speakers bring true cinema
performance to those who have smaller theater rooms and can't
use Sonance in-wall speakers. In fact, earning THX® Select
certification guarantees that in rooms up to 2,000 cubic feet,
Cinema Select LCR Cabinet speakers will reproduce film
soundtracks just as their filmmakers intended them to sound.
The new enclosure is a key to the Cinema Select LCR Cabinet
speaker's superior performance. The 1"-thick MDF baffle and
back panels maintain ultra-high rigidity and banish resonances.
An exclusive laminate made-up of ½" MDF and ½" particle
board maximizes stiffness and reduces resonances in the top,
bottom and side panels.
Sonance Cinema Select LCR Cabinet speakers establish a
formidable standard of home entertainment performance that
makes them ideal for both multi-channel home theater and
music applications.
Features:
• Cabinet design offers legendary Sonance quality and
performance to listeners who can't use in-wall speakers.
• THX Select certification guarantees cinema-quality
®
performance in rooms up to 2,000 ft
• Same drivers and voicing as Cinema Select in-wall speakers
allows mix-and-match between in-wall and cabinet versions
while maintaining character and quality of 'Sonance sound'.
• Tweeter acoustic back chamber widens and smoothes
high-frequency performance.
• Ultra-rigid 1" MDF baffle and back panels minimize resonances.
• Cabinet top, bottom & sides made from an exclusive laminate
of ½" MDF and ½" particle board, for superior stiffness and
resonance damping.
• Tweeter level control and boundary compensation control
maximize performance in a variety of installations.
• Large connection terminals accept up to 12AWG speaker wire.
• Compact size increases installation options.
w w w . s o n a n c e . c o m
212 Avenida Fabricante
San Clemente, CA 92672-7531 USA
(800) 582-7777 or (949) 492-7777
FAX: (949) 361-5151
Technical Support: (800) 582-0772
©2004 Sonance, All Rights Reserved. Sonance, Sonance Cinema Select and RotoLock are trademarks of Sonance. THX and THX Select are trademarks or registered trademarks of THX, LTD.
LCR Cabinet Speakers
3.
All specifications are subject to change without notice. 04/05
Sonance Cinema
Cinema Select

SPECIFICATIONS

Cinema Select LCR Cabinet
Tweeter
Woofer
Frequency Response
Impedance
Power Handling
Sensitivity
Baffle & Back Panel Material
Top, Bottom & Side Panel Material
Grille Material
Adjustments
Dimensions (W x H x D)
Shipping Weight
DIMENSIONS
Sonance Cinema Select
LCR Cabinet Speaker
® Series
® LCR
Cabinet
1" (25mm) Silk dome, Ferrofluid-cooled,
shielded magnet
6½" (165mm) Carbon fiber cone, rubber
surround, shielded magnet
80Hz – 20kHz ±3dB
8 Ohms nominal; 5 Ohms minimum
5 watts minimum; 135 Watts maximum
90dB SPL (2.83V 1 meter)
1" MDF
Laminate (½" MDF / ½" particle board)
Black cloth
±3dB Tweeter level, boundary compensation
7½" (190mm) x 11" (279mm) x 11½" (292mm)
18 lbs. (8.2 KG) each
